GPEN (Gigabit Passive Ethernet Network)
Concept
Cut costs, not speed – forget about the expensive GPON!
This is the cheapest way for any ISP to deliver high-speed internet to individual apartments.
GPEN Concept
MikroTik GPEN concept can replace any existing or future GPON solution. It provides all the benefits of
GPON, but utilizes well-proven, simple and inexpensive Ethernet solutions.
GPEN doesn’t require expensive GPON OLT equipment in your
server rooms, just a regular switch port!
Similar to GPON, GPEN solution will require clients to provide power, but instead of powering GPON’s
ONT device, power will be used for extending the Ethernet cable (with our GPeR devices) and powering
the netPower device. That is the GPEN analogue of GPON Passive optical splitters – netPower provides
additional functionality and possibilities.
And the best part of this technology – it give you all the flexibility for a fraction of the price. You can
connect netPower to your server room by Ethernet, Active optical line or use it to power one end of point-
to point backbone wireless link. GPEN – the evolution of GPON done right!
GPEN Concept
2
GPEN Concept
GPEN11
The GPEN11 is a power injector that can power your uplink devices via PoE. It is part of the GPEN (Gigabit
Passive Ethernet Network) concept, which aims to replace GPON installations with lower cost and more
easy to deploy Ethernet alternative.
It also has a designated
space for an ISP sticker on the
front. Sticker size: 66 x 25 mm
(2,5 x 1 Inches).
GPEN11 can be mounted inside customer premises, next to the wireless router which provides connectivity
to the users. The GPEN11 itself will then power the ISP router, whether it is an outdoor wireless unit
mounted on the roof or a network switch somewhere in the building. The GPEN unit can be securely
attached to a wall or the communications cabinet. The Ethernet cable can be routed either directly
through its bottom cable opening or into the wall, as preferred.
Specifications
Product code GPEN11
Number of 1 GbE Ethernet ports 2
Number of DC inputs 1
PoE-out Yes, Passive PoE
Supported input voltage 12 - 57 V
Dimensions 92 x 104 x 24 mm
Operating temperature -40°C to +70°C tested
Included parts
Screw kit
GPEN Concept
3
GPEN Concept
GPEN21
The GPEN21 is a smart power injector that serves as
an advanced software controlled repeater. Not only
can it power your uplink devices via PoE, it can also
provide a range of useful software features:
• Interface management and monitoring
• GPEN link fault detection
• VLAN support
• SNMP reporting
• Basic Trac Shaping
It also has a designated space for an ISP sticker on the
front. Sticker size: 66 x 25 mm (2,5 x 1 Inches).
GPEN21 has an Ethernet and SFP port for fiber connectivity. Customers
can choose to use GPEN21 to power optical module for uplink to
provider, or to provide PoE to power Ethernet uplink to provider
(that uses our GPER and/or NetPower products) The GPEN unit can
be securely attached to a wall or the communications cabinet. The
Ethernet cable can be routed either directly through its bottom cable
opening or into the wall, as preferred.
Specifications
Product code GPEN21
Number of 1 GbE Ethernet ports 2
Number of 1G SFP ports 1
Number of DC inputs 2
Included parts
PoE-out Yes, Passive PoE up to 57 V
PoE-in 802.3af/at
Supported input voltage 12 - 57 V
Dimensions 92 x 104 x 24 mm
Operating temperature -40°C to +70°C tested
GPEN Concept
Screw kit
4
GPEN Concept
GPEN21 software provides
Interface
management and
monitoring
GPEN link fault
detection
VLAN support
Basic Trac
Shaping
GPEN Concept
5
GPEN Concept
GPeR
The Gigabit Passive Ethernet Repeater (GPeR) is part of our new GPEN (Gigabit Passive Ethernet Network)
concept, which aims to replace GPON installations with lower cost and more easy to deploy Ethernet
alternative.
The GPeR unit allows to extend Ethernet cable by additional hop (< 100 - 150 m to regular network
devices, and up to 210 m to another GPeR unit) up to 1,500 m. Handy for highrise buildings, multi-
apartment buildings, with many floors and sections, where very long Ethernet cables might be a problem.
Maximium allowed length of CAT6 Ethernet cable between GPeR and power source/router is up to 100 m
(depending on cable quality, high quality - up to 150 m).
Maximium allowed distance of CAT6 Ethernet cable between two GPeR devices is up to 210 m (depending
on cable quality).
Specifications
Product code GPeR
Gigabit Ethernet ports 2
Switch chip Marvell E6341
Powering PoE
PoE-in 802.3af/at or Passive PoE (24 - 57 V)
PoE-out Jumper selectable Passive PoE passthrough
Max power consumption 2 W
Operating temperature -40°C to +70°C tested
GPEN Concept
6
GPEN Concept
GPeR IP67 Case
We bring you a sturdy and aordable outdoor enclosure for GPeR units. It can be
easily mounted on walls and poles. Despite the name, meticulous testing revealed that
in real life the enclosure has an IP68 rating with protection from immersion in water, as
well as protection from dust. Get an outdoor enclosure for the GPeR to safely extend
Ethernet network in mines, caves, maintenance shafts or outdoors.
Product code: GPeR-IP67-Case
GPEN Concept
7
GPEN Concept
netPower 15FR
With netPower 15FR switch you can forget about expensive GPON base stations and optical splitters. This
switch is a part of our GPEN concept – aimed to bring the speed and versatility of fiber networking while
using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to
individual apartments.
You don’t have to worry about power
options in the attic or the utility room –
netPower 15FR has 15 reverse PoE ports.
Depending on your setup, netPower can
draw the necessary power even from a
single client! Another Ethernet port has
PoE-out – you can use it to power an
aggregate link such as our Wireless Wire
Dish or a security camera, for example.
netPower 15FR
– bringing the cost down and the speed up!
There are two SFP ports for fiber connectivity. The
outdoor enclosure allows you to install this switch
GPEN Concept
in all kinds of environments – from damp attics to
elevator shafts and dierent poles with hose clamps.
netPower 15FR has a non-blocking throughput of 3.6
Gbps, switching capacity of 7.2 Gbps and forwarding
rate of 5.4 Mpps.
8
GPEN Concept
Specifications
Product code CRS318-1Fi-15Fr-2S-OUT
CPU 98DX224S 800 MHz
Size of RAM 256 MB
Storage type Flash
Storage size 16 MB
Switch chip model 98DX224S
Number of 100 Mbps Ethernet ports 16
SFP ports 2
Operating system SwOS / RouterOS (Dual boot)
RouterOS license level 5
PoE-in Ports 1 - 14 and 16
PoE-out On Ether15
Supported input voltage 18 - 57 V (DC jack); 36 - 57 V (PoE-in)
Number of DC jacks 1 *
Dimensions 304 x 212 x 71 mm
Operating temperature -40°C to +70°C tested
Max power consumption 29 W
* power adapter not included
Included parts
Hose clamp 1 Hose clamp 2 K-66 fastening
GPEN Concept
set
DC to Terminal
block adapter
9
GPEN Concept
To power netPower from a single GPEN
To power netPower that provides PoE-out to uplink from a single GPEN
Examples Power adapters
48POW
48 V, 1.46 A, 70 W
24HPOW
24 V, 2.5 A, 60 W
48V2A96W
48 V, 2 A, 96 W
MT48-480095-11DG
48 V, 0.95 A, 45.6 W
MT48-570080-11DG
57 V, 0.8 A, 45.6 W
