Milwaukee 48-59-2001 Operator’s Manual
OPERATOR'S MANUAL
MANUEL de L'UTILISATEUR
MANUAL del OPERADOR
Cat. No. / No de cat.
48-59-2001
M4™ LITHIUM-ION BATTERY CHARGER
M4™ REDLITHIUM 2.0 BATTERY
CHARGEUR AU LITHIUM-ION M4™
BATTERIE AU LITHIUM-ION REDLITHIUM M4™ 2.0
CARGADOR PARA BATERÍAS DE IONES DE LITIO DE M4™
BATERÍA DE IONES DE LITIO DE M4™ REDLITHIUM 2.0
WARNING To reduce the risk of injury, user must read and understand operator's manual.
AVERTISSEMENT An de réduire le risque de blessures, l'utilisateur doit lire et bien
comprendre le manuel.
ADVERTENCIA Para reducir el riesgo de lesiones, el usuario debe leer y entender el manual.
CAUTION
GENERAL SAFETY RULES
WARNING
READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all
instructions listed below, may result in electric shock, re and/or serious personal injury.
SAVE THESE INSTRUCTIONS
This operator's manual contains important safety
and operating instructions for MILWAUKEE M4™
Lithium-Ion batteries and the MILWAUKEE M4™
Lithium-Ion battery charger. Before using the batteries and charger, read this operator's manual, your
tool operator's manual, and all labels on the battery,
charger and tool.
1.
M4™ LITHIUM-ION BATTERIES ONLY IN
MILWAUKEE M4™ LITHIUM-ION CHARGERS.
Other types of chargers may cause personal
injury or damage. Do not wire a battery to a
power supply plug or car cigarette lighter. Batteries will be permanently disabled or damaged.
2. USE MILWAUKEE M4™ LITHIUM-ION BATTER-
IES ONLY ON MILWAUKEE M4™ LITHIUM-ION
TOOLS. Use with other tools may result in a risk
of re, electric shock or personal injury.
3. AVOID DANGEROUS ENVIRONMENTS. Do not
charge battery in rain, snow, damp or wet locations. Do not use battery or charger in the presence of explosive atmospheres (gaseous fumes,
dust or ammable materials) because sparks may
be generated when inserting or removing battery,
possibly causing re.
4. CHARGE IN A WELL VENTILATED AREA. Do
not block charger vents. Keep them clear to allow
proper ventilation. Do not allow smoking or open
ames near a charging battery. Vented gases
may explode.
5. MAINTAIN CHARGER CORD. When unplugging
charger, pull plug rather than cord to reduce the
risk of damage to the electrical plug and cord.
Never carry charger by its cord. Keep cord from
heat, oil and sharp edges. Make sure cord will
not be stepped on, tripped over or subjected to
damage or stress. Do not use charger with damaged cord or plug. Have a damaged cord replaced
immediately with identical replacement parts (see
“Maintenance”).
6. DO NOT USE AN EXTENSION CORD UNLESS
IT IS ABSOLUTELY NECESSARY. Using the
wrong, damaged or improperly wired extension
cord could result in the risk of re and electrical
shock. If an extension cord must be used, plug
the charger into a properly wired 16 gauge or
larger extension cord with pins that are the same
number, size and shape as the pins on the charger. Make sure that the extension cord is in good
electrical condition.
7. CHARGER IS RATED FOR 120 VOLT AC ONLY.
Charger must be plugged into an appropriate
receptacle.
8. USE ONLY RECOMMENDED ATTACHMENTS.
Use of an attachment not recommended or sold
by the battery charger or battery manufacturer
may result in a risk of re, electric shock or personal injury.
9. UNPLUG CHARGER when not in use. Remove
battery from unplugged chargers.
TO REDUCE THE RISK OF INJURY, CHARGE MILWAUKEE
10. TO REDUCE THE RISK OF ELECTRIC SHOCK,
always unplug charger before cleaning or maintenance. Use a Ground Fault Circuit Interrupter
(GFCI) to reduce shock hazards.
11. DO NOT BURN OR INCINERATE BATTERIES.
Batteries may explode, causing personal injury or
damage. Toxic fumes and materials are created
when batteries are burned.
12. DO NOT CRUSH, DROP, OR DAMAGE bat-
teries. Do not use a battery or charger that has
received a sharp blow, been dropped, run over,
or damaged in any way (e.g., pierced with a nail,
hit with a hammer, stepped on).
