MIMO UM-710S, UM-720S, UM-710F, UM-720F User Manual

PAGE 1 OF 21

www.mimomonitors.com

UM-710S/ UM-720S

UM-710F/ UM-720F

Super Slim Foldable Design

User Manual

PAGE 2 OF 21

Table of Contents

Safety Instructions ……………………………………… 3~4

Product Features ………………………………………… 5

Package Contents ……………………………………….. 6

Connections and Installation …………………………. 7

Installing Monitor Driver ………………………………. 8~9

MIMO Display Setting ……..……………………………. 10

Installing Touch Screen Controller ………………….. 11~14

System Requirements and Restrictions ……………. 15

Troubleshooting ………………………………………….. 16~18

Specifications ……………………………………………... 19

PAGE 3 OF 21

▣ Safety Instructions

These safety instructions must be followed to ensure your safety and prevent property damage.

Warning/Cautions:

Otherwise, it may result in personal injury or property damage.

Make sure to read the instructions carefully and use the product in the correct manner..

▪ Power Source:

- Make sure to use USB Cable (DC 5V) only.

* MIMO doesn‟t require any additional power source

▪ Do not place MIMO in a location exposed to
moisture, dust, smoke, water, or in a car.

* Otherwise, this may result in electric shock or fire.

▪ Clean the product using a soft cloth with a

monitor cleaner only.

- Make sure to disconnect USB Cable while cleaning

- Ensure that water does not enter the product and that it is not

wet.

* Otherwise, this may result in electric shock, fire or a

malfunction.

▪ Do not force on LCD(Touch Panel) Screen

- Do not tap or scratch LCD(Touch Panel) Screen with a sharp
object.

* Otherwise, LCD(Touch Panel) may get damage.

PAGE 4 OF 21

▪ Product Input/Output Connectors

- Do not insert any metal, such as chopsticks, coins, pins and
steel,

- If foreign material enters the product, disconnect the USB cable
and contact a Service Center.

▪ Do not install MIMO in an unstable location

- Otherwise, it may fall and cause personal injury and/or damage
the product.

▪ Ensure that users do not disassemble, repair or

modify the product themselves

- If the product needs to be repaired, contact a Service Center.

If water enters the product, disconnect the USB and contact a Service Center.

This may result in a product malfunction, electric shock, or fire.

PAGE 5 OF 21

▣ Product Features

▶ USB powered monitor with Touch Screen Panel (UM-720S, UM-720F)

▶ Super Slim Foldable and Portable Design

▶ With only USB cable connection, a user may utilize MIMO as Multiple Input/Output device for Video

Conference, Instant Messaging, News and Stock casting.

• Each model has different functions and features as listed Product Matrix below

▶ Product Matrix

▣ Model Name

UM-710S

UM-720S

UM-710F

UM-720F

▣ Extension Monitor









▣ Pivot





▣ Touch Screen

 

▣ VESA 75 Compatible





▣ Color

Black Color

White Color

Black Color

White Color

Black Color

White Color

Black Color

White Color

* Product Colors and Designs may vary upon each product and above listed specifications are
subject to change without prior notice

* Pivot Caution: MIMO screen rotates one way only
. Horizontal to Vertical: Clockwise
. Vertical to Horizontal: Counter-clockwise

Do not force to rotate the screen opposite way

PAGE 6 OF 21

▣ Package Contents

Please make sure the following items are included with your monitor.
Contact a local dealer to buy optional items.

▶ UM-710S/ UM-720S

UM-710S/ UM-720S USB CABLE Install Disc + User Manual

▶ UM-720F

UM-710F/ UM-720F USB CABLE

Bracket for VESA 75 Install Disc + User Manual

※ Package Contents are subject to vary upon each model, please contact your local
dealer if any items are missing.

PAGE 7 OF 21

▣ Connections and Installation

MIMO requires USB connection only.

① USB Cap: USB mini B type connector inside

▶ Buttons

▶ System Requirements

• CPU : Intel Pentium/Celeron/AMD/K6/Athlon/Duron 1.2GHz or above

• RAM : 512MB RAM or above

• USB : at least one or more USB2.0 port

• HDD : 30MB HDD space above

• O/S : Windows 2000 SP4/XP SP2 32bit/Vista 32bit

▶ Using the Software

With only USB cable connection, a user may operate MIMO as an Extension monitor with Touch Screen
Panel(UM-720S, UM-720F). For more detail functions and feature please refer to page 5 “Product Features”)

①

①
