Mighty Clean MC2200BL Operator's Manual

1

Model MC2200BL

OPERATOR'S MANUAL
ELECTRIC HIGH-PRESSURE WASHER

Before operating this product, please read this manual
thoroughly and retain it for future reference.

SUMEC NORTH AMERICA
3939 Royal Drive NW
Unit #234
Kennesaw, GA 30144

MC2200BL.indd 1 15-4-30 ��2:26

2

DO NOT RETURN PRODUCT TO PLACE OF PURCHASE.
IF YOU HAVE ANY QUESTIONS, CALL OUR TOLL-FREE HOTLINE.

[phone]

ForceToolsUSA.com

MC2200BL.indd 2 15-4-30 ��2:26

I

TABLE OF CONTENTS

MC2200BL Operator's Manual

Description of Product Parts………………………………………………………………………………......02

Technical Specifications…………………………………………………………………………………….....04

Intended Use……………………………………..…………………………………………………………......04

Important Safety Instructions……………………………………………………………………………….....05

Installation Instructions………………………………………………………………………………………...10

Operating Instructions……………………………………………………………………………………….....15

Cleaning and Maintenance………………………………………………………………………………….....19

Moving and Storage Instructions………………………………………………………………….................20

Disposal....…………………………………………………………………………………………………........21

Troubleshooting……....………………………………………………………………………………………...21

Warranty………………………………………………………………………………………………...............24

MC2200BL.indd 1 15-4-30 ��2:26

2

DESCRIPTION OF PRODUCT PARTS

Parts list
As shown in Fig. 1-3

1. Gun / power cord / hose holder

2. Handle with soft grip

3. Spray tips storage slots

4. Pressure adjusting knob

5. Support

6. High-pressure water outlet

7. Water inlet

8. Locking/releasing pin (not visible in this illustration)

9. On / Off Switch

10. Wheel

11. Plug

12. Power cord with GFCI

13. Attachments storage

14. Detergent intake hose

15. Nozzle cleaning needle

16. High-pressure hose

17. Quick-connect wand

18. Spray gun high-pressure water inlet

19. Trigger switch

20. Safety lock

21. Trigger handle

22. 0° nozzle

23. 15° nozzle

24. 40° nozzle

25. Soap nozzle

26. Turbo nozzle

27. Nozzle cleaning needle

Fig.1

Fig.2

Fig.3

MC2200BL.indd 2 15-4-30 ��2:26

3

CHECK THE DELIVERY PARTS
As shown in Fig. 4

Carefully remove the pressure washer and parts from its packaging. Identify all the parts packaged in
the carton against the parts list. Please contact our customer service center (Monday-Friday 8:30AM­5:00PM ET) at [phone] if anything is missing.

A High-pressure washer x1
B High-pressure hose x1
C Quick-connect wand x1
D Trigger handle x1
E1 0° nozzle x1
E2 15° nozzle x1
E3 40° nozzle x1
E4 Soap nozzle x1
E5 Nozzle cleaning needle x1
F Nozzle pin x1
G Operating manual x1

WARNING: If any parts are damaged or missing, do not operate this tool until the missing parts

are replaced. Failure to heed this warning could result in serious personal injury.

NOTE! Always recycle the packaging in accordance with local recycling schemes.

Fig.4

MC2200BL.indd 3 15-4-30 ��2:26

4

TECHNICAL SPECIFICATIONS

INTENDED USE

Model MC2200BL

Input voltage rating 120 V, 60 Hz

Input power 13 A

Working pressure 2200psi

Max. pressure 2500psi

Flow rate 1.25GPM (280L/H)

Inlet pressure 44psi

Supply water temperature (max.) Cold tap water 104

o

F (40oC)

Electrical cord 35ft. (10.7m)

High-pressure hose 25ft. (7.6m)

Detergent injection rate 3%~12%

The pressure washer is intended for cleaning the walls of buildings, facades, terraces,
footpaths, garden equipment, machinery, vehicles, tools, etc. with a pressure water
nozzle. If required, you can also use the pressure washer with added household
cleaning agents.

The pressure washer is to be used only for its prescribed purpose, any other use is
deemed to be a case of misuse. The user/operator and not the manuafacturer will be
liable for any damage or injuries of any kind caused as a result of this.

Please note that our equipment has not been designed for use in commercial, trade
or industrial applications. Our warranty will be voided if the pressure washer is used

in commercial, trade or industrial businesses or for equivalent purposes.

