PANEL MOUNT GAUGE
2”, 2½”, & 3½” - U-Clamp Case
Miljoco offers a variety of panel mounted pressure gauges,
matching our line of vapor actuated remote reading panel
mounted thermometers. These instruments are rugged,
reliable, and accurate for a wide variety of uses such as air
compressors, portable chillers, packaged pump sets, etc.
U-clamp gauges are designed to be installed in a panel from
the rear using a mounting bracket and case studs.
A coil syphon must be installed on the connection when used on
steam applications.
General Specifications
CASE: Brightly-finished 300 series stainless steel.
LENS: Polycarbonate.
DIAL: Aluminum, white finished with black markings.
POINTER: Black, adjustable.
MOVEMENT: Brass with precision-milled teeth.
TUBE & SOCKET : Phosphor-bronze tube, brass socket.
CONNECTION:
1/8” NPT back outlet is standard to 400 psi.
1/4” NPT back outlet is standard from 600-1000psi.
ACCURACY: ±2-1-2% (ASME B40.100 Grade A).
PROCESS TEMPERATURE: -40 to 200°F (-40 to 93°C).
AMBIENT TEMPERA TURE: -40 to 140°F (-40 to 60°C).
Models & Dimensions (in.)
ØØ
CAUTION:
NSF® Service
Many Miljoco gauges are
listed by NSF
the food service industry.
Consult factory for available
models and ranges.
®
for use in
P2567
Standard Ranges
edoCegnaR.giF.viD
100
200
300
400
500
600
800
20
30
40
50
60
70
80
90
01
11
±2-1-2% Accuracy
0-gH"0351
isp51-0-gH"035/011/2
isp03-0-gH"035/011/2
isp06-0-gH"0301/011/1
isp001-0-gH"0302/032/5
isp051-0-gH"0302/032/5
isp003-0-gH"0305/0301/01
isp51-021.0
isp03-051
isp06-0011
isp001-0011
isp061-0022
isp002-0022
isp003-0055
isp004-0055
isp006-00501
isp0001-000101
laiD
ledoM
eziS
6602P
"2SSni-sserP42.290.150.2637.
6402P
"2SBAni-sserP42.290.150.2637.
7602P
"2SSdedaerhT42.290.160.2637.
7652P
"½2SSdedaerhT68.290.165.2637.
7653P
"½3SSdedaerhT49.390.105.3637.
esaC
lairetaM
sneL
ABCT
epyT
To Order
P 2 5 6 7 0 7
Model Number Range Code
Options
Silicone Dampening
Ø 0.125” Capillary Connection (specify length)
