Miele G 6830, G 6835 Operating instructions

Download
Operating Instructions Dishwasher
To prevent accidents and machine damage, read these instructions be­fore installation or use.
en-US M.-Nr. 10 546 860HG05
2
Contents
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 6
Filling the salt reservoir..................................................................................... 25
Salt refill indicator............................................................................................. 26
Adding rinse aid ...............................................................................................27
Rinse aid indicator............................................................................................ 28
Adjusting the upper basket .............................................................................. 38
3D cutlery tray+ (depending on model)............................................................ 44
Cutlery basket (depending on model) .............................................................. 46
3
Contents
4
Contents
Water connection .............................................................................................. 100
Water intake ........................................................................................................ 100
Drainage .............................................................................................................. 101
Sound emission testing ....................................................................................102
5

IMPORTANT SAFETY INSTRUCTIONS

This dishwasher complies with current safety requirements. Inap­propriate use can, however, lead to personal injury and damage to property.
To avoid the risk of accidents and damage to the dishwasher, please read the installation plan and the operating instructions carefully before it is installed and used for the first time. Both con­tain important information on its installation, safety, use and main­tenance.
Keep the installation plan and the operating instructions in a safe place and pass them on to any future owner.
Miele cannot be held liable for damage caused by non-compliance with this information.
6
IMPORTANT SAFETY INSTRUCTIONS

Correct use

This dishwasher is intended for use in domestic households and
similar residential environments.
This dishwasher is not suitable for outdoor use.It must only be used as specified in these operating instructions
for cleaning domestic dishes and cutlery. Any other usage is not supported by the manufacturer and could be dangerous.
This appliance is not intended for use by persons (including chil-
dren) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge.
7
IMPORTANT SAFETY INSTRUCTIONS

Safety with children

Children must be kept away from the appliance unless they are
constantly supervised.
Children should be supervised to ensure that they do not play with
the appliance. Keep small children away from the appliance at all times to avoid the risk of injury. There is the risk that children may lock themselves in the dishwasher.
If the automatic door opening mechanism (depending on model) is
active keep young children away from the area in which the door opens. Danger of injury in the unlikely event of a fault with the open­ing mechanism.
Danger of suffocation! Ensure that any plastic wrappings, bags,
etc. are disposed of safely and kept out of the reach of children.
Keep children away from detergents. Dishwasher detergents can
cause burning in the mouth, nose and throat if swallowed, or inhibit breathing. Keep children away from the dishwasher when the door is open. There could still be detergent residues in the cabinet. Seek medical attention immediately if your child has swallowed or inhaled detergent.
8
IMPORTANT SAFETY INSTRUCTIONS

Technical safety

Installation, repair, and maintenance work should only be per-
formed by a Miele-authorized service technician. Work by unquali­fied persons could be dangerous and may void the warranty.
Before installation, check the dishwasher for visible signs of dam-
age. Under no circumstances should you use a damaged dish­washer. A damaged dishwasher could be dangerous.
The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective grounding system. It is most important that this basic safety requirement is present and regularly tested and, where there is any doubt, the elec­trical system in the house should be checked by a qualified electri­cian. Miele cannot be held liable for the consequences of an inadequate grounding system (e.g. electric shock).
Reliable and safe operation of this dishwasher can only be as-
sured if it has been connected to the electrical supply.
If the dishwasher is plugged into the electricity supply using a 3-
pin plug with a grounding contact (it must not be hard-wired), the electrical socket must be easily accessible after the dishwasher is in­stalled so that it can be disconnected from the electrical supply at any time.
There must be no electrical sockets behind the dishwasher. There
is a danger of overheating and fire risk if the dishwasher is pushed up against a plug.
The dishwasher must not be installed under a cooktop. The high
radiant temperatures which are sometimes generated by a cooktop could damage the dishwasher. For the same reason, it should not be installed next to open fires or other appliances which give off heat, such as heaters, etc.
9
IMPORTANT SAFETY INSTRUCTIONS
To avoid the risk of damage to the dishwasher, make sure that the
connection data on the data plate (fuse rating, voltage, and fre­quency) matches the electrical supply before connecting the dish­washer to the mains. Consult a qualified electrician if in any doubt.
Do not connect the dishwasher to the electrical supply until it has
been fully installed and any adjustment has been made to the door springs.
The dishwasher may only be operated if the door opening mecha-
nism is working correctly. Otherwise there could be a risk of danger while the automatic door opening mechanism (depending on model) is active. To check that the door opening mechanism is working correctly:
– The door springs must be adjusted equally on both sides. They
are correctly adjusted when the door remains stationary when left half open (approx. 45° opening angle). It is also important that the door cannot fall open.
– The door locking pins automatically retract when the door opens
at the end of the drying phase.
Do not connect the appliance to the electrical supply by a multi-
socket adapter or an extension lead. These do not guarantee the re­quired safety of the appliance (e.g. danger of overheating).
This appliance must not be installed and operated in a non-sta-
tionary location (e.g., on a ship).
Do not install the dishwasher in a room where there is a risk of
frost. Frozen hoses may burst or split. The reliability of the electronic module may be impaired at temperatures below freezing point.
To avoid any damage to the appliance, the dishwasher must only
be operated when it is connected to a fully vented plumbing system.
The water pressure (flow pressure at the connection point) must
be between 7.25 - 145 psi.
10
IMPORTANT SAFETY INSTRUCTIONS
A damaged appliance could be dangerous. If the dishwasher gets
damaged, turn off the electrical supply and contact Miele.
The manufacturer's warranty will be invalidated if the appliance is
not repaired by a Miele-authorized service technician.
Defective components should be replaced by Miele original parts
only. Only with these parts can the manufacturer guarantee the safety of the appliance.
During installation, maintenance and repair work, the appliance
must be disconnected from the electrical supply (turn it off and with­draw the plug from the socket).
If the connection cable is damaged, it must be replaced with a
special cable of the same type (available from Miele) by a Miele-au­thorized service technician only.
Do not sit the dishwasher on the hose. The hose needs to be free
of kinks and able to move freely after installation. Do not place hose or power cord next to a heat source e.g. hot water pipes. Do not ex­pose hose or power cord to corrosive substances (e.g. chloride). Damage of hose or power cord could cause electrical shock or water damage.
This dishwasher is supplied with a special bulb to cope with par-
ticular conditions (e.g. temperature, moisture, chemical resistance, abrasion resistance and vibration). This special bulb must only be used for the intended purpose. It is not suitable for room lighting. Replacement bulbs may only be fitted by a Miele-authorized techni­cian or the Miele Technical Service.
11
IMPORTANT SAFETY INSTRUCTIONS

Proper installation

The dishwasher must be installed and connected in compliance
with the installation plan.
Be careful when installing the dishwasher. Wear protec-
tive gloves to avoid injury on any sharp metal components.
The dishwasher must be correctly aligned horizontally to ensure
problem-free operation.
In order to ensure stability, built-under and integrated dishwashers
must only be installed under a continuous counter which is secured to adjacent cabinetry.
The door springs must be adjusted equally on both sides. They
are correctly adjusted when the door remains stationary when left half open (approx. 45° opening angle). It is also important that the door cannot fall open. The appliance may only be used with correctly adjusted door springs.
12
IMPORTANT SAFETY INSTRUCTIONS

Proper use

Do not use solvents in the dishwasher. Danger of explosion!Do not inhale or ingest powder detergent. Dishwasher detergents
contain irritant or corrosive ingredients which can cause burning in the nose, mouth, and throat if swallowed, or inhibit breathing. Seek medical attention immediately if detergent has been swallowed or in­haled.
Avoid leaving the door open unnecessarily as someone could trip
over it and be injured by it.
Do not sit or lean on the opened door. This could cause the dish-
washer to tip and be damaged, and you could get injured.
Dishes can be very hot at the end of a program. Allow them to
cool until they are comfortable enough to handle before unloading.
Only use detergent and rinse aid formulated for domestic dish-
washers. Do not use dishwashing liquid.
Do not use commercial or industrial detergents as these may
cause damage, and there is a risk of a severe explosive chemical re­action (such as an explosive oxyhydrogen gas reaction).
Do not fill the rinse aid reservoir with powder or liquid detergent.
This will cause serious damage to the reservoir.
Inadvertently filling the salt reservoir with powder or liquid dish-
washer detergent will damage the water softener. Make sure you have picked up the correct packet of dishwasher salt before filling the salt reservoir!
Only use special coarse grained dishwasher salt for reactivation.
Do not use other salts such as cooking salt, agricultural grade or gritting salt. These may contain insoluble additives which can impair the functioning of the water softener.
13
IMPORTANT SAFETY INSTRUCTIONS
In an appliance with a cutlery basket (depending on model), cut-
lery is cleaned and dried more efficiently if placed in the basket with the handles downwards. However, to avoid the risk of injury, place knives and forks with the handles upwards.
Plastic items which cannot withstand being washed in hot water,
such as disposable plastic containers or plastic cutlery should not be cleaned in the dishwasher. The high temperatures in the dish­washer may cause them to melt or lose shape.
If you use the “FlexiTimer/Delay Start” option (depending on
model), make sure that the dispenser is dry before adding detergent. Wipe dry if necessary. Detergent will clog if poured into a damp dis­penser and may not be thoroughly dispersed.
Please observe the information given in “Technical data” regarding
the capacity of the dishwasher.

Accessories

Use only genuine original Miele parts. If spare parts or acces-
sories from other manufacturers are used, the warranty may become invalid.

Disposal of your old dishwasher

Make the door lock inoperative so that children cannot acciden-
tally shut themselves in. Remove or destroy the locking bracket of the door lock, and make appropriate arrangements for the disposal of the appliance.
14
IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS AND PASS THEM ON TO ANY FUTURE USER

FCC Declaration of Conformity

These devices comply with FCC Rules Part15. This equipment
has been tested and found to be in compliance with the limits for a ClassB digital device, pursuant to Part15 of the FCC Rules of Oper­ation and is subject to the following conditions: These devices may not cause harmful interference. These devices must accept any interference received, including in­terference that may cause undesired operation.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be in­stalled and operated with minimum distance 8" (20cm) between the radiator and your body.