13. DO NOT DISASSEMBLE. Incorrect reassembly
may result in the risk of electric shock, re or
exposure to battery chemicals. If it is damaged,
take it to a MILWAUKEE service facility.
14. BATTERY CHEMICALS CAUSE SERIOUS
BURNS. Never allow contact with skin, eyes, or
mouth. If a damaged battery leaks battery chemicals, use rubber or neoprene gloves to dispose of
it. If skin is exposed to battery uids, wash with
soap and water and rinse with vinegar. If eyes
are exposed to battery chemicals, immediately
ush with water for 20 minutes and seek medical
attention. Remove and dispose of contaminated
clothing.
15.DO NOT SHORT CIRCUIT. A short-circuited
battery pack may cause re, personal injury, and
product damage. A battery pack will short circuit
if a metal object makes a connection between
the positive and negative contacts on the battery
pack. Do not place a battery pack near anything
that may cause a short circuit, such as coins, keys
or nails in your pocket.
16. DO NOT ALLOW FLUIDS TO FLOW INTO BAT-
TERY PACK. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and
bleach or bleach containing products, etc., can
cause a short circuit..
17. STORE YOUR BATTERY AND CHARGER in a
cool, dry place. Do not store battery where tem-
peratures may exceed 120°F (50°C) such as in
direct sunlight, a vehicle or metal building during
the summer. Charger will charge the battery when
the battery's internal temperature is between
14°F (-10°C) and 140°F (60°C). When the battery
temperature is outside that range, charging will
not occur.
READ AND SAVE
ALL INSTRUCTIONS
FOR FUTURE
REFERENCE.
2
FUNCTIONAL
WARNING
WARNING
DESCRIPTION
1. Contacts
2. Tabs
3. Vents
4. Bay
5. Slots
4
5
6
6. Light indicator
Continuous red light: charging
Continuous green light: charging is complete
Flashing red light: battery is too hot or too cold charging will begin automatically when battery
reaches correct charging temperature
Flashing green and red light. Damaged or faulty
battery
1
2
SYMBOLOGY
Volts
Direct Current
Alternating Current
Double Insulated
Properly Recycle Batteries
Hertz
Amps
UL Listing for Canada and U.S.
mA
Milliamps
SPECIFICATIONS
Charger Cat. No. ................................ 48-59-2001
Input Volts AC ....................................................120
Input Milliamps...................................................300
Output Volts DC .....................................................4
Output Amps ..........................................................3
M4™ Li-Ion Battery Packs ............................ 4 V DC
M4™ LITHIUM-ION
3
a short circuit, never immerse your tool, battery
pack or charger in uid or allow a uid to ow
inside them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and
bleach or bleach containing products, etc., can
cause a short circuit.
Do not expose your battery or cordless tools to water
or rain, or allow them to get wet. This could damage
the tool and battery. Do not use oil or solvents to
clean or lubricate your battery. The plastic casing
will become brittle and crack, causing a risk of injury.
Store batteries at room temperature away from moisture. Do not store in damp locations where corrosion
of terminals may occur. As with other battery types,
permanent capacity loss can result if the battery is
stored for long periods of time at high temperatures
(over 120° F). MILWAUKEE Lithium-Ion batteries
maintain their charge during storage longer than
other battery types. After about six months of storage,
charge the battery as normal.
battery pack even if it is damaged, dead or completely discharged. When burned, toxic fumes
and materials are created.
Disposing of MILWAUKEE Lithium-Ion
MILWAUKEE Lithium-Ion battery packs are more
environmentally friendly than some other types of
power tool battery packs (e.g., nickel-cadmium).
Always dispose of your battery pack according to
federal, state and local regulations. Contact a recycling agency in your area for recycling locations.
Even discharged battery packs contain some energy.
Before disposing, use electrical tape to cover the
terminals to prevent the battery pack from shorting,
which could cause a re or explosion.
The RBRC™ Battery Recycling Seals (see "Sym-
bology") on your tool battery packs indicate that
MILWAUKEE has arranged for the recycling of
that battery pack with the Rechargeable Battery
Recycling Corporation (RBRC). At the end of your
battery pack's useful life, return the battery pack to
a MILWAUKEE Branch Oce/Service Center or the
participating retailer nearest you. For more information, visit the RBRC web site at www.rbrc.org.
BATTERY
To reduce the risk of re, personal
injury, and product damage due to
Maintenance and Storage
To reduce the risk of injury or ex-
plosion, never burn or incinerate a
Battery Packs
RBRC Battery Recycling Seals
3
WARNING
CHARGER
WARNING
OPERATION
Charge only MILWAUKEE M4™
MILWAUKEE Lithium-Ion Charger. Other types of
batteries may cause personal injury and damage.
