Milestone ML 44PSS Operating Manual

OPERATING MANUAL

FOR

PRESENTATION SCALER SWITCHER

Milestone Electronics Pvt. Ltd.

PRESENTATION SCALER SWITCHER

A unit whereby multiple VGA, COMPOSITE VIDEO inputs along with their
respective can be switched to individual respective outputs along with their
with VGA as individual or scaled output. PRESENTATION SCALER
SWITCHER by Milestone is available in two models as follows:

MODEL INPUTS OUTPUTS

ML 44PSS 4 VGA, 4 C-VIDEO 1 VGA/SCALED, 1 C-VIDEO

Features

INSTALLATION Easy to install - plug and play kind.

COMPATIBILITY

Fully compatible to VGA, SVGA & EVGA monitors and
standard C-Video.

SELECTION

Channel selectable from

 Individual front panel local keypad.
 Wired remote keypad (optional).
 RF Wireless remote keypad (optional).
 IR Wireless remote keypad (optional).
 Remote contact closure.
 RS232C interface.
 RS422/RS485 interface (optional).

INDICATION LED indication for working set.

VGA OUTPUT 1 VGA Output

C-VIDEO OUTPUT 1 C-VIDEO Output

CABLES

 Standard VGA cables for VGA I/P & O/P.
 Standard C-Video Cable

OPERATION

Manual / RS232C.

1

SPECIFICATIONS

MODEL 44PSS

INPUT CONNECTORS

 D15F (VGA)
 RCA (VIDEO)

4
4

OUTPUT CONNECTORS

 D15F (VGA)
 RCA (VIDEO)

1
1

LED INDICATION

 POWER
 VGA
 C.VIDEO

SCALER MODE ENABLED
SCALER OUTPUT
(VGA,C-VIDEO)

1
1 to 4
1 to 4

1

2

KEYPAD SELECTION

 VGA
 C-VIDEO
 CLEAR

SCALER MODE ENABLED

1 to 4
5 to 8

CLR

SCALER

REMOTE KEYPAD/
CONTACT CLOSURE

D9M x 2

RS 232 INTERFACE D9Fx 1

OPERATING DISTANCE
FROM REMOTE KEYPAD.

30 M

MAINS INPUT (AC) 230 V
DIMENSION

 RACK TYPE 19 INCH

1U

WEIGHT 2750 g

2

REAR PANNEL CONNECTORS DETAILS

1. Standard RCA for C-Video

2. Standard D15 Female for VGA.

3. D-9 F- for RS232C

4. D-9 M- for select from remote keypad.

The Connectors are:-

a) D15F VGA I/P (1 to4) -4 Nos.
b) RCA C-Video Female (C-Video 1 t0 4) -4 Nos.
c) D15F VGA/Scaler O/P VGA 1 -1 No.
d) RCA C- Video female (C-Video) -1 No.
e) D9M (RS232 C). -1 No.
h) D9M Select (Remote Keypad) -2 Nos.
(as explained in remote keypad selection)

HOW TO USE THE UNIT

1) Connecting the cables .

a) Connect VGA inputs to Laptops or Computers.
b) Connect C-Video to CD or DVD player or Camera.
c) Connect one VGA output to the VGA input of the Projector.

(Similarly for C-Video if required).

2) Operation in individual output mode;-

In this mode scaler mode (scaler LED) should be OFF. Both 2
outputs i.e. VGA, C-Video work independently. Both two outputs are
independent of others.
Select the required channels using various selection methods.

3) Operation in Scaler output mode:-

Press the scaler key to go in scaler model (LED ON). When scaler
LED is ON, VGA (output) goes in Scaler mode. Whichever key is
pressed last the output is seen in VGA i.e. C-Video is converted to
VGA output.
C-Video output still works independently, only VGA output is scaled.

Note: – To Blank All the O/P’s press Clear Key. To Blank VGA O/P only press
any key on VGA for more than one Sec. Similarly for C-Video.

3

OPERATION

 Local Keypad

Select the required channel from the front panel keypad.

 Remote contact closure/ remote keypad

Rear panel has two D9 male connector, operational at a distance of 50
meters. Milestone’s remote keypad or any other remote contact closure
can be connected at this connector.

The connector diagram for D9 male connector is as follows:

D-9 MALE1 CHANNELS

1 VGA 1
2 VGA 2
3 VGA 3
4 VGA 4
5 C-VIDEO 1
6 C-VIDEO 2
7 C-VIDEO 3
8 C-VIDEO 4
9 GRD

4

D-9 MALE2 CHANNELS

1 --­2 --­3 --­4 --­6 SCALER ENABLE/DISABLE
8 CLEAR
9 GRD

Note: 1. To select VGA 1, short 1and 9 through contact switch or use

Milestone’s remote keypad.

4

Remote RS232 interface

D9 female connector from rear panel is used for selecting the switcher
through RS232C Interface.

The pin configuration is as follows:

D-9 FEMALE SIGNAL

3 Rx
5 GRD

The simple command used for selecting the channels is as follows:

CHANNEL DECIMAL ASCI I

VGA 1 1! 31, 21
VGA 2 2! 32, 21
VGA 3 3! 33, 21

VGA 4 4! 34, 21
C-VIDEO 1 5! 35, 21
C-VIDEO 2 6! 36, 21
C-VIDEO 3 7! 37, 21
C-VIDEO 4 8! 38, 21

SACLER ENABLE e! 65, 21

SCALER DISABLE E! 45, 21

BLANK ALL g! 67, 21

VGA BLANK h! 68, 21

C-VIDEO BLANK i! 69, 21

Communication parameters are 9600 baud, no parity, 8-bit and 1 stop bit.

---X---X---X---X---

5
