Milnor M76ED User Manual

M76ED

75-lb Capacity Dryer

Standard Features:

• 75-lb. Capacity

• Residual Moisture Control

• Single Phase Reversing

• Self-Diagnostic Microprocessor Control

• 100% Axial Airflow

• Completely Sealed Basket

• Non-Perforated Ribs and Basket

• Dual-Paned Door Glass

• Four-Point Roller Support System

• High Capacity Lint Drawer

• F.S.S. (Fire Suppression System)

•

Optional Features:

• Stainless Steel Front, Cabinet & Basket

OPL

Why Purchase Milnor EcoDry?

100% Axial Airflow (standard)

EcoDry tumblers incorporate a 100% axial airflow design with a completely
sealed basket. This ensures the most efficient drying available on the market
today without sacrificing dry times.

Four-Point Roller Support System (standard)

EcoDryers are designed with a four-point roller support system, eliminating costly repairs and downtime due to
trunnion failures.

Single Phase Reversing (standard)

Single Phase Reversing is standard on the M50ED and M76ED (optional on other units). What once was an expensive
option requiring an upgrade from single phase to three phase electrical service is now available in single phase.
A reversing tumbler ensures that the load doesn’t “rope” or “ball up”, providing a quicker, more even drying process.

Residual Moisture Control (standard)

EcoDry utilizes a unique Residual Moisture Control (RMC) sensing system to measure the presence of moisture in the load.
The patented system senses when the load is dry, shutting the unit down to prevent over-drying. This saves time, utility costs
as well as prolongs the life of dried items.

M76ED OPL Dryer

Your local Milnor independent authorized dealer.

www.milnor.com

M76ED

M76ED Specifications

Tumbler Capacity (dry weight) 75 lbs. (34.02 kg)

Tumbler Diameter 37” (93.98 cm)

Tumbler Depth 35-1/2” (90.17 cm)

Tumbler Volume 22.09 cu ft (625.52 L)

Tumbler/Drive Motor

Blower/Fan Motor 3/4 hp (0.56 kW )

Door Opening

Door Sill Height 27-5/16” (69.37 cm)

F.S.S. Water Connection 3/4”-11.5 NH

Dryers per 20’/40’ Container 9 / 20

Dryers per 48’/53’ Truck 25 / 27

Width 38-1/4” (97.16 cm)

Depth 49-13/16” (126.52 cm)

Height 70-1/2” (179.07 cm)

Airflow 60 Hz
gas/electric/steam 50 Hz

Exhaust Connection 8” (20.32 cm)

GAS MODEL:

ELECTRICAL MODEL:

Exhaust Connection

200-208V 60 Hz / All Other 1 hp (0.75 kW) / 3/4 hp (0.56 kW )

(Diameter) 27-3/8” (69.53 cm)

600 cfm (17.00 cmm)
500 cfm (14.16 cmm)

Approx. Net Wt.

Approx. Ship Wt.

Heat Input 60 Hz

Inlet Pipe Connection

Approx. Net Wt.

Approx. Ship Wt.

(Diameter)

Oven Size Oven Size

kW Btu/hr (kcal/hr) kW Btu/hr (kcal/hr)

18.4 62,763 (15,816) 20.3 69,418 (17,493)

20.2 68,975 (17,381) 20.4 69,521 (17,519)

745 lbs (337.93 kg)
775 lbs (351.53 kg)
130,000 btu/hr (32,760 kcal/hr)
110,000 btu/hr (27,720 kcal/hr)

50Hz

1/2” M.N.P.T.

745 lbs (337.93 kg)
775 lbs (351.53 kg)
8” (20.32 cm)

STEAM MODEL:

Approx. Net Wt.

Approx. Ship Wt.

Steam Consumption

Operating Steam Pressure

Exhaust Connection

(Diameter)

Boiler Horsepower (Normal Load)

Supply Connection
Return Connection

* Specications in parentheses are metric equivalents.

745 lbs (337.93 kg)
775 lbs (351.53 kg)
107 lb/hr (48.53 kg/hr)
150 psi max (10.34 bar)
8” (20.32 cm)
3 Bhp
3/4” F.N.P.T.
3/4” M.N.P.T.

2/1/10

Electrical Service Specifications

SERVICE
VOLTAGE

200 1ø 2 20.3 114.4 -- 150 220 3ø 3 18.5 60.2 57.8 80

208 1ø 2 22.0 118.7 -- 150 230 3ø 3 20.3 -- 60.0 80

220 1ø 2 18.5 95.7 93.3 120 240 3ø 3 22.0 64.2 -- 80

230 1ø 2 20.3 -- 97.2 130 380 3ø 4 18.5 39.6 37.2 50

240 1ø 2 22.0 103.0 -- 130 400 3ø 4 20.3 -- 40.2 50

208 3ø 3 22.0 73.8 -- 100 416 3ø 4 22.0 -- 39.6 50

PHASE

WIRE

SERVICE

APPROX AMP DRAW

OVEN kW

60 Hz 50 Hz 60 Hz 50 Hz

ELECTRIC

CIRCUIT

BREAKER

SERVICE

VOLTAGE

PHASE

WIRE

SERVICE

ELECTRIC

OVEN kW

APPROX AMP DRAW

Pellerin Milnor Corporation, PO Box 400, Kenner, LA 70063 USA,
Phone [phone] Toll Free: 800.469.8780 Fax: [phone]

www.milnor.com

CIRCUIT

BREAKER

Electrical Service Specifications

SERVICE

PHASE

VOLTAGE

120 1ø 2 18.6 -- 25

200 1ø 2 8.6 -- 20

208 1ø 2 8.7 -- 20

220 1ø 2 -- 8.8 20

230 1ø 2 8.8 8.8 20

240 1ø 2 9.1 -- 20

120 1ø 2 15.2 -- 20

200 1ø 2 6.7 -- 20

208 1ø 2 6.8 -- 20

220 1ø 2 6.9 6.8 20

230 1ø 2 -- 6.8 20

240 1ø 2 7.1 -- 20

WIRE

SERVICE

APPROX AMP DRAW

60 Hz 50 Hz

GAS

STEAM

CIRCUIT

BREAKER
