Mifold Grab-and-Go Booster User Manual

the Grab-and-Go Booster

®

4 to 12 years
Group 2/3 (15-36kg)
Approved to ECE R44.04

P/N - 1021 Rev D

GB

32

Congratulations on buying your mifold
Grab-and-Go booster seat. mifold is the most

advanced, compact, and portable booster seat
ever invented. mifold is more than 10x smaller
than a regular booster seat, and is just as safe*.

We hope that you are delighted and satised

with mifold. We always enjoy hearing from
customers with your ideas, thoughts, feedback,
pictures and videos.

You can contact us in many ways:

[e-mail]

@mifoldBooster

www.mifold.com/contact

pinterest.com/mifold

facebook.com/mifold

instagram.com/mifold

*Safety claim based on compliance with
UNECE Regulation 44/04.

Introduction to your mifold

Grab-and-Go Booster Seat

Before using this booster seat it is important to
understand how to properly install your booster
seat, secure your child correctly, and familiarise
yourself with the features and functions of the
booster seat.

It is important to take the time to read and
understand these instructions fully. This is best
done with the mifold Grab-and-Go booster seat
in front of you.

Read all the safety warnings before using the
booster seat.

User Manual Storage

It is most important that these instructions
remain with the mifold Grab-and-Go booster seat
at all times. Store these instructions in the slot
located on the edge of the mifold Grab-and-Go
booster seat.
Read and follow all instructions and information
in this manual, on the product
labels, and in the vehicle owner’s manual for
booster seat and vehicle seat belt use.

54

mifold Grab-and-Go Booster Seat Features

E

F

A

LH

G

H

I

C RH

B

RH

C LH

B

LH

RH

D

D

Shoulder Belt Guide Strap

Shoulder Belt Guide

Shoulder Belt Guide Buckle

Booster Seat Cushion

User Manual

Booster Seat

Lap Belt Guide (RH & LH)

Lap Belt Slot (RH & LH)

Lap Belt Guide Release Button (RH & LH)

E

F

G

H

I

A

B

C

D

76

Safety Instructions Safety Instructions

yy Always give preference to using the rear

seats of your vehicle even if your highway
code permits the use on the front seat.

yy Check your highway code as this regulation

may vary according to the country.

yy Check the vehicle manual for advice on

tting your car seat in the front of
the vehicle.

yy Airbags can cause injury. Do not use this

seat on passenger seats tted with a

frontal airbag.

yy Your mifold Grab-and-Go booster seat

must be positioned and installed so that,
under normal vehicle usage conditions,
no part can become jammed under or
between any moveable seat, or in the
vehicle door.

yy Make sure there is no loose luggage or

other large objects that are likely to cause
injuries in the event of an accident. These
items may cause injury to other occupants.
Always secure loose items.

yy Shade your booster seat from sunlight to

avoid hot items causing injury to your child.

yy Do not modify or add to your car seat in

any way without the approval of a
competent authority or the manufacturer,
as this will void any warranty.

yy Toxic cleaning uids can cause illness.

Never use bleach, do not iron, do not
machine wash and do not tumble dry as
this could damage the product.

yy Do not leave your child unattended while in

the booster seat and in the vehicle.

yy Always replace the booster seat after any

accident in case of any unseen damage.

yy Store your booster seat in a safe area when

your child is not in the car seat.
An unsecured booster seat can cause
injuries in the event of a collision.

yy If you are in any doubt about any part

of the installation or proper use of your
booster seat, contact the booster seat
manufacturer.

yy Failure to follow these instructions may

affect your child’s safety.

yy Keep these instructions with the booster

seat to refer to for future reference.

98

The seat can be used for a child approximately
4 years to 12 years, weighing 15kg – 36kg,
securing the child with the adult 3 point seat belt
approved to ECE R16.

Note: Your car seat is designed to t only with a
3 point lap and diagonal seat belt
and must not at any time be tted using only a
2 point lap belt.

Install your booster seat

Prepare Your

Booster Seat

Open the booster seat and fold out the upper body.