Industry Canada Statement

This digital apparatus does not exceed the ClassB limits for Ra-
dio Noise Emissions from digital apparatus set out in the Radio Inter­ference Regulations of the Canadian Department of Communica­tions.
Complies with Canadian ICES-003 ClassB specifications.
15

Guide to the dishwasher

Appliance overview

a
Upper spray arm (not visible)
b
Cutlery tray (depending on model)
c
Upper basket
d
Middle spray arm
e
Heat exchanger return (depending on
model)
f
Lower spray arm
16
g
Filter combination
h
Data plate
i
Rinse aid reservoir
j
Double-chamber detergent dispenser
k
Reservoir for reactivation salt

Control panel

Guide to the dishwasher
a
Program selection
b
Display
c
Option buttons
d
Start button with indicator light
e
Arrow buttons
These operating instructions apply to several different dishwasher models with different heights. The specific dishwasher models are referred to as follows: Standard = 31 11/16“ (80.5 cm) high dishwashers (integrated) and 33 1/4” (84.5 cm) high dishwashers (freestanding) XXL = 33 1/4“ (84.5 cm) high dishwashers (integrated)
f
OK button
g
button (FlexiTimer) with indicator light
h
Program selection button
i
(On/Off) button
17
Guide to the dishwasher

Display functions

General information

The display is used to select or set the following:
– The program
– The FlexiTimer (Delay Start)
– The Settings menu
The display can show the following:
– The current time of day
– The program stage
– The estimated time left for the pro-
gram to run
– Any relevant fault messages and in-
formation
To save energy, the dishwasher switches off after a few minutes if you do not press any buttons during this time. To switch the dishwasher back on again, press the button.

Settings menu

The Settings menu is used to adapt the electronic module of the dishwasher to changing requirements. See the “Set­tings menu” chapter for more informa­tion on accessing the settings menu.
The arrows in the display indicate addi­tional options. You can use the  ar­row buttons underneath the display, as appropriate, to select these options.
The OK button is used to confirm a message or setting and also to move to the next menu or another level.
The option which is selected will have a check next to it.
To exit a sub-menu, use the  arrow buttons to select the Back  option in the display and confirm your choice with OK. If you do not press any of the buttons for several seconds, the display with re­turn to the previous level. You may need to enter your settings again.
18

Caring for the environment

Disposal of the packing mate­rial
The cardboard box and packing materi­als protect the appliance during ship­ping. They have been designed to be biodegradable and recyclable.
Ensure that any plastic wrappings, bags, etc. are disposed of safely and kept out of the reach of children. Dan­ger of suffocation!

Disposal of your old appliance

Electrical and electronic appliances contain valuable materials. They also contain certain substances, compounds and components which were essential for the proper functioning and safe use of the equipment. Handling these mate­rials improperly by disposing of them in your household waste can be harmful to your health and the environment. There­fore, please do not dispose of your old appliance with regular household waste and follow local regulations on proper disposal.
Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. Please en­sure that your old appliance is kept away from children until removal. Ob­serve safety requirements for appli­ances that may tip over or pose an en­trapment hazard.
19
Caring for the environment

Energy-saving dishwashing

This dishwasher is economical in the consumption of water and energy. For best results follow these tips:
– For most economical dishwashing,
make full use of the baskets without overloading the dishwasher.
– Choose a program that best suits the
degree of soiling and the type of dishes being washed.
– Select the Normal program (depend-
ing on model) for energy-saving dish­washing. This program is the most ef­ficient in terms of its combined en­ergy and water consumption at clean­ing normally soiled dishes.
– If your dishwasher is connected to a
hot water supply, select the Energy
Saver program for washing a lightly to
moderately soiled load. Because the water is not heated in this program, dishes may still be slightly damper at the end of this program than it would be with other programs.
– Follow the detergent manufacturer's
recommendations on detergent dosage.
– When using powder or liquid deter-
gent, you can use 1/3 less detergent if baskets are only half full.
20

Before using for the first time

Opening the door

At the end of programs with a drying phase (see “Program overview”), the door will open automatically a little in order to help the drying process. This function can be deactivated if pre­ferred (see “Settings menu - Au­toOpen”).
To open the door, reach under the
door grip and pull.

Closing the door

Push the baskets in.Then lift the door upwards and push
until it clicks into position.
Danger of crushing injuries!
Do not put your hand inside the door as it is closing.

Child lock

The child lock can be used to prevent children opening the dishwasher. The door can then only be opened by using a lot of force.
Open the door fully so that the door
catch rail retracts again.
If the door is opened during operation, all functions are automatically inter­rupted.
Water in the dishwasher may be
hot. Danger of scalding! Only open the door during operation
if absolutely necessary and exercise extreme caution when doing so.
Keep the area around the door
free of obstructions.
To lock the door, push the slide un-
derneath the recessed handle to the right.
To unlock the door, push the slide to
the left.
21
Before using for the first time

Basic settings

Turn the dishwasher on with the
button.
The welcome screen will appear when the dishwasher is turned on for the first time.

Language

The display will change automatically to the screen for setting the language.
Use the  arrow buttons to select
the language you want and also the country, if appropriate, and confirm your selection with OK.
For more information about the func­tion of the display, see “Display”.
A check will appear next to the lan­guage that has been set.

Time of day

The display will then change to the screen for setting the time.
The time of day needs to be set before the “FlexiTimer” programming option can be used. You can also show the current time of day in the display.
Use the  arrow buttons to set the
hour and confirm with OK.
Then set the minutes and confirm
with OK.
Keeping the arrow buttons pressed will increase or decrease the time automatically.
The display will then change to the screen for setting the clock display.
Select whether or not the time of day
should appear in the display and con­firm your selection with OK.
If you have selected Display On, con-
firm the message about higher energy consumption with OK.
22
Before using for the first time

Water hardness

The display changes to the screen for setting the water hardness.
– The dishwasher must be pro-
grammed to the correct water hard­ness for your area.
– Your local water authority will be able
to advise you of the water hardness level in your area.
– Where the water hardness fluctuates
e.g. between 10 - 16 gr/gal (10 - 15 °d), always program the dishwasher to the higher value (16 gr/gal or 15 °d in this example).
It is useful to know your water hardness so that you can provide the service technician with this information in the event of any service calls.
Enter the water hardness below:
____________ gr/gal (°d)
The dishwasher is programmed at the factory for a water hardness level of 1 gr/gal (1 °d).
The message Set-up successfully com-
pleted will then appear in the display.
After confirming this with OK, the prompts Refill salt and Refill rinse aid may appear.
Add salt and rinse aid if necessary
(see “Before using for the first time, Dishwasher salt” and “Rinse aid”).
Confirm the messages with OK.
The program selected will appear briefly in the display and the appropriate indi­cator light will come on. Then, the display will show the esti­mated program duration for the pro­gram selected.
These basic settings will be saved after the dishwasher has been through one complete program.
Use the  arrow buttons to select
the hardness of your water supply and confirm with OK.
See “Settings menu, Water hardness” for more information.
23
Before using for the first time

Before using the appliance for the first time, you require:

– Approx. 2 qt (2 l) of water
– Approx. 2 kg (4 lbs) of dishwasher
salt
– Domestic dishwasher detergent
– Rinse aid formulated for domestic
dishwashers
Every dishwasher is tested at the fac­tory. There will be residual water in the appliance from this test. It is not an in­dication that it has been used previ­ously.

Dishwasher salt

In order to achieve good cleaning re­sults, the dishwasher needs to operate with soft water. Hard water results in a build-up of calcium deposits on dishes and in the dishwasher. Water supplies with a hardness level higher than 4 gr/gal (4 °d) needs to be softened. This takes place automatically in the integrated softener assembly. The softener assembly in the dishwasher is suitable for a water hardness level of up to 73 gr/gal (70 °d).
If the water in your area is very soft and consistently lower than 5gr/gal (5 °d - German scale) you do not have to add dishwasher salt. The prompt to add salt will be switched off automatically if the softener assembly has been programmed for this to hap­pen.
Dishwasher detergent will dam-
age the softener assembly. Do not fill the salt container with
dishwasher detergent (even liquid detergent).
Use only special, coarse-grained
dishwasher salt or other pure kitchen salt.
Other types of salt may contain in­soluble components which can dam­age the softener assembly.
The softener assembly requires dish­washer salt. Depending on the water hardness level (< 22 gr/gal or 21 °d), dishwasher salt is not required if combination tablets are being used (see “Operation - Deter­gent”).
24

Filling the salt reservoir

Important! Before filling the salt reservoir with dishwasher salt for the first time, you must fill it with approx. 2qt (2 l) of water to enable the salt to dissolve.
Once the dishwasher has been used for the first time, there is always suf­ficient water in the reservoir.
Remove the lower basket from the
wash cabinet and unscrew the salt reservoir cap.
Water will run out of the reservoir when the cap is removed.
It should therefore only be removed in order to refill the salt reservoir.
Before using for the first time
Place the funnel provided over the
salt reservoir and carefully fill with salt until the reservoir is full. The salt reservoir holds approx. 4 lbs (2 kg) of salt depending on the brand used.
Fill the reservoir with approx. 2 qt (2 l)
of water (first use only).
Clean any excess salt from around
the reservoir opening and then screw the cap on again firmly.
Immediately after filling the salt reser-
voir, run the QuickIntenseWash pro­gram with the Short programming op­tion selected and without any dishes in the dishwasher to remove any traces of salt from the wash cabinet.
25
Before using for the first time

Salt refill indicator

Fill the salt reservoir with dishwasher
salt for reactivation when Refill salt appears in the display. If it appears during a program, wait until the end of the program.
Confirm with OK.
The salt refill indicator will go out.
Risk of corrosion!
Immediately after filling the salt reservoir, run the QuickIntenseWash program with the Short programming option selected and without any dishware in the dishwasher to re­move any traces of salt from the wash cabinet.
After the salt reservoir has been filled, the refill indicator may still appear in the display if the salt concentration has not yet reached the correct level. If this is the case, confirm again with OK.
If you only ever use Tab products in your dishwasher, you can switch off both refill indicators for salt and rinse aid if you wish (see “Settings menu, Switching off the refill indicators”).
If you switch to using detergent that does not contain salt or rinse aid, it is important to remember to add dishwasher salt and rinse aid and to switch the indicators back on.
The salt refill indicator will be turned off if you have programmed the dishwasher for a water hardness below 5 gr/gal (5°d).
26

Rinse aid

Rinse aid is needed to prevent spotting on dishes and glassware. The rinse aid is filled in the reservoir and the set amount will be automatically dosed.
Filling the rinse aid reservoir with
detergent will damage the reservoir. Only pour rinse aid formulated for residential dishwashers into the reservoir.
When using “Tab” detergents rinse aid is not needed.

