Always read the operating instructions and the installation sheet
before setting up, installing, and commissioning the appliance. This
prevents both personal injury and damage to the machine.
en-CAM.-Nr. 11 859 130HG07
Contents
Warnings and safety instructions ....................................................................5
Guide to the appliance...................................................................................... 14
This dishwasher complies with all current local and national safety
requirements. Inappropriate use can, however, lead to personal
injury and material damage.
Please observe the installation sheet and read the operating
instructions carefully before setting up the dishwasher and using it
for the first time. They both contain important information on the
installation, safety, use, and maintenance of the machine. This
prevents both personal injury and damage to the dishwasher.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
section on installing the dishwasher as well as the safety
instructions and warnings.
Miele cannot be held liable for injury or damage caused by noncompliance with these instructions.
Keep the installation sheet and the operating instructions in a safe
place and pass them on to any future owner.
5
Warnings and safety instructions
Correct application
This dishwasher is intended for use in domestic households and
similar residential environments.
This dishwasher is not suitable for outdoor use.
This dishwasher is intended for use at altitudes of up to 4,000m
above sea level.
This dishwasher must only be used for cleaning domestic
dishware and cutlery. All other types of use are not permitted.
This dishwasher is not intended for use by people with reduced
physical, sensory, or mental capabilities or lack of experience and
knowledge, unless they have been given supervision and instruction
concerning its use by a person responsible for their safety. They may
only use the dishwasher without supervision if they have been
shown how to use it in a safe manner. They must be able to
recognize and understand the possible consequences of incorrect
operation.
6
Warnings and safety instructions
Safety with children
Children under 8 years of age must be kept away from the
dishwasher unless they are constantly supervised.
Children must not be allowed to clean or maintain the appliance.
Children should be supervised in the vicinity of the dishwasher.
Never allow children to play with the dishwasher. There is a danger
that children might shut themselves in the dishwasher.
If the automatic door opening mechanism is active (depending on
the model), keep young children away from the area in which the
dishwasher door opens. There is a danger of injury in the unlikely
event of a fault with the opening mechanism.
Danger of suffocation. While playing, children may become
entangled in packaging material (such as plastic wrapping) or pull it
over their head, presenting the risk of suffocation. Keep packaging
material away from children.
Keep children away from detergents. Detergents cause severe
skin burns and severe eye damage. They can cause burning in the
mouth and throat, or inhibit breathing. It is therefore important to
keep children away from the dishwasher when the door is open.
Detergent residues could still be present in the machine. Seek
medical advice immediately if a child has swallowed or inhaled any
detergents.
7
Warnings and safety instructions
Technical safety
Unauthorized installation, maintenance, and repairs can cause
considerable danger for the user. Installation, maintenance, and
repairs must only be carried out by a qualified technician.
Damage to the dishwasher can compromise your safety. Before
using the dishwasher and in particular following transport, check it
for any visible damage. Never use a damaged dishwasher.
The electrical safety of the dishwasher can only be guaranteed
when correctly grounded. It is most important that this basic safety
requirement is fulfilled. If in doubt, the electrical installation should
be checked by a qualified electrician.
Miele cannot be held liable for the consequences of an inadequate
or lack of grounding system (e.g., electric shock).
Reliable and safe operation of this dishwasher can only be
assured if it has been connected to the domestic electricity supply.
If the dishwasher is plugged into the domestic electricity supply
using a 3-pin plug with a grounding contact (it must not be hardwired), the electrical socket must be easily accessible after the
dishwasher is installed so that it can be disconnected from the
domestic electricity supply at any time.
There must be no electrical sockets behind the dishwasher
because the building-in niche may be too small. Danger of
overheating and fire risk if the dishwasher were to be pushed up
against a plug.
The dishwasher must not be installed underneath a cooktop. The
high temperatures radiated by cooktops could damage the
dishwasher below. For the same reason, the dishwasher must not be
installed next to open fires or other appliances that give off heat,
such as heaters etc., not normally found in a kitchen.
8
Warnings and safety instructions
Ensure that the connection data on the dishwasher’s data plate
(fuse rating, frequency, and voltage) match the domestic electricity
supply. This data must correspond in order to avoid the risk of
damage to the dishwasher. Compare these before connecting the
appliance to the electricity supply. If in any doubt, consult a qualified
electrician.
Do not connect the dishwasher to the domestic electricity supply
until it has been fully installed and any adjustments have been made
to the door springs.
The dishwasher may only be operated if the door opening
mechanism is working correctly. Otherwise there could be a risk of
danger while the automatic door opening mechanism (depending on
the model) is active.
To check that the door opening mechanism is working correctly:
- The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half
open (approx. 45° opening angle). It is also important that the
door cannot fall open.
- The door locking pins automatically retract when the door opens
at the end of the drying phase.
Multi-socket adapters and extension leads do not guarantee the
required safety of the appliance (risk of fire). Do not connect the
dishwasher to the domestic electricity supply using a power bar or
an extension cord.
The dishwasher must not be used in a non-stationary location
(e.g., on a ship).
Do not install the dishwasher in a room where there is a risk of
frost. Frozen hoses are at risk of tearing or bursting. The reliability of
the electronic control unit may be impaired at temperatures below
freezing point.
To avoid any damage to the dishwasher, it must only be operated
when it is connected to a fully vented plumbing system.
9
Warnings and safety instructions
The water-connection pressure needs to be between 50 and
1,000kPa.
A damaged dishwasher could be dangerous. If the dishwasher
gets damaged, turn it off at the electricity supply immediately and
contact your Miele dealer or Miele Service.
The manufacturer’s warranty will be invalidated if the appliance is
not repaired by a Miele authorized service technician.
We recommend replacing defective components with original
spare parts. If original Miele spare parts are installed correctly, Miele
ensures full compliance with safety requirements and the warranty
remains valid.
During installation, maintenance, and repair work, the dishwasher
must be disconnected from the domestic electricity supply (turn it off
and withdraw the plug from the socket).
If the power cable is damaged, it must only be replaced with a
specific cable of the same type (available from Miele Service). For
safety reasons, this must only be done by Miele Service or a service
technician authorized by Miele.
Do not sit the dishwasher on the hose. The hose needs to be free
of kinks and able to move freely after installation. Do not place the
hose or power cord next to a heat source e.g., hot water pipes. Do
not expose the hose or power cord to corrosive substances (e.g.,
chloride). Damage to the hose or power cord could cause electrical
shock or water damage.
Correct installation
The dishwasher must be installed and connected in compliance
with the supplied installation sheet.
Be careful before and while installing the dishwasher.
Some metal parts pose a risk of injury/being cut. Wear
protective gloves.
10
Warnings and safety instructions
The dishwasher must be correctly aligned horizontally to ensure
problem-free operation.
In order to ensure stability, built-under and integrated dishwashers
must only be installed under a continuous countertop which is
secured to adjacent cabinetry.
The dishwasher must only be built into a tall unit if additional
safety precautions are taken. In order to safely install the appliance
in a tall unit, please use the tall unit installation kit and observe the
installation sheet provided. Otherwise there is the danger of the unit
tipping over.
The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half
open (approx. 45° opening angle). It is also important that the door
cannot fall open.
The appliance must only be operated with properly adjusted door
springs.
If the door cannot be adjusted properly, contact Miele Service.
The maximum weight of the front panel that can be aligned with the
factory fitted door springs is 10–12kg (depending on model).
Correct use
Do not use solvents in the wash cabinet. There is a danger of
explosion.
Dishwasher detergents can cause burning on the skin and in the
eyes, nose, mouth, and throat. Avoid contact with detergents. Do not
inhale powder detergents. Do not swallow dishwasher detergents.
Seek medical attention immediately if detergent has been swallowed
or inhaled.
Avoid leaving the dishwasher door open unnecessarily. You could
injure yourself on the opened door or trip over it.
Do not sit, stand, or lean on the opened door. The dishwasher
could tip over. This could injure you or damage the dishwasher.
11
Warnings and safety instructions
Dishware may be very hot at the end of the program. Allow
dishware to cool until it is comfortable enough to handle before
unloading them.
Only use detergent and rinse aid formulated for domestic
dishwashers. Do not use liquid dish soap.
Do not use any commercial or industrial detergents. These may
cause material damage, and there is a risk of a severe explosive
chemical reaction (such as an explosive oxyhydrogen gas reaction).
Do not fill the rinse aid reservoir with powder or liquid detergent.
This will cause damage to the rinse aid reservoir.
Do not fill the AutoDos (depending on model) with powder or
liquid detergent. Loose detergent will damage the AutoDos.
Do not fill the salt reservoir with powder or liquid detergent.
Dishwasher detergent will damage the water softener.
Use only special, coarse-grained reactivation salt or other pure
evaporated salt. Other types of salt may contain insoluble
components which can cause the water softener to malfunction.
In dishwashers with a cutlery basket (depending on model), knives
and forks should be placed with the handles upwards in the basket
for safety reasons. Knives and forks placed with the handles
downwards pose a danger of injury. However, cutlery placed handle
down in the basket will come out cleaner and drier.
Plastic items which cannot withstand being washed in hot water,
such as disposable plastic containers or plastic cutlery, should not
be cleaned in the dishwasher. The high temperatures in the
dishwasher may cause them to melt or lose shape.
If you use the timer option (depending on model), the detergent
compartment must be dry. Wipe dry with a cloth first if necessary.
The detergent will clump together if the detergent compartment is
not dry, and this may mean that it is not fully rinsed out.
12
Warnings and safety instructions
Accessories and spare parts
Only use original Miele accessories. If other parts are used,
warranty, performance, and, if applicable, product liability claims will
be invalidated.
Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the
discontinuation of your dishwasher.
