SERVICE PARTS LIST
BULLETIN NO.
54-00-CCKT
See
page two
for available
accessories and
applicable die sets,
ball pull, coupler
& quick connect
anvil assy.
No. 2676-20
M18™ ForceLogic™ Knockout Tool
Shown with optional quick connect
anvil assembly, ball pull and coupler
(See page two)
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
Cordless M18™ ForceLogic™ Knockout Tool
CAT. NO.
2676-20
SERIAL
NUMBER
Milwaukee Tool:
Force Logic™ 10T Knockout Tool
2676-20 and applicable die sets, ball pull,
coupler and quick connect anvil assy.
F75A
REVISED BULLETIN
WIRING INSTRUCTION
DATE
Nov. 2021
Due to the combination of hydraulics and electronics in this tool,
service can only be performed at this Milwaukee factory Repair Center:
MILWAUKEE TOOL Central Repair
1401 Sycamore Avenue l Greenwood, MS 38930-7277
Please send your tool directly to this location for service.
Or
Via e-Service at: www.milwaukeetool.com/e-service
questions, please call 1.800.SAWDUST (1.800.729.3878)
Or
Return it to a MILWAUKEE factory Service Center location, freight prepaid and insured.
A copy of the proof of purchase should be included with the return product.
If you have questions please contact Milwaukee Product Service at:
Product Technical Support via phone at: 262.783.8642
Or
Via email at: METProductSupport @milwaukeetool.com
Disassembly is not recommended and could void the warranty.
Drwg. 3
4
7/16" 3/4" 1-1/8"
ConduitN ominal Part Part 1/2" (13mm)7 /8" (22mm) 1-1/4" (32mm)S tainless Mild
Size Hole Size Number Description Number Description Pilot HoleP ilot HoleP ilot HoleS teel Steel
1/2" 0.885" / (22.5mm) 49-16-2660S SS 1/2" die 49-16-2661S SS 1/2" punch 49-16-2680 ----- -----
3/4" 1.115" / 28.3mm) 49-16-2662 3/4" die 49-16-2663 3/4" punch ----- 49-16-2681 -----
1" 1.362" / (34.6mm) 49-16-2664 1" die 49-16-2665 1" punch ----- 49-16-2681 -----
1-1/4" 1.701" / (43.2mm) 49-16-2666 1-1/4" die 49-16-2667 1-1/4" punch ----- 49-16-2681 -----
1-1/2" 1.951" / (49.6mm) 49-16-2668 1-1/2" die 49-16-2669 1-1/2" punch ----- 49-16-2681 -----
2" 2.416" / (61.4mm) 49-16-2670 2" die 49-16-2671 2" punch ----- 49-16-2681 -----
2-1/2" 2.914" / (74.0mm) 49-16-2672 2-1/2" die 49-16-2673 2-1/2" punch ----- ----- 49-16-2682
3" 3.539" / (89.9mm) 49-16-2674 3" die 49-16-2675 3" punch ----- ----- 49-16-2682
3-1/2" 4.044" / (102.7mm) 49-16-2676 3-1/2" die 49-16-2677 3-1/2" punch ----- ----- 49-16-2682
4" 4.544" / (115.4mm) 49-16-2678 4" die 49-16-2679 4" punch ----- ----- 49-16-2682
5" 5.665" / (143.9mm) 49-16-2686 5" die 49-16-2687 5" punch ----- -----
6" 6.748" / (171.4mm) 49-16-2689 6" die 49-16-2688 6" punch ----- -----
14 ga.
12 ga.
12 ga.
10 ga.
49-16-2707
Ø 1-1/8" - long
DIES
PUNCHES
DRAW STUDS
CAPACITY
6
5
1
2
3
No. 42-86-0050
1
Quick Connect
Anvil Assembly
No. 42-90-0020
2
Coupler
4
No. 42-90-0010
3
Ball Pull
5
No. 42-55-2676
Blow Molded Case (not shown)
6
No. 12-20-2637
Service Nameplate (not shown)
No. 10-20-1047
Warning Label (not shown)
No. 49-16-2685
Adaptor For Milwaukee power unit to
competitor dies and punches (not shown)
No. 49-16-2684
EXACT™ Adaptor For competitor power units
to EXACT™ 2-1/2" to 4" dies (3/4" studs)
(not shown)
