SERVICE PARTS LIST
BULLETIN NO.
54-00-2749
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
M18™ FUEL™ 18 GA. 1/4" Narrow Crown Stapler
CATALOG NUMBER
AVAILABLE SERVICE PARTS PAGE 2
2749-20
SERIAL
NUMBER
L30A and L30B
REVISED BULLETIN
WIRING INSTRUCTION
DATE
Oct. 2021
Due to the combination of the compressed air system and electronics in this tool,
service can only be performed at Milwaukee Authorized Repair Centers:
MILWAUKEE TOOL Central Repair
1401 Sycamore Avenue l Greenwood, MS 38930-7277
Please send your tool directly to this location for service.
Or
Via e-Service at: www.milwaukeetool.com/e-service
questions, please call 1.800.SAWDUST (1.800.729.3878)
Or
Visit www.milwaukeetool.com to nd your closest
Milwaukee authorized Hydraulic repair center
Or
Return it to a MILWAUKEE factory Service Center location, freight prepaid and insured.
A copy of the proof of purchase should be included with the return product.
If you have questions please contact Milwaukee Product Service at:
Product Technical Support via phone at: 262.783.8642
Or
Via email at: METProductSupport @milwaukeetool.com
Disassembly is not recommended and could void the warranty.
Drwg. 2
113
EXAMPLE:
00
Component Parts (Small #) Are Included
0
When Ordering The Assembly (Large #).
20
124
21
20
21
27
28
(x2)
32
116
114
65
66
32
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
20 --------------- Framer Belt Hook (1)
21 05-74-0019 M5 x 14mm Cap Hd. Hex Socket Screw (1)
27 28-20-0031 Reciever Cover (1)
28 05-74-0445 M4 x 22mm Mach. Scr. w/ 3mm Hex (2)
32 42-38-0033 No Mar Pad (2)
65 42-70-0525 Retaining E-Ring (1)
66 44-14-0028 Work Contact Bracket (1)
113 12-20-0245 Service Nameplate (1)
114 42-55-6150 Contractor Bag (1)
115 10-20-3696 Magazine Label (Not Shown) (1)
116 10-20-3697 Warning Label (1)
124 42-70-0021 Belt Hook Assembly (1)