When to Charge the Battery Pack
Remove the battery pack from the tool for charging
Remove the battery from the tool for charging when
convenient for you and your job. MILWAUKEE batteries do not develop a "memory" when charged
after only a partial discharge. It is not necessary to
run down the battery before placing it on the charger.
•Use the Fuel Gauge (on the tool) to determine when
to charge your MILWAUKEE Lithium-Ion battery.
• You can "Top-O" your battery's charge before start-
ing a big job or long day of use.
• The only time it is necessary to charge the
MILWAUKEE Lithium-Ion battery is when the battery has reached the end of its charge. To signal the
end of charge, power to the tool will drop quickly,
allowing you just enough power to nish making a
cut, drilling a hole, or driving a fastener. Charge the
battery as needed.
Align the large tab on the battery with the large slot
in the bay and slide the battery into the charger as
far as possible.
The red light will come on, either ashing (battery
is too hot or cold) or continuous (pack is charging).
• A fully discharged battery with an internal tem-
perature in the normal range will charge in about 45
minutes (between 32°F and 140°F). Heavily cycled
batteries may take longer to charge completely.
• After charging is complete, the continuous green
light will come on.
• The charger will keep the battery fully charged if it
is left on the charger.
• If the light indicator ashes red and green, check that
the battery is fully seated into the bay. Remove the
battery and reinsert. If the light continues to ash
red and green, the battery may be extremely hot or
cold, or wet. Allow the battery to cool down, warm up,
or dry out and then reinsert. If the problem persists,
contact a MILWAUKEE service facility.
• If the light indicator does not come on, check that
the battery is fully seated into the bay. Remove the
battery and reinsert. If the light indicator still does
not come on, contact a MILWAUKEE service facility.
Charging a Hot or Cold Battery Pack
The Red Flashing Indicator light on the charger indicates that the battery pack temperature is outside
the charging range. Once the battery pack is within
the acceptable range, normal charging will take place
and the red light will be continuous. Hot or cold batteries may take longer to charge.
Battery
Temperature
140°F or more
32°F to 140°F
32°F or less
Lithium-Ion batteries in the M4™
How to Charge the Battery
Li-Ion Charging Status
Red Indicator
Light
Flashing
Continuous
Flashing
Charging Status
Not charging
Normal charging
Not charging
Powering the Charger with an Inverter
The charger will operate with most generators and
inverters rated at 100 Watts or higher.
Use the ribs on the bottom of the charger to mark
the hanging points.
Store your charger in a cool, dry place.
As a general practice, it is best to unplug battery
chargers and remove batteries when not in use.
No battery pack damage will occur, however, if the
charger and battery pack are left plugged in.
battery from the charger before performing any
maintenance. Never disassemble the battery or
charger. Contact a MILWAUKEE service facility
for ALL repairs.
To reduce the risk of injury and damage, never
immerse your battery or charger in liquid or allow
a liquid to ow inside them.
Clean out dust and debris from charger vents and
electrical contacts by blowing with compressed air.
Use only mild soap and a damp cloth to clean the
battery pack and charger, keeping away from all electrical contacts. Certain cleaning agents and solvents
are harmful to plastics and other insulated parts.
Some of these include gasoline, turpentine, lacquer
thinner, paint thinner, chlorinated cleaning solvents,
ammonia and household detergents containing am-
monia. Never use ammable or combustible solvents
around batteries, charger, or tools.
The charger has no serviceable parts.
or Generator
Mouting to the Wall
Marking
Ribs
Maintenance and Storage
To reduce the risk of injury, always
unplug the charger and remove the
Cleaning
Repairs
SERVICE - UNITED STATES
1-800-SAWDUST (1.800.729.3878)
Monday-Friday, 7:00 AM - 6:30 PM CST
or visit www.milwaukeetool.com
Contact Corporate After Sales Service Technical
Support with technical, service/repair, or warranty
questions.
Email: metproductsupport@milwaukeetool.com
Become a Heavy Duty Club Member at
www.milwaukeetool.com to receive important
notications regarding your tool purchases.
