Mimosa C5 User Manual

Important

This device requires unlocking prior to use. For all
unlocking instructions and options, prior to on-site
installation, please go to mimosa.co/start.

Power Requirements

This device accepts +/- 48VDC complying with

802.3at (PoE+), and supports all Mimosa Gigabit
PoE devices.

Included Items

C5 device, Ethernet cable gland, stainless steel
pole clamp, and silicon dielectric gel packet.

Required Items

• Any Mimosa Gigabit PoE device.

• Mimosa FlexiMount or Mimosa J-Mount for
optimal device aiming.

• Minimum 10 AWG (5.26 mm2) ground cable.

• Mimosa Gigabit NID.

• Phillips head screwdriver.

Extensive Instructions and Support

mimosa.co/support

C5

1. Mount

Attach the device to your preferred mount using
the included pipe clamp.

2. Ground

Attach ground wire (not
included) to integrated
grounding screw point.

Install the Mimosa
Gigabit NID at the
premises entry point
for Electrostatic Dis­charge (ESD) protec­tion.

To prevent device damage, avoid ground voltage

potential dierence between the device ground

and the Gigabit NID.

a

AND

b

To device

To premises

To ground

To ground

3. Connect

Push unterminated
shielded CAT6/6A Eth­ernet cable through the
hole in the bottom of
the gland.

Apply a bead of dielec­tric silicone to Ethernet
pins, the cable entry
area and top ridge of
the gland.

Then crimp the RJ45
connector to the cable.

Connect the Ethernet
cable and press the
gland onto the device’s
plastic retaining clips.

4. Unlock and Congure

Visit mimosa.co/start to unlock the device and

detailed conguration instructions.

Warnings, Warranty, Compliance &
Regulatory Statements

Export Control

These commodities, technology, or software were exported from the United
States in accordance with the Export Administration Regulations. Diversion
contrary to U.S. law is prohibited.

Important Safety and Handling Information

Failure to follow any of the safety instructions in this guide, instructions on any
Mimosa-provided packaging, and heed WARNINGS (indicated by ), could

result in re, electric shock, other injury or death, and incur damage to this

product or other property and void the product’s Limited Warranty.

There are no End User serviceable parts inside the equipment.

Read all operating and safety instructions contained herein and accompanying
the product as provided by Mimosa Networks, Inc. (“Mimosa”).

Electrical Safety Information

Do not operate this product in any location that can be submerged by
water.

Do not install or maintain this product during the presence of an
electrical storm to avoid risk of electric shock from lightning.
In order to comply with the Mimosa Limited Warranty conditions in this
document, you must properly ground the device according to the

a

b

included instructions. Failure to properly ground the device according to
the included instructions and use shielded CAT6/6A Ethernet cabling will
violate the product warranty and could lead to serious injury or death.

This device is a Safety Class II-compliant device including supplemental
insulation to protect against electric shock, and does not require a
connection to earth ground.

Installation of the product must comply with local and national electrical
codes.

Power specications for connected devices are indicated on the device’s

own label or documentation. Connecting to any power source that does
not meet the voltage, frequency and current requirements listed may

damage the power supply or product, and pose a re hazard.

Mandatory Grounding Instructions

IMPORTANT: In order to comply with the Mimosa Limited Warranty conditions in
this document, you must properly ground the device according to these instruc­tions. Failure to properly ground the device will violate the product warranty.

Required Step 1- Direct Grounding on the Device:

A minimum grounding wire of 10 AWG (5.26 mm2) with a secured grounding
terminal, and shorter in length than 1 meter is required. It is NOT supplied with
the product.

1. Ensure that NO power is being supplied to the product.

2. Locate the Ground point screw next to the Ground icon on the device

3. Remove the provided Ground Screw

4. Thread the ground wire terminal and ground wire meeting the above speci­cations over the screw removed in the previous step.

5. Replace and tighten the screw with the threaded ground terminal and cable
at the product Ground point.

6. Secure the other end of the grounding cable to the properly grounded struc­ture (pole, tower, mast, etc.) meeting local and national electrical regulations
and codes.

Required Step 2 - Use Mimosa Gigabit NID for Grounding via CAT6/6A Shielded
Ethernet:

The Mimosa Gigabit NID is required to provide enhanced Electrostatic Dis­charge (ESD) protection for devices and the premises during electrical events.
Failure to follow all instructions provided with the separately sold Mimosa

Gigabit NID will violate the product warranty and could lead to serious injury or

death.

End User Product Warranty

Products purchased from Mimosa Networks, Inc. (“Mimosa”) are warranted
against defects in material, and workmanship for a period of either (i) twelve
(12) months from the date of activation, or (ii) thirty-six (36) months from the
original date of shipment, whichever is earlier. Please go to www.mimosa.co/
warranty to determine whether your product is in warranty.

The sole responsibility of Mimosa under this warranty shall be limited to the
repair or replacement of in-warranty defective product, at Mimosa’s sole option.

Out of warranty products shipped to Mimosa will not be returned.
This warranty does not cover costs associated with the removal and/or rein­stallation of the product for repair nor for any parts that are readily replaced in
normal use.

Mimosa or its designated partner will repair or replace product found to be

defective during the dened warranty period.