Transport
Damage to the dishwasher can compromise your safety. Before
using the dishwasher, check it for any visible transport damage.
Never use a damaged dishwasher.
Only transport the dishwasher in an upright position so that no
water flows into the electrical controls, as this would cause faults.
If you wish to transport the dishwasher, empty it and securely
fasten all loose parts such as baskets, hoses, and power cables.
Disposal of your old dishwasher
Remove the door of the dishwasher so that children cannot
become trapped inside.
13
Guide to the appliance
Machine overview
a
Door locking pins
b
Top spray arm
c
3D MultiFlex Cutlery Tray (depending
on model)
d
Upper basket (depending on model)
e
Middle spray arm
f
Aeration valve
g
Lower spray arm
h
Filter combination
i
Salt reservoir
14
j
Data plate
k
Rinse aid reservoir
l
Detergent compartment
m
Door locking pins
n
Top spray arm
o
3D MultiFlex Cutlery Tray (depending
on model)
p
Upper basket (depending on model)
q
Middle spray arm
r
Aeration valve
s
Lower spray arm
t
Filter combination
u
Salt reservoir
v
Data plate
w
Rinse aid reservoir
x
Detergent compartment
Guide to the appliance
15
Guide to the appliance
Control panel
y
Program selection
Normal = Normal
Pots= Pots & pans
Crystal = China & crystal
Quick= QuickIntenseWash
Sani= SaniWash
More= Additional
programs/settings
z
Display
For further information, see “Display
functions” under “Guide to the
appliance”.
{
Start button with indicator light
For starting the selected program.
|
IntenseZone button
For increasing the cleaning
performance in the lower basket.
}
Express button
For reducing the program cycle time.
~
Timer button
For selecting a later program start.
OKbutton
For selecting menu options and
values displayed.
For confirming messages.
buttons
For program selection.
For changing the values displayed.
For scrolling to other menu pages.
Backbutton
For navigating back to the previous
menu or deleting values which have
been set previously.
Program program selection button
For program selection.
Optical interface
For Miele Service.
On/Off button
For turning the dishwasher on and
off.
m
Program selection
Normal = Normal
Pots= Pots & pans
Crystal = China & crystal
Quick= QuickIntenseWash
Sani= SaniWash
More= Additional
programs/settings
16
Guide to the appliance
n
Display
For further information, see “Display
functions” under “Guide to the
appliance”.
p
IntenseZone button
For increasing the cleaning
performance in the lower basket.
s
OKbutton
For selecting menu options and
values displayed.
For confirming messages.
t
buttons
For program selection.
For changing the values displayed.
For scrolling to other menu pages.
u
Backbutton
For navigating back to the previous
menu or deleting values which have
been set previously.
v
Program program selection button
For program selection.
17
Guide to the appliance
Display functions
The display is used to select or set the
following:
- the program
- the timer
- theSettings
The display can show the following:
- the program stage
- the estimated time left for the
program to run
- any relevant fault messages and
information
To save energy, the dishwasher
switches off after a few minutes if you
do not press any buttons during this
time.
Press the button to switch the
dishwasher back on.
The OKbutton is used to confirm a
message or setting and also to move to
the next menu or another menu level.
Under More, a scroll bar will
appear in the right of the display. This
offers further options. These options
can be shown using the buttons.
You can alter the dishwasher’s controls
to suit changing requirements in the
Settings menu (see “Settings”).
The option which is selected will have a
check next to it.
To exit a sub-menu again, press the
Backbutton.
If you do not press any buttons for
several seconds, the display will revert
to the previous menu level. You will then
have to enter your settings again.
These operating instructions apply to
several different dishwasher models of
different heights.
The different dishwasher models will
be named as follows:
normal = dishwasher measuring
80.5cm high (built-in appliance)
or 84.5cm high (freestanding
appliance)
XXL = dishwasher measuring 84.5cm
high (built-in appliance).
18
Caring for the environment
Disposal of the packaging
material
The cardboard box and packaging
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also the
amount of waste.
Disposal of your old appliance
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials,
compounds and components which
were essential for the proper
functioning and safe use of the
equipment. These could be hazardous
to your health and to the environment if
disposed of with general waste or if
handled incorrectly. Therefore, please
do not dispose of your old appliance
with general waste.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please
ensure that your old appliance is kept
away from children until removal.
Observe safety requirements for
appliances that may tip over or pose an
entrapment hazard.
19
Initial commissioning
Every dishwasher is tested at the
factory. There will be residual water in
the machine from this test. It is not an
indication that the dishwasher has
been used previously.
Opening the door
In some programs the door
automatically opens slightly to assist
the drying process.
This function can be deactivated, if
preferred (see “AutoOpen” under
“Settings”).
At the end of the program, if the
AutoOpen function is on, the door
locking pins automatically retract.
To prevent a technical fault, do not
hold the door locking pins firmly
when they are retracting.
If the door is opened during operation,
all functions are automatically
interrupted.
Risk of scalding due to hot
water.
During operation, water in the
dishwasher may be very hot.
During operation, only open the door
with extreme caution.
Risk of injury due to door
opening automatically.
The door may open automatically at
the end of a program.
Keep the area around the door free
of obstructions.
To open the door, reach under the
recessed grip and pull the handle.
Open the door fully to disengage the
locking mechanism.
20
Initial commissioning
Closing the door
Push the baskets in.
Raise the door upward until the catch
engages.
Risk of crushing due to the door
closing.
When closing the door, you are at
risk of shutting your fingers in it.
Do not put your hand inside the door
as it is closing.
Activating the child lock
Use the child lock to prevent children
opening the dishwasher door. The door
can then only be opened by using a lot
of force.
To lock the door, push the slide
underneath the door grip to the right.
To unlock the door, push the slide to
the left.
21
Initial commissioning
Basic settings
Switching on the dishwasher
Switch the dishwasher on with the
button.
The welcome screen will appear when
the dishwasher is turned on.
For further information about the
display functionality, see “Display
functions” under “Guide to the
appliance”.
Setting the language
The display will change automatically to
the screen for setting the language.
Select the language you want as well
as the country, if applicable, using
the buttons and confirm with OK.
For further information on setting the
language, see “Language” under
“Settings”.
A check will appear next to the
language that has been set.
Setting the water hardness
The display changes to the screen for
setting the water hardness.
- You should program the dishwasher
to the correct water hardness for your
area.
- Your local water authority will be able
to advise you of the water hardness
level in your area.
- Where the water hardness fluctuates,
e.g., between 10–16gr/gal (10–
15°dH), always program the
dishwasher to the higher value (16gr/
gal (15°dH) in this example).
It is useful to know your water hardness
so that you can provide the service
technician with this information in the
event of any service calls.
Enter the water hardness below:
____________gr/gal (°dH)
The dishwasher is programmed at the
factory for a water hardness level 1gr/
gal (1°dH).
22
Set the water hardness level in your
area and confirm with OK.
See “Water hardness” under
“Settings” for more information.
Initial commissioning
Finally, prompts will appear in the
display.
After confirming these prompts with
OK, the messages Refill salt and
Refill rinse aid may appear.
Add salt and rinse aid if necessary
(see “Reactivation salt” and “Rinse
aid” under “Initial commissioning”).
Select OK to confirm the messages.
The program selected will appear in the
display briefly and the indicator light for
the program selected will come on.
The display will then show the
estimated program cycle time for the
program selected.
23
Initial commissioning
Reactivation salt
In order to achieve good cleaning
results, the dishwasher needs to
operate with soft water. Hard water
results in a build-up of calcium deposits
on dishware and in the dishwasher.
Domestic water with a hardness level
higher than 5gr/gal (5°dH) must be
softened. This occurs automatically in
the integrated water softener. The water
softener is suitable for a water hardness
level of up to 73gr/gal (70°dH).
In order to be reactivated, the water
softener requires reactivation salt.
Depending on the water hardness level
(<22gr/gal, or <21°dH), reactivation
salt may not be required if combination
detergents are being used (see “Active
ingredients” under “Detergents”).
If the water in your area is very soft
and constantly lower than 5gr/gal(5°dH), you do not need to add
reactivation salt. The salt refill
indicator will automatically turn off
after the water hardness has been set
accordingly (see “Water hardness”
under “Settings”).
Damage to the water softener
from detergent.
Dishwasher detergent will damage
the water softener.
Do not fill the salt reservoir with
powder or liquid detergent.
Damage caused by using
unsuitable salts.
Some types of salt may contain
insoluble components which can
cause the water softener to
malfunction.
Use only special, coarse-grained
reactivation salt or other pure
evaporated salt.
24
If you only ever use combination
detergent products in your
dishwasher, you can turn off both refill
reminders if you wish (see “Refill
reminders” under “Settings”).
Please make sure that if you stop
using combination detergents, you
refill the reactivation salt and rinse
aid. Turn the refill reminders back on
if required.
Filling the salt reservoir
Before filling the salt reservoir for the
first time, you must fill it with approx.
2l of water to enable the salt to
dissolve.
Once the dishwasher has been used
once, there is always sufficient water
in the salt reservoir.
Remove the lower basket from the
wash cabinet and unscrew the salt
reservoir cap.
Initial commissioning
Danger of corrosion due to saline
solution.
Water or saline solution will run out
of the salt reservoir when the cap is
opened. Salt solution that runs out
can cause corrosion in the wash
cabinet and to the wash items.
The cap should therefore only be
removed in order to refill the salt
reservoir.
Fill the salt reservoir with approx. 2l
of water (first use only).
Place the funnel provided over the
salt reservoir and carefully fill with
reactivation salt until the reservoir is
full. The salt reservoir holds up to
2kg of salt, depending on the type of
salt used.
