Page 1
Cat. No.
M18 HAL
OPERATOR'S MANUAL
To reduce the risk of injury, user must read and understand operator's manual.
WARNING
M18™ HIGH PERFORMANCE LED AREA LIGHT
Page 2
2
IMPORTANT SAFETY
INSTRUCTIONS
WARNING
Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric
shock, fi re and/or serious injury. Save all warnings and
instructions for future reference.
WORK AREA
SAFETY
• To reduce the risk of injury, close supervision is
necessary when an appliance is used near children.
• Store idle light out of reach of children. Warm lights
can become hazardous in the hands of children.
• Do not use outdoors.
ELECTRICAL
SAFETY
• Power cord plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Un-
modifi ed plugs and matching outlets will reduce risk
of electric shock.
• Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
• Do not expose light to rain or wet conditions. Water
entering a light will increase the risk of electric shock.
• To reduce the risk of electric shock, do not put
light in water or other liquid. Do not place or store
appliance where it can fall or be pulled into a tub or
sink.
• Do not abuse the
cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
• Do not unplug by pulling on the cord. To unplug,
grasp the plug, not the cord.
• Unplug the cord from outlet when not in use and
before servicing or cleaning.
• Always use a suitable extension cord to reduce the
risk of electric shock.
• If operating a light in a damp location is unavoidable, use a ground fault circuit interrupter (GFCI)
protected supply. Use of an GFCI reduces the risk
of electric shock.
PERSONAL SAFETY
• Do not overreach. Keep proper footing and balance
at all times. This enables better control of the light in
unexpected situations.
• Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
light in unexpected situations.
BATTERY TOOL USE
AND CARE
• Recharge only with the charger specifi ed by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fi re when used with
another battery pack.
• Use light only with specifi cally designated battery
packs. Use of any other battery packs may create a
risk of injury and fi re.
• When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fi re.
• Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact accidentally occurs, fl ush with water. If liquid con-
tacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
• Do not use a battery pack or tool that is damaged or
modifi ed. Damaged or modifi ed batteries may exhibit
unpredictable behavior resulting in fi re, explosion or
risk of injury.
• Do not expose a battery pack or tool to fi re or ex-
cessive temperature. Exposure to fi re or tempera
ture
above 130°C (265°F) may cause explosion.
• Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specifi ed in the instructions. Charging im-
properly or at temperatures outside the specifi ed range
may damage the battery and increase the risk of fi re.
SERVICE
• Have your light serviced by a qualifi ed repair per-
son using only identical replacement parts. This
will ensure that the safety of the light is maintained.
• Never service damaged battery packs. Service of
battery packs should only be performed by the manufacturer or authorised service providers.
SPECIFIC SAFETY
RULES
•
•
WARNING
Some dust created by
power sanding, sawing,
grinding, drilling, and
other construction activities contains chemicals known
to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• lead from lead-based paint
• crystalline silica from bricks and cement and other
masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to
fi lter out microscopic particles.
Maintain labels and nameplates. These carry
important information. If unreadable or missing,
contact a MILWAUKEE
®
service facility for a
replacement.
Page 3
3
SYMBOLOGY
Volts
Direct Current
Alternating Current
Double Insulated
CAUTION
Laser Light
- Do Not Stare Into Beam
EXTENSION CORDS
Grounded tools require a three wire extension
Guidelines for Using Extension Cords
•If you are using an extension cord outdoors, be sure
it is acceptable for outdoor use.
•Be sure your extension cord is properly wired and in
good electrical condition. Always replace a damaged
extension cord or have it repaired by a qualifi ed
person before using it.
•Protect your extension cords from sharp objects,
excessive heat and damp or wet areas.
cord. As the distance from the supply outlet
increases, you must use a heavier gauge extension
cord. Using extension cords with inadequately
sized wire causes a serious drop in voltage,
resulting in loss of power and possible tool damage.
READ AND SAVE ALL INSTRUCTIONS
FOR FUTURE USE.
Regulatory Compliance Mark (RCM).