Adding rinse aid

Before using for the first time
Add rinse aid only until it is visible in
the opening.
The rinse aid reservoir holds approx.
3.7 oz. (110 ml).
Close the flap firmly so that it clicks
into place. Otherwise water can enter the rinse aid reservoir during a pro­gram.
Press the button on the lid of the
rinse aid reservoir in the direction of the arrow until the flap springs open.
Wipe up any spilled rinse aid. This
prevents over-foaming occurring dur­ing the next program.
You can adjust the rinse aid dosage for best results (see “Settings menu ­Rinse aid”).
27
Before using for the first time

Rinse aid indicator

When the Refill rinse aid message ap­pears in the display, the reservoir con­tains sufficient rinse aid for 2 - 3 pro­grams only.
Add rinse aid.Confirm with OK.
The rinse aid refill indicator will go out.
If you only ever use Tab products in your dishwasher, you can turn off both refill indicators for salt and rinse aid if you wish (see “Settings menu - Turn­ing off the refill indicators”).
28

Loading the dishwasher

Tips

Remove coarse food residues from the dishes.
There is no need to rinse items under running water!
Do not wash items soiled with
ash, sand, wax, grease, or paint in the dishwasher. These will damage the dishwasher.
Dishes can be loaded anywhere in the baskets, but the following notes should be observed:
– Do not place dishes or cutlery inside
other pieces. They will cover each other.
– Load the dishes so that water can
access all surfaces. This ensures that they get properly cleaned.
– Make sure that all items are securely
positioned.
– Make sure that small items cannot
fall through the holders in the bas­kets. Small items, e.g., lids, should there­fore be placed in the cutlery tray or cutlery basket (depending on model).
Some foods may contain natural dyes, e.g., carrots, tomatoes or tomato sauce. Plastic items in the dishwasher may discolor if large quantities of these foodstuffs find their way into the dishwasher on the dishes. The stability of plastic items is not affected by this discoloration. Cleaning silver cutlery in the dish­washer may also cause plastic items to discolor.
– Hollow items such as cups, glasses,
pans, etc. must be inverted in the basket.
– Tall, narrow, hollow items, e.g.,
champagne glasses, should be placed in the center of the basket to ensure better water coverage.
– Concave items such as mugs or
bowls should be placed at an angle so that the water can run off.
– The spray arms must not be blocked
by items which are too tall or hang through the baskets. If in doubt, test for free movement by manually rotat­ing the spray arms.
29
Loading the dishwasher
Items not recommended for dish­washing
– Wooden cutlery, cutting boards and
dishes or items with wooden parts
– Craft items, antiques, valuable vases,
and decorative glassware
– Plastic items which are not heat-re-
sistant: the high temperatures in the dishwasher may cause them to melt or lose shape.
– Copper, brass, tin and aluminum
items may discolor or become matt.
– Colors painted over a glaze may fade
after a number of washes.
– Delicate glassware and glassware
containing lead crystal: clouding may occur over time.
Please note:
Silverware previously cleaned with a silver polish may still be damp or spot-
ted at the end of a program, where wa­ter has not run off smoothly. It may need to be rubbed dry with a soft cloth.

Glass care

– Clouding may occur on glasses after
frequent washing. If delicate glass­ware is washed in the dishwasher, ensure that only very low tempera­tures are used (see program chart), or a special glass-care program is used (depending on model). This will re­duce the risk of clouding.
– Purchase glassware which is dish-
washer-safe (e.g., Riedel glassware).
– Use detergents with glass protective
additives.
Silver which has been in contact with foods containing sulphur can discolor. These include egg yolk, onions, mayon­naise, mustard, fish, and marinades.
Aluminum components (e.g.,
range hood grease filters) must not be cleaned with a commercial or in­dustrial cleaning agent.
These may damage the material.
Tip: When purchasing new dishes and cutlery, make sure they are dishwasher­safe.
30
Loading the dishwasher

Loading examples

Loading for 10 standard place settings with cutlery tray

Upper basket
Cutlery tray (depending on model)
Lower basket
31
Loading the dishwasher

Loading for 16 standard place settings with cutlery tray

Upper basket Lower basket
Cutlery tray (depending on model)
32
Loading the dishwasher

Loading for 10 standard place settings with cutlery basket

Upper basket
Cutlery basket
Lower basket
33
Loading the dishwasher

Loading for 13 standard place settings with cutlery basket

Upper basket
Cutlery basket
Lower basket
34
Loading the dishwasher

FlexAssist

The yellow FlexAssist components indi­cate which elements of the baskets for dishes and cutlery tray are moveable. They also act as grips and have sym­bols embossed on them to show what the moveable parts are used for.

Upper basket

For safety reasons, do not oper-
ate the dishwasher without the upper and lower baskets in place (except when running the Tall items program, if available).

Cup rack

Using the yellow lever, lift the cup
rack upwards to make room for tall items.
Glasses can be arranged along the po­sitioning rail of the cup rack to give them some support during the program.
Lower the cup rack and lean the
glasses against it or double stack smaller pieces.
Use the upper basket for small, light-
weight and delicate items such as cups, saucers, glasses, dessert bowls, etc. Shallow pans or casserole dishes can also be placed in the upper basket.
Long items such as soup ladles, mix-
ing spoons, and long knives should be placed lying down across the front of the upper basket.
35
Loading the dishwasher

Hinged spikes

The rows of spikes can be lowered to make more room for larger items such as casserole dishes.
Press the yellow lever downwards
and then lower the spikes .

XXL cup rack (depending on model)

The cup rack can be set at two different widths so that it can also accommodate large cups.
Pull the cup rack upwards and click it
back into position at the required width.
36
Loading the dishwasher

Glassware rail

The glassware rail is designed to hold glasses with long stems securely.
Lower the glassware rail with the yel-
low lever and lean tall glasses against it.
You can also move one of the side in-
serts in the cutlery tray to make more room for tall glasses (see “Cutlery, 3D cutlery tray”).

Adjusting the height

You can set the glassware rail at two different heights.
Pull the rail upwards and click it back
into position at the required height.
Use the lower position for small glasses and tumblers.
Use the higher position for tall glasses and glasses with stems.
37
Loading the dishwasher

Adjusting the upper basket

In order to gain more space for taller items the upper basket can be adjusted on three levels with 3/4" (2 cm) between each level.
The upper basket can also be set at an angle with one side high and the other side low. Make sure, however, that the basket can slide smoothly in and out of the cabinet.
Pull the upper basket out.

To raise the upper basket:

Lift the basket until it clicks into
place.

Dishwashers with cutlery basket

(see data plate for model number)
Upper basket adjust-
Plate in inches (cm)
Upper basket Lower ADA Full-size
basket
ment
Upper 7 7/8"
(20)
9 7/16"
(24)
12 3/16“
(31)
13
3/4” (35*)
Middle 8 11/16"
(22)
Lower 9 7/16"
(24)
10 1/4"
(26)
11"
(28)
11 7/16"
(29)
10 5/8"
(27)

Dishwashers with cutlery tray

(see data plate for model number)
Upper basket adjust-
Plate in inches (cm)
Upper basket Lower ADA Full-size
basket
ment
Upper 7 7/8"
(15)
7 1/2"
(19)
12 3/16“
(31)
13
3/4” (35*)
Middle 6 11/16"
(17)
Lower 7 1/2"
(19)
8 1/4"
(21)
9 1/16"
(23)
11 7/16"
(29)
10 5/8"
(27)

To lower the upper basket:

Pull upwards on the levers at either
side of the upper basket.
Adjust the basket to the desired
height and then push the levers se­curely back down into position.
Depending on the setting of the upper basket, the following plate dimensions can be accommodated.
38
* When tilted, plates of up to 13 3/4“ (35 cm) can be accommodated (see ”Lower bas­ket“).
Depending on the setting of the upper basket, a variety of plate dimensions can be accommodated.
Loading the dishwasher

Lower basket

For larger and heavier items such as
plates, serving platters, saucepans, bowls, etc. Glasses, cups and small items such as saucers can also be placed in the lower basket. Do not place thin, deli­cate glassware in the lower basket.

Removable MultiComfort insert

The rear section of the lower basket is used for washing cups, glasses, plates, pots and pans.
You can remove the MultiComfort insert to make more room for larger items such as casserole dishes.

Removing the insert

Pull the yellow handle forwards and
remove the insert.

Refitting

Place large platters and dishes in the
center of the lower basket.
When tilted, plates up to 13 3/4" (35 cm) in diameter can be accommodated.
Fit the insert into the lower basket
with the hooks under the long cross­piece .
Press down on the insert until it clicks
into position .
39
Loading the dishwasher

FlexCare glass holder

Silicone padding in the FlexCare glass holder provides a stable and secure hold for delicate stemware.
Stem glassware, e.g. wine glasses or
champagne flutes, can be leaned against the glass rack or suspended from it.
The glass holder can be raised to
make more room for tall items.
You can set the glass holder at two dif­ferent heights.

Glassware rail

The glassware rail is designed to hold glasses with long stems securely.
Lower the rail and lean tall glasses
against it.
Slide the glass holder to the desired
height until the catches click into place at the top or bottom.
40
Loading the dishwasher

Hinged spikes

The spikes at the front are used for washing plates, soup bowls, platters, dessert bowls, and saucers.
The spikes can be lowered to make more room for large items, e.g. pots, pans and dishes.
Press the yellow lever downwards ,
and then lower the spikes .

Bottle holder

The bottle holder can be used to wash narrow items, e.g., milk and baby bot­tles.
If the bottle holder is not needed, lift
it up and fold the sides down, as illustrated.
41
Loading the dishwasher

Pot rests and filters

You can also wash Miele pot rests and Miele hood filters.
Select the Grates & Filters program for
optimum dishwashing results.
Protruding parts can damage the
dishwasher. Load the dishwasher in such a way
that no corners protrude over the side of the basket.
Heavy and sharp wash loads can
damage the coating of the basket struts.
Load pot rests and filters carefully.

Pot rests

Rust damages the dishwasher.
Wash only pot rests that are undam-
aged and not rusty.
Place the upper basket in the top po-
sition.
Load the pot rest in the lower basket.
To do so, remove the MultiComfort insert and fold over the front row of spikes.
Place the pot rest on the bottom of
the basket and against the struts on one side. On the other side of the basket, flip up the glass holder and place this side of the pot rest on the silicone padding of the glass holder.
42

Filters

You can wash two range hood filters in the upper basket and two in the lower basket at once. If you only want to wash two filters, put them in the top basket.
Upper basket
Loading the dishwasher
Lower basket
Be careful when unloading the
filters. At the end of the program, the
filters may still contain hot water.
43
Loading the dishwasher

Cutlery

3D cutlery tray+ (depending on model)

Arrange the cutlery in the tray as
shown.
To make unloading much easier, cutlery should be grouped in zones, one for knives, one for forks, one for spoons, etc.
Spoon heads should be placed in con­tact with at least one of the serrated re­tainers on the base of the cutlery tray to ensure that water runs off them freely.
The upper spray arm must not be
blocked by items which are too big.
The side sections of the tray can be moved into the middle using the yellow grips in order to accommodate tall cookware in the upper basket (see also “Upper basket - Glassware rack”).
If spoon handles do not fit between the holders, lay them the other way round.
For optimum cleaning results arrange spoons with the inner part facing the center of the cutlery tray.
44
You can use the yellow slide to adjust the height of the middle section of the cutlery tray to make more room for large items of cutlery, such as serving spoons and ladles.
Loading the dishwasher
Both rows of spikes in the middle sec­tion of the cutlery tray can be flipped over to make room for larger pieces of cutlery.
Raise the spikes and then flip them
over .
45
Loading the dishwasher

Cutlery basket (depending on model)

The cutlery basket can be placed any­where on the front rows of spikes in the lower basket.
To avoid the risk of injury, knives and
forks should be placed with the han­dles upwards in the basket. However, cutlery placed handle down in the basket will come out cleaner and drier.
Fit it onto the cutlery basket if re-
quired.
Place small items of cutlery in the in-
dividual slots on three sides of the cutlery basket.