The End User is responsible for delivering defective product in accordance with
Mimosa’s Return Material Authorization (RMA) processes published at
www.mimosa.co/legal/RMA

Limitation of Warranty

Mimosa’s product warranty is invalidated if the RMA product is altered or

otherwise tampered with in a manner that modies the product from its original
shipping conguration and/or form factor, and could violate the End User’s

authority to operate the equipment, unless said activity was performed by or

with the written authorization of a Mimosa representative.

Modications include:

(a) External surfaces that have been painted, labeled, or otherwise modied

from the original shipping condition.

(b) Modications of the product with third party hardware, rmware, and/

or software.

(c) Any product subjected to abnormal physical or electric stress, including,

but not limited to, lightning strikes, negligence, accident, or misuse.
(d) Any product damaged due to incorrect installation, including, but not lim­ited to, improper product mounting, cabling, cabling defects or connection
to power.
(e) Failure induced by connected third party products.

Improper grounding, or failure to ground the product as instructed in this guide
will void the End User warranty.

Mimosa will not warrant any product which has been installed outdoors without
the use of minimum CAT 6/6A shielded Ethernet cable and proper earth
grounding.

Disclaimer

EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN, MIMOSA NET­WORKS AND ITS SUBSIDIARIES, LICENSORS AND AFFILIATES ( COLLECTIVELY,
“MIMOSA”), AND ANY THIRD PARTY DATA, SERVICE, SOFTWARE AND HARDWARE
PROVIDERS MAKE NO OTHER REPRESENTATION OR WARRANTY OF ANY KIND
AND HEREBY DISCLAIM ALL WARRANTIES, EXPRESS OR IMPLIED, STATUTORY
OR OTHERWISE, INCLUDING, BUT NOT LIMITED TO, ANY REPRESENTATIONS OR
WARRANTIES OF DESIGN, MERCHANTABILITY, ACCURACY, QUALITY OF SERVICE
OR RESULTS, AVAILABILITY, QUIET ENJOYMENT, FITNESS FOR A PARTICULAR
PURPOSE, NON-INFRINGEMENT AND ANY WARRANTIES ARISING FROM ANY
COURSE OF DEALING, USAGE OR TRADE PRACTICE IN CONNECTION WITH SUCH
PRODUCTS AND SERVICES. YOU ACKNOWLEDGE THAT NEITHER MIMOSA NOR
ITS THIRD PARTY PROVIDERS CONTROL YOUR EQUIPMENT OR THE TRANSFER
OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE INTERNET,
AND THAT THE PRODUCTS AND SERVICES PROVIDED BY MIMOSA MAY BE
SUBJECT TO LIMITATIONS, INTERRUPTIONS, DELAYS, CANCELLATIONS AND
OTHER PROBLEMS INHERENT IN THE USE OF COMMUNICATIONS FACILITIES.
MIMOSA AND ANY THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY
INTERRUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA LOSS,
CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE RESULTING FROM
ANY OF THE FOREGOING.

IN ADDITION, MIMOSA MAKES NO WARRANTY OR UNDERTAKING, AND MAKES
NO REPRESENTATION OF ANY KIND THAT THE LICENSED PRODUCTS WILL MEET
YOUR REQUIREMENTS, ACHIEVE ANY INTENDED RESULTS, BE COMPATIBLE
OR WORK WITH ANY OTHER APPLICATIONS, SYSTEMS OR SERVICES, OPERATE
WITHOUT INTERRUPTION, MEET ANY PERFORMANCE OR RELIABILITY STAN­DARDS, BE ERROR FREE OR THAT ANY ERRORS OR DEFECTS CAN OR WILL BE
CORRECTED, OR THAT THE LICENSED PRODUCTS ARE NOT VULNERABLE TO
FRAUD OR UNAUTHORIZED USE.

Limitation of Liability

EXCEPT TO THE EXTENT PROHIBITED BY THE LAWS IN YOUR JURISDICTION, IN
NO EVENT WILL MIMOSA OR ITS SUPPLIERS OR LICENSORS BE LIABLE FOR SPE­CIAL, INCIDENTAL, CONSEQUENTIAL OR OTHER DAMAGES (INCLUDING LOST
PROFIT, LOST DATA, OR DOWNTIME COSTS), NOR FOR DAMAGES BASED ON
UNAUTHORIZED USE OR ACCESS, ARISING OUT OF THE USE, INABILITY TO USE,
OR THE RESULTS OF USE OF THE PRODUCT, WHETHER BASED IN WARRANTY,
CONTRACT, TORT OR OTHER LEGAL THEORY, AND WHETHER OR NOT ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL MIMOSA, ITS
SUPPLIERS’ OR ITS LICENSORS’ DIRECT LIABILITY EXCEED THE VALUE OF THE
LICENSED PRODUCTS GIVING RISE TO SUCH LIABILITY. THESE LIMITATIONS
SHALL APPLY NOTHWITHSTANDING ANY FAILURE OF ESSENTIAL PURPOSE OF
ANY LIMITED REMEDY. IN NO EVENT SHALL MIMOSA BE RESPONSIBLE FOR
DAMAGES OR CLAIMS OF ANY NATURE OR DESCRIPTION RELATING TO NET­WORK PERFORMANCE, INCLUDING COVERAGE, YOUR SELECTION OF MIMOSA
PRODUCTS FOR YOUR PARTICULAR APPLICATION AND/OR FAILURE OF MIMOSA
PRODUCTS TO MEET GOVERNMENT OR REGULATORY REQUIREMENTS.