Clean off salt residues from around
the salt reservoir opening. Next,
screw the salt reservoir cap on again
firmly.
Immediately after filling the salt
reservoir and each time you remove
the salt reservoir cap, run the
65°C QuickIntenseWash program
with the Express program option
selected without wash items in the
dishwasher to dissolve and remove
any traces of salt from the wash
cabinet.
25
Initial commissioning
Refilling the salt
Fill the salt reservoir with reactivation
salt when Refill salt appears in the
display.
Confirm with OK.
The salt refill indicator will go out.
Danger of corrosion due to saline
solution.
Salt solution that runs out can cause
corrosion in the wash cabinet and to
the wash items.
Each time you remove the salt
reservoir cap, you must run the
65°C QuickIntenseWash program
with the Express program option
selected without wash items in the
dishwasher. This will dissolve and
remove any traces of salt from the
wash cabinet.
After the salt reservoir has been filled,
the refill indicator may still appear in the
display if the salt concentration has not
yet reached the correct level. In this
case, still confirm the message again
with OK.
The salt refill indicator will be turned off
if you have programmed the dishwasher
for a water hardness below 5gr/gal
(5°dH).
26
Initial commissioning
Rinse aid
Rinse aid is necessary to ensure water
does not cling and leave marks on
dishware during the drying phase and
helps dishware dry faster after it has
been washed.
Rinse aid is poured into the container
and the amount set is dispensed
automatically.
Liquid dish soap or detergent
can cause damage.
Liquid dish soap and detergent can
damage the rinse aid reservoir.
Only fill it with rinse aid formulated
for domestic dishwashers.
Alternatively, you could use liquid citric
acid at a concentration of up to 10%.
The resulting rinsing and drying quality
will not, however, be as good as when
rinse aid is used.
Risk of acid damage.
The dishwasher can be damaged by
high concentrations of acid.
Under no circumstances should you
use citric acid with a higher acid
content.
If you only ever wish to use
combination detergent products in
your dishwasher, you do not need to
add rinse aid.
However, for optimum rinsing and
drying results, use dishwasher
detergent and add reactivation salt
and rinse aid separately.
If you only ever use combination
detergent products containing salt and
rinse aid in your dishwasher, you can
turn off both refill reminders if you
wish (see “Refill reminders” under
“Settings”).
Please make sure that if you stop
using combination detergents, you
refill the reactivation salt and rinse
aid. Turn the refill reminders back on
if required.
27
Initial commissioning
Adding rinse aid
Press the yellow button on the lid
of the rinse aid reservoir.
The lid will spring open.
Close the lid firmly until you hear it
click into place. Otherwise, water can
enter the rinse aid reservoir during a
program.
Wipe up any spilled rinse aid. This
prevents over-foaming occurring
during the next program.
You can adjust the rinse aid dosage
for best wash results (see “Rinse aid”
under “Settings”).
Filling the rinse aid reservoir
When Refill rinse aid appears in the
display, the reservoir contains sufficient
rinse aid for 2–3 programs only.
Add rinse aid in plenty of time.
Confirm with OK.
The rinse aid refill indicator will go out.
Fill with rinse aid until the filling level
indicator (arrow) changes to a dark
colour while the door is horizontally
open.
The rinse aid reservoir holds
approximately 110ml.
28
Settings
You can alter the dishwasher’s
controls to suit changing requirements
by adjusting the settings.
The settings can be altered at any
time.
Opening the Settings menu
Switch the dishwasher on with the
button if it is switched off.
Use the Program button to select the
More option.
The first of the additional programs will
appear in the display.
Select the Settings menu option
using the buttons and confirm
with OK.
The first option in the Settings menu will
appear in the display.
For further information about the
display functionality, see “Display
functions” under “Guide to the
appliance”.
Changing settings
Use the buttons to select the
menu option you want to change and
confirm your selection with OK.
Sub-menu options that have already
been selected will have a check
beside them.
Use the buttons to select the
setting you want and confirm with
OK.
To exit a sub-menu again, press the
Backbutton.
The display will revert to the menu level
above.
Closing the Settings menu
Press the Back button.
The display will change to the More
menu.
29
Settings
Language
The display can be set to appear in one
of several different languages.
You can change the language used in
the display and also the country via the
Language sub-menu.
The flag after the word Language
serves as a guide if a language that
you do not understand has been set.
In this case, keep selecting the menu
option that has a flag after it until you
reach the Language sub-menu.
Water hardness
Your dishwasher is fitted with a water
softener.
- You should program the dishwasher
to the correct water hardness for your
area.
- Your local water authority will be able
to advise you of the water hardness
level in your area.
- Where the water hardness fluctuates
(e.g., between 10-16gr/gal or 10–
15°dH), always program the
dishwasher to the higher value (16gr/
gal or 15°dH in this example).
If the water hardness in your area is
available in a unit other than °dH, you
can convert the values as follows:
1°dH = 1.04gr/gal = 0.18mmol =
1.78°fH
°dgr/gal°fHDisplay
1121
2242
3353
4474
5595
66116
77137
88148
99169
10101810
30
Settings
°dgr/gal°fHDisplay
11112011
12132212
13142313
14152514
15162715
16172916
17183117
18193218
19203419
20213620
21223821
22234022
23244123
24254324
25264525
26274726
27284927
28295028
29305229
30315430
31325631
32335832
33345933
34356134
35366335
36386536
37-4539-4766-8037-45
46-5948-6282-10546-59
606310760
61-7064-73109-12561-70
Setting the water hardness
Select the water hardness level in
your area and confirm with OK.
31
Settings
Rinse Aid
You can adjust the rinse aid dosage for
best results.
The rinse aid dosage can be set from 0
to 6ml.
3ml is the factory default setting.
The rinse aid dosage can turn out to be
higher than the set value due to the
automatic adjustment of the program.
If spots appear on dishware:
- Increase the rinse aid dosage.
If clouding or smearing appears on
dishware:
- Decrease the rinse aid dosage.
Display brightness
You can set the display brightness to
one of 7 different levels.
Refill reminders
If you only ever use combination
detergent products or automatic
dispensing using Miele PowerDisks (if
available), you can turn off the refill
reminders for reactivation salt and rinse
aid if you wish.
Please make sure that if you stop
using combination detergents, you
refill the reactivation salt and rinse
aid. Switch the refill reminders back
on.
AutoOpen
In some programs the door
automatically opens slightly to assist
the drying process.
This function can be deactivated if you
wish.
Risk of damage due to steam.
Steam from the dishwasher could
damage the edges of delicate
countertops when you open the door
at the end of the program and the
blower is no longer running.
If you have deactivated the
automatic door opening function but
would still like to open the door at
the end of the program, then make
sure that you open the door fully.
32
Settings
Extra clean
You can choose this function to
increase the cleaning performance of
the programs.
If you activate this function, the
program cycle times and the main wash
temperatures will increase. The water
and energy consumption may increase.
If this function is switched on, it will be
applied to all programs until it is
switched off again.
Extended drying
You can select this function in order to
increase the program drying
performance.
If you activate this function, the
program cycle times and final rinse
temperatures will increase. The energy
consumption may increase.
If this function is switched on, it will be
applied to all programs until it is
switched off again.
2nd interim rinse
You can choose this function to
increase the cleaning performance of
the programs with a second interim
rinse.
When this function is activated, water
consumption may increase.
If this function is switched on, it will be
applied to all programs until it is
switched off again.
Hygiene cycle
If you mainly use low-temperature
programs (< 50°C/122°F), there is a
risk of bacteria and unpleasant odours
building up in the wash cabinet (see
“Hygiene cycle” under “Cleaning and
care”).
If this function is switched on, a
message will be displayed
recommending the use of a hightemperature program after several lowtemperature programs have been run.
33
Settings
Software version
You can display the electronic software
version of your dishwasher electronics
for technical support purposes.
Showroom program
For demonstration purposes only.
The dishwasher is equipped with a
demo mode for showroom use.
Factory default
You can reset all dishwasher settings to
the factory default settings.
Select Reset and confirm with OK.
34
Caring for the environment
Energy-saving dishwashing
This dishwasher is exceptionally
economical in its use of water and
electricity.
For best results, follow these tips:
- Washing in a dishwasher generally
uses less water and energy than
washing by hand.
- There is no need to pre-rinse items
under running water. This would
unnecessarily increase water and
energy consumption.
- Make full use of the baskets without
overloading the dishwasher. This
results in the most economical
dishwashing in terms of energy and
water consumption.
- Choose a program that best suits the
degree of soiling and the type of
dishware being washed (see
“Program overview”).
- Select the Normal program for
energy-saving dishwashing. This
program is the most efficient in terms
of its combined energy and water
consumption for cleaning dishware
with a normal level of soiling.
- You can connect the dishwasher to a
hot water supply. A hot water
connection is particularly suitable
with energy-saving water heating
sources, such as solar energy with a
circulation system.
If the water is heated by electricity,
we would recommend connection to
cold water.
- Follow the detergent manufacturer’s
recommendations on detergent
dosage.
- When using powder or liquid
detergent, you can use 1/3 less
detergent if baskets are only half full.
35
Loading the dishwasher
General information
Remove coarse food residues from
dishware.
There is no need to pre-rinse items
under running water.
Damage can be caused by ash,
sand, wax, lubricating grease, or
paint.
These substances will contaminate
the dishwasher and can then no
longer be removed.
Do not wash items soiled with these
substances in the dishwasher.
Dishware can be loaded anywhere in
the baskets, but the following notes
should be observed:
- Do not place dishware and cutlery
inside other pieces where they may
be concealed.
- Load dishware so that water can
access all surfaces. This ensures that
dishware will be properly cleaned.