To unlock the lap belt guides, slide the Lap
Belt Guide Release button forward.
To lock the guides, release the Lap Belt
Guide Release button.

NO

2

1

1110

Extract the lap belt guides and position
according to the chart.

To access the
shoulder belt guide
strap, pull open the
shoulder belt guide
buckle.

To shorten or lengthen
the shoulder belt guide
pull the strap in the
desired direction.

4 5

3

Ensure that the shoulder belt guide
is positioned above and centred on
your child’s shoulder.

6 6a

1312

Extract the vehicle seat belt and pass it
across the front of your child. Slide lap belt
portion of vehicle seat belt through both lap
belt guides and connect the seat belt tongue
into the vehicle buckle.

Position your child sitting upright on the
booster seat and if necessary, slide lap belt
guides into the position nearest to, but not
touching the child’s thigh. Pull out on lap belt
guides to check they are locked into position.

8 8a

9

Install Your

Booster Seat

Ensure that the booster seat is laid at and up

against the back rest of the vehicle seat.

7 7a

1514

Ensure that the lap portion of the vehicle seat
belt has passed through the lap belt slots on
both sides of the booster seat.

12

Insert the lap portion only of the vehicle seat
belt through the red belt guides on each side of
the booster.

WARNING! If the vehicle seat belt

tongue is up against the red lap
belt guide such that you cannot
tighten the seat belt, this condition
is unacceptable. You must use a
different seat position.

11

To position the shoulder belt guide, attach the
shoulder belt guide to the diagonal portion of
the vehicle seat belt, by opening the clip and
inserting the seat belt. Then close the clip.

10 10a

1716

Final checklist

However safe a child seat is, however well
built it is, your child’s safety depends on you
carrying out the following checks before every
journey:

yy Check that the booster seat is facing

forwards in the vehicle and in the direction
of travel.

yy Check that the vehicle seat belt is tted

correctly with the shoulder belt engaged
with the shoulder belt guide, the lap strap
is attached to the red lap belt guides, and the
tongue is connected to the buckle.

yy Check that the vehicle seat belt is not

twisted or slack

IMPORTANT! Misusing your child seat

will reduce the protection and safety
you offer your child.

Remove any twists or seat belt slack by
pulling on the lap portion and then the
diagonal portion of the adult seat belt.
Ensure that the lap portion is positioned
over the child’s lap and supported on the
child’s pelvis.

13

1918

Additional information

This booster seat is not approved for use on
aircraft. For more information, contact the
airline.

To dispose of your booster seat safely always
render the seat unusable.

IMPORTANT! Make sure the

instruction book is removed from the
slot before cleaning.

Toxic cleaning uids can cause illness.
Never use bleach, do not iron, do not machine
wash, do not tumble dry as this could
damage the cover and require replacing.

Safety Warning

Notice

This booster seat is a “Universal” child restraint
system. It has been approved in accordance
with regulation ECE R44/04, and is suitable for
general use in vehicles, and is compatible with
the majority of vehicle seats.

yy This child restraint is likely to t if the

vehicle manufacturer states that the

vehicle approval species suitability for

“Universal” child restraint systems.

yy This restraint system is classied as

“Universal” in accordance with the strictest
approval criteria, whereas earlier models
do not correspond to these new provisions.

yy This restraint system can only be installed

in vehicles with 3-point static or retractable
seat belts that have been approved
compliant with the UN/ECE No.16 or other
equivalent standards.

If in doubt, contact the manufacturer of the
restraint system.

Maintenance advice

The booster seat cover is not removable. In case
of light staining, clean using a damp cloth
or soapy water.

Distributed in the U.K. by:

Whitestep Ltd.

www.whitestep.co.uk

[e-mail]

Tel: [phone]

1021, Rev D

[e-mail]

@mifoldBooster

www.mifold.com/contact

pinterest.com/mifold

facebook.com/mifold

instagram.com/mifold

the Grab-and-Go Booster

®

Manufactured by:

carFoldio Ltd.

Unit 2407, PO Box 6945

London, W1A 6US, England, U.K.

Tel: [phone] (from within the U.K.)

Tel: [phone] (International)