Some legal jurisdictions do not allow exclusions of implied warranties or condi­tions, or for the exclusion or limitation of liability for incidental or consequential
damages, so the above exclusion may not apply to you. You may have other

rights specic to your legal jurisdiction. EXCEPT TO THE EXTENT ALLOWED BY

THE LAW OF YOUR JURISDICTION, THESE WARRANTY TERMS DO NOT EXCLUDE,
RESTRICT OR MODIFY, AND ARE IN ADDITION TO, ANY MANDATORY STATUTORY
RIGHTS APPLICABLE TO YOU IN THE LICENSE OF ANY EMBEDDED SOFTWARE.
The United Nations Convention on Contracts for the International Sale of Goods
shall not apply to any transactions regarding the sale of the Products.

Industry Canada

This Class B digital apparatus complies with Canadian CAN ICES-3(B).

Cet appareil numérique de la classe B est conforme à la norme NMB-3(B)
Canada.

Under Industry Canada regulations, this radio transmitter may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential radio interference to other
users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for suc­cessful communication.

Pour réduire le risque d’interférence aux autres utilisateurs, le type d’antenne
et son gain doivent être choisies de façon que la puissance isotrope rayonnée
équivalente (PIRE) ne dépasse pas ce qui est nécessaire pour une communica­tion réussie.

5 GHz Integrated Client Device

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not

cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.

Cet appareil est conforme à la norme RSS Industrie Canada exempts de licence
norme(s). Son fonctionnement est soumis aux deux conditions suivantes:
(1) Cet appareil ne peut pas provoquer d’interférences et (2) Cet appareil doit
accepter toute interférence, y compris les interférences qui peuvent causer un
mauvais fonctionnement du dispositif.

European Compliance Statement

CE Marking on this product represents that this product complies with
all requirements that are applicable to it.

Alert sign must be indicated if a restriction on use applied to the product and it
must follow the CE marking.

Europe EU Declaration of Conformity

This device can be used in the European Community. A copy of the EU Declara­tion of Conformity is available at: www.mimosa.co/compliance.

Български (Bulgarian) - Mimosa Networks, Inc. декларира, че това Mimosa Net­works, Inc. приспособление е в съответствие със съществените изисквания
и другите приложими правила на Директива 1999/5/ЕС.

Česky (Czech) - Společnost Mimosa Networks, Inc. tímto prohlašuje, že tento
Mimosa Networks, Inc. zařízení je ve shodě se základními požadavky a dalšími
příslušnými ustanoveními směrnice 1999/5/ES.

Dansk (Danish) - Undertegnede Mimosa Networks, Inc. erklærer herved, at
følgende udstyr Mimosa Networks, Inc. enhed overholder de væsentlige krav og

øvrige relevante krav i direktiv 1999/5/EF.

Deutsch (German) - Hiermit erklärt Mimosa Networks, Inc., dass sich das
Mimosa Networks, Inc. Gerät in Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie

1999/5/EG benden.

Eesti (Estonian) - Käesolevaga kinnitab Mimosa Networks, Inc., et see Mimosa

Networks, Inc. seade vastab direktiivi 1999/5/EÜ põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.

English - Hereby, Mimosa Networks, Inc. declares that this Mimosa Networks,
Inc. device is in compliance with the essential requirements and other relevant

provisions of Directive 1999/5/EC.

Español (Spanish) - Por medio de la presente Mimosa Networks, Inc. declara que
este Mimosa Networks, Inc. dispositivo cumple con los requisitos esenciales y

cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.

Ελληνικά (Greek) - Mε την παρούσα, η Mimosa Networks, Inc. δηλώνει ότι αυτή
η συσκευή Mimosa Networks, Inc. συσκευή συμμορφώνεται προς τις βασικές
απαιτήσεις και τις λοιπές σχετικές διατάξεις της Οδηγίας 1999/5/ΕΚ.

Français (French) - Par la présente Mimosa Networks, Inc. déclare que ce
Mimosa Networks, Inc. appareil est conforme aux exigences essentielles et aux

autres dispositions pertinentes de la directive 1999/5/CE.

Islenska (Icelandic) - Mimosa Networks, Inc. lýsir því hér með yr að þetta Mimo­sa Networks, Inc. tæki fullnægir lágmarkskröfum og öðrum viðeigandi ákvæðum
Evróputilskipunar 1999/5/EC.

Italiano (Italian) - Con la presente Mimosa Networks, Inc. dichiara che questo

Mimosa Networks, Inc. dispositivo è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.

Latviski (Latvian) - Ar šo Mimosa Networks, Inc. deklarē, ka šī Mimosa Networks,
Inc. ierīce atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to
saistītajiem noteikumiem.

Lietuvių (Lithuanian) - Šiuo „Mimosa Networks, Inc.“ deklaruoja, kad šis Mimosa
Networks, Inc. atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos

nuostatas.