- The spray arms must not be blocked
by items which are too tall or hang
through the baskets. Test for free
movement by manually rotating the
spray arms.
- Make sure that small items cannot
fall through the holders in the
baskets.
Small items such as lids should
therefore be placed in the 3D
MultiFlex Tray or cutlery basket
(depending on model).
Some foods such as carrots,
tomatoes, or ketchup may contain
natural dyes. These dyes can
discolour plastic items in the
dishwasher if large quantities of these
foods are in contact with the dishware
inside the machine. The stability of
plastic items is not affected by this
discolouration.
Washing silverware can also cause
plastic items to discolour.
- Make sure that all items are securely
positioned.
- Hollow items such as cups, glasses,
and pots should be placed upside
down in the baskets.
- Tall, narrow, hollow items such as
champagne glasses should be
placed in the centre of the basket
rather than in the corners. This
ensures the hollow items are more
easily accessed by the water jets.
- Wide based items should be placed
at an angle so that water can run off
them freely.
36
Loading the dishwasher
Wash items not suitable for
dishwashers:
- Wooden cutlery and dishware or
items with wooden parts. These may
discolour and fade. The glue used in
these items is not dishwasher-proof
and wooden handles may come
loose after being washed in a
dishwasher.
- Craft items, antiques, valuable vases,
and decorative glassware. Such
items are not suitable for
dishwashers.
- Plastic items that are not heat
resistant. The high temperatures in
the dishwasher may cause them to
melt or lose shape.
- Copper, brass, tin, and aluminum
items. These may discolour or
become dull.
- Colours painted over a glaze. These
may fade after a number of washes.
- Delicate glassware and glassware
containing lead crystal. Clouding may
occur over time.
Silverware
Silverware that has been in contact with
foods containing sulphur can discolour.
These include egg yolk, onions,
mayonnaise, mustard, fish, and
marinades.
Silverware previously cleaned with a
silver polish may still be damp or
spotted at the end of a program, where
water has not run off smoothly.
Damage due to caustic alkaline
detergents.
Aluminum parts (e.g., the grease
filters of ventilation hoods) can be
damaged by caustic alkaline
detergents. In extreme cases, there
is a risk of an explosive chemical
reaction (such as an explosive
oxyhydrogen gas reaction).
Aluminum components must not be
cleaned in the dishwasher with
caustic alkaline commercial or
industrial detergents.
Useful tip: When purchasing new
dishware and cutlery, make sure they
are dishwasher safe if you want to wash
them in the dishwasher.
Glass care
- Clouding may occur on glasses after
frequent washing. When washing
delicate glassware in the dishwasher,
ensure that only a special glass-care
program with very low temperatures
is selected (see “Program overview”).
This will reduce the risk of clouding.
- Purchase glassware that is
dishwasher-safe (e.g., Riedel
glassware).
- Use detergents with glass protective
additives.
Useful tip: Rub the silverware dry with
a cloth.
37
Loading the dishwasher
Loading examples
Loading for 10 standard place settings with cutlery tray
Upper basket
Cutlery tray
Lower basket
38
Loading the dishwasher
Loading for 16 standard place settings with cutlery tray
Upper basket
Cutlery tray
Lower basket
39
Loading the dishwasher
Loading for 10 standard place settings with cutlery basket
Upper basket
Cutlery basket
Lower basket
40
Loading the dishwasher
Loading for 13 standard place settings with cutlery basket
Upper basket
Cutlery basket
Lower basket
41
Loading the dishwasher
Upper basket
Loading the upper basket
Risk of damage due to water
leakage.
If you run the dishwasher without the
upper basket, water can leak out of
the dishwasher.
Only run the dishwasher with the
upper basket in place (except during
the Tall items program, if available).
Use the upper basket for small,
lightweight, and delicate items such
as cups, saucers, glasses, dessert
bowls, etc.
Shallow pans or casserole dishes can
also be placed in the upper basket.
Long items such as soup ladles and
mixing spoons should be placed lying
down across the front of the upper
basket.
Loading the FlexCare cup rack
You can put cups, small bowls, and flat
dishware on the FlexCare cup rack.
Glasses can be arranged along the cup
rack so they sit securely during the
program.
Lower the cup rack to do so.
Raise the cup rack upwards to make
room for tall items.
42
Loading the dishwasher
Adjusting the FlexCare cup rack
You can set the height and depth of the
cup rack at 2different levels so that it
can accommodate larger cups and so
that taller items can be placed
underneath it.
Pull the cup rack upwards and click it
into the desired position (see arrow).
Loading the silicone elements of the
FlexCare cup rack
The silicone elements in the cup rack
are specially designed to hold tall
glasses with long stems securely.
Lower the cup rack and lean the
glasses against the openings.
If you wish you can adjust the left
insert of the 3D MultiFlex Tray to
make space for taller glasses (see
“3D MultiFlex Tray” under “Cutlery”).
43
Loading the dishwasher
Lowering the spikes
On both right-hand rows of spikes, you
can lower every other spike to make it
easier to arrange larger dishware, like
cereal bowls.
Press the yellow lever downward ,
and then lower the dark grey spikes
.
Place the bowls vertically in the row
of spikes.
44
Loading the dishwasher
Adjusting the upper basket
In order to gain more space for taller
items in the lower basket or upper
basket, the upper basket can be
adjusted on 3 levels with 3/4" (2cm)
between each level.
The upper basket can also be set at an
angle so that water can run off freely
from recesses. Make sure, however,
that the basket can slide smoothly in
and out of the wash cabinet.
Pull out the upper basket.
To raise the upper basket:
Lift the basket up until it clicks into
place.
To lower the upper basket:
Pull upwards on the levers at either
side of the upper basket.
Adjust the basket to the desired
height and then push the levers
securely back down into position.
When adjusting the upper basket,
make sure that tall plates in the lower
basket do not block the middle spray
arm.
45
Loading the dishwasher
Lower basket
Loading the lower basket
Place larger and heavier items such
as plates, serving platters,
saucepans, bowls, etc., in the lower
basket.
Glasses, cups, and small plates and
saucers can also be placed in the
lower basket.
Loading the MultiComfort area
The rear section of the lower basket is
used for washing cups, glasses, plates,
pots, and pans.
Place very large plates in the middle
of the lower basket.
Useful tip: When tilted, plates up to
133/4" (35cm) in diameter can be
accommodated.
46
Loading the dishwasher
Lowering the spikes
The rows of spikes at the front are used
for loading plates, soup bowls, platters,
dessert bowls, and saucers.
Both right-hand rows of spikes can be
lowered to make more room for large
items such as pots, pans, and serving
dishes.
Press the yellow lever downward ,
and then lower the spikes .
Loading the FlexCare glass holder
The silicone elements in the glass
holder provide a stable and secure hold
for delicate stemware.
Stemware such as wine glasses,
champagne flutes, and beer glasses
can be leaned against the glass
holder or suspended from it.
The glass holder can be raised to
make more room for tall items.
You can set the glass holder at 2
different heights.
Slide the glass holder to the desired
height until the catches click into
place at the top or the bottom.
47
Loading the dishwasher
Cutlery tray/cutlery basket
(depending on model)
Load the utensils into the 3D
MultiFlex Tray or into the cutlery
basket (depending on the model).
Loading the 3D MultiFlex Tray
To make unloading easier, utensils
should be grouped in zones, one for
knives, one for forks, one for spoons,
etc.
Spoon heads should be placed in
contact with at least one of the serrated
retainers on the base of the cutlery tray
to ensure that water runs off them
freely.
You can push the left insert to the
middle in order to accommodate tall
items and long stemmed glasses in the
upper basket (see “Loading the silicone
elements of the FlexCare cup rack”
under “Upper basket”).
You can put large and long utensils in
the recessed middle part of the tray.
Arrange tall items (such as cake
server) so that they do not block the
upper spray arm.
You can adjust the height of the righthand insert to create more space in the
right-hand part of the tray for larger
utensil items or smaller dishware.
If spoon handles do not fit between
the holders, then lay them the other
way round.
48
Pull the insert inward by the yellow
handle and click it into place in one of
the two positions.
Loading the cutlery basket
The cutlery basket can be placed
anywhere on the front rows of spikes in
the left or right corner of the lower
basket.
To avoid the risk of injury, knives and
forks should be placed with the
handles upward in the cutlery basket.
However, cutlery placed handle down
in the basket will come out cleaner
and drier.
Loading the dishwasher
Install the insert onto the cutlery
basket if required.
Place small utensils in the individual
slots on 3sides of the cutlery basket.
Loading the cutlery insert for the
cutlery basket
Use the insert supplied for heavily
soiled items of cutlery. As this insert
separates the items, they do not
overlap and can be more easily
accessed by the water jets.
Place the items into the insert with
the handles facing downward.
Arrange them evenly along the insert.
49
Detergent
Active ingredients
Damage caused by using
unsuitable detergents.
Detergents that are not suitable for
domestic dishwashers can cause
damage to the dishwasher or to the
wash items.
Only use detergents formulated for
domestic dishwashers.
Modern detergents contain various
active ingredients, the most important
of which are:
- Water softening complexing agents
to prevent calcification.
- Alkalis to aid removal of dried-on
soiling.
- Enzymes to break down starch and
loosen protein.
Most dishwasher detergents are mildly
alkaline and contain enzymes and
oxygen-based bleaching agents.
There are different types of detergent:
- Powder and liquid gel detergents.
These detergents allow you to adjust
the amount dispensed according to
the amount of wash items and the
level of soiling.
- Tab detergents. These are suitable for
most levels of soiling.
As well as the usual detergents,
combination products are also
available.
These contain rinse aid and water
softener (reactivation salt).
Only use these combination detergents
for the water hardness levels
recommended by the manufacturer on
the packaging.
