Fully Integrated
36” MasterCool
All Refrigerator:
K 2901 Vi / K 2911 Vi
All Freezer:
F 2901 Vi / F 2911 Vi
Bottom Mount:
KF 2901 Vi / KF 2911 Vi
French Door:
KF 2981 Vi
Shown: KF 2981 Vi
8mieleusa.comInfo subject to change Miele Help Desk (P): (800) 999-1360
Page 2
Fully Integrated
36” MasterCool
SPECIFICATIONS
3
Overall Unit Dimensions 35
Niche
Minimum Cabinet Niche Opening 36” (915 mm) W* x 84” - 85
Electrical
Electrical Requirements
Power Cord NEMA 5-15 plug, 5 ft (1.52 m)
Plumbing K 29x1 Vi F 29x1 Vi KF 29x1 Vi
Water Supply Requirements -
Water Connection Line
Shipping
Shipping Weight 435 lbs (197 kg) 462 lbs (210 kg) 507 lbs (230 kg)
Shipping Dimensions 40” (1016 mm) W x 89
Please note the following:
• This specication sheet is for a single built-in unit.
• When combining multiple MasterCool units side-by-side, please refer to the Merging Kit specication sheet.
*If design calls for a partition less than 6 5/16” (160 mm) the left unit’s cutout will require an additional 1/8” (3 mm) to the width to allow installation of
the Heating Mat/Merge Kit.
/4” (908 mm) W x 833/4”- 853/16” (2127 - 2164 mm) H x 24” (610 mm) D [Depth does not include door panel]
3
/16” (2134 - 2164 mm) H x 243/4” (629 mm) D
K 29x1 Vi F 29x1 Vi KF 29x1 Vi
110V / 120V, 60Hz, 15 Amps
In the case of side-by-side installations, a separate outlet must be used for each appliance.
Connect to a cold water supply only. Do not connect to a low-mineral or
a reverse osmosis system. Must be connected to a shut-off valve. The
water shut-off valve must be accessible after installation. The water pressure must be between 29 psi (2 bar) and 116 psi (8 bar). If the pressure is
higher than 120 psi (8.3 bar), a pressure reducing valve must be installed.
-
Standard 1/4” O.D flexible water line. Water line is not included.
K 29x1 Vi F 29x1 Vi KF 29x1 Vi
13
/16” (1,294 mm) H x 291/4” (800 mm) D
K 2901 Vi (Right Hinged)
Material# 10744550
K 2911 Vi (Left Hinged)
Material# 10744600
F 2901 Vi (Right Hinged)
Material# 10744940
F 2911 Vi (Left Hinged)
Material# 10745030
KF 2901 Vi (Right Hinged)
Material# 10745810
KF 2911 Vi (Left Hinged)
Material# 10745830
KF 2981 Vi (French Door)
Material# 10745930
Page 2 of 7
Page 3
CUTOUT DIMENSIONS
• Niche depth assumes a 3/4” (19 mm) panel, please
adjust according to custom panel thickness
Fully Integrated
36” MasterCool
CUTOUT DETAILS
• The electrical connection must not be positioned higher
than 9” (228.6 mm) above the oor.
For All Freezers and Bottom Mount units only:
• The 1/4” (6.4 mm) plumbed water connection should
not be positioned higher than 2” (50.8 mm) above the
oor.
Notes:
In case of an emergency the electrical outlet and water
shutoff must be easily accessible and must not be concealed behind the appliance.
Page 3 of 7
Page 4
ELECTRICAL AND WATER CONNECTION
(Water Connection For F 29x1 Vi & KF 29x1 Vi Only)
Rear View
Water Connection:
• 1/4” water line is required
• Located at the rear of the appliance on a 4’ 11” line.
• 1/4” compression fitting, ready to accept 1/4” line.
Fully Integrated
36” MasterCool
Side View
Notes:
• In case of an emergency the electrical outlet and water
shutoff must be easily accessible and must not be
concealed behind the appliance.
• In the event that connection points are located behind the
unit the electrical outlet and water connection should be
located no higher than 9 5/8” from the oor.
Page 4 of 7
Page 5
Width: 29 3/4" in all cases
Thickness: Minimum 3/4" outside frame
Height: Determined using the following calculation:
Panel Height = HOC - TKH
HOC = Total height of cabinet or side panel
TKH = Toe-kick height
Note: Finish back side of panels to insure appearance
Panel may extend above unit. This is not
considered in height calculation
Maximum panel weight: 105.8 Pounds
Miele
Fully Integrated
Freezer
TKH
HOC
Panel Height
These units do not come equipped with a front panel. They are designed to accept a custom door panel supplied by
the cabinet maker. Miele has a unique panel integration system which allows the panels to align with the surrounding
cabinets.