4
SERVICE - CANADA
Milwaukee Tool (Canada) Ltd
1.800.268.4015
Monday-Friday, 7:00 AM - 4:30 PM CST
or visit www.milwaukeetool.ca
LIMITED WARRANTY
Every MILWAUKEE Battery Pack (sold with cordless product and/or as
a replacement battery pack) is warranted to the original purchaser only
to be free from defects in material and workmanship. Subject to certain
exceptions, MILWAUKEE will repair or replace a battery pack which, after
examination, is determined by MILWAUKEE to be defective in material or
workmanship for the stated warranty period from date of purchase. Return
of the battery pack to a MILWAUKEE factory Service Center location or
MILWAUKEE Authorized Service Station, freight prepaid and insured,
is required. For the proper shipping procedure of battery packs, contact
1.800.SAWDUST (1.800.729.3878), or go to www.milwaukeetool.com. A
copy of the proof of purchase should be included with the return product.
This warranty does not apply to damage that MILWAUKEE determines
to be from repairs made or attempted by anyone other than MILWAUKEE
authorized personnel, misuse, alterations, abuse, normal wear and tear,
lack of maintenance, or accidents.
Battery Pack
48-11-1812
48-11-1828
(Serial number prefix "B41E"
and later)
48-11-1840
48-11-1850
48-11-1860
48-11-1865
48-11-1880
48-11-1890
48-11-2402
48-11-2440
48-11-2460
48-11-2830
(Serial number prefix "C71")
48-11-0490
48-11-1815
48-11-1820
48-11-1835
48-11-2001
48-11-2401
48-11-2420
48-11-2430
48-11-1828
(Serial number prefix "B41D"
and earlier)
48-11-1830
(Serial number prefix “A95”)
48-11-2830
(Serial number prefix "A71")
48-11-0100
48-11-1024
48-11-1830
(Serial number prefix “E95”)
48-11-1970
48-11-2230
The warranty period for MILWAUKEE M18™ 48-11-1828 (with the serial
number prefix "B41D" and earlier), V18™48-11-1830 (with the serial number
prefix “A95”), and V28™ 48-11-2830 (with the serial number prefix "A71")
is five (5) years / 2000 charges from the date of purchase, whichever first
occurs. The first 1000 charges or 2 years of the warranty, whichever first
occurs, are covered through free replacement of the defective battery. This
means that for the earlier of the first 1000 charges or two (2) years from
the date of purchase/first charge, a replacement battery will be provided
to the customer for any defective battery free of charge. Thereafter, the
remaining charges up to a total of 2000 or the remainder of the five (5)
year period from the date of purchase, whichever first occurs, will be
covered on a pro rata basis. This means that every customer gets an ad-
ditional 1000 charges or three (3) years of pro rata warranty on the these
battery packs, depending upon the amount of use. MILWAUKEE M18™
48-11-1828 (with the serial number prefix "B41E" and later),
V18™48-11-1830 (with the serial number prefix “E95”), and M28™ 4811-2830 (with the serial number prefix "C71") have different warranty
periods, as listed.
Warranty Registration is not necessary to obtain the applicable warranty
on a MILWAUKEE battery pack. The manufacturing date of the product
will be used to determine the warranty period if no proof of purchase is
provided at the time warranty service is requested.
ACCEPTANCE OF THE EXCLUSIVE REPAIR AND REPLACEMENT
REMEDIES DESCRIBED HEREIN IS A CONDITION OF THE CONTRACT
FOR THE PURCHASE OF EVERY MILWAUKEE PRODUCT. IF YOU DO
NOT AGREE TO THIS CONDITION, YOU SHOULD NOT PURCHASE
THE PRODUCT. IN NO EVENT SHALL MILWAUKEE BE LIABLE FOR
USA & CANADA
Cat. No. Chemistry
Lithium-Ion (Li-Ion) Three (3) Years
Lithium-Ion (Li-Ion) Two (2) Years
Lithium-Ion (Li-Ion)
Nickel-Cadmium (Ni-Cd),
Nickel-Metal-Hydride (Ni-MH),
Lithium-Ion (Li-Ion)
Warranty Period
(from date of purchase)
Two (2) Years –
plus, Three (3) Years
Pro-Rata (prorated)*
One (1) Year
5
ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES, OR FOR ANY COSTS, ATTORNEY FEES, EXPENSES, LOSSES
OR DELAYS ALLEGED TO BE AS A CONSEQUENCE OF ANY DAMAGE
TO, FAILURE OF, OR DEFECT IN ANY PRODUCT INCLUDING, BUT NOT
LIMITED TO, ANY CLAIMS FOR LOSS OF PROFITS. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES, WRITTEN OR ORAL. TO THE EXTENT PERMITTED BY LAW, MILWAUKEE
DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR USE OR PURPOSE; TO THE EXTENT
SUCH DISCLAIMER IS NOT PERMITTED BY LAW, SUCH IMPLIED
WARRANTIES ARE LIMITED TO THE DURATION OF THE APPLICABLE
EXPRESS WARRANTY AS DESCRIBED ABOVE. SOME STATES DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU, THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
This warranty applies to product sold in the U.S.A. and Canada only.