The cleaning and drying performance of
these combination detergents can vary
greatly.
For optimum cleaning and drying
results, use dishwasher detergent and
add salt and rinse aid separately.
50
Detergent
Risk of chemical burns from
detergent.
Dishwasher detergents can cause
burning on the skin and in the eyes,
nose, mouth, and throat.
Avoid contact with detergents.
Do not inhale or ingest powder
detergents. Do not swallow
dishwasher detergents. Seek
medical attention immediately if
detergent has been swallowed or
inhaled.
Keep children away from detergents.
Detergent residues could still be
present in the machine. Keep
children away from the dishwasher
when the door is open. Do not fill the
detergent dispenser until just before
starting the program and activate the
door child lock (depending on
model).
Detergent dispensing
The detergent compartment holds a
maximum of 50ml.
There are marks in the detergent
compartment to aid with dispensing:
20, 30, max. When the door is opened
to a horizontal position, they show the
approximate fill level in ml and the
maximum fill height.
Follow the detergent dosage
recommended by the manufacturer
on the packaging.
Unless directed otherwise, use one
detergent tab or add 20 to 30ml of
detergent to the detergent
compartment, depending on the level
of soiling of the dishware.
If you use less than the recommended
amount of detergent, the dishware may
not get properly clean.
Some tabs may not dissolve completely
when the program QuickIntenseWash is
used.
51
Detergent
Adding detergent
Press the yellow button on the lid
of the detergent compartment.
The lid will spring open.
The lid will also open at the end of a
program.
The detergent must not cause the
detergent-compartment lid to get
stuck. This can prevent the lid from
opening during the program.
Do not overfill the detergent
compartment.
Ensure that the detergent packaging
is properly closed after use. This
prevents the detergent from getting
damp and clumping together.
Add the detergent to the detergent
compartment.
Push the lid shut until you hear it click
into place.
52
You can also apply a small amount of
detergent to the inner panel of the
door in programs that have a prewash stage (see “Program overview”).
Operation
Switching on the dishwasher
Make sure the spray arms can rotate
freely.
Close the door.
Turn on the water supply if it is turned
off.
Press the button.
The program selected will appear in the
display briefly and the indicator light for
the program selected will come on.
Then the display will show the
estimated duration for the selected
program.
The Start indicator light will flash.
Selecting a program
Choose your program according to the
type of load and the degree of soiling.
The different programs and their uses
are described under “Programoverview”.
Use the Program button to select the
program required.
The indicator light next to the program
selected will come on.
Additional programs can be selected
under More.
Use the Program button to select the
More option.
The first of the additional programs will
appear in the display.
Use the buttons in the display to
select the program you want.
You can now select program options
(see “Program options”).
If any program options are selected, the
appropriate indicator lights will also
light up.
53
Operation
Display of program cycle time
The estimated duration of the selected
program appears on the display before
the program begins. During the
program, the time left until the end of
the program is displayed.
The displayed duration may vary for the
same program. It is influenced by, for
example, the temperature of the
incoming water, the reactivation cycle
of the water softener, the detergent
type, the amount of dishware, and how
soiled it is.
Starting a program
The dishwasher can only be started if
the door is closed.
Press the Startbutton.
If necessary, confirm the previously
displayed message with OK.
The program starts.
The Start indicator light will come on.
During the course of the program, you
can use OK to display the name of the
program which is currently running.
Risk of scalding due to hot
water.
During operation, water in the
dishwasher may be very hot.
During operation, only open the door
with extreme caution.
When a program is selected for the first
time, the display will show the average
program cycle time for a cold water
connection.
The program cycle times shown under
“Program overview” refer to standard
test loads and temperatures.
Each time a program is run, the control
module calculates the program cycle
time required depending on the
temperature of the water taken into the
dishwasher and the amount of
dishware.
54
Operation
End of program
The program has ended when the
display shows the message Ready.
In some programs, if the AutoOpen
function is activated, the door will
automatically open slightly (see
“AutoOpen” under “Settings”). This
improves the drying process.
The drying fan may continue to run for
a few minutes at the end of the
program.
Risk of damage due to steam.
Steam from the dishwasher could
damage the edges of delicate
countertops when you open the door
at the end of the program and the
blower is no longer running.
If you have deactivated the
automatic door opening function (see
“AutoOpen” under “Settings”), but
would still like to open the door at
the end of the program, then make
sure that you open the door fully.
Energy management
To save energy, the dishwasher will
switch off automatically 10minutes
after the last time a button is pressed or
after the end of a program.
You can turn the dishwasher back on
again with the button.
The dishwasher will not turn itself off
while a program is running or if there is
a fault.
55
Operation
Turning off the dishwasher
The dishwasher can be turned off at
any time using the button.
Confirm the query Turn appliance off
with OK.
Turning the dishwasher off during a
program stops the program.
You can also do this to stop an ongoing
timer.
Risk of damage from leaking
water.
Leaking water can cause damage.
If the dishwasher is not going to be
used for a longer period of time, e.g.,
during vacations, the water supply
faucet should be turned off.
Unloading the dishwasher
Dishware tends to break and chip more
easily when it is hot. Allow dishware to
cool until it is comfortable enough to
handle before unloading them.
The dishware will cool much faster if
you open the door when the program
has ended.
First unload the lower basket, then
the upper basket, and finally the 3D
MultiFlex Tray (if present).
This will prevent water drops from the
upper basket and 3D MultiFlex Tray
from falling onto the dishware in the
lower basket.
56
Operation
Interrupting a program
A program will be interrupted as soon
as the door is opened.
Close the door and press the Start
button.
The program will continue from the
point at which it was interrupted.
Risk of scalding due to hot
water.
During operation, water in the
dishwasher may be very hot.
During operation, only open the door
with extreme caution.
Cancelling or changing a
program
If a program is cancelled, important
program stages may be missed.
A program should only be cancelled
in the first few minutes.
If a program has already started and
you wish to cancel it, proceed as
follows:
Turn the dishwasher off with the
button.
Confirm the query Turn appliance off
with OK.
If you would like to select another
program:
Switch the dishwasher on again with
the button.
If you have dispensed detergent
manually, check whether the
detergent compartment is still closed.
If the lid is already open, fill it with
detergent again and close the lid.
Select the program you want, and
then start it.
57
Options
Timer
You can set the start time of a program.
The program start time can be delayed
for between 30minutes and 24hours.
With start time delays between
30minutes and 3hours, the delay can
be set in 30minute stages. It is set in
hours for periods longer than this.
During manual detergent dispensing,
the detergent will clump together if
the detergent compartment is not
dry, and this may mean it is not fully
rinsed out.
When using the timer function, make
sure that the detergent compartment
is dry before adding detergent. Wipe
dry with a cloth first, if necessary.
Do not use any liquid detergents.
These can leak out.
Danger to health due to
detergent.
To prevent children coming into
contact with dishwasher detergent:
Do not fill the detergent dispenser
until just before starting the
program, i.e., before you activate
the timer. Use the child lock to
secure the dishwasher door.
Activating the timer
Turn the dishwasher on with the
button.
The Start indicator light will flash.
Select the program you want to use.
Press theTimer button.
The most recently set “Start in” time will
be shown on the display. The Timer
indicator light will light up.
Set the required time after which the
program should start automatically
using the buttons.
Pressing and holding buttons or
will automatically adjust the time.
Confirm with OK.
The Start indicator light will come on.
58
Options
After you have activated the timer, all
the displays will turn off after a few
minutes to save energy.
Press the button to switch the
display back on again for a few
minutes.
The time up until the program starts will
count down in the display in hours for
durations above 10hours, and in
minutes for durations below 10hours.
At the end of the delay period, the
program selected begins automatically.
The time left will appear in the display
and the Timer indicator light will go
out.
Starting a program before the time
for the timer has elapsed:
A program can be started before the
time for the timer has elapsed.
Proceed as follows:
Turn the dishwasher off with the
button.
Turn the dishwasher on again with
the button.
Select the program you want.
Press the Startbutton.
The program starts. The Start indicator
light will come on.
59
Program overview
Program When to useProgram sequence
1
Normal
Pots &
Pans
China
&Crystal
QuickIntenseWa
sh
SaniWash To sanitize dishware, e.g. baby bottles,
Rinse&
Hold
Program for regular use to completely
wash a full load of normally soiled
dishes with the ability to adjust energy
and water consumption based on the
soil load of the dishes.
For heavily soiled dishes and normally
soiled pots,pans and utensils with dried
on residue; use 20% more detergent
than recommended.
For temperature sensitive glassware and
lightly soiled dishes, use 50% detergent
recommended. GlassCare program for
temperature-sensitive glasses and
dishes with light soiling.
“Quick program” for standard dishes
soiling that has not dried on.
cutting boards and preparation dishes.
To rinse dishes when a complete
program is not needed.
Pre-
wash
140–
158/60
–70
75
113/45
-149/65
-118–
149/48
Main
Interim
wash
°F/°C°F/°C
rinse
Final
rinse
133–
149/56
–65
55–70
131–
158/55
–70
140/60
131–
158/55
–65
–70
----
Drying
1
This program is used for energy labeling purposes.
60
Program overview
Consumption
EnergyWater
Cold waterHot waterGallons/LitersCold waterHot water
Values were calculated under standardized testing conditions. In practice there may be
variations to these figures due to variable conditions and data recorded by the sensors.
Durations shown will reflect your household conditions.
Selecting program options will also affect consumption levels and program durations (see
“program options”).
The energy consumption with a hot water supply includes the energy used to heat the
water (exception: EnergySaver, if available).
61
Program options
Selecting program options
You can use program options to adjust
the programs.