Magyar (Hungarian) - Alulírott, Mimosa Networks, Inc. nyilatkozom, hogy a Mimo­sa Networks, Inc. eszköz megfelel a vonatkozó alapvetõ követelményeknek és az
1999/5/EC irányelv egyéb elõírásainak.

Malti (Maltese) - Hawnhekk, Mimosa Networks, Inc., jiddikjara li dan Mimosa
Networks, Inc. tagħmir jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti
oħrajn relevanti li hemm d-Dirrettiva 1999/5/EC.

Nederlands (Dutch) - Hierbij verklaart Mimosa Networks, Inc. dat dit Mimosa

Networks, Inc. toestel in overeenstemming is met de essentiële eisen en de

andere bepalingen van richtlijn 1999/5/EG.

Norsk (Norwegian) - Mimosa Networks, Inc. erklærer herved at dette Mimosa
Networks, Inc. apparatet er i samsvar med de grunnleggende kravene og øvrige

relevante krav i EU-direktivet 1999/5/EF.

Polski (Polish)- Niniejszym Mimosa Networks, Inc. oświadcza, że ten Mimosa Net­works, Inc. urządzenie są zgodne z zasadniczymi wymogami oraz pozostałymi
stosownymi postanowieniami Dyrektywy 1999/5/EC.

Português (Portugese) - Mimosa Networks, Inc. declara que este Mimosa

Networks, Inc. dispositivo está em conformidade com os requisitos essenciais e
outras disposições da Directiva 1999/5/CE.

Română (Romanian) - Prin prezenta, Mimosa Networks, Inc. declară că acest
Mimosa Networks, Inc. aparat este în conformitate cu cerinţele esenţiale şi cu
celelalte prevederi relevante ale Directivei 1999/5/CE.

Slovensky (Slovak) - Mimosa Networks, Inc. týmto vyhlasuje, že toto Mimosa Net­works, Inc. zariadenie spĺňa základné požiadavky a všetky príslušné ustanovenia
Smernice 1999/5/ES.

Slovensko (Slovene) - Mimosa Networks, Inc. izjavlja, da je ta Mimosa Networks,
Inc. naprava skladne z bistvenimi zahtevami in ostalimi ustreznimi določili
direktive 1999/5/ES.

Suomi (Finnish) - Mimosa Networks, Inc. vakuuttaa täten, että tämä Mimosa

Networks, Inc. tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen mukainen.

Svenska (Swedish) - Härmed intygar Mimosa Networks, Inc. att denna Mimosa

Networks, Inc. apparat står i överensstämmelse med de väsentliga egenskapsk­rav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

RoHS & WEEE Compliance

User Information for Consumer Products Covered by EU Directive 2002/96/EC

on Waste Electric and Electronic Equipment (WEEE).

This document contains important information for users with regards
to the proper disposal and recycling of Mimosa Networks, Inc.
products. Consumers are required to comply with this notice for all
electronic products bearing this symbol.

English - Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this sym­bol on the product and/or its packaging must not be disposed of with unsorted
municipal waste. The symbol indicates that this product should be disposed
of separately from regular household waste streams. It is your responsibility
to dispose of this and other electric and electronic equipment via designated
collection facilities appointed by the government or local authorities. Correct
disposal and recycling will help prevent potential negative consequences to
the environment and human health. For more detailed information about the
disposal of your old equipment, please contact your local authorities, waste
disposal service, or the shop where you purchased the product.

Български (Bulgarian) - Информация относноопазването на околната среда
за потребители вЕвропейския съюз
Европейска директива 2002/96/EC изисква уредите, носещи този символ
върху изделието и/или опаковката му, да не се изхвърля т с несортирани
битови отпадъци. Символът обозначава, че изделието трябва да се
изхвърля отделно от сметосъбирането на обикновените битови отпадъци.
Ваша е отговорността този и другите електрически и електронни уреди да
се изхвърлят в предварително определени от държавните или общински
органи специализирани пунктове за събиране. Правилното изхвърляне
и рециклиране ще спомогнат да се предотвратят евентуални вредни за
околната среда и здравето на населението последствия. За по-подробна
информация относно изхвърлянето на вашите стари уреди се обърнете
към местните власти, службите за сметосъбиране или магазина, от който
сте закупили уреда.

Čeština (Czech) - Informace o ochraně životníhoprostředí pro zákazníky v zemích

Evropské unie

Evropská směrnice 2002/96/ES zakazuje, aby zařízení označené tímto symbolem
na produktu anebo na obalu bylo likvidováno s netříděným komunálním
odpadem. Tento symbol udává, že daný produkt musí být likvidován odděleně
od běžného komunálního odpadu. Odpovídáte za likvidaci tohoto produktu a
dalších elektrických a elektronických zařízení prostřednictvím určených sběrných
míst stanovených vládou nebo místními úřady. Správná likvidace a recyklace
pomáhá předcházet potenciálním negativním dopadům na životní prostředí
a lidské zdraví. Podrobnější informace o likvidaci starého vybavení si laskavě
vyžádejte od místních úřadů, podniku zabývajícího se likvidací komunálních
odpadů nebo obchodu, kde jste produkt zakoupili.

