New MikroTik LoRa products – Internet of things has never been so aordable
MikroTik is bringing you new, powerful LoRa products for the fraction of the cost you would
expect.
R11e-LoRa8/R11e-LoRa9 – a new LoRaWAN concentrator gateway card in mini PCIe form factor
based on Semtech SX1301 chipset. It enables LoRaWAN connectivity for any MikroTik product that
has mini PCIe slot with connected USB lines.
With the support of 8 dierent channels, Listen Before Talk (LBT) and spectral scan features this
product will astound you with its enticing price
point.
wAP LoRa8/LoRa9 kit – an out-of-the-box solution to use LoRaWAN gateway. This kit contains
a pre-installed UDP packet forwarder to any public or private LoRa servers and an outdoor
weatherproof wireless access point with 2.4 GHz WLAN interface and Ethernet port that could be
used as a backend.
This particular wAP form-factor has been tested in many other MikroTik products – it can deliver
excellent and stable performance in almost any weather conditions.
You can use the optional internal 2 dBi antenna or attach
an external antenna. For extra network coverage we
suggest adding MikroTik LoRa Antenna kit.
Functional and non-intrusive design, astonishing
durability and great value – that is the wAP
LoRa8 kit, the long-awaited LoRa solution for
LoRa enthusiasts of any level.
LoRa series
1
LoRa series
LoRa Antenna kit with a 6.5 dBi Omni antenna for 824-960 MHz, 1 m long SMA cable and
mechanical holder for quick and easy mast attachment – when you need that extra network
coverage.
1 m SMA cable U-bolt kit
+ +
1 m
LoRa Antenna kit specifications
Product code TOF-0809-7V-S1
Frequency 824 - 960 MHz
Gain 6.5 dBi
Patterns
Horizontal beamwidth 360°
Vertical beamwidth 30°
Nominal impedance 50 Ω
Lightning protection DC ground
Connector SMA female
Weight 0.6 kg
Dimensions Ø 25 x 950 mm
Mast diameter Ø 30 - 50 mm
LoRa series
2
R11e-LoRa8/R11e-LoRa9 specifications
Product code R11e-LoRa8 R11e-LoRa9
Interface Mini-PCIe
Supported class A and C
LoRa series
Frequency
RF Output power 863-870 MHz 20 dBm 902-928 MHz 23 dBm
Receive max sensitivity -137 dB @ SF12
Range
Operating ambient
temperature
Max power consumption 2 W
863-870 MHz (EU863-870, RU864-870,
IN865-867)
Up to 15 km in rural environment and up to 2 km in urban environment when using
MikroTik LoRa 6.5 dBi antenna kit
-40°C .. +70°C
902-928 MHz (AU915-928, US902-928,
AS923, KR920-923)
wAP LoRa8/LoRa9 kit specifications
Product code RBwAPR-2nD&R11e-LoRa8 RBwAPR-2nD&R11e-LoRa9
CPU QCA9531 650 MHz
Size of RAM 64 MB
10/100 Ethernet ports 1
Wireless Built-in 2.4 GHz 802.11b/g/n, dual-chain
Antenna gain 2 dBi
PoE in Ye s
Supported input voltage 9 V - 30 V (Passive PoE)
Dimensions 185 x 85 x 30 mm
Operating ambient
temperature
Operating system RouterOS, License level 4
Max power consumption 7 W
-40°C .. +60°C
Wireless specifications
Rate (2.4 GHz) Tx (dBm) Rx (dBm)
1MBit/s 22 -96
11MBit/s 22 -89
6MBit/s 20 -93
Rate (2.4 GHz) Tx (dBm) Rx (dBm)
54MBit/s 18 -74
MCS0 20 -93
MCS7 16 -71
LoRa series
3
LoRa series
Our LoRa are ready to work with “The Things Network” - the famous open source infrastructure
that provides free LoRaWAN network coverage and has tons of apps for your needs. With the
help of “The Things Network” you can get started with the Internet of things within a day. And it is
easily upgradable to enterprise-grade network “The Things Industries”.
Cattle tracking, smart irrigation, level monitors for liquids, smart pulse sensors and thermostats,
smart parking and so on – the possibilities are endless. And the setup is so easy, anyone can
learn it. There is a large community of developers and enthusiasts all around the globe – you
will never be alone with your questions and ideas regarding the LoRaWAN network. No need to
reinvent the wheel – join “The Things Network” to save time and energy with smart solutions!
With this product family we aim to provide the most aordable LoRa solution to date without
compromising quality or performance.