Cutlery insert for the cutlery basket

Use the insert supplied for heavily soiled items of cutlery. The insert sepa­rates the items so that they can be more easily accessed by water.
46
Insert cutlery with the handles facing
downwards.
Distribute them evenly along the in-
sert.

Operation

Detergent

Only use detergents formulated
for domestic dishwashers.

Active ingredients

Modern detergents contain various ac­tive ingredients, the most important of which are:
– Complexing agents to prevent calcifi-
cation.
– Alkalis to aid the removal of dried-on
soiling.
– Enzymes to break down starch and
loosen protein.
– Oxygen-based bleaching agents to
remove colored stains (e.g., tea, cof­fee, tomato sauce).
Most dishwasher detergents are mildly alkaline and contain enzymes and oxy­gen-based bleaching agents.
There are different types of detergent:
You can also buy Tab products (see “Options, DetergentAgent”, if applica­ble). In addition to detergent, these products contain rinse aid and salt substitutes. They are available as “3 in 1” or when they also contain other components such as glass and stainless steel pro­tective additives and enhanced cleaning power, as “5 in 1”, “7 in 1”, “All in 1” etc. Refer to the manufacturer's packaging as to whether Tab products are suitable for the water hardness level in your area. Please note that the cleaning and dry­ing results of Tab detergents can vary greatly.
For optimum cleaning and drying re­sults, use Miele dishwasher detergent and add Miele salt and Miele rinse aid separately.
– Powder and liquid gel detergents.
These detergents allow you to adjust the amount dispensed according to the amount of load and level of soil­ing.
– Tab detergents. These are suitable for
most levels of soiling.
47
Operation

Detergent dosage

Follow the dosage recommended by
the manufacturer on the packaging.
Unless directed otherwise, use one
detergent tab or add 1 1/4 - 2 table­spoons (20 - 30 ml) detergent to compartment II, depending on the level of soiling. With very heavy soil­ing you can also add a small amount of detergent to compartment l.
Tabs may not dissolve completely
when the “QuickIntenseWash” pro­gram (if available) is used.
Use only the recommended amount of detergent. Continued use of too much detergent may cause machine damage.
Dishwasher detergents can
cause burning in the nose, mouth,
and throat if swallowed, or inhibit
breathing.
Avoid inhaling or swallowing dish-
washer detergent. Keep children
away from detergent. Keep detergent
out of the reach of children. Keep
children away
from the dishwasher when the door
is open. There could still be deter-
gent residues in the dishwasher. Only
add detergent just before starting the
program and lock the door with the
child lock (depending on model).
48

Adding detergent

Press the opening catch on the deter-
gent dispenser. The flap will spring open.
The flap is always open at the end of a program.
Operation
Add the required amount of detergent
and close the flap.
Make sure that the detergent packag-
ing is properly closed after use to avoid it getting damp and becoming lumpy.

Dispensing aid

Compartment I holds a maximum of 2 teaspoons (10 ml), Compartment II holds a maximum of 3 ½ tablespoons (50 ml) of detergent.
The marks in compartment II indicate the levels of approximately 1 ¼ and 2 tablespoons (20 and 30 ml) respec­tively. The marks indicate the approxi­mate fill level in ml when the door is open in a horizontal position.
49
Operation

Turning on

Make sure the spray arms are not ob-
structed.
Close the door.Turn on the water supply if it is turned
off.
Press the button for at least 2 sec-
onds.
The program selected will appear briefly in the display and the appropriate indi­cator light will come on. Then, the display will show the esti­mated program duration for the pro­gram selected.

Selecting a program

Choose your program according to the type of load and the degree of soiling.
The different programs and their uses are described in the Program Over- view chapter.
Use the program selection button
to select the program required.
The indicator light of the selected pro­gram will come on.
Additional programs can be selected using the Additional option.
Use the program selection button
to select the Additional option.
The first of the additional programs will appear in the display.
Use the  arrow buttons to select
the program required.
During the course of the program, you can use OK to display the name of the program which is currently running.
50
You can now select program options (see “Options”).
If any program options are selected, the appropriate indicator lights will also light up.
Operation

Starting a program

The dishwasher can be started only if the door is closed.
Press the Start or OK button.
The program will begin.
The Start indicator light will come on.
A program should only be canceled in the first few minutes, if at all. Oth­erwise important program stages could be omitted.

Time display

The estimated duration of the program selected appears in hours and minutes in the display before the program be­gins. During the program, the time left until the end of the program is dis­played.
Each program phase is indicated by a symbol:
Pre-wash / Soak Wash Interim rinse Rinse cycle Drying Finish
The program duration displayed may vary with the same program. It is influ­enced by, among other things, the wa­ter temperature at each intake, the re­activation process, the softener assem­bly, the type of detergent, the amount of dishes, and the amount of soiling.
When a program is selected for the first time, the display will show the average program duration for a cold water in­take.
The times shown in the program over­view refer to standard test loads and temperatures.
Each time a program is run, the elec­tronic module calculates the program duration required depending on the temperature of the water taken into the dishwasher and the amount of dishes.
51
Operation

Energy management

To save energy, the dishwasher will switch off automatically 10 minutes af­ter the last time a button has been pressed or after the end of a program.
Press the button to switch the
dishwasher back on.
The dishwasher will not turn off auto­matically if the time of day display has been activated (see “Settings menu ­Time of day”).
The dishwasher will not switch off while a program or the FlexiTimer is running or if there is a fault.

At the end of the program

The program has finished when End appears in the display and the door has opened slightly (if applicable).
In the QuickIntenseWash program, the door will not open until a few minutes after the program has finished.
The drying fan may continue to run for a few minutes at the end of the pro­gram.
Open the door fully so that the door
locking pins retract again.
You can now empty the dishwasher.
If you have deactivated the auto-
matic door opening function (see
“Settings menu, AutoOpen”), but
would still like to open the door at
the end of the program, make sure
that you open the door fully.
Otherwise steam from the dish-
washer could damage the edge of
the counter because the fan is no
longer running.
52
Operation

Turning off the dishwasher

At the end of a program: The dishwasher can be switched off
at any time using the button.
Switching the dishwasher off during a program stops the program.
Turning the dishwasher off during the run-up to a delay start time (FlexiTimer) will also stop the process.
If the dishwasher is not going to be used for a longer period of time, e.g., while on vacation, the water supply should be turned off.

Unloading the dishwasher

Dishes tend to break and chip more easily when they are hot. Allow the dishes to cool until they are comfortable enough to handle before unloading them.
The dishes will cool much faster if you open the door when the program has ended.
First unload the lower basket, then the upper basket, and finally the cutlery tray (depending on model). This will prevent water drops from the upper basket and cutlery tray from fall­ing onto the dishes in the lower basket.
53
Operation

Interrupting a program

A program will be interrupted as soon as the door is opened.
Close the door and press the Start
button.
The program will continue from the point at which it was interrupted.
Water in the dishwasher may be
hot. Danger of scalding! Only open the door if absolutely nec-
essary and exercise extreme caution when doing so. Before closing the door again, leave it ajar for approx. 20 seconds. This will enable the tem­perature in the wash cabinet to set­tle. After that, close the door and press the Start button.

Changing a program

If the detergent dispenser flap has al-
ready opened, do not change the
program.
If a program has already started and you wish to change it, proceed as fol­lows:
Turn the dishwasher off with the
button.
Turn the dishwasher on again with the
button.
Select the program you want, and
then start it.
54

Options

Options

Options can be selected and dese­lected using the appropriate buttons and the display before starting the pro­gram.
Turn the dishwasher on with the
button.
The Start indicator light flashes.
Select a program.Press the button for the option you
want.
The indicator light for the relevant but­ton will come on if the option is avail­able for the program selected.
If the option is not compatible with the program selected, a message to this ef­fect will appear in the display.
In this instance, confirm the message
with OK.
Press the Start button to start the
program.
The option selected will remain active for that particular program until the set­ting is changed.
When used in combination with the QuickIntenseWash program, the Short option results in a wash program with­out drying or automatic opening of the door (if available).

Extra economical

The Extra Economical option reduces the energy consumption of programs in which this option is available by up to 20%.
In order to achieve optimum cleaning results, the program duration is ex­tended with this option.

Intensive lower rack

The Intensive Lower Rack option inten­sifies cleaning performance in the lower basket in programs in which this option is available.
Energy and water consumption are in­creased slightly due to the extended wash duration in the lower basket.

Extra dry

The Extra Dry option improves the dry­ing performance in programs in which this option is available.

Short

The Short option reduces the duration of programs in which this option is available by up to 30% (see “Program overview”).
In order to achieve optimum cleaning results, energy consumption may in­crease slightly with this option.
Energy consumption is increased due to an extended fan running time and an increased final rinse temperature.
55
Options

FlexiTimer with EcoStart

The FlexiTimer gives you three ways of starting the program by means of de­laying the start. You can set the start time or the finish time of a program. You also have the option of taking advan­tage of time variable economy rates of electricity using the EcoStartfunction.
When using the delay start function, make sure that the detergent com­partment is dry before adding deter­gent. Wipe dry with a cloth if neces­sary. If the compartment is wet, pow­der detergent can become lumpy and stick to the dispenser, with the result that it is not fully dispensed. Do not use liquid detergent when se­lecting delay start, as it can run into the dishwasher before it is required.
To prevent children coming into
contact with dishwasher detergent: Do not fill the detergent dispenser
until just before starting the pro­gram, i.e., before you activate the
FlexiTimer with OK. Also activate the child lock.
Switch the dishwasher on with the
button.
The Start indicator light flashes.
Select the desired program.Press the button.
You can use the arrow buttons to select the Start at, Finish at, or EcoStart function or Back .
Confirm selection of the function you
want with OK.
The current time of day will appear and the hour number pad will be high­lighted.
You can now enter the time you want using the  arrow buttons and con­firm with OK.
If, while you are setting the time, you do not press any buttons for several sec­onds, the display will revert to the previ­ous menu. You will then have to enter your settings again.
If the time of day (clock) display has been switched off (see “Settings menu, Time of day”) the display mes­sage will go out if you have activated a delay start time after a few minutes and only the Start indicator light will flash slowly.
56
Press any button to switch the display back on again for a few minutes.
Options

Start at

With the Start at function, you set the exact time at which you want the pro­gram to start.
Use the  arrow buttons to set the
hour and confirm with OK.
The hour will be saved and the minute number pad will be highlighted.
Use the  arrow buttons to set the
minutes and confirm with OK.
The saved start time for the program selected will appear in the display. The Start indicator light will come on.
When the set time is reached, the pro­gram selected will start automatically. The time remaining will appear in the display, the indicator light will go out and the Start indicator light will light up.

