PANEL MOUNT GAUGE
2”, 2½”, & 3½” - Front Flange Case
Miljoco offers a variety of panel mounted pressure
gauges, matching our line of vapor actuated remote
reading panel mounted thermometers. These
instruments are rugged, reliable, and accurate for a wide
variety of uses such as air compressors, portable
chillers, packaged pump sets, etc. Front flanged gauges
are designed to be installed in a panel using three screws
from the front.
on the connection when used on steam applications.
General Specifications
CASE: Brightly-finished 300 series stainless steel.
LENS: Polycarbonate.
DIAL: Aluminum, white finished with black markings.
POINTER: Black, adjustable.
MOVEMENT: Brass with precision-milled teeth.
TUBE & SOCKET : Phosphor-bronze tube, brass socket.
CONNECTION:
1/8” NPT back outlet is standard to 400 psi.
1/4” NPT back outlet is standard from 600-1000psi.
ACCURACY: ±2-1-2% (ASME B40.100 Grade A).
PROCESS TEMPERATURE: -40 to 200°F (-40 to 93°C).
AMBIENT TEMPERA TURE: -40 to 140°F (-40 to 60°C).
Models & Dimensions (in.)
Ø
ledoM
6302P
P6302P
7302P
7352P
7353P
CAUTION: A coil syphon must be installed
Ø
laiD
eziS
"2SSni-sserP49.290.150.265.2
"2SBAni-sserP49.290.160.265.2
"2SSdedaerhT49.290.150.265.2
"½2SSdedaerhT84.390.165.262.3
"½3SSdedaerhT03.490.105.300.4
esaC
lairetaM
sneL
ABCD
epyT
±2-1-2% Accuracy
P2036
Standard Ranges
edoCegnaR.giF.viD
100
200
300
400
500
600
800
20
30
40
50
60
70
80
90
01
11
0-gH"0351
isp51-0-gH"035/011/2
isp03-0-gH"035/011/2
isp06-0-gH"0301/011/1
isp001-0-gH"0302/032/5
isp051-0-gH"0302/032/5
isp003-0-gH"0305/0301/01
isp51-021.0
isp03-051
isp06-0011
isp001-0011
isp061-0022
isp002-0022
isp003-0055
isp004-0055
isp006-00501
isp0001-000101
To Order
P 2 0 3 6 0 7
Model Number Range Code
Options
Silicone Dampening
Ø 0.125” Capillary Connection (specify length)
20