Dansk (Danish) - Miljøinformation for kunder i EU
EU-direktiv 2002/96/EF kræver, at udstyr der bærer dette symbol på produktet
og/eller emballagen ikke må bortskaes som usorteret kommunalt aald.
Symbolet betyder, at dette produkt skal bortskaes adskilt fra det almindelige
husholdningsaald. Det er dit ansvar at bortskae dette og andet elektrisk og

elektronisk udstyr via bestemte indsamlingssteder udpeget af staten eller de

lokale myndigheder. Korrekt bortskaelse og genvinding vil hjælpe med til at
undgå mulige skader for miljøet og menneskers sundhed. Kontakt venligst de
lokale myndigheder, renovationstjenesten eller den butik, hvor du har købt
produktet, angående mere detaljeret information om bortskaelse af dit gamle

udstyr.

Deutsch (German) - Umweltinformation für Kunden innerhalb der Europäischen
Union

Die Europäische Richtlinie 2002/96/EC verlangt, dass technische Ausrüstung, die

direkt am Gerät und/oder an der Verpackung mit diesem Symbol versehen ist,

nicht zusammen mit unsortiertem Gemeindeabfall entsorgt werden darf. Das

Symbol weist darauf hin, dass das Produkt von regulärem Haushaltmüll getrennt
entsorgt werden sollte. Es liegt in Ihrer Verantwortung, dieses Gerät und andere

elektrische und elektronische Geräte über die dafür zuständigen und von der
Regierung oder örtlichen Behörden dazu bestimmten Sammelstellen zu entsor­gen. Ordnungsgemäßes Entsorgen und Recyceln trägt dazu bei, potentielle neg­ative Folgen für Umwelt und die menschliche Gesundheit zu vermeiden. Wenn
Sie weitere Informationen zur Entsorgung Ihrer Altgeräte benötigen, wenden Sie
sich bitte an die örtlichen Behörden oder städtischen Entsorgungsdienste oder

an den Händler, bei dem Sie das Produkt erworben haben.

Eesti (Estonian) - Keskkonnaalane informatsioon Euroopa Liidus asuvatele
klientidele

Euroopa Liidu direktiivi 2002/96/EÜ nõuete kohaselt on seadmeid, millel on
tootel või pakendil käesolev sümbol keelatud kõrvaldada koos sorteerimata
olmejäätmetega. See sümbol näitab, et toode tuleks kõrvaldada eraldi tavalistest
olmejäätmevoogudest. Olete kohustatud kõrvaldama käesoleva ja ka muud elek­tri- ja elektroonikaseadmed riigi või kohalike ametiasutuste poolt ette nähtud
kogumispunktide kaudu. Seadmete korrektne kõrvaldamine ja ringlussevõtt ai­tab vältida võimalikke negatiivseid tagajärgi keskkonnale ning inimeste tervisele.
Vanade seadmete kõrvaldamise kohta täpsema informatsiooni saamiseks võtke
palun ühendust kohalike ametiasutustega, jäätmekäitlusrmaga või kauplusega,

kust te toote ostsite.

Español (Spanish) - Información medioambiental paraclientes de la Unión
Europea

La Directiva 2002/96/CE de la UE exige que los equipos quel leven este símbolo
en el propio aparato y/o en su embalaje no deben eliminarse junto con otros
residuos urbanos no seleccionados. El símbolo indica que el producto en

cuestión debe separarse de los residuos domésticos convencionales con vistas
a su eliminación. Es responsabilidad suya desechar este y cualesquiera otros
aparatos eléctricos y electrónicos a través de los puntos de recogida que ponen
a su disposición el gobierno y las autoridades locales. Al desechar y reciclar
correctamente estos aparatos estará contribuyendo a evitar posibles conse­cuencias negativas para el medio ambiente y la salud de las personas. Si desea

obtener información más detallada sobre la eliminación segura de su aparato

usado, consulte a las autoridades locales, al servicio de recogida y eliminación

de residuos de su zona o pregunte en la tienda donde adquirió el producto.

Ελληνικά (Greek) - Στοιχεία περιβαλλοντικής προστασίας για πελάτες εντός της
ΕυρωπαϊκήςΈνωσης
Σύμφωνα με την Κοινοτική Οδηγία 2002/96/EC, ο εξοπλισμός που φέρει αυτό
το σύμβολο στο προϊόν ή/και τη συσκευασία του δεν πρέπει να απορρίπτεται
μαζί με τα μη διαχωρισμένα αστικά απορρίμματα. Το σύμβολο υποδεικνύει
ότι αυτό το προϊόν θα πρέπει να απορρίπτεται ξεχωριστά από τα συνήθη
οικιακά απορρίμματα. Είστε υπεύθυνος για την απόρριψη του παρόντος και
άλλου ηλεκτρικού και ηλεκτρονικού εξοπλισμού μέσω των καθορισμένων
εγκαταστάσεων συγκέντρωσης απορριμμάτων, οι οποίες ορίζονται από το
κράτος ή τις αρμόδιες τοπικές αρχές. Η σωστή απόρριψη και ανακύκλωση
συμβάλλει στην πρόληψη ενδεχόμενων αρνητικών επιπτώσεων στο περιβάλλον
και την υγεία. Για περισσότερες πληροφορίες σχετικά με την απόρριψη του
παλαιού σας εξοπλισμού, επικοινωνήστε με τις τοπικές αρχές, τις υπηρεσίες
αποκομιδής απορριμμάτων ή το κατάστημα από το οποίο αγοράσατε το
προϊόν.

