USER MANUAL
MI 413
Free & Total Chlorine
High Range Meter
Dear Custom er ,
Thank you for choos ing a Martini produc t. This
manual will provide you with the necessary
information for the correct use of the instrument.
Please read it c arefully b efore usi ng the meter.
This instrument is in compliance with
directives.
SPECIFICATIONS:
Range 0.00 to 10.0 0 m g/L Cl2
Resolution
0.01 mg/L (0.00-3.50
mg/L);0.10 mg/L (above
3.50 mg/L)
Precision ±0.10 mg/L @ 5.00 mg/L
Light Source Tungsten lamp
Light
Detector
Silicon Photocell and 525
nm narrow band
interferen ce fil ter
Method
Adaptation of the USEPA
method 330.5 and
Standard Method 4500Cl G.
Environment
0 to 50°C (32 to 122°F);
100% RH max.
Battery Type
1 x 9 volt
Auto-Shut off After 10' of non-use
Dimensions
192 x 104 x 52 mm
(7. 5 x 4.1 x 2”)
Weight 380 g
MEASUREMENT PROCEDURE:
1• Turn the meter on by pressing
ON/OFF.
2• When the LCD displays “- - -”, the
meter is ready.
3• Add 5 mL of DPD 0
reagent by using a
syringe.
4• Fill t he cuvet up to th e
10 mL mark with 5 mL
of unreacted sample
usi ng a pipet te.
5• Replace the cap and
shake gently for a few
seconds.
6• Reinsert the cuvet into
the holder and ensure
that the notch on the
cap is positioned
securely into the
groove.
7• Pr ess ZERO and “ SIP” will blink on the
display.
8• After a few seconds the display will
show “-0.0-”. The m eter is n ow zero ed
and ready for measurement.
9• Remove the cuvet. Open it.
10• For free chlorine measurement:
Add 3 drops of DPD 1 reagent.
Replace the cap and swirl gently.
11• Immediately insert the cu vet in to the
holder and ensure that the notch on
the cap is positioned securely into the
groove.
12• Press READ and “SIP”
will blink during
measurement.
13• The instrument directly
displays concentration in
mg/L of chlorine.
14• Then, for total chlorine measurement,
remove the cuvet and add to the
reacted sample 3 drops of DPD 3.
Replace the cap and swirl gently.
15• Reinsert the cuvet into the holder and
ensure that the notch on the cap is
positioned sec urely into the groove.
16• Wait for 2 minutes and 30 seconds
then press
READ and
“SIP” will bl ink
during
measurement.
17• The instrument directly displays
concentration in mg/L of total
chlorine.
Interferences
• Brom ine (positiv e error)
• Chlorine dioxid e (positive error)
• Iodine (positive error)
• Oxidized Manganese and Chromium
(positive error)
• Ozone (positive error)
• Alkalinity above 250 mg/L CaCO3 or
acidity above 150 mg/L CaCO3 will not
reliable develop the full amount of
color or it may rapidly f ade. To resolve
this, neutralize the sam pl e wit h di l uted
HCl or NaOH.
GUIDE TO DISPLAY CODES:
This prompt appears for 1 second each
time the instrument is turned on.
The dashes “- - -”
indicates that the
meter is in a ready
state and zeroing can
be performed.
Sampling In Progress.
Flashing “SIP” prompt
appears each time the
met er is perf orming a
measurement.
“-0.0-”, the m eter i s in
a zeroed state and
measurement can be
performed.
The blinking "BAT"
indicates that the
battery voltage is
getting low and the
battery needs to be
replaced.
“-bA-”, the battery is
dead and must be
replaced. Once this
indication is displayed,
the m eter will l ock up.
Change the battery
and restart the meter.
“Conf”, the meter has
lost its configuration. Contact your dealer
or the nearest Martini Customer Service
Center.
ERROR MESSAGES
On zero reading
• Blinking “-0.0-” indicates that the zeroing
procedure failed due to a low signaltonoise ratio. In this
case
press ZERO again.
• “no L”, the
instrum ent can not
adjust the light
level . Pl eas e check
that the sample
does not contain
any debris.
• “L Lo”, there is
not enough light to
perform a
measurement.
Please check the
preparation of the
zero cuvet.
• “L H i”, t here is too
much light to
perform a
measurement.
Please check the preparation of th e zero
cuvet.
On sam ple reading
• “-SA-”, t her e i s t oo
much light for the
sample
measurement.
Please check if the
rig ht sampl e cuvet is
inserted.
• “Inv”, the sample
and the zero cuvet
are i nverted.
• “ZErO”, a zero
reading was not
taken. Follow the instruction in the
measurement procedure for zeroing the
meter.
• Under range. A blinking “0.0 0” indi cates
that the sample
absorbs less light
than the zero
reference.
Check the procedure
and make sure you
use the sam e cuvet
for reference (zero)
and measurement.
• A flashing value of
the maximum
concentration
indicates an over
range condition.
The concentration of the s am pl e is bey on d
the programmed range: dilute the sam ple
and re-run the test.
BATTERY REPLACEMENT
Battery replacement must only take place
in a non-hazardous environment.
Simply rotate the battery cover on the back
of the meter.
Detach the
battery from
the terminals
and attach a
fresh 9V
battery while
paying
attention to
the correct
polarity.
Insert th e battery and replace the cover.
ACCESSORIES:
MI513-045 Free & Total Chlorine
reagent set (45 tests)
MI0001 Glass cuvets (2 pcs)
MI0002 C ap s for cuvets (2 pcs)
MI0003 Stoppers for cuvets (2 pcs)
MI0004 T issue for wipp ing cuvets
(4 pcs)
MI0005 9V batt ery (1 pc)
WARRANTY
This instr ument is warranted against def ects in
materials and manuf acturing f or a period of two
years from the date of purchase.
If during t his peri od t he r epair or r ep lac emen t of
parts is required, where the d amage is n ot due
to negligence or erroneous operation by the
user, pleas e
return the meter to eith er distrib utor or our offic e
in the origin al p acking and t he rep air will b e free
of charge.
Damages du e to accidents, mis use, tamperin g
or lack of prescribed maintenance are not
covered.