Panel size is determined in the following manner:
Panel Notes
If
Simply
Fully Integrated
36” MasterCool
CUSTOM PANEL DETAILS
For Models:
• F 2901 Vi • F 2911 Vi
• K 2901 Vi • K 2911 Vi
For Models:
• KF 2901 Vi • KF 2911 Vi
For Models:
• KF 2981 Vi
Max. Panel Weight:
F 29x1 Vi - 68;bs
K 29x1 Vi - 106 lbs
Optional Accessory:
Clean Touch Steel Panel:
• KFP 3605
Material# 11499100
Max. Top Panel Weight:86 lbs
Max. Bottom Panel Weight: 19 lbs
Optional Accessory:
Clean Touch Steel Panel:
• KFP 3615 - Top Panel
Material# 11499140
• KFP 3625 - Bottom Panel
Material# 11499150
Max. Top Panel Weight (x2):150 lbs
Max. Bottom Panel Weight: 19 lbs
Optional Accessory:
Clean Touch Steel Panel:
• KFP 3635 - Top Panel
Material# 11499420
• KFP 3625 - Bottom Panel
Material# 11499150
the adjoining cabinets are taller than the height of machine (HOM) - the front panel may be extended accordingly.
maintain the toekick height and extend the panel the needed distance.
Adjoining cabinet
Extended Panel
Machine
Page 5 of 7
Page 6
HINGING DETAILS 115° OPENING
0-3/4"
1"
1-1/4"
1-1/2"
0-1/8"
F
ro
nt
Pa
n
el
0-3/4"
1-1/4"
1-1/2"
1-3/4"
1"
Cabinet Front
rooD °511rooD °09
snoitpo ssenkcihTsnoitpo ssenkcihT
Available for the following models:
• K 29x1 Vi
• F 29x1 Vi
• KF 29x1 Vi
1-1/4” (32 mm)
1-1/2” (38 mm)
1-3/4” (44 mm)
0-3/4” (19 mm)
1” (25 mm)
Fully Integrated
36” MasterCool
0-3/4” (19 mm)
2-5/8”
(67mm)
2-5/8”
(67mm)
2-1/3” (59mm)
2-1/3” (59mm)
2-1/24”(52mm)
2-1/24”(52mm)
1-3/8”(35mm)
1-3/8”(35mm)
1-1/6”
1-1/6”
17/24” (18mm)
17/24” (18mm)
(29.6mm)
(29.6mm)
1/4”(6.4mm)
1/4”(6.4mm)
1-3/4”(44.5mm)
1-3/4”(44.5mm)
3”(76.2mm)
3”(76.2mm)
0-1/8” (3 mm)
Top View)
(K29x1Vi, F29x1Vi, KF29x1Vi)
1-1/2” (38 mm)
1” (25 mm)
1-1/4” (32 mm)
Top View
(KF2981Vi)
Page 6 of 7
Page 7
HINGING DETAILS 90° OPENING
0-1/8"
Front Panel
1"
1-1/4"
1-1/2"
0-3/4"
0-3/4"
1-1/4"
1-1/2"
1-3/4"
2"
1"
Cabinet Front
0-3/4"
1"
1-1/4"
1-1/2"
F
ro
nt
Pa
n
el
0-3/4"
1-1/4"
1-1/2"
1-3/4"
1"
Cabinet Front
snoitpo ssenkcihTsnoitpo ssenkcihT
0-3/4"
1"
1-1/4"
1-1/2"
0-1/8"
F
ro
nt
Pa
n
el
0-3/4"
1-1/4"
1-1/2"
1-3/4"
1"
Cabinet Front
rooD °511rooD °09
snoitpo ssenkcihTsnoitpo ssenkcihT
Door Swing
14 3/8"
MAX
NOTE: Additional space needed depending on the thickness
of front panels and handle used.
Freezer units cannot be stop pinned at 90°
Available for the following models:
• K 29x1 Vi
• KF 29x1 Vi
2” (51 mm)
1-1/4” (32 mm)
1-3/4” (44 mm)
1-1/2” (38 mm)
0-3/4” (19 mm)
1” (25 mm)
Fully Integrated
36” MasterCool
7/16”
(11 mm)
1-3/16”
(30mm)
1-7/16”
(36.5mm)
1-11/16”
(43mm)
1-15/16”
(49.2mm)
0-1/8” (3 mm)
Top View
(K29x1Vi, KF29x1Vi)
Handle or object that is
NOT ush with Cabinet
Front.
0-3/4” (19 mm)
1” (25 mm)
1-1/4” (32 mm)
1-1/2” (38 mm)
Top View
(KF2981Vi)
Specification Sheets TRS 03242020
Page 7 of 7