Finish at

With the Finish at function, you set the time at which you wish the program to end.
Use the  arrow buttons to set the
hour and confirm with OK.
The hour will be saved and the minute number pad will be highlighted.
Use the  arrow buttons to set the
minutes and confirm with OK.
The estimated start time for the pro­gram selected will appear in the display. The Start indicator light will come on.
A message will appear in the display if the program cannot be completed by the set finish time because it has too long a running time.
When the estimated time is reached, the program selected will start automat­ically. The time remaining will appear in the display, the indicator light will go out and the Start indicator light will light up.
57
Options

EcoStart

The EcoStart function allows you to take advantage of time variable economy rates of electricity. Before you can use this option, you must set up to three electricity rate time zones (see “Settings menu, EcoStart”). You then set the latest time at which the program selected should end. The dishwasher will start automatically in the lowest rate zone within the time set.
Use the  arrow buttons to set the
hour and confirm with OK.
The hour will be saved and the minute number pad will be highlighted.
Use the  arrow buttons to set the
minutes and confirm with OK.
The estimated start time of the program selected will appear in the display. The and Start indicator lights will light up.
The program selected will start auto­matically in the most economical time period and finish no later than at the fin­ish time set. The time left will appear in the display, the indicator light will go out and the indicator light for the Startbutton will light up.

Changing or deleting set times

You can change the set times or the program before the start time in the dis­play is reached.
Press the button.Use the  arrow buttons to select
the setting you want to change and confirm with OK.
Use the  arrow buttons to select
the Change or Delete function and confirm with OK.
After confirming the Change function, you can change the set time.
After confirming the Delete function, the program duration will appear in the dis­play and the program will start. The indicator light will go out and the Start indicator light will light up.
If you open and close the door again before the start time is reached, the message Continue with Start will appear in the display. Press the Start button to restart the FlexiTimer.
58
Options

EcoTech Heat exchanger

This dishwasher is equipped with a heat exchanger in which fresh water for the rinse cycle is pre-heated in order to save energy. The heat exchanger is re­filled with fresh water towards the end of each phase that uses fresh water and is held there ready for the next part of the program.
If you do not wish to use this function it can be switched off (see “Settings ­EcoTech Heat exchanger”).
If water in the heat exchanger is not used for several weeks, it will be auto­matically drained and pumped away for hygiene reasons. This process takes a few minutes and will also be carried out if the dishwasher is switched off or the door is open. The display will remain dark. The mes­sage Empty system will appear in the display when the button is pressed. No other functions are available during this process. Automatic drainage cannot be inter­rupted.
The heat exchanger should only be
used in conjunction with a cold-fill
water supply.
This function should be switched off
if your dishwasher is connected to a
hot water supply.
The heat exchanger can be manually drained for transporting the appliance, e.g. before moving house (see“Settings
- EcoTech Heat exchanger”).
59

Program overview

Program When to use Program sequence
1)
Normal
Pots & Pans
China &Crystal
Quick Intense­Wash
SaniWash To sanitize dishware, e.g. baby bot-
Rinse& Hold
Program for regular use to completely wash a full load of normally soiled dishes with the ability to adjust en­ergy and water consumption based on the soil load of the dishes.
For heavily soiled dishes and normally soiled pots,pans and utensils with dried on residue; use 20% more de­tergent than recommended.
For temperature sensitive glassware and lightly soiled dishes, use 50% de­tergent recommended. GlassCare program for temperature-sensitive glasses and dishes with light soiling. Use 50% of the detergent amount.
“Quick program” for standard dishes soiling that has not dried on.
tles, cutting boards and preparation dishes.
To rinse dishes when a complete pro­gram is not needed.
Pre-
wash
As
needed
2X 167/
X 113/
X
Main
Interim
wash
°F/°C °F/°C
117­140/ 47­60
75
149/
156/692X 158/70X
rinse
45
65
Final
Drying
rinse
X 140/60X
X 136/58X
X 136/58X
X 140/60X
1)
This program is the most efficient in terms of its combined energy and water consumption for cleaning normally soiled crockery. This program is used for energy labeling purposes.
60
Program overview
Consumption
Energy Water
Cold water Hot water Gallons/Liters Cold water Hot water
50°F/10°C 120°F/49°C 50°F/10°C 120°F/49°C
kWh kWh h:min h:min
0.92 1.11 3.2/12.1 2:38 2:00
1.25 1.55 3.8/14.5 3:38 3:07
0.80 1.05 3.4/13.0 2:33 2:03
1.15 1.25 3.0/11.5 1:15 0:58
2)
Duration
2)
1.40 1.65 3.3/12.5 3:02 2:31
0.01 0.20 1.1/4.0 0:14 0:14
2)
Values quoted are in accordance with 10CFR430/ C373-04. In practice there may be variations to these figures due to variable conditions and data recorded by the sensors. Durations shown will reflect your household conditions. Selecting program options will also affect consumption levels and program durations (see “Programme options”). The energy consumption with a hot water supply includes the energy used to heat the water (exception: EnergySaver, if available).
61
Program overview
Program When to use Program sequence
Extra Quiet
Economy Water and energy saving program
Energy Saver
Grates& Filters
Clean Machine
Sensor Wash
Extra quiet program for mixed loads with standard, slightly dried-on food residue with a longer program dura­tion.
for standard dishes soiling that has not dried on, with a long soaking time and a low temperature.
The water intake temperature must be 115°F (45°C) for light to normally soiled dishes.
Wash program for cleaning Miele grates, the Miele griddle plate, and Miele ventilation hood filters.
Special cleaning program to remove grease deposits from the dish­washer.
Program for dried-on remains and non-sensitive loads. Temperature, waterintake, program duration and electricity consumption are auto­matically adjusted to suit the level of soiling of the dishes.
Pre-
wash
2X X X X X
As
needed
Main
wash
°F/°C °F/°C
115/46 X 131/55 X
129/54 X 111/44 X
X 167/75 X 136/58 X
167/75 2X 158/70 X
113­149/
45-65
Interim
rinse
As
needed
Final rinse
140-60 X
Drying
62
Program overview
Consumption
2)
Duratiion
2)
Energy Water
Cold water Hot water Gallons/Liters Cold water Hot water
50°F/10°C 120°F/49°C 50°F/10°C 120°F/49°C
kWh kWh h:min h:min
0.80 1.00 2.5/9.5 4:35 4:28
0.65 0.85 2.5/9.5 3:58 3:25
0.06 7.1/27.0 2:00
1.40 1.70 3.8/14.5 4:00 3:25
2.00 2.30 5.7/21.5 3:07 2:35
0.75 3) -1.15
2)
Values quoted are in accordance with 10CFR430/ C373-04. In practice there may be
4)
0.85 3) -1.50
4)
1.7/4.0 3) -
6.5/15.0
1:57-3:59 1:46-3:33
4)
variations to these figures due to variable conditions and data recorded by the sensors. Durations shown will reflect your household conditions. Selecting program options will also affect consumption levels and program durations (see “Programme options”). The energy consumption with a hot water supply includes the energy used to heat the water (exception: EnergySaver, if available).
3)
Part load with light soiling
4)
Full load with heavy soiling
63

Settings menu

Adjusting default values

Opening the Settings menu

Switch the dishwasher on with the
button if it is switched off.
Use the program selection button
to select the Additional option.
The first of the additional programs will appear in the display.
Select the Settings  menu option with
the arrow buttons and confirm with OK.
The first option in the Settings menu will appear in the display.
For more information about the func­tion of the display, see “Display”.
Use the arrow buttons to select
the menu option you want to change and confirm your selection with OK.
Sub-menu options which have already been selected will have a check be­side them.

Language

The display can be set to appear in one of several different languages.
You can change the language in the display via the Language  sub-menu.
Select the language you want as well
as the country, if appropriate, and confirm with OK.
The flag after the word Language  acts as a guide if a language which you do not understand has already been set. If this is the case, keep selecting the option which has a flag after it until you reach the Language  sub-menu.
To exit a sub-menu, use the  ar-
row buttons to select Back  and confirm with OK.
The display will revert to the menu above.
64
Settings menu

Time of day

The dishwasher is delivered with the time of day (clock) display deactivated.
To save energy, the dishwasher will turn off automatically a few minutes after the last time a button has been pressed or after the end of a program.

Setting the time of day (clock) display

When the time of day (clock) display has been activated, the current time of day will appear in the display a few min­utes after the last time a button has been pressed or after the end of a pro­gram. This increases energy consump­tion.
Select the Display option and confirm
with OK.
Select the setting you want and con-
firm with OK.
If you have selected On, confirm the
message about higher energy con­sumption with OK.

Setting the clock format

You can select either a 24-hour or 12­hour clock.
Select the Clock format option.Select the setting you want and con-
firm with OK.

Setting the clock

You can set the current time of day. The current time of day must be set be­fore you can use the “FlexiTimer” pro­gram option.
Select the Set option.Set the hour with the  arrow but-
tons and confirm with OK. Then set the minutes and confirm with OK.
The time of day has now been saved.
65
Settings menu

Water hardness

This appliance is fitted with a softener assembly. The dishwasher must be programmed for the water hardness in your area.
– The dishwasher must be pro-
grammed to the correct water hard­ness for your area.
– Your local water authority will be able
to advise you of the water hardness level in your area.
– Where the water hardness fluctuates
e.g. between 10- 16gr/gal (10­15°d), always program the dish­washer to the higher value (16gr/gal or 15°d in this example).
Select the water hardness level for
your area and confirm your selection with OK.
A check will appear beside the water hardness which has been set.
°d gr/gal °f Display
1 1 2 1
2 2 4 2
3 3 5 3
4 4 7 4
5 5 9 5
6 6 11 6
7 7 13 7
8 8 14 8
9 9 16 9
10 10 18 10
°d gr/gal °f Display
11 11 20 11
12 13 22 12
13 14 23 13
14 15 25 14
15 16 27 15
16 17 29 16
17 18 31 17
18 19 32 18
19 20 34 19
20 21 36 20
21 22 38 21
22 23 40 22
23 24 41 23
24 25 43 24
25 26 45 25
26 27 47 26
27 28 49 27
28 29 50 28
29 30 52 29
30 31 54 30
31 32 56 31
32 33 58 32
33 34 59 33
34 35 61 34
35 36 63 35
36 38 65 36
37-45 39-47 66-80 37-45
46-60 48-63 82-107 46-60
61-70 64-73 109-125 61-70
66
Settings menu

Rinse aid

You can adjust the rinse aid dosage for best results. The rinse aid dosage is set in stages from 0 to 6. It is set to 3 at the factory.
If spots appear on dishware and glass­ware:
– Increase the rinse aid dosage.
If clouding or smearing appears on dishware and glassware:
– Decrease the rinse aid dosage. Select the setting you want and con-
firm your choice with OK.

