PWR-LINE PRO
PWR-LINE PRO
PWR-LINE PRO (PL7510Gi) is a smart accessory to your existing network for places, where your signal or your cable is
unable to reach. Usually data over power-lines would be capped at 100 Mbps, but with PWR-LINE PRO you can reach
speed up to 600 Mbps!
Simply plug this device directly into one of the LAN ports of your MikroTik router and add another one somewhere
further in your premises. They will link together seamlessly through the power lines – now you have a perfectly
stable network connection in that tricky spot where cable management would be maddening! You can install up to
eight PWR-LINE devices to further build your network.
Please note that PWR devices must be connected
via the same electrical phase circuit. In order for the
PWR-LINE PRO to reach maximum throughput, your AC
socket must have a grounding connection.
This product works best with other PL75xx series
products, but is backwards compatible with PL64xx
and PL74xx as well. PWR-LINE PRO – don’t let the
cables limit you!
Compatible with other
MikroTik devices!
PWR-LINE PRO
2
Specifications
Product code PL7510Gi
PLC chipset QCA7550
Size of RAM 16 MB
Memory 4 MB Flash
10/100/1000 Ethernet ports 1
PoE-out Passive 24 V
Max PoE-out power 8 W
Supported input voltage 100 V - 240 V (50 - 60 Hz)
Max power consumption 14 W
Operating temperature -40°C .. +60°C
PWR-LINE PRO
Dimensions 94 x 105 x 32 mm
Power cord length 30 cm
Supported standard HomePlug AV2
Power plug type IEC C5
Included parts
IEC C5 cord Fastening set
(K62)
PWR-LINE PRO