Please consult the ‘Service Center Search’ in the Parts & Service section of
MILWAUKEE’s website www.milwaukeetool.com or call 1.800.SAWDUST
(1.800.729.3878) to locate your nearest service facility for warranty and
non-warranty service on a MILWAUKEE Battery Pack.
LIMITED WARRANTY
Every MILWAUKEE power tool* (see exceptions below) is warranted
to the original purchaser only to be free from defects in material and
workmanship. Subject to certain exceptions, MILWAUKEE will repair
or replace any part on an electric power tool which, after examination,
is determined by MILWAUKEE to be defective in material or workman-
ship for a period of ve (5) years** after the date of purchase unless
otherwise noted. Return of the power tool to a MILWAUKEE factory
Service Center location or MILWAUKEE Authorized Service Station,
freight prepaid and insured, is required. A copy of the proof of purchase
should be included with the return product. This warranty does not
apply to damage that MILWAUKEE determines to be from repairs
made or attempted by anyone other than MILWAUKEE authorized
personnel, misuse, alterations, abuse, normal wear and tear, lack of
maintenance, or accidents.
Normal Wear: Many power tools need periodic parts replacement and
service to achieve best performance. This warranty does not cover
repair when normal use has exhausted the life of a part including,
but not limited to, chucks, brushes, cords, saw shoes, blade clamps,
o-rings, seals, bumpers, driver blades, pistons, strikers, lifters, and
bumper cover washers.
*This warranty does not cover Air Nailers & Staplers; Airless Paint
Sprayer; Cordless Battery Packs; Gasoline Driven Portable Power
Generators; Hand Tools; Hoist – Electric, Lever & Hand Chain;
M12™ Heated Gear; Reconditioned Product; and Test & Measurement Products. There are separate and distinct warranties available
for these products.
**The warranty period for Job Site Radios, M12™ Power Port, M18™
Power Source, Jobsite Fan and Trade Titan™ Industrial Work Carts
is one (1) year from the date of purchase. The warranty period for the
Drain Cleaning Cables is two (2) years from the date of purchase. The
warranty period for the M18™ Compact Heat Gun and the 8 Gallon
Dust Extractor is three (3) years from the date of purchase. The warranty period for the LED in the LED Work Light and the LED Upgrade
Bulb for the Work Light is the lifetime of the product subject to the
limitations above. If during normal use the LED or LED Bulb fails, the
part will be replaced free of charge.
Warranty Registration is not necessary to obtain the applicable warranty on a MILWAUKEE power tool product. The manufacturing date
of the product will be used to determine the warranty period if no proof
of purchase is provided at the time warranty service is requested.
ACCEPTANCE OF THE EXCLUSIVE REPAIR AND REPLACEMENT
REMEDIES DESCRIBED HEREIN IS A CONDITION OF THE CON-
TRACT FOR THE PURCHASE OF EVERY MILWAUKEE PRODUCT.
IF YOU DO NOT AGREE TO THIS CONDITION, YOU SHOULD NOT
PURCHASE THE PRODUCT. IN NO EVENT SHALL MILWAUKEE BE
LIABLE FOR ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL OR
PUNITIVE DAMAGES, OR FOR ANY COSTS, ATTORNEY FEES,
EXPENSES, LOSSES OR DELAYS ALLEGED TO BE AS A CONSEQUENCE OF ANY DAMAGE TO, FAILURE OF, OR DEFECT IN
ANY PRODUCT INCLUDING, BUT NOT LIMITED TO, ANY CLAIMS
FOR LOSS OF PROFITS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU. THIS WARRANTY IS EXCLUSIVE AND IN LIEU
OF ALL OTHER EXPRESS WARRANTIES, WRITTEN OR ORAL.
TO THE EXTENT PERMITTED BY LAW, MILWAUKEE DISCLAIMS
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR USE OR PURPOSE; TO THE EXTENT SUCH
DISCLAIMER IS NOT PERMITTED BY LAW, SUCH IMPLIED WARRANTIES ARE LIMITED TO THE DURATION OF THE APPLICABLE
EXPRESS WARRANTY AS DESCRIBED ABOVE. SOME STATES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WAR-
USA & CANADA
Loading...