EcoStart

In order to run your dishwasher in the most economical way, you can use the
EcoStart option to take advantage of
your electricity supplier's time variable rates (see “Options - FlexiTimer with EcoStart”). With this option selected, your dish­washer will start automatically at your electricity supplier's cheapest rate times.
To use this option, you must first set up to three electricity rate time zones in which the dishwasher can start. You can allocate different priorities to these time zones. The time with the cheapest electricity rate will be given Priority 1.
Contact your electric supplier to find out the times of the cheapest electricity rates.
Once the electricity rate times have been set, you can use the EcoStart op­tion to set the latest finish time required for each program. The dishwasher will then start automati­cally in the cheapest electricity rate time and the program will end at the latest at the finish time set.
67
Settings menu

Setting the electricity rate times

Before you can use the EcoStart option, you must set at least one electricity rate time.
Use the  arrow buttons to select
the electricity rate time (R1-R3) you want to set and confirm with OK.
The start of the electricity rate time se­lected will appear in the display and the hour number block will be highlighted.
Use the  arrow buttons to set the
hours and minutes for the start time and confirm both with OK.
The end of the electricity rate time se­lected will appear in the display and the hours number block will be highlighted.
Use the  arrow buttons to set the
hours and minutes for the end time and confirm both with OK.
The electricity rate time will be saved and its priority will appear in the display.

Changing the electricity rate times

You can change the start, finish or pri­ority of an electricity rate time.
Use the  arrow buttons to select
the electricity rate time (R1-R3) you want to change and confirm with OK.
Select the setting you want to change
and confirm with OK.
Use the  arrow buttons to change
the setting and confirm with OK.
Confirm the message with OK.
The change will be saved.
Use the  arrow buttons to set the
priority you want and confirm with OK.
Confirm the message with OK.
The electricity rate time will be acti­vated.
68
Settings menu

Deleting the electricity rate times

You can delete the settings for an
electricity rate time and in doing so deactivate the EcoStart option for this time zone.
Use the  arrow buttons to select
the electricity rate time (R1 - R3) you want to delete and confirm with OK.
For example, select Delete R1 and
confirm with OK.
For example, select Delete R1? and
confirm with OK.
The settings for the electricity rate time selected will be reset.
Confirm the message with OK.
The electricity rate time has now been deleted.

Networking

Your dishwasher is equipped with an in­tegrated WLAN module.
In order to connect your dishwasher to your WLAN network, you must first acti­vate the network function.
This will add the Miele@home menu op­tion to the “Settings” menu.
Networking is deactivated at the fac­tory.
Make sure that your WLAN network
signal strength is strong enough at
the installation site of your dish-
washer.
Select the setting you want and con-
firm with OK.
69
Settings menu

Miele@home

This menu option is only displayed if you have activated the network set­tings (see “Settings - Network”).
There are a number of ways of connect­ing your dishwasher to your WLAN net­work:

Miele@mobile app

The Miele@mobile app can be used to connect to your network.
Download the Miele@mobile app
from one of the App stores.
Follow the instructions in the app.

WPS Push button

As an alternative to networking your dishwasher via the Miele@mobile app, we recommend using WPS (Wireless Protected Setup). To do so, you will need a WPS-compatible router.
Select the WPS push button menu op-
tion.
Please wait will appear in the display.
Activate the “WPS” function on your
router within two minutes.
Once connection has been estab-
lished, confirm the message with OK.
The dishwasher will then revert to the
Miele@home menu.
If the connection fails, you have proba­bly not connected WPS to your router quickly enough. Repeat the steps above.
70
Settings menu

Remote control

Once you have installed the Miele@mo­bile app on your tablet PC or your smartphone, you will be able to operate your dishwasher remotely. Your dish­washer must be signed on to a WLAN network. The Remote control function is activated at the factory.
If you do not wish to use remote control you can deactivate the function.
Select the setting you want and con-
firm with OK.
Use the option Back  to access the
Settings  menu.
Use Close to leave the Settings 
menu.
Use the program selection button
to select the Additional option again.
Once you have activated the Remote
control function, the MobileControl menu
option will be listed under Addi­tional.
If the time of day (clock) display has been switched off (see “Settings menu, Time of day”) the display mes­sage will go out if you have activated a delay start time after a few minutes and only the Start indicator light will flash slowly.
Press any button to switch the display back on again for a few minutes.
If you open the door and then close it again before you have started a pro­gram with the remote control, the message Continue with Start appears in the display. Press the Start button to reactivate the MobileControl function.
If you now do not wish to operate the dishwasher remotely with the Miele@mobile app, you can cancel the
MobileControl function.
Switch the dishwasher off with the
button.
In order to operate the dishwasher with the Miele@mobile app, please activate the MobileControl function.
Confirm the MobileControl menu op-
tion with OK.
Close the door and press the Start
button.
The Start indicator light will come on and Remote active will appear in the dis­play.
The dishwasher can now be operated remotely using the Miele@mobile app.
71
Settings menu

Module settings

We recommend connecting your dish­washer to your WLAN network using the Miele@mobile app or via WPS.
If you would rather set up the connec­tion to your router yourself, or you have a special network configuration, you can enter the relevant settings with the necessary technical knowledge.
Start module activity
If you wish to reset all entered settings and values for Miele@home, you can re­store the factory default settings on your WLAN module. Any settings which do not affect Miele@home will remain unchanged.
Select Default settings and confirm
with OK.
Please wait will appear in the display.
The message Module status: Process suc-
cessful will appear in the display after a
few minutes. Confirm the message with OK.
The WLAN module factory default set­tings have been restored.
If the factory default settings were not restored to your WLAN module, repeat the instructions above.
72
Settings menu

Soak

You can use this function to loosen dried-on food residues in the program selected. Once activated, this function will be carried out with all programs until you deactivate it. If you are using powder dishwasher de­tergent, add approx. 5 g to compart­ment I.
Select the setting you want and con-
firm with OK.

Pre-Rinse

You can use this function to remove easily loosened food residues in the program selected. Once activated, this function will be carried out with all programs until you deactivate it.
Select the setting you want and con-
firm with OK.

Brightness

There are seven different display bright­ness settings.

Refill indicators

If you consistently use a Tab detergent and the refill indicators for salt and rinse aid are bothering you, you can deacti­vate them if you wish.
Select the setting you want and con-
firm with OK.
If you switch to using detergent that
does not contain salt or rinse aid, it
is important to remember to add
dishwasher salt and rinse aid and to
switch the indicators back on.

Check filters

You can adjust the interval at which the message to remind you to check the fil­ters appears. You can set an interval between 30 and 60 program cycles.
The “Check filters” message is set at the factory to appear after every 50 pro­gram cycles.
Select the interval you want and con-
firm this with OK.
Select the brightness you want and
confirm this with OK.
73
Settings menu

AutoOpen

At the end of programs with a drying phase, the door will open automatically a little in order to help the drying process (see “Program overview”). In the QuickIntenseWashprogram, the door will open a few minutes after the program has finished.
This function can be deactivated if wished.
Select the setting you want and con-
firm with OK.
If you have deactivated the auto-
matic door opening function and would like to open the door as soon as the program has finished, make sure that you open the door fully. Otherwise steam from the dish­washer could damage the edge of the counter because the fan is no longer running.

BrilliantLight

This dishwasher has interior lighting. When the door is open, the lighting will switch off automatically after 15 min­utes.
The interior lighting can be switched off. Select the setting you want and con-
firm with OK.

EcoTech Heat exchanger

This dishwasher is equipped with a heat exchanger (see “Programming options, Heat exchanger”).

Status

The heat exchanger function can be switched off if you do not wish to use it.
Select the State menu option.Select the setting you want and con-
firm with OK.

Manual draining

You can manually empty the heat ex­changer, e.g. if it will not be used for a longer period of time, or before moving the appliance to a new location.
74
Select the Empty manually option and
confirm with OK.
The process will start immediately.
Settings menu

Software version

You can display the electronic software version of your dishwasher electronics for technical support purposes.
Confirm the display with OK.

Showroom program

For demonstration purposes only.
The dishwasher is fitted with various demonstration programs for showroom use.
– Demo mode
Demonstration program for show­rooms.
– Demo with sound
This program activates the circulation pump to demonstrate the sound of the dishwasher.
– Demo Drying Plus
The door will open automatically.
– BrilliantLight
The interior lighting is on constantly.

Factory default settings

You can reset all dishwasher settings to the factory default settings.
WLAN module settings (where applica­ble) have to be reset separately (see “Settings -Miele@home - Module set­tings”).
Select Reset and confirm with OK.

Closing the Settings menu

You can exit the Settings menu using
Close.
Select Close and confirm with OK.
The program selected will appear in the display briefly and the indicator light for the program selected will come on.
75

Cleaning and care

Check and clean your dishwasher regularly. This will help avoid prob­lems and faults.
All surfaces are susceptible to
scratching. Contact with unsuitable cleaning
agents can alter or discolor all sur­faces.

Cleaning the wash cabinet

Generally, the wash cabinet is self cleaning if the correct amount of deter­gent is used.
If, however, there are limescale or grease deposits in the wash cabinet, these can be removed with a special cleaning agent (available from Miele). Follow the instructions on the packag­ing.
If you mainly use low temperature pro­grams (< 120°F/50 °C), there is a risk of bacteria and unpleasant odors building up in the wash cabinet. To prevent this happening the dishwasher will automat­ically increase the temperature in the fi­nal rinse of the selected program after several programs using low tempera­tures have been run.

Cleaning the door and the door seal

Bacteria could build up on the door seal and the sides of the dishwasher door as these surfaces are outside the wash cabinet and are not accessed and cleaned by the spray arm jets.
Wipe the door seals regularly with a
damp cloth to remove food deposits.
Wipe off any food or drink residues
which may have dripped onto the sides of the dishwasher door before closing it.
Clean the filters in the wash cabinet
regularly.
76
Cleaning and care

Cleaning the door front

If soiling remains longer, it may
happen that the surfaces can be­come discolored or changed.
Remove any soiling immediately.
Clean the front with a solution of
warm water and a little dishwashing liquid applied with a soft sponge. Wipe the surfaces dry using a soft cloth.
Glass cleaners may be used to
clean the exterior. However do not allow them to sit or “puddle”, this can cause damage to the surface.
Remove the cleaner promptly.
To better maintain your appliance avoid the following:
– Cleaning products containing soda,
ammonia, acid, or chloride
– Descaling agents
– Abrasive cleaning products, such as
scouring powder, scouring liquid, or pumice stones,
– Cleaners containing solvents
– Stainless steel cleaners
– Dishwasher cleaner
– Oven cleaners
– Glass cleaner
– Hard, abrasive brushes or sponges,
e.g., pot scourers, brushes or sponges which have been previously used with abrasive cleaning agents
– Eraser sponges
– Sharp metal scrapers
– Steel wool
– Steam cleaning appliances
77
Cleaning and care

Filter system

The filter system in the base of the wash cabinet prevents food from being redeposited on dishes. It also protects the circulation pump from damage caused by foreign objects.
This dishwasher must not be
used without all the filters in place!
Collection of coarse soil may cause the filters to clog. The level of soiling and time it takes before the filters need cleaning will vary depending on use.
The message Check filters will appear in the display after every 50 program cy­cles (factory default setting).
You can set the interval for the “Check filters” message to appear to a value between 30 and 60 program cycles (see “Settings menu - Check filters”).
Check the filter system.Clean it if necessary.Then confirm the message with OK.
The message will go out.

