SERVICE PARTS LIST
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
M18™ FORCELOGIC™ Brushless Press Tool w/ One-Key™
CATALOG NO. 2922-20
SEE PAGE TWO FOR THE REPLACEMENT
OF EXTERNAL SERVICE COMPONENTS
STARTING
SERIAL NO.
L38A
BULLETIN NO.
54-00-2922
REVISED BULLETIN
WIRING INSTRUCTION
DATE
Mar. 2022
Due to the complexities of One-Key™ electronics
and/or
Hydraulic/Pneumatic construction in this tool,
contact the following for service related questions and issues:
e-Service at: www.milwaukeetool.com/e-service
or
questions, please call 1.800.SAWDUST (1.800.729.3878)
or
Visit www.milwaukeetool.com to nd your closest
Milwaukee authorized Hydraulic repair center
or
Return it to a MILWAUKEE factory Service Center location, freight prepaid and insured.
A copy of the proof of purchase should be included with the return product.
If you have questions please contact Milwaukee Product Service at:
Product Technical Support via phone at: 262.783.8642
or
Via email at: METProductSupport @milwaukeetool.com
Disassembly is not recommended and could void the warranty.
Drwg. 3
43
44
2b
74
2c
2b 2c 2d 2e 3c 3b 3a
2a
(2x)
STREAMLINE™ ACR PRESS JAWS
for use with M18 FORCELOGIC™ PRESS TOOLS
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
90 49-16-2661M
91 42-55-8986 Blow Molded Carrying Case-
for Streamline™ Jaws Only
42-55-8985 Blow Molded Carrying Case for Tool and Streamline Jaw Kit (1)
92 49-16-2650M 1/4" Streamline™ Jaw (1)
93 49-16-2652M 3/8" Streamline™ Jaw (1)
94 49-16-2653M 1/2" Streamline™ Jaw (1)
95 49-16-2654M 5/8" Streamline™ Jaw (1)
96 49-16-2655M 3/4" Streamline™ Jaw (1)
97 49-16-2656M 7/8" Streamline™ Jaw (1)
98 43-46-0014 Crimp/Depth Gauge (1)
Streamline™ Press Jaw Kit (Cont. 91-98)
76
2d 2e
3
3a 3b
3
3c
65
(1)
(1)
45
46
51
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
2a 44-60-2673 Roller (2)
2b 06-81-0011 M5 x 8mm Cylinder Head Screw (1)
2c --------------- Roller Head (Cradle) (1)
2d --------------- Cylinder Pin (1)
2e --------------- Spring (1)
3 --------------- Retention Bolt Assembly (1)
3a --------------- Retaining Pin (1)
3b --------------- Flat Gripper (1)
3c --------------- Snap Ring (1)
43 --------------- Battery Door (1)
44 05-73-0015 M3 x 10mm Pan Hd. Screw (1)
45 44-86-0111 3mm Retainer (1)
46 --------------- 3mm Hex Nut (1)
51 12-20-0326 Service Nameplate (1)
52 --------------- 3V Coin Cell Battery (CR2032) (1)
60 42-55-2673 Blow Molded Carrying Case-Tool Only (1)
65 10-20-5416 Warning Sticker (1)
74 14-46-0272 Roller Head Service Kit (1)
76 14-46-0276 Retention Bolt Service Kit (1)
52
60
RLS® ACR PRESS JAWS
for use with M18 FORCELOGIC™ PRESS TOOLS
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
100 49-16-2662R
101 42-55-0106
for
102 49-16-2650R 1/4"
103 49-16-2652R 3/8"
104 49-16-2653R 1/2"
105 49-16-2654R 5/8"
106 49-16-2655R 3/4"
107 49-16-2656R 7/8"
108 49-16-2657R 1-1/8"
109 42-36-0052 Crimp/Depth Gauge (1)
RLS® Press Jaw Kit (Contains 101-109)
Blow Molded Carrying Case -
RLS® Jaws Only
RLS® Jaw (1)
RLS® Jaw (1)
RLS® Jaw (1)
RLS® Jaw (1)
RLS® Jaw (1)
RLS® Jaw (1)
RLS® Jaw (1)
(1)
(1)