To do this, you can select or deselect
the program options before running the
program.
Switch the dishwasher on with the
button.
The Start indicator light will flash.
Select a different program as
required.
Press the button for the program
option you want.
The indicator light for the relevant
button will come on if the program
option is available for the program
selected.
If the program option is not compatible
with the selected program, a message
to this effect will appear in the display.
In this instance, confirm the message
with OK.
Press the Startbutton to start the
program.
The selected program option will remain
active for that particular program until
the setting is changed.
Express
The Express option reduces the
program cycle time.
In order to achieve optimum cleaning
results, the temperature, and therefore
the energy consumption, will increase
with this option.
The time by which the program cycle
time is shortened varies according to
the selected program.
Selecting the Express option may
take precedence over other selected
options.
When used in combination with the
QuickIntenseWash program, the
Express option results in a rinse
designed solely for the purpose of
flushing out the wash cabinet to
remove salt solution that leaked out
after refilling the salt reservoir.
IntenseZone
The IntenseZone program option
increases cleaning performance in the
lower basket.
Energy consumption increases due to
the extended wash duration in the lower
basket and increased temperature.
62
Cleaning and care
Check the condition of your
dishwasher regularly (approx. every
4–6months). This way, faults and
problems can be avoided.
Damage caused by unsuitable
cleaning agents.
All surfaces are susceptible to
scratching. Contact with unsuitable
cleaning agents can alter or
discolour all surfaces.
Only use cleaning agents formulated
for use on the relevant surfaces.
Cleaning the wash cabinet
The wash cabinet is largely selfcleaning, provided that the correct
amount of detergent is always used.
If, despite this, limescale or grease
deposits build up in the cabinet, these
can be removed with a proprietary
dishwasher cleaner (available from
Miele Service or Miele’s online store).
Follow the instructions on the product
packaging.
The frequent use of low-temperature
wash programs (<50°C) increases the
risk of contamination and odours inside
the wash cabinet. Run the Pots & Pans
program once per month to clean the
wash cabinet and prevent odours from
developing.
Clean the filters in the wash cabinet
regularly.
63
Cleaning and care
Hygiene cycle
If you mainly use low-temperature
programs, there is a risk of bacteria and
unpleasant odours building up in the
wash cabinet. If you repeatedly use
low-temperature programs, you should
regularly run a high-temperature
program. This is to prevent the build-up
of residues and odours.
You can activate or deactivate a
Hygiene info message (see “Settings –
Hygiene cycle”).
If you deactivate this message, run the
Intensive75°Cprogram once per month
to clean the wash cabinet and prevent
odours from developing.
Cleaning the door and the door
seal
The door seal and the sides of the
dishwasher door are not accessed and
cleaned by the spray arm jets. As a
result, mould can develop here.
Wipe the door seals regularly with a
damp cloth to remove food deposits.
Wipe off any food or drink residues
which may have dripped onto the
sides of the dishwasher door before
closing it.
Cleaning the control panel
The control panel should only be
wiped with a damp cloth.
64
Cleaning and care
Cleaning the appliance front
Damage due to soiling.
Soiling that is left too long might
become impossible to remove and
could cause the external surfaces to
alter or discolour.
Remove any soiling immediately.
Clean the front with a clean sponge
and a solution of hot water and dish
soap. After cleaning, wipe the front
dry using a soft cloth.
A clean, damp microfibre cloth
without cleaning agent can also be
used for cleaning.
To avoid damage to the outer
surface, do not use:
- cleaning agents containing soda,
ammonia, acid or chloride
- cleaning agents containing lime scale
remover
- abrasive cleaning agents, such as
scouring powder, scouring liquid, or
pumice stones
- cleaning agents containing solvents
- stainless steel cleaning agents
- dishwasher cleaners
- oven cleaners
- glass cleaners
- hard, abrasive brushes or sponges,
e.g., pot scourers, brushes, or
sponges which have been previously
used with abrasive cleaning agents
- eraser sponges
- sharp metal scrapers
- steel wool
- steam cleaners
65
Cleaning and care
Cleaning the spray arms
Particles of food can get stuck in the
spray arm jets and bearings. The spray
arms should therefore be inspected
regularly (approx. every 2–4months).
Never run a wash program without
using the spray arms.
Damage due to soiling entering
the circulation system.
Without filters, soiling can enter the
circulation system and cause a
blockage.
Do not run a wash program without
the lower spray arm or without the
filters.
When cleaning the filters and spray
arms, make sure that coarse soiling
cannot get into the circulation
system.
Turn the dishwasher off.
Removing the cutlery tray (if present)
In order to be able to remove the upper
spray arm, you first have to remove the
cutlery tray (if present).
Pull out the cutlery tray.
Press the rail safety clips on both
sides of the cutlery tray together
and remove the safety clips.
Take out the cutlery tray completely.
66
Cleaning and care
Removing the upper spray arm
Push the upper spray arm upward
to engage the inner ratchet. Then
unscrew the spray arm by rotating the
screw thread anti-clockwise.
Removing the middle spray arm
Removing the lower spray arm
Remove the lower basket.
Rotate the screw thread of the lower
spray arm anti-clockwise and pull
the spray arm upwards to remove.
Cleaning the spray arms
Rotate the screw thread of the middle
spray arm clockwise and remove
the spray arm.
Use a pointed object to push food
particles that are stuck in the spray
arm jets into the spray arm.
Rinse the spray arm thoroughly under
running water.
67
Cleaning and care
Refitting the spray arms
Refit the upper spray arm and tighten
it by hand.
Refit the middle spray arm.
Refit the lower spray arm and ensure
that the filter combination lies flat in
the base of the wash cabinet.
Rotate the screw thread of the lower
spray arm clockwise until the arrow in
the viewing window points to the lock
symbol.
Inserting the cutlery tray (if present)
Slide the cutlery tray back onto the
rails from the front.
Replace the safety clips in the rails on
both sides of the cutlery tray.
Make sure the spray arms can rotate
freely.
Damage due to soiling entering
the circulation system.
The lower spray arm is used to
secure the filter combination.
Without filters, coarse soiling can
enter the circulation system and
cause a blockage.
Do not run a wash program without
the lower spray arm or without the
filters.
68
Cleaning and care
Checking the filters in the
wash cabinet
The filter combination in the base of the
wash cabinet retains coarse soil from
the suds solution. This prevents soiling
getting into the circulation system and
re-entering the wash cabinet through
the spray arms.
Damage due to soiling entering
the circulation system.
Without filters, soiling can enter the
circulation system and cause a
blockage.
Do not run a wash program without
the lower spray arm or without the
filters.
When cleaning the filters and spray
arms, make sure that coarse soiling
cannot get into the circulation
system.
Filters can become blocked by soiling
which collects over time. The level of
soiling and time it takes before the
filters need cleaning will vary depending
on use.
Cleaning the filters
Switch the dishwasher off.
Remove the lower spray arm (see
“Cleaning the spray arms” under
“Cleaning and care”).
Before removing the filter
combination, remove any coarse
soiling to prevent it from entering the
circulation system.
Remove the filter combination.
The message Check filters will appear in
the display after every 50program
sequences.
Check the filter combination.
Clean it, if necessary.
Then confirm the message with OK.
69
Cleaning and care
In order to clean the inside of the
filter, pull the microfilter on the plastic
ring downwards and away from the
filter combination.
Rinse all the filters under running
water.
If necessary, use a soft cleaning
brush to remove soiling.
Insert the microfilter back into the
filter combination.
Replace the filter combination so that
it lies flat in the base of the wash
cabinet.
Refit the lower spray arm to the filter
combination using the screw thread.
Rotate the screw thread clockwise
until the arrow in the viewing window
points to the lock symbol.
Damage due to soiling entering
the circulation system.
The lower spray arm is used to
secure the filter combination.
Without filters, coarse soiling can
enter the circulation system and
cause a blockage.
Do not run a wash program without
the lower spray arm or without the
filters.
70
Cleaning the drain pump
If water remains in the wash cabinet
after the end of a program, the water
has not been pumped away. The drain
pump may be blocked by foreign
objects. These foreign objects are easy
to remove.
Disconnect the dishwasher from the
power supply.
To do this, turn off the dishwasher
and withdraw the plug.
Take the filter combination out of the
wash cabinet (see “Cleaning the
filters” under “Cleaning and care”).
Cleaning and care
Press the catch of the drain pump
cover inwards .
Scoop the water out of the wash
cabinet using a small container.
Tip the cover inwards until it is
released .
Rinse the cover thoroughly under
running water and remove all foreign
objects.
71
Cleaning and care
The drain pump (see arrow) is
underneath the cover.
Risk of injury from glass
splinters.
It is especially difficult to see glass
splinters in the drain pump.
Take care when cleaning the drain
pump.
Damage caused by incorrect
cleaning.
The components are delicate and
can be damaged during cleaning.
Take care when cleaning the drain
pump.
Carefully remove all foreign objects
from the drain pump. Turn the drain
pump impeller by hand to check that
there are no more obstructions. You
will feel a little resistance when you
turn the impeller.
Refit the cover by placing it down
vertically from above.
Ensure that the catch engages
correctly.
72
Frequently Asked Questions
With the help of the following guide, minor faults in the performance of the
machine, some of which may result from incorrect operation, can be remedied
without contacting the Service Department. This will save you time and money
because you won't need a service call.
This guide may help you find the reason for the fault and help you correct it.
This section only lists faults that you can remedy yourself. All other faults are
shown in Fault FXX.
Technical problems
ProblemPossible cause and solution
The display remains
dark and the Start
indicator light is not
flashing after the
dishwasher has been
turned on with the
button.
The dishwasher stops
during a program.
The dishwasher is not plugged in.