Français (French) - Informations environnementales pour les clients de l’Union
européenne

La directive européenne 2002/96/CE exige que l’équipement , sur lequel est
apposé ce symbole sur le produit et/ou son emballage ne soit pas jeté avec les

autres ordures ménagères. Ce symbole indique que le produit doit être éliminé
dans un circuit distinct de celui pour les déchets des ménages. Il est de votre

responsabilité de jeter ce matériel ainsi que tout autre matériel électrique ou

électronique par les moyens de collecte indiqués par le gouvernement et les
pouvoirs publics des collectivités territoriales. L’élimination et le recyclage en
bonne et due forme ont pour but de lutter contre l’impact néfaste potentiel de
ce type de produits sur l’environnement et la santé publique. Pour plus d’infor-

mations sur le mode d’élimination de votre ancien équipement, veuillez prendre

contact avec les pouvoirs publics locaux, le service de traitement des déchets,

ou l’endroit où vous avez acheté le produit.

Italiano (Italian) - Informazioni relative all’ambiente per i clienti residenti nell’Uni-

one Europea
La direttiva europea 2002/96/EC richiede che le apparecchiature contrasseg­nate con questo simbolo sul prodotto e/o sull’imballaggio non siano smaltite

insieme ai riuti urbani non dierenziati. Il simbolo indica che questo prodotto
non deve essere smaltito insieme ai normali riuti domestici. È responsabil-

ità del proprietario smaltire sia questi prodotti sia le altre apparecchiature

© 2016 Mimosa Networks, Inc. All rights reserved.

elettriche ed elettroniche mediante le speciche strutture di raccolta indicate

dal governo o dagli enti pubblici locali. Il corretto smaltimento ed il riciclaggio

aiuteranno a prevenire conseguenze potenzialmente negative per l’ambiente e
per la salute dell’essere umano. Per ricevere informazioni più dettagliate circa

lo smaltimento delle vecchie apparecchiature in Vostro possesso, Vi invitiamo

a contattare gli enti pubblici di competenza, il servizio di smaltimento riuti o il
negozio nel quale avete acquistato il prodotto.

Latviešu valoda (Latvian) - Ekoloģiska informācija klientiem Eiropas Savienības
jurisdikcijā
Direktīvā 2002/96/EK ir prasība, ka aprīkojumu, kam pievienota zīme uz paša
izstrādājuma vai uz tā iesaiņojuma, nedrīkst izmest nešķirotā veidā kopā ar ko­munālajiem atkritumiem (tiem, ko rada vietēji iedzīvotāji un uzņēmumi). Šī zīme
nozīmē to, ka šī ierīce ir jāizmet atkritumos tā, lai tā nenonāktu kopā ar parasti­em mājsaimniecības atkritumiem. Jūsu pienākums ir šo un citas elektriskas un
elektroniskas ierīces izmest atkritumos, izmantojot īpašus atkritumu savākšanas
veidus un līdzekļus, ko nodrošina valsts un pašvaldību iestādes. Ja izmešana
atkritumos un pārstrāde tiek veikta pareizi, tad mazinās iespējamais kaitējums
dabai un cilvēku veselībai. Sīkākas ziņas par novecojuša aprīkojuma izmešanu
atkritumos jūs varat saņemt vietējā pašvaldībā, atkritumu savākšanas dienestā,
kā arī veikalā, kur iegādājāties šo izstrādājumu.

Lietuvškai (Lithuanian) - Aplinkosaugos informacija,skirta Europos Sąjungos
vartotojams
Europos direktyva 2002/96/EC numato, kad įrangos, kuri ir kurios pakuotė yra
pažymėta šiuo simboliu, negalima šalinti kartu su nerūšiuotomis komunalinėmis
atliekomis. Šis simbolis rodo, kad gaminį reikia šalinti atskirai nuo bendro
buitinių atliekų srauto. Jūs privalote užtikrinti, kad ši ir kita elektros ar elektroninė
įranga būtų šalinama per tam tikras nacionalinės ar vietinės valdžios nustatytas
atliekų rinkimo sistemas. Tinkamai šalinant ir perdirbant atliekas, bus išvengta
galimos žalos aplinkai ir žmonių sveikatai. Daugiau informacijos apie jūsų senos
įrangos šalinimą gali pateikti vietinės valdžios institucijos, atliekų šalinimo tarny­bos arba parduotuvės, kuriose įsigijote tą gaminį.

