netPower 16P
An outdoor 18 port switch with 16 Gigabit PoE-out ports and 2 SFP+
Power all your access points anywhere!
netPower 16P
Powering a bunch of access points or IP cameras and a few uplinks on a tower has never been easier.
netPower 16P has 16 Gigabit Ethernet ports with PoE-out and two SFP+ ports for 10G fiber uplinks.
Its sturdy and compact outdoor
enclosure allows the switch to be
mounted in all kinds of environments –
from damp attics and shafts to towers,
masts and poles with hose clamps.
netPower 16P has a non-blocking throughput
of 36 Gbps, switching capacity of 72 Gbps and
forwarding rate of 53.6 Mpps.
netPower 16P – a simple solution for complicated tasks
When using both the high and low voltage adapters, the netPower will automatically choose the correct
PoE standard and voltage, based on the devices you connect to each port. You can also specify it manually.
Compatible
with MikroTik
power supplies
24HPOW 48POW 48V2A96W
netPower 16P
2
netPower 16P
Specifications
Product code CRS318-16P-2S+OUT
CPU 98DX226S, 800 MHz
CPU temperature monitor Ye s
Size of RAM 256 MB
Storage 16 MB flash
Switch chip model 98DX226S
Number of 1G Ethernet ports 16
Number of 10G SFP+ ports 2
Operating system RouterOS (License level 5) / SwOS (dual boot)
Dimensions 303 x 212 x 78 mm
Operating temperature -40°C to +70°C
Powering
PoE-out Passive PoE with auto sensing, 802.3af/at
PoE-out ports Ether1 - Ether16
Max PoE-out on low (< 30 V) voltage 5.6 A (2.8 A per 8port group, max 1.1 A per port)
Max PoE-out on high (> 30 V) voltage 2.8 A (1.4 A per 8port group, max 0.6 A per port)
The total output power limit will also depend on your power
Max total out (A)
Number of DC jacks 2
Supported input voltage 18-30 V / 48- 57 V
Max power consumption 316 W
Max power consumption without attachments 16 W
supply max current limit. You should not exceed your power
supply current limit or the board may reboot
Certification & Approvals
Certification IP55
netPower 16P
3
netPower 16P
Switching test results
CRS318-16P-2S+OUT
Mode Configuration
Switching
Switching
Switching
Switching
Like other CRS products, CRS318-16P-2S+OUT comes with a decent built-in CPU, that can utilize all RouterOS features, but with some
performance restrictions (indicated in table below).
Non blocking Layer
2 throughput
Non blocking Layer
2 capacity
Non blocking Layer 1
throughput
Non blocking Layer 1
capacity
RouterOS v6.45.7
1518 byte 512 byte 64 byte
kpps Gbps kpps Gbps kpps Gbps
2925,9 35532,1 8458,7 34646,8 53571,4 27428,6
2926,9 71088,5 8459,7 69301,9 53572,4 54858,1
2927,9 36000,0 8460,7 36000,0 53573,4 36000,0
2928,9 72000,0 8461,7 72000,0 53574,4 72000,0
CPU Layer 3 performance results
CRS318-16P-2S+OUT
Mode Configuration
RouterOS v6.45.7
1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 104,1 1264,2 119,1 487,8 141,1 72,2
Bridging 25 bridge filter rules 59,7 725,0 59,7 244,5 70,4 36,0
Routing none (fast path) 104,1 1264,2 129,7 531,3 143,5 73,5
Routing 25 simple queues 56,7 688,6 57,9 237,2 65,2 33,4
Routing 25 ip filter rules 44,1 535,6 45,6 186,8 48,4 24,8
Included parts
Hose clamp 1 Hose clamp 2 K-66 fastening
set
* Power supply is NOT included with the product. You are welcome to use your preferred power option, like battery
pack etc. Compatible also with MikroTik power supplies 24HPOW, 48POW and 48V2A96W
2 DC to Terminal
block adapters
netPower 16P