MC2200BL.indd 4 15-4-30 ��2:26

5

IMPORTANT SAFETY INSTRUCTIONS

Please read all of the safety precautions before operating this pressure washer
every time.
Please pay particular attention to all sections with following symbols.

The following signal words and meanings are intended to explain the levels of risk
associated with this pressure washer.

DANGER!

Indicates an imminently hazardous situation which, if not avoided, will result in death
or serious injury.

WARNING!

Indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injury.

CAUTION!

Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.

CAUTION!

(Without Safety Alert Symbol) Indicates a situation that may result in property damage.

WARNING! -

When using this pressure washer, basic precautions should always

be followed, including the following:

1. Read all the instructions before using the pressure washer.

2. To reduce the risk of injury, close supervision is necessary when a product is used
near children.

3. Know how to stop the pressure washer and release pressure quickly. Be
thoroughly familiar with the controls.

MC2200BL.indd 5 15-4-30 ��2:26

6

4. Stay alert-watch what you are doing.

5. Do not operate the pressure washer when fatigued or under the influence of
alcohol or drugs.

6. Keep operating area clear of all persons.

7. Do not overreach or stand on unstable support. Keep good footing and balance
at all times.

8. Follow the maintenance instructions specified in the manual.

9. This pressure washer is provided with a Ground Fault Circuit Interrupter built
into the power cord plug. If replacement of the plug or cord is needed, use only
identical replacement parts.

10. This pressure washer or its power cord contains lead, a chemical known to cause
cancer, birth defects or other reproductive harm. Wash hands after handling.

WARNING -

Risk of injection or injury – Do Not Direct Discharge Stream At

persons.

11. Never operate the pressure washer without all components properly connected to
the pressure washer (handle, gun/wand assembly, nozzle, etc.).

12. Never operate pressure washer with broken or missing parts. Check equipment
regularly and repair or replace worn or damaged parts immediately.

13. Never put hand or fingers over the nozzle or spray tip while operating the pressure
washer.

14. Never spray flammable liquids or use pressure washer in areas containing
combustible dust, liquids or vapors. An electric spark could cause an explosion.

15. Never leave the wand unattended while the pressure washer is running or
switched on.

16. Never disconnect the high-pressure discharge hose from the pressure washer
while the system is pressurized. To depressurize washer, turn power and water
supply off, then depress gun trigger 2-3 times.

17. Never cover the pressure washer during operation to allow free air cooling.

18. Always wear safety glasses or goggles when operating or performing
maintenance.

19. Always move switch on washer to “OFF” position before connecting or
disconnecting cord to electrical outlets.

20. Always turn water supply "ON" before turning pressure washer "ON" unless
draining for storage. Running pump dry causes serious damage.

21. Always hold gun and wand firmly when starting and operating the pressure

MC2200BL.indd 6 15-4-30 ��2:26

7

washer.

22. Always follow detergent manufacturer’s label recommendations for proper use
of detergents. Always protect eyes, skin and respiratory system from detergent if
used.

23. Always lock the trigger of spray gun in the safety position when not in use.

24. Do not use pressure that exceeds the operating pressure of any of the parts (hoses,
fittings, etc.) in the pressurized system. Never use with any other manufacturer’s
accessories or components.

25. Do not spray electrical apparatus and wiring or the pressure washer itself.

26. Do not operate the pressure washer with the inlet water filter removed. Keep filter
clear of debris and sediment.

27. Discharge residual pressure by depressing the trigger until no more water comes
out of the nozzle.

28. Keep clear of nozzle. Never direct high-pressure spray at any person, animal or
self.

29. To minimize the amount of water getting into the pressure washer, the pressure
washer should be placed as far as possible from the cleaning site during

operation.

GROUND FAULT CIRCUIT INTERRUPTER PROTECTION

This pressure washer is provided with a ground fault circuit interrupter (GFCI) built
into the plug of the power cord. This device provides additional protection from the
risk of electric shock. Should replacement of the plug or cord become necessary,
use only identical replacement parts that including of GFCI protection.
TEST BEFORE EACH USE. Press the “TEST” button. Red indicator should disappear.

Press “RESET” button again for use. DO NOT USE if above test fails.

EXTENSION CORDS

If possible, do not use extension cords with this pressure washer; however, if you
must use one, observe all of the warning and instructions listed below:

WARNING

Extension cords are not recommended unless these are plugged into a ground fault
circuit interrupter (GFCI) found in circuit boxes or protected receptacles.

1. Use only extension cords that are intended for outdoor use. These extension

MC2200BL.indd 7 15-4-30 ��2:26