Malti (Maltese) - Informazzjoni Ambjentali għal Klijenti-Unjoni Ewropea
Id-Direttiva Ewropea 2002/96/KE titlob li t-tagħmir li jkun h is-simbolu fuq
il-prodott u/jew fuq l-ippakkjar ma jistax jintrema ma’ skart muniċipali li ma ġiex
isseparat. Is-simbolu jindika li dan il-prodott għandu jintrema separatament
minn ma’ l-iskart domestiku regolari. Hija responsabbiltà tiegħek li tarmi dan
it-tagħmir u kull tagħmir ieħor ta’ l-elettriku u elettroniku permezz ta’ faċilitajiet
ta’ ġbir appuntati apposta mill-gvern jew mill-awtoritajiet lokali. Ir-rimi b’mod
korrett u r-riċiklaġġ jgħin jipprevjeni konsegwenzi negattivi potenzjali għall-amb­jent u għas-saħħa tal-bniedem. Għal aktar informazzjoni dettaljata dwar ir-rimi
tat-tagħmir antik tiegħek, jekk jogħġbok ikkuntattja lill-awtoritajiet lokali tiegħek,
is-servizzi għar-rimi ta’ l-iskart, jew il-ħanut minn fejn xtrajt il-prodott.

Magyar (Hungarian) - Környezetvédelmi információ azeurópai uniós vásárlók
számára
A 2002/96/EC számú európai uniós irányelv megkívánja, hogy azokat a ter­mékeket, amelyeken, és/vagy amelyek csomagolásán az alábbi címke megjelenik,
tilos a többi szelektálatlan lakossági hulladékkal együtt kidobni. A címke azt jelöli,
hogy az adott termék kidobásakor a szokványos háztartási hulladékelszállítási
rendszerektõl elkülönített eljárást kell alkalmazni. Az Ön felelõssége, hogy ezt,
és más elektromos és elektronikus berendezéseit a kormányzati vagy a helyi
hatóságok által kijelölt gyűjtõredszereken keresztül számolja fel. A megfelelõ
hulladékfeldolgozás segít a környezetre és az emberi egészségre potenciálisan
ártalmas negatív hatások megelõzésében. Ha elavult berendezéseinek
felszámolásához további részletes információra van szüksége, kérjük, lépjen
kapcsolatba a helyi hatóságokkal, a hulladékfeldolgozási szolgálattal, vagy azzal
üzlettel, ahol a terméket vásárolta.

Nederlands (Dutch) - Milieu-informatie voor klantenin de Europese Unie

De Europese Richtlijn 2002/96/EC schrijft voor dat apparatuur die is voorzien
van dit symbool op het product of de verpakking, niet mag worden ingezameld
met niet-gescheiden huishoudelijk afval. Dit symbool geeft aan dat het product
apart moet worden ingezameld. U bent zelf verantwoordelijk voor de vernietig­ing van deze en andere elektrische en elektronische apparatuur via de daarvoor
door de landelijke of plaatselijke overheid aangewezen inzamelingskanalen. De
juiste vernietiging en recycling van deze apparatuur voorkomt mogelijke negati­eve gevolgen voor het milieu en de gezondheid. Voor meer informatie over het
vernietigen van uw oude apparatuur neemt u contact op met de plaatselijke

autoriteiten of afvalverwerkingsdienst, of met de winkel waar u het product hebt
aangeschaft.

Norsk (Norwegian) - Miljøinformasjon for kunder i EU
EU-direktiv 2002/96/EF krever at utstyr med følgende symbol avbildet på pro-

duktet og/eller pakningen, ikke må kastes sammen med usortert avfall. Symbolet
indikerer at dette produktet skal håndteres atskilt fra ordinær avfallsinnsamling
for husholdningsavfall. Det er ditt ansvar å kvitte deg med dette produktet
og annet elektrisk og elektronisk avfall via egne innsamlingsordninger slik

myndighetene eller kommunene bestemmer. Korrekt avfallshåndtering og gjen­vinning vil være med på å forhindre mulige negative konsekvenser for miljø og
helse. For nærmere informasjon om håndtering av det kasserte utstyret ditt, kan
du ta kontakt med kommunen, en innsamlingsstasjon for avfall eller butikken
der du kjøpte produktet.

Polski (Polish) - Informacja dla klientów w Unii Europejskiej o przepisach dotyczą-

cych ochrony środowiska
Dyrektywa Europejska 2002/96/EC wymaga, aby sprzęt oznaczony symbolem
znajdującym się na produkcie i/lub jego opakowaniu nie był wyrzucany razem
z innymi niesortowanymi odpadami komunalnymi. Symbol ten wskazuje, że
produkt nie powinien być usuwany razem ze zwykłymi odpadami z gospodarstw
domowych. Na Państwu spoczywa obowiązek wyrzucania tego i innych urządzeń
elektrycznych oraz elektronicznych w punktach odbioru wyznaczonych przez
władze krajowe lub lokalne. Pozbywanie się sprzętu we właściwy sposób i jego
recykling pomogą zapobiec potencjalnie negatywnym konsekwencjom dla
środowiska i zdrowia ludzkiego. W celu uzyskania szczegółowych informacji
o usuwaniu starego sprzętu, prosimy zwrócić się do lokalnych władz, służb
oczyszczania miasta lub sklepu, w którym produkt został nabyty.