Insert the plug.
The circuit breaker has tripped.
Reset the circuit breaker (see data plate for the
minimum fuse rating).
If the circuit breaker trips again, contact Miele
Service.
The circuit breaker has tripped.
Reset the circuit breaker (see data plate for the
minimum fuse rating).
If the circuit breaker trips again, contact Miele
Service.
73
Frequently Asked Questions
Fault messages
ProblemPossible cause and solution
One of the following
fault messages is
displayed:
Fault FXXThere may be a technical fault.
WaterproofThe Waterproof system has reacted.
Fault F78Circulation pump fault.
Before remedying the fault:
Switch the dishwasher off.
Switch the dishwasher back on after a few
seconds.
Restart the desired program.
If the fault message appears again, there is a
technical fault.
Switch the dishwasher off.
Turn off the water supply.
Contact Miele Service.
Switch the dishwasher off.
Turn off the water supply.
Contact Miele Service.
Switch the dishwasher off.
Switch the dishwasher back on.
Restart the desired program.
If the fault message appears again, there is a
technical fault.
Switch the dishwasher off.
Turn off the water supply.
Contact Miele Service.
74
Frequently Asked Questions
Door release
ProblemPossible cause and solution
The following fault is
indicated via the
display:
Door faultThe door does not open automatically.
Before remedying the fault:
Switch the dishwasher off.
There may be a technical fault.
Open the door manually (see “Opening the door”
under “Before using for the first time”) and turn the
dishwasher back on again.
If the same fault message appears again, contact
Miele Service.
The door locking pins do not retract after the door is
opened.
There may be a technical fault.
Turn the dishwasher back on.
If the same fault message appears again, contact
Miele Service.
75
Frequently Asked Questions
Water intake fault
ProblemPossible cause and solution
One of the following
messages appears in
the display:
Open water supplyThe water supply is turned off.
Turn on the water supply fully.
IntakeBefore remedying the fault:
Switch the dishwasher off.
There is a problem with the water intake.
Turn on the water supply fully and start the
program again.
Clean the filter in the water intake (see “Cleaning
the filter in the water intake” under “Cleaning and
care”).
The water connection pressure is lower than
50kPa.
Seek professional advice.
The on-site connection for the water drainage may
be too low and you will need to vent the water
drainage (see “Water drainage” under
“Installation”).
Fault F18A technical fault has occurred.
Switch the dishwasher off.
Turn off the water supply.
Contact Miele Service.
76
Frequently Asked Questions
Water drainage fault
ProblemPossible cause and solution
The following message
appears on the display:
Drain
Before remedying the fault:
Switch the dishwasher off.
Water drainage fault.
There might be water in the wash cabinet.
Clean the filter combination (see “Cleaning the
filters” under “Cleaning and care”).
Clean the drain pump (see “Cleaning the drain
pump” under “Cleaning and care”).
Remove any kink or loop in the drain hose.
77
Frequently Asked Questions
General dishwasher problems
ProblemPossible cause and solution
The indicator lights and
display are dark.
Detergent residue is left
in the detergent
compartment at the end
of a program.
The detergent
compartment lid cannot
be closed.
At the end of a program
there is a film of
moisture on the inside
of the door and possibly
on the interior cabinet
walls.
Water remains in the
wash cabinet at the end
of a program.
The dishwasher has switched off automatically to
save energy.
Switch the dishwasher on again with the button.
The detergent compartment was still damp when
detergent was added.
Only add the detergent when the detergent
compartment is dry.
Residual detergent is blocking the catch.
Remove the residual detergent.
This is part of the normal function of the drying
system. The moisture will dissipate after a short
while.
Before remedying the fault:
Switch the dishwasher off.
The filter combination in the wash cabinet is clogged.
Clean the filter combination (see “Cleaning the
filters” under “Cleaning and care”).
The drain pump is blocked.
Clean the drain pump (see “Cleaning the drain
pump” under “Cleaning and care”).
The drain hose is kinked.
Remove any kinks from the drain hose.
78
Frequently Asked Questions
Noises
ProblemPossible cause and solution
There is a knocking
noise in the wash
cabinet.
There is a rattling noise
in the wash cabinet.
Knocking noise in the
water pipes
A spray arm is hitting the dishware.
Carefully open the door and rearrange the
dishware that is obstructing the spray arm.
Dishware is moving around in the wash cabinet.
Carefully open the door and rearrange the
dishware so that it sits securely.
There is a foreign object (e.g., glass shard) in the
drain pump.
Remove the foreign object from the drain pump
(see “Cleaning the drain pump” under “Cleaning
and care”).
This may be caused by the on-site installation or the
cross-section of the piping.
However, this will not affect the functioning of the
dishwasher in any way. If in doubt, contact a
plumber.
79
Frequently Asked Questions
Poor cleaning results
ProblemPossible cause and solution
The dishware is not
clean.
There are smears on
glassware and cutlery.
There is a bluish sheen
on the surface of
glassware. The film can
be wiped off.
The dishware was not loaded correctly.
See notes under “Loading the dishwasher”.
The program was not powerful enough.
Select a more powerful program (see “Program
overview”).
Activate the Extra clean function (see “Extra clean”
under “Settings”).
Activate the “Second interim rinse” function (see
“Settings – Second interim rinse”).
Not enough detergent was dispensed.
Use more detergent during manual dispensing or
change the detergent you are using.
Increase the dispensing quantity during automatic
dispensing (if available) (see “Settings – AutoDos”).
Items are blocking the path of the spray arms.
Carry out a rotation check and if needed rearrange
the items so that the spray arms can rotate freely.
The filter combination in the wash cabinet is not
clean or was incorrectly fitted.
This may have caused the spray arm jets to become
blocked.
Clean and/or fit the filter combination correctly.
Clean the spray arm jets if necessary (see
“Cleaning the spray arms” under “Cleaning and
care”).
The rinse aid dosage is set too high.
Reduce the dosage (see “Rinse aid” under
“Settings”).
80
Frequently Asked Questions
ProblemPossible cause and solution
The dishware is not dry
or glasses and cutlery
are flecked.
Glassware has a brown
or blue tinge. The film
cannot be wiped off.
Glassware is dull and
discoloured. The film
cannot be wiped off.
Tea or lipstick stains
have not been
completely removed.
The rinse aid dosage is set too low or the rinse aid
reservoir is empty.
Replenish the reservoir, increase the dosage, or
change the brand of rinse aid (see “Rinse aid”
under “Before using for the first time”).
The dishware was taken out of the wash cabinet too
soon.
Leave the dishware in for longer (see “Unloading
the dishwasher” under “Operation”).
The duration of the drying phase for the selected
program is not sufficient for the dishware (particularly
for plastic dishware).
Select the Extra dry function (see “Extra dry” under
“Settings”).
You have used combination products that have
insufficient drying performance.
Switch to another detergent or replenish the rinse
aid (see “Rinse aid” under “Before using for the
first time”).
Ingredients from the detergent have formed a
deposit.
Switch to another detergent straight away.
The glassware is not dishwasher-safe. The surface
has altered.
No remedy.
Purchase glassware which is dishwasher safe.
The wash temperature of the selected program was
too low.
Select a program with a higher wash temperature.
The bleaching effect of the detergent is too low.
Switch to another detergent.
81
Frequently Asked Questions
ProblemPossible cause and solution
Plastic parts are
discoloured.
White residue is visible
on the dishware.
Clouding has occurred
on glassware and
cutlery. The film can be
wiped off.
Natural dyes, e.g., from carrots, tomatoes, or
ketchup may be the cause. The amount of detergent
used or its bleaching effect was not sufficient to deal
with natural dyes.
Use more detergent (see “Detergent”).
Parts that are already discoloured will not revert to
their original colour.
The rinse aid dosage is set too low.
Increase the dosage (see “Rinse aid” under
“Settings”).
The salt reservoir is empty.
Fill the salt reservoir (see “Reactivation salt” under
“Before using for the first time”).
The salt reservoir cap has not been screwed on
correctly.
Replace it, making sure that it screws back on
correctly.
Unsuitable combination detergents were used.
Switch to another detergent. If using detergent
tabs or powder detergent, do not choose
combination products and ensure you refill the
reactivation salt and rinse aid.
The water softener is programmed to too low a water
hardness level.
Program the water softener to a higher water
hardness level (see “Water hardness” under
“Settings”).
Too much detergent was dispensed.
Reduce the dispensing quantity during automatic
dispensing (if available) (see “Settings – AutoDos”).
Activate the “Second interim rinse” function (see
“Settings – Second interim rinse”).
Not enough combination detergent was dispensed.
The water softener performance is not sufficient.
Increase the dispensing quantity during automatic
dispensing (if available) (see “Settings – AutoDos”).
Add more reactivation salt.
82
Frequently Asked Questions
ProblemPossible cause and solution
There are rust stains on
cutlery.
The affected items are not corrosion resistant.
No remedy.
Purchase cutlery which is dishwasher-proof.
A program was not run after reactivation salt was
added. Traces of salt have got into the normal wash
cycle.
Always run the 65°C QuickIntenseWash
program with the Express program option
selected and without any dishware in the
dishwasher after adding reactivation salt.
The salt reservoir cap has not been screwed on
correctly.
Replace it, making sure that it screws back on
correctly.
83
Technical Service
Contact in the event of a fault
In the event of a fault which you cannot
remedy yourself, please contact your
Miele dealer or Miele Service.
Contact information for Miele Service
can be found at the end of this
document.
Please quote the model identifier and
serial number of your appliance (SN)
when contacting Miele Service. This
information can be found on the data
plate.
The data plate is located on the right
side of the door.
Warranty
For further information, please refer to
your warranty booklet.