Product meets applicable regulatory
requirements.
SPECIFICATIONS
Cat. No. ................................................. M18 HAL
AC Input Volts ..................................... 220 - 240 V
DC Input Volts.................................................... 18
Max AC Input Amps ..................................... 0.22A
Max DC Input Amps....................................... 2.2A
Hertz .................................................................. 50
This tool is only suitable for indoor use.
Never expose tool to rain.
Page 4
4
ACCESSORIES
WARNING
Always remove battery pack and unplug
tool before changing
or removing accessories. Only use accessories
specifi cally recommended for this tool. Others
may be hazardous.
ASSEMBLY
WARNING
Recharge only with
the charger specifi ed
for the battery. For
specifi c charging instructions, read the opera-
tor’s manual supplied with your charger and
battery.
Inserting/Removing the Battery
Insert the battery pack by sliding battery pack into
the body of the tool. Insert the battery pack until the
battery latches lock.
To remove the battery pack, press in both battery
latches and slide the battery pack off of the tool.
Inserting/Removing Power Cord
To operate on AC power, plug in a suitable extension
cord to the receptacle. To remove, unplug the extension cord from the receptacle.
OPERATION
WARNING
To reduce the risk of
injury, do not look
directly into the light
when the area light is on.
Use the ON/OFF button
to cycle through High,
Medium, Low and OFF settings. Press and hold the
ON/OFF button to turn OFF immediately. Rotate
light head to desired angle.
MAINTENANCE
WARNING
To reduce the risk of
injury, always unplug
the tool and charger
and remove the battery pack from the charger or
tool before performing any maintenance. Never
disassemble the tool, battery pack or charger. Contact a MILWAUKEE
®
service facility for ALL repairs.
Maintain Area Light
Keep your area light, battery pack and charger in
good repair by adopting a regular maintenance
program. If the area light does not work properly,
WARNING
To reduce the risk of
personal injury and
damage, never immerse your tool, battery pack or charger in liquid
or allow a liquid to fl ow inside them.
Cleaning
Clean dust and debris from vents. Keep handles
clean, dry and free of oil or grease. Use only mild
soap and a damp cloth to clean, since certain cleaning agents and solvents are harmful to plastics and
other insulated parts. Some of these include gasoline,
turpentine, lacquer thinner, paint thinner, chlorinated
cleaning solvents, ammonia and household detergents containing ammonia. Never use fl ammable or
combustible solvents around tools.
return the area light to a MILWAUKEE
®
service
facility for repairs.
For a complete listing of accessories, go online to
www.milwaukeetools.com.au/
www.milwaukeetools.co.nz or contact a local
distributor.
For a list of MILWAUKEE® dealers, guarantee or service agents please contact MILWAUKEE
®
Customer Service or visit our website.
(Australia Toll Free Telephone Number 1300 361 505)
(New Zealand Toll Free Telephone Number 0800 279 624)
or visit www.milwaukeetools.com.au / www.milwaukeetools.co.nz.
WARRANTY - AUSTRALIA and NEW ZEALAND
SERVICE - AUSTRALIA and NEW ZEALAND
MILWAUKEE®prides itself in producing a premium quality product that is Nothing But Heavy Duty®.
Your satisfaction with our products is very important to us! If you encounter any problems with the
operation of this tool, please contact your authorised MILWAUKEE® dealer.
Please refer to Australian and New Zealand warranty supplied with tool. This warranty applies only to
product sold in Australia and New Zealand.
Milwaukee Electric Tool Corporation
13135 West Lisbon Road, Brookfield, Wisconsin U.S.A. 53005
Milwaukee Electric Tool Corporation (Australia)
Techtronic Industries (Australia) Pty. Ltd.
Rowville, Victoria, Australia, 3178
Milwaukee Electric Tool Corporation (New Zealand)
Techtronic Industries (New Zealand) Pty. Ltd.
Mangere, Auckland, New Zealand, 2022
Professionally made in China for Milwaukee Electric Tool Corporation