Português (Portuguese) - Informação ambiental paraclientes da União Europeia

A Directiva Europeia 2002/96/CE exige que o equipamento que exibe este
símbolo no produto e/ou na sua embalagem não seja eliminado junto com os
resíduos municipais vnão separados. O símbolo indica que este produto deve
ser eliminado separadamente dos resíduos domésticos regulares. É da sua

responsabilidade eliminar este e qualquer outro equipamento eléctrico e elec-

trónico através das instalações de recolha designadas pelas autoridades gover­namentais ou locais. A eliminação e reciclagem correctas ajudarão a prevenir as
consequências negativas para o ambiente e para a saúde humana. Para obter
informações mais detalhadas sobre a forma de eliminar o seu equipamento
antigo, contacte as autoridades locais, os serviços de eliminação de resíduos ou

o estabelecimento comercial onde adquiriu o produto.

Română (Romanian) - Informaţii de mediu pentruclienţii din Uniunea Europeană
Directiva europeană 2002/96/CE impune ca echipamentele care prezintă acest
simbol pe produs şi/sau pe ambalajul acestuia să nu e casate împreună cu
gunoiul menajer municipal. Simbolul indică faptul că acest produs trebuie să
e casat separat de gunoiul menajer obişnuit. Este responsabilitatea dvs. să
casaţi acest produs şi alte echipamente electrice şi electronice prin intermediul
unităţilor de colectare special desemnate de guvern sau de autorităţile locale.
Casarea şi reciclarea corecte vor ajuta la prevenirea potenţialelor consecinţe
negative asupra sănătăţii mediului şi a oamenilor. Pentru mai multe informaţii
detaliate cu privire la casarea acestui echipament vechi, contactaţi autorităţile
locale, serviciul de salubrizare sau magazinul de la care aţi achiziţionat produsul.

Slovenčina (Slovak) - Informácie o ochrane životnéhoprostredia pre zákazníkov
v Európskej únii
Podľa európskej smernice 2002/96/ES zariadenie s týmto symbolomna produkte
a/alebo jeho balení nesmie byť likvidované spolu s netriedeným komunálnym
odpadom. Symbol znamená, že produkt by sa mal likvidovať oddelene od
bežného odpadu z domácností. Je vašou povinnosťou likvidovať toto i ostatné
elektrické a elektronické zariadenia prostredníctvom špecializovaných zberných
zariadení určených vládou alebo miestnymi orgánmi. Správna likvidácia a
recyklácia pomôže zabrániť prípadným negatívnym dopadom na životné
prostredie a zdravie ľudí. Ak máte záujem o podrobnejšie informácie o likvidácii
starého zariadenia, obráťte sa, prosím, na miestne orgány, organizácie zaobera­júce sa likvidáciou odpadov alebo obchod, v ktorom ste si produkt zakúpili.

Slovenščina (Slovene) - Okoljske informacije za stranke v Evropski uniji
Evropska direktiva 2002/96/ES prepoveduje odlaganje opreme s tem simbolom
na izdelku in/ali na embalaži z nesortiranimi komunalnimi odpadki. Ta simbol
opozarja, da je treba izdelek zavreči ločeno od preostalih gospodinjskih odpad­kov. Vaša odgovornost je, da to in preostalo električno in elektronsko opremo
oddate na posebna zbirališča, ki jih določijo državne ustanove ali lokalne oblasti.
S pravilnim odlaganjem in recikliranjem boste preprečili morebitne škodljive
vplive na okolje in zdravje ljudi. Če želite izvedeti več o odlaganju stare opreme,
se obrnite na lokalne oblasti, odlagališče odpadkov ali trgovino, kjer ste izdelek

kupili.

Suomi (Finnish) - Ympäristöä koskevia tietoja EU- alueen asiakkaille
EU-direktiivi 2002/96/EY edellyttää, että jos laitteistossa on tämä symboli itse tu­otteessa ja/tai sen pakkauksessa, laitteistoa ei saa hävittää lajittelemattoman yh­dyskuntajätteen mukana. Symboli merkitsee sitä, että tämä tuote on hävitettävä
erillään tavallisesta kotitalousjätteestä. Sinun vastuullasi on hävittää tämä elek­troniikkatuote ja muut vastaavat elektroniikkatuotteet viemällä tuote tai tuotteet

viranomaisten määräämään keräyspisteeseen. Laitteiston mahdolliset kielteiset

vaikutukset ympäristöön ja ihmisten terveyteen. Lisätietoja vanhan laitteiston
oikeasta hävitystavasta saa paikallisilta viranomaisilta, jätteenhävityspalvelusta
tai siitä myymälästä, josta ostit tuotteen

Svenska (Swedish) - Miljöinformation för kunder i Europeiska unionen
Det europeiska direktivet 2002/96/EC kräver att utrustning med denna symbol
på produkten och/eller förpackningen inte får kastas med osorterat kommunalt
avfall. Symbolen visar att denna produkt bör kastas efter att den avskiljts

från vanligt hushållsavfall. Det faller på ditt ansvar att kasta denna och annan
elektrisk och elektronisk utrustning på fastställda insamlingsplatser utsedda av
regeringen eller lokala myndigheter. Korrekt kassering och återvinning skyddar

mot eventuella negativa konsekvenser för miljön och personhälsa. För mer
detaljerad information om kassering av din gamla utrustning kontaktar du dina
lokala myndigheter, avfallshanteringen eller butiken där du köpte produkten.

705-00010 REV A
