3.5M ANDAMAN CANTILEVER UMBRELLA
Assembly Instructions
Item No. 3191785
Please carefully read the below warnings and instructions. Save the
!
instructions for future reference.
1.Please carefully read all instructions before assembly and use
2.Please separate and identify all parts, ensuring that you have all parts listed
3.To avoid damaging your umbrella, it is recommended that you assemble it on a clean, protected surface
4.Washers must be used when indicated during the assembly process
5.Loosely tighten the nuts and then securely tighten when all are in position. Be careful not to over tighten the
nuts during assembly.
PARTS LIST
CODE PARTS
A
Frame & Canopy
B
C
D
E
Plastic Base
Housing Cover
Square Tube
Rotary Knob
QTY. CODE PARTS QTY.
1PC
H
1PC
1PC
1PC
1PC
HARDWARE LIST
Screw & Washer
I
Allen Key
4PCS
1PC
F
G
Stay Pole
Umbrella Cover
1PC
1PC
J
Crank
1PC
10-1
Assembling Instruction
Fix the square tube (D) with
1 2
the plastic base (B) using
screw & washer (H).
D
H
B
Fill the base with water or
3 4
sand to make it stable.
Place the plastic circle（C）
onto umbrella base pole.
C
Place the frame & canopy （A） onto
the umbrella base pole, using rotary
knob (E) to fix.
ATTENTION: The base
needs to be secured with
water or sand to help keep the
umbrella stable.
A
E
10-2
1-1
1-3
1-2
HOW TO OPEN AND
ADJUST THE UMBRELLA
5
Squeeze the handle and push it
in the upwards direction
towards the top of the umbrella
pole until it locks into place.
Operating Instruction
J
6
Open the umbrella by rotating
the crank clockwise. Vertically
adjust height as required.
10-3
2-1
2-2
2-3
Operating Instruction
7
Click to tilt umbrella angle as
you like （approx 90 degree of
each side）.
1
2
8
1
2
10-4
1-1
1-2
HOW TO RELOCATE YOUR UMBRELLA
9
Open the handle cover
to expose the pulling
handle and winding
mechanism
Operating Instruction
1
10
3 54
Remove the crank handle from
the pole and insert into the
base winding mechanism.
2
Unwind the handle and cord
10-5
11
Now that the handle and
wheels are fully extended,
the umbrella base can be
easily pulled to your new
location
Operating Instruction
12
Do not attempt to pull your umbrella up a
steep slope or grassed surface.
10-6
1-2
1-1
Operating Instruction
Once the umbrella base is in the
desired location, wind up the cord
and handle and store in base. Retract
the wheels by winding the handle in
an anti-clockwise direction.
13
1
3
2
4
5
Remove the handle and
replace in its original
position in the upright
pole. Close the
housing cover.
6
10-7
1-1
1-2
HOW TO CLOSE THE
UMBRELLA
14
Close the umbrella frame by
rotating the handle
counter-clockwise.
Operating Instruction
15
Close the total frame & canopy by moving the crank
downwards to the lowest position hole.
10-8
Operating Instruction
16
Assemble the stay pole （F）.
G
2
1
F
17
Lift the umbrella cover (G) to the top of the umbrella using the stay pole (F).
Pull the umbrella cover (G) down over the umbrella with your hands.
G
F
L
10-9
18
Once it has fully covered
the umbrella,pull the zip
closed and put the stay
pole in the protective
bag.
Operating Instruction
19
ATTENTION: DO NOT use in extreme
weather conditions including high wind
and heavy rain.
CARE AND CLEANING:
1. To clean, wipe with damp cloth. Do not use bleach, acid solvents or abrasive cleaners.
2. During winter or periods of heavy rain and wind, it is strongly recommended that the umbrella be stored in its cover,
in a dry protected area.
10-10