Filter system

Turn the dishwasher off.
Turn the handle counter-clockwise to
release the filter system .
Lift the filter system out of the dish-
washer . Remove any coarse parti­cles and rinse the filter well under running water. Use a nylon brush if necessary.
Ensure that coarse soil does not
get into the circulation system and
cause a blockage.
78
Cleaning and care
To clean the inside of the filter, the flap must be opened:
Press catches together in the di-
rection of the arrows as shown, and open the filter .
Rinse all the filters under running wa-
ter.
Then close the flap so that the catch
engages.
Replace the filter system so that it lies
flat in the base of the wash cabinet.
Then turn the handle clockwise until
both arrows point towards each other. This will lock the filter system in place.
Take care when you are fitting
the filter system that it is secured in
position correctly.
Otherwise coarse soil could get into
the circulation system and cause a
blockage.
79
Cleaning and care

Cleaning the spray arms

Particles of food can get stuck in the spray arm jets and bearings. The spray arms should therefore be inspected and cleaned regularly (approx. every 4 - 6 months).
Turn the dishwasher off.
Remove the spray arms as follows: Take out the cutlery tray (if your dish-
washer is fitted with one).
Push the top spray arm upwards to
engage the inner ratchet. Then un­screw the spray arm.
Pull the lower spray arm firmly up-
wards to remove it.
Push the middle spray arm upwards
to engage the ratchet. Then un- screw the spray arm .
Remove the lower basket.
80
Use a pointed object to push the food
particles that are stuck in the spray arm jets into the spray arm.
Rinse the spray arms thoroughly un-
der running water.
Replace the spray arms and check
that they rotate freely.

Frequently Asked Questions

With the help of the following guide, minor faults in the performance of the appli­ance, some of which may result from incorrect operation, can be put right without contacting Miele Service. This will save time and money.
The following guide may help you to find the reason for a fault, and to correct it. You should, however, note the following:
Unauthorized or incorrect repairs could cause personal injury or damage to
the appliance. Repair work to electrical appliances must only be carried out by a suitably qual-
ified and competent person in strict accordance with current local and national safety regulations. The manufacturer cannot be held liable for unauthorized work.

Technical problems

Problem Possible cause and solution
The display remains dark and the Start indi­cator light is not flash­ing after the dishwasher has been turned on with the button.
The dishwasher stops during a program.
The time display is flashing with the door shut. The program has not started.
The dishwasher is not plugged in. Insert the plug.
The circuit breaker has tripped. Reset the fuse (see data plate for the correct fuse
rating).
The circuit breaker has tripped. Reset the fuse (see data plate for the correct fuse
rating).
If the circuit breaker trips again, contact Miele Ser-
vice.
The door has not closed properly, because it had not been fully opened after the door had been opened automatically.
Open the door fully so that the door locking pins
retract again.
Then close the door.
81
Frequently Asked Questions
Problem Possible cause and solution
One of the following fault messages is dis­played:
Fault FXX There may be a technical fault.
Waterproof The WaterProof System has reacted.
Fault F78 A fault has occurred in the circulation pump.
Before fixing the fault: Turn the dishwasher off with the button.
After a few seconds:
Turn the dishwasher back on.Select the desired program.Press the Start button.
If the error message is displayed again, there is a technical fault.
Contact Miele Service.
Turn off the water supply.Contact Miele Service.
Turn the dishwasher off for at least 30 seconds
with the button.
Turn the dishwasher back on.Select the desired program.Press the Start button.
If the error message is displayed again, there is a technical fault.
Contact Miele Service.
82
Frequently Asked Questions

Water intake fault

Problem Possible cause and solution
One of the following fault messages is dis­played:
Open water supply The water supply is turned off.
Turn on the water supply fully.
Intake Before fixing the fault:
Turn the dishwasher off with the button.
There is a problem with the water intake. Turn on the water supply fully and start the pro-
gram again.
Clean the water intake filter (see “Frequently asked
questions”).
The water pressure at the intake is lower than 4.35
psi. Contact a plumber.
The following message appears in the display during the Energy Saver program: Intake temp. low
The intake water has not reached the required tem­perature of 120°F (45°C) (see “Water connection, Wa­ter intake”).
Start the program again.If the fault message appears again, select a differ-
ent program.
83
Frequently Asked Questions

Water drainage fault

Problem Possible cause and solution
The following fault mes­sage is appears in the display: Drain
Before fixing the fault: Turn the dishwasher off with the button.
There is a problem with the water intake. There might be water in the wash cabinet.
Clean the filter system (see “Cleaning and care -
Filter system”).
Clean the drain pump (see “Frequently asked
questions”).
Clean the non-return valve (see “Frequently asked
questions”).
Remove any kink or loop in the drain hose.
84
Frequently Asked Questions

General problems

Problem Possible cause and solution
The indicator lights and display are dark.
The interior lighting does not switch on when the door is opened.
Detergent residue is left in the dispenser at the end of a program.
The dispenser cover cannot be closed.
The inside of the door and/or the interior walls are wet after a program has finished.
Water remains in the wash cabinet at the end of a program.
The dishwasher has switched off automatically to save energy.
Turn the dishwasher on again with the button.
The interior lighting has been switched off. Switch the lighting back on again (see “Settings
menu - BrilliantLight”).
The dispenser was still damp when detergent was added.
Make sure the dispenser is dry before adding de-
tergent.
Detergent residue is blocking the latch. Remove the detergent residue.
This is caused by the drying system and does not in­dicate a fault. The moisture will dissipate after a while.
Before fixing the fault: Turn the dishwasher off with the button.
The filter system in the wash cabinet is clogged. Clean the filter system (see “Cleaning and care -
Filter system”).
The drain pump or non-return valve is blocked. Clean the drain pump or the non-return valve (see
“Frequently asked questions”).
The drain hose is kinked. Remove the kink.
85
Frequently Asked Questions

Noises

Problem Possible cause and solution
There is a knocking noise in the wash cabi­net.
There is a rattling noise in the wash cabinet.
There is a knocking noise from the water pipe
A spray arm is hitting the dishes. Interrupt the program, and rearrange the items
which are obstructing the spray arm.
Dishes is moving around in the wash cabinet. Interrupt the program and rearrange loose pieces.
A foreign object (e.g., a cherry pit) has become lodged in the drain pump.
Remove the foreign object from the drain pump
(see “Maintenance - Cleaning the drain pump and non-return valve”).
This may be caused by the installation or the diameter of the water pipe.
This has no influence on dishwasher function. If in
doubt, contact a suitably qualified plumber.
86
Frequently Asked Questions

Poor cleaning results

Problem Possible cause and solution
The dishes are not clean.
Smearing appears on glassware and cutlery. There is a bluish sheen on the surface of glass­ware; film can be wiped off.
The dishes were not loaded correctly. See notes in “Loading the dishwasher”.
The program was not powerful enough. Select a more intensive program (see “Program
overview”).
Not enough detergent was dispensed. Use more detergent, or change your detergent.
Items are blocking the path of the spray arms. Rearrange the items so that the spray arms can ro-
tate freely.
The filter system in the base of the wash cabinet is not clean or is not correctly fitted. This may cause the spray arm jets to get blocked.
Clean and/or fit the filter system correctly.Clean the spray arm jets if necessary (see “Clean-
ing and care - Cleaning the spray arms”).
The non-return valve is open and blocked. Dirty water has flowed back into the wash cabinet.
Clean the drain pump and the non-return valve
(see “Frequently asked questions”).
The rinse aid dosage is set too high. Reduce the dosage (see “Settings menu - Rinse
aid”).
87
Frequently Asked Questions
Problem Possible cause and solution
Dishes is not dry or cut­lery and glasses are spotty.
Glasses have a brown­ish-blue discoloration; the deposit cannot be wiped off.
Glasses are dull and discolored; the deposit cannot be wiped off.
Tea or lipstick stains have not been com­pletely removed.
Plastic parts are discol­ored.
The rinse aid dosage is set too low or the rinse aid reservoir is empty.
Replenish the reservoir, increase the dosage, or
change the brand of rinse aid (see “Before using for the first time - Rinse aid”).
Dishes was taken out of the cabinet too soon. Leave it in for longer (see “Operation”).
Combination tabs have been used which have im­paired drying performance.
Change your detergent, or replenish the rinse aid
(see “Before using for the first time - Rinse aid”).
Detergent deposits. Switch to another detergent.
The glassware is not dishwasher-safe. The surfaces are affected.
There is no remedy.
Purchase glassware which is dishwasher-safe.
The wash temperature of the selected program was too low.
Select a program with a higher wash temperature.
The bleaching effect of the detergent is too low. Switch to another detergent.
Natural dyes, e.g., from carrots, tomatoes, or ketchup may be the cause. The amount of detergent used or its bleaching effect was not sufficient to deal with nat­ural dyes.
Use more detergent (see “Operation - Detergent”).
Discoloration is irreversible.
88
Frequently Asked Questions
Problem Possible cause and solution
White residue is visible on dishes and cutlery, clouding occurs on glassware; this film can be wiped off.
There are rust stains on the cutlery.
The rinse aid dosage is too low. Increase the dosage (see “Settings menu, Rinse
aid”).
The salt reservoir is empty. Fill the salt reservoir (see “Before using for the first
time, Dishwasher salt”).
The salt reservoir cap has not been screwed on cor­rectly.
Replace it, making sure that it screws back on cor-
rectly.
An unsuitable Tab detergent has been used. Change your detergent.
The softener assembly is programmed too low for the water hardness level.
Program the softener assembly to a higher water
hardness level (see “Settings menu, Water hard­ness”).
The affected items are not corrosion resistant. There is no remedy.
Purchase cutlery which is dishwasher-safe.
A program was not run after dishwasher salt was added. Traces of salt have got into the wash cycle.
Always run the QuickIntenseWash program with
the Short programming option selected and with­out any dishes in the dishwasher after adding dishwasher salt.
The salt reservoir cap has not been screwed on cor­rectly.
Replace it, making sure that it screws back on cor-
rectly.
89

Frequently asked questions

Cleaning the drain pump and non-return valve

If the water has not been pumped away at the end of a program, the drain pump or the non-return valve might be blocked. They are, however, easy to clean.
Disconnect the dishwasher from the
electrical supply. Turn off the dish­washer and withdraw the plug.
Take the filter system out of the wash
cabinet (see “Cleaning and care, Cleaning the filters”).
Scoop the water out of the wash cab-
inet using a suitable container or utensil.
The drain pump is located underneath the non-return valve (see arrow).
Remove all foreign objects from the
drain pump (glass or bone splinters). Before returning the non-return valve, check that the drain pump is not blocked. Spin the impeller several times in both directions to check for obstructions.
Press the catch for the non-return
valve inwards .
Tilt the non-return valve inwards until
it is released .
Rinse it thoroughly under running wa-
ter and remove any dirt from the non­return valve.
90
Carefully reinsert the non-return valve
and secure it with the locking clamp.
Make sure the locking clamp
clicks into place!
Be careful not to damage any
delicate components when cleaning
the drain pump and the non-return
valve.