84
Optional accessories
Dishwasher detergent, rinse aid, and
cleaning and care products are
available for this dishwasher, as are
optional accessories.
All the products have been designed for
Miele appliances.
These and many other useful products
can be ordered directly from Miele’s
online store, Miele Service, or from your
Miele dealer.
Detergents
You have chosen excellent quality and
performance with your Miele
dishwasher. To achieve optimum results
all the time, it is important to use the
right dishwasher detergents. Not all offthe-shelf products deliver the same
results in all dishwashers.
For this reason Miele offers dishwasher
products specifically designed for Miele
appliances.
Detergent tabs
- Sparkling results even with stubborn
food deposits
- Specially designed cap for accurate
and easy dispensing
Reactivation salt
- Prevents limescale on dishware and
in the appliance
- Extra coarse grained
- Combination product with other
functions such as rinse aid, salt, and
glass protection additives
- Phosphate free – kind to the
environment
- Water-soluble wrapping – no need to
unwrap
Rinse aid
- For sparkling glasses
- Helps dishware to dry
- With glass protection formula against
corrosion
85
Optional accessories
Appliance care
Miele cleaning and care products
provide optimum care for your
dishwasher.
Dishwasher cleaner
- For use with the Clean Machine
program without detergent
dispensing
- Cleans the dishwasher effectively
and thoroughly
- Removes grease, bacteria, and
associated unpleasant odours
- Ensures excellent dishwashing
results
Descaling agent
- Removes heavy limescale deposits
- Mild and gentle with natural citric
acid
Dishwasher conditioner
- Removes odours, limescale, and light
deposits
- Maintains the elasticity and leak
tightness of the seals
Dishwasher freshener
- Neutralizes unpleasant odours
- Fresh, pleasant lime and green tea
scent
- Easy and convenient to attach to the
dishwasher basket
- Very economical; lasts for 60 rinses
86
*INSTALLATION*
Installation
Water intake
Danger to health due to wash
water.
Water in the dishwasher must not be
used as drinking water.
Do not drink any water from the
dishwasher.
Health risk and risk of damage
due to contaminated incoming water.
The quality of the incoming water
must correspond to the drinking
water specification of the country in
which the dishwasher is being
operated.
Connect the dishwasher to a drinking
water supply.
The dishwasher may be connected to
cold or hot water (up to max. 65°C)
supplies.
We recommend connecting to a cold
water supply to reduce energy
consumption.
If energy-saving water heating sources,
such as solar energy circulation
systems, are used, we recommend
connecting to the hot water. This saves
both time and electrical energy costs.
Hot water is used in all programs.
The EnergySaver program (if available)
requires a hot water connection of
between a minimum of 45°C and a
maximum of 65°C (intake temperature).
The higher the water intake
temperature, the better the cleaning and
drying results.
The intake hose is approx. 5ft (1.5m)
long. A 5ft (1.5m) long, flexible metal
extension hose (tested to
14,000kPa/140bar) is available as an
optional accessory from Miele specialist
retailers or Miele Service.
87
*INSTALLATION*
Installation
A faucet with a 9/16" male thread must
be provided on site. If this type of
faucet is not available, only a qualified
installer may connect the dishwasher to
the domestic water supply.
A backflow preventer is not required.
The appliance meets the requirements
of the applicable DIN standards.
The water-connection pressure needs
to be between 50 and 1,000kPa. If the
water connection pressure is too high, a
pressure reducing valve must be fitted.
Risk of damage from leaking
water.
The connection point is subject to
water pressure. Water leaking from it
can cause damage.
You should therefore open the faucet
slowly and check for leaks. Correct
the position of the washer and screw
thread if appropriate.
Risk of damage due to excessive
pressure.
A brief increase in the water pressure
can damage components of the
dishwasher.
This dishwasher must only be
operated when it is connected to a
fully primed plumbing system.
Risk of damage from leaking
water.
The intake hose is under water
pressure.
The intake hose must not be
shortened or damaged in any way.
Do not sit the dishwasher on the
hose. The hose needs to be free of
kinks and able to move freely after
installation. Do not place the hose or
power cord next to a heat source
e.g., hot water pipes. Do not expose
the hose or power cord to corrosive
substances (e.g., chloride). Damage
to the hose or power cord could
cause electrical shock or water
damage.
88
*INSTALLATION*
Installation
Water drainage
The appliance drainage system has a
non-return valve, which prevents dirty
water from flowing back into the
dishwasher via the drain hose.
The dishwasher is supplied with approx.
5ft (1.5m) of flexible drain hose with an
internal diameter of 7/8" (22mm).
The hose can be extended using a
connection piece to attach a further
length of hose. The drainage length
must not be longer than 13ft (4m) and
the delivery head must not exceed 3ft
(1m).
If the hose is to be directly connected
to the drainage outlet on site, use the
supplied hose clip (see the installation
diagram).
The hose can be directed to the left or
the right of the appliance.
The on-site connector for the drain hose
can be used for various hose diameters.
If the connector extends too far into the
drain hose, it must be shortened.
Otherwise, the drain hose can become
clogged.
Lay the drain hose so that it does not
kink and is not being subjected to
pressure or tugged.
Risk of damage from leaking
water.
Leaking water can cause damage.
After servicing the appliance, ensure
that the drain does not leak.
The drain hose must not be shortened.
89
*INSTALLATION*
Installation
Venting the water drainage
If the on-site drainage connection is
situated lower than the guide path for
the lower basket rollers in the open
door, the drainage system must be
vented. Otherwise, a siphoning effect
during a program can cause the
appliance to empty itself of water.
Open the dishwasher door fully.
Remove the lower basket.
Insert a screwdriver into the middle
opening of the vent valve in the left
wash cabinet wall .
Press the screwdriver further into the
opening and push it through the
membrane behind.
The vent opening for the water drain is
now open.
90
*INSTALLATION*
Installation
Electrical connection
Installation, repairs and other
work by unqualified persons could
be dangerous.
Check that the voltage, frequency
and fuse rating shown on the data
plate match the household mains
supply.
The power outlet must be accessible
after installation. Do not use an
extension cord to connect the
dishwasher to the mains. Danger of
overheating! See data plate on the
right side of the door.
A damaged power cord must only be
replaced with a genuine Miele cord
by a Miele service technician.
Grounding instructions
THIS APPLIANCE MUST BE
GROUNDED.
In the event of a malfunction or
breakdown, grounding will reduce the
risk of electric shock by providing a
path of least resistance for the electrical
current. This appliance is equipped with
a cord having an equipment grounding
conductor and a grounding plug. The
plug must be plugged into an
appropriate outlet that is installed and
grounded in accordance with all local
codes and ordinances.
Improper connection of the
equipment grounding conductor can
result in electric shock.
Do not modify the plug provided with
the appliance; if it will not fit the
outlet, have a proper outlet installed
by a qualified electrician.
If there is any question concerning
the proper electrical connection or
grounding of this appliance to the
powersupply, please consult a
licensed electrician or call Miele’s
Customer Service Department:
USA: 1-888-99-MIELE(64353)
CDN: 1-800-565-6435
Specifications
The dishwasher comes equipped with a
4ft (1.2m) power cord (measured from
the rear of the dishwasher) with a
molded plug for connection to 120V,
60Hz, 15A grounded receptacle.
91
*INSTALLATION*
Installation
Hardwired electrical connection
It is possible to hardwire this appliance
to an existing power cable.
CAUTION: Before servicing,
disconnect the power supply by
either removing the fuse, shutting off
the power main or manually
“tripping” the circuit breaker.
Installation work and repairs should
only be performed by a qualified
technician in accordance with all
applicable codes and standards.
Repairs and service by unqualified
persons could be dangerous and the
manufacturer cannot be held
responsible.
Before connecting the appliance to
the power supply, make sure that the
voltage and frequency listed on the
data plate correspond with the
household electrical supply. This
data must correspond to prevent
machine damage. Consult an
electrician if in doubt.
Prior to making a hardwire
connection to the terminal, remove
the powercord. Otherwise there will
be a risk of electric shock from the
attached plug.
An existing flexible supply cord or cable
shall have a minimum thickness of
AWG14.
120V, 60Hz, 15A fuse rating
Black wire (live): connect to L
White wire (neutral): connect to N
Green wire (ground): connect to
After attaching the permanent
power supply cord, check that all
wires are correctly and securely
placed in the connector and the
strain relief is tightened.
GROUNDING INSTRUCTIONS
THIS APPLIANCE MUST BE
GROUNDED.
This appliance must be connected to a
grounded metal, permanent wiring
system, or an equipment-grounding
conductor must be run with the circuit
conductors and connected to the
equipment-grounding terminal or lead
on the appliance.
92
Sound emission testing
Prerequisites for sound emission testing
Load the dishwasher with 16 standard place settings and use the Normal
program.
Setup for sound emission testing
The dishwasher must be set up according to the following specifications.
Install the dishwasher into an analyzing unit.
Secure the front panel.
Push the provided fleece strips (depending on model) under the base until it is
flush with the appliance feet.
Push the base into place in such a way that it is flush with the door panel .
93
Sound emission testing
Remove the protective film from the provided insulating strip (depending on
model) .
Stick the insulating strip onto the front top edge of the base board .
94
Importer
Miele Limited
Headquarters and Miele Centre
161 Four Valley Drive
Vaughan, ON L4K 4V8
www.miele.ca
Customer Care Centre
Phone: 800 565-6435
customercare@miele.ca
Miele & Cie. KG
Carl-Miele-Straße 29
33332 Gütersloh
Germany
Manufacturer
Canada
Please have the model and serial number
of your appliance available when
contacting Customer Service.
G7106
M.-Nr. 11 859 130 / 00en-CA
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