Customer service

Repairs

For problems that you cannot resolve on your own, please contact:
– your Miele dealer or
– Miele Service
The telephone number for Miele is listed at the back of these instruc­tions.
In the event of a fault which you cannot correct yourself please contact the Miele Service Department at the phone number on the back of this booklet.

Warranty

For more information, please refer to the included warranty.

MieleCare (USA only)

MieleCare, our Extended Service Con-
tract program, gives you the assurance of knowing that your appliance invest­ment is covered by 5 years of worry free ownership. MieleCare is the only Extended Service Contract in the industry that guarantees repairs by a Miele Authorized Service Provider using genuine Miele parts. Only genuine Miele parts installed by factory trained professionals can guar­antee the safety, reliability, and longevity of your Miele appliance.
Please note that unless expressly ap­proved in writing by Miele’s Service de­partment, Extended Service Contracts offered by other providers for Miele products will not be recognized by Miele. Our goal is to prevent unautho­rized (and untrained) service personnel from working on your Miele products, possibly doing further damage to them, you and/or your home.
To learn more about MieleCare Ex­tended Service Contracts, please con­tact your appliance dealer or visit us online at:
http://www.mieleusa.com
91

Optional accessories

Dishwasher detergent and rinse aid, as well as cleaning and care products, are available as optional accessories. All the products are designed for use with Miele dishwashers.
These and many other useful products can be ordered from a Miele dealer or via the Miele Webshop (see end of this booklet for contact details).

Dishwasher detergent, rinse aid, and salt

When you decide to buy a Miele dish­washer, you choose excellent quality and performance. However, ensuring that your dishwasher always delivers the best possible results will also de­pend on your choice of dishwasher de­tergent, rinse aid, and dishwasher salt, as cleaning results can vary depending on the brand used. With Miele products, you can be sure of optimum results as these products have been specially designed for Miele dish­washers.

Detergent tabs

– Sparkling results even with stubborn
food deposits
– Combination product with other com-
ponents such as rinse aid, salt, and glass protection additives
– Phosphate-free - kind to the environ-
ment
– Water-soluble wrapping - no need to
unwrap

Powder detergent

– With active oxygen for thorough
cleaning
– With enzymes which are effective
even in low temperature programs
– With glass protection against corro-
sion

Rinse aid

– For sparkling glasses
– Helps dishware to dry
– With glass protection against corro-
sion
92
– Specially designed cap for accurate,
easy dispensing

Dishwasher salt

– Prevents lime scale on dishware and
in the appliance
– Extra coarse-grained

Dishwasher care products

Miele cleaning and care products pro­vide optimum care for your dishwasher.

Dishwasher cleaner

– Cleans the dishwasher effectively
and thoroughly
– Removes grease, bacteria, and un-
pleasant odors
– Ensures excellent dishwashing re-
sults

Dishwasher descaler

– Removes heavy lime scale deposits
– Mild and gentle with natural citric
acid

Dishwasher conditioner

– Removes odors, lime scale, and light
deposits
Optional accessories
– Maintains the elasticity and leak
tightness of the seals

Dishwasher freshener

– Neutralizes unpleasant odors
– Fresh, pleasant lime and green tea
scent
– Easy to attach to the dishwasher
basket
– Very economical, lasts for 60 wash
cycles
93

Miele@home

a
Miele@home-compatible appliance
b
Miele@home-compatible appliance with SuperVision functionality
c
WLAN router
d
Mobile devices (Smartphone, Tablet PC, Notebook)
e
Connection to home automation systems
f
Internet connection
94
Miele@home
Your home device / is network-en­abled.
In order to connect your home device to the network, a WLAN module or a WLAN stick is required (depending on the home device integrated, supplied, or acquired as optional accessory).
When using a WLAN routerand the Miele@mobile app, your home device can be linked to the Miele@home sys­tem.
Appliances with network capability and linked to the Miele@home system send information about their operating status and transmit relevant program se­quence data to the apps of the mobile deviceor the master appliance, an oven with SuperVision function, for example.
Displaying information, controlling appliances
– Mobile deviceswith Miele@mobile
app Smartphone, Tablet PC or Notebook can be used to display status infor­mation about the appliances; you may also activate certain control functions. Additional application op­tions of the Miele@mobile app can be found in the information about the in­tegrated respective appliances.
WLAN
Tip: Before installing the applicance in
its final location, ensure the signal strength is sufficient for your WLAN net­work.
To connect applicances with integrated WLAN module to your WLAN network, you must first activate the network function (see “Settings”).
To connect applicances with external WLAN module or WLAN stick to your WLAN network, you must first insert the WLAN module or install the WLAN stick (see “Installation instructions of the WLAN module or WLAN stick”).
Additional information
Separate installation and operating in­structions are enclosed with the acces­sories.
Additional information regarding Miele@home is available on the Miele Website and in the instruction manuals of the individual Miele@home compo­nents.

Miele@mobile App

The Miele@mobile App is available to download free of charge from the Apple
App Store® or from the Google Play Store™.
– SuperVision master appliance
The status of some network-enabled appliances can be shown on the dis­play of other network-enabled appli­ances.
95
96

Installation Instructions

Please refer to the Installation Diagram supplied with these instructions. To comply with IEC sound testing protocols, please contact Miele for additional
instructions.
Information is subject to change. Please refer to our website to obtain the most current product specification, technical & warranty information.
97

Electrical connection

Installation, repairs and other
work by unqualified persons could be dangerous.
Check that the voltage, frequency and fuse rating shown on the data plate match the household mains supply.
The power outlet must be accessible after installation. Do not use an ex­tension cord to connect the dish­washer to the mains. Danger of over­heating! See data plate on the right side of the door.
A damaged power cord must only be replaced with a genuine Miele cord by a Miele service technician.

Grounding instructions

THIS APPLIANCE MUST BE GROUNDED.
In the event of a malfunction or break­down, grounding will reduce the risk of electric shock by providing a path of least resistance for the electrical cur­rent. This appliance is equipped with a cord having an equipment grounding conductor and a grounding plug. The plug must be plugged into an appropri­ate outlet that is installed and grounded in accordance with all local codes and ordinances.
Improper connection of the
equipment grounding conductor can
result in electric shock.
Do not modify the plug provided with
the appliance; if it will not fit the out-
let, have a proper outlet installed by
a qualified electrician.
If there is any question concerning
the proper electrical connection or
grounding of this appliance to the
powersupply, please consult a li-
censed electrician or call Miele’s
Technical Service Department:
USA: 1-800-999-1360
CDN: 1-800-565-6435
Specifications
The dishwasher comes equipped with a 4ft (1.2m) powercord (measured from the rear of the dishwasher) with a molded plug for connection to 120V, 60Hz, 15A grounded receptacle.
98
Electrical connection
Hardwired electrical connection
It is possible to hardwire this appliance to an existing power cable.
CAUTION: Before servicing, dis-
connect the power supply by either removing the fuse, shutting off the power main or manually “tripping” the circuit breaker.
Installation work and repairs should only be performed by a qualified technician in accordance with all ap­plicable codes and standards. Re­pairs and service by unqualified per­sons could be dangerous and the manufacturer cannot be held respon­sible.
Before connecting the appliance to the power supply, make sure that the voltage and frequency listed on the data plate correspond with the household electrical supply. This data must correspond to prevent machine damage. Consult an electri­cian if in doubt.
Prior to making a hardwire con-
nection to the terminal, remove the
powercord. Otherwise there will be a
risk of electric shock from the at-
tached plug.
An existing flexible supply cord or cable shall have a minimum thickness of AWG14. 120V, 60Hz, 15A fuse rating Black wire (live): connect to L White wire (neutral): connect to N Green wire (ground): connect to
After attaching the permanent
power supply cord, check that all
screws on the terminal block and the
strain relief are tightened.

GROUNDING INSTRUCTIONS

THIS APPLIANCE MUST BE GROUNDED.
This appliance must be connected to a grounded metal, permanent wiring sys­tem, or an equipment-grounding con­ductor must be run with the circuit con­ductors and connected to the equip­ment-grounding terminal or lead on the appliance.
99

Water connection

Water intake

Water in the dishwasher must
not be used as drinking water.
– The dishwasher may be connected to
a cold or hot water supply up to a maximum of140°F/60°C. For reduced energy consumption, we recommend a cold water connection. We recommend connection to a hot water supply only if it is economical, e.g. a solar-powered supply with re­circulation line. When connected to a hot water supply, all program phases which would otherwise be carried out with cold water will be carried out with hot water
– The Energy Saver program (if available)
requires a hot water supply between 115°F/45°C (minimum) and 140°F/60°C (maximum). The higher the water intake tempera­ture, the better the cleaning and dry­ing results.
– The inlet hose is approx.5ft long. A
5ft long flexible metal hose (pressure tested to 2030psi) is available as an optional accessory if required.
– A faucet with a 3/8" male thread
must be provided on site.
– This appliance is constructed to
comply with ANSI/ASSE 1001 // IEC/ EN/DIN 61770 // VDE 0700 Part 600, and may be connected to a suitable supply without an extra non-return valve if national regulations permit.
– Water pressure: Must be between
4.5- 145psi (0.3- 10bar) If the water pressure is lower than this, the fault message Intake will appear in the dis­play (see “Frequently asked ques­tions”). If the water pressure is too high, a pressure relief valve must be fitted.
After connecting the dishwasher to
the water supply, check that the wa-
ter intake is airtight.
To avoid any damage to the ap-
pliance, the dishwasher must only be
operated when it is connected to a
fully vented plumbing system.
The intake hose must not be
shortened or damaged in any way as
it contains electrical components.
Do not sit the dishwasher on the
hose. The hose needs to be free of
kinks and able to move freely after
installation. Do not place hose or
power cord next to a heat source
e.g. hot water pipes. Do not expose
hose or power cord to corrosive sub-
stances (e.g. chloride). Damage of
hose or power cord could cause
electrical shock or water damage.
100
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
