Miele EGW4060-14 User Manual

Operating instructions

Built-in Plate Warmer EGW 4060-14

To prevent accidents and machine damage read these instructions

before

installation or use.

M.-Nr. 06 543 300

Contents

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Guide to the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Before using the plate warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Operating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Selecting a temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Warming times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Cleaning the plate warmer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Non-slip mat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Help protect our environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Installation Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Built-in measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Combinations EGW 40x0 -14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Installing the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Aligning the appliance front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

IMPORTANT SAFETY INSTRUCTIONS

Installation

This appliance is intended for residential use only. Only use the appliance for its intended purpose.

Improper use of the appliance can lead to personal injury and material damage. The manufacturer cannot be held responsible for damages caused by improper use of the plate warmer.

This appliance complies with current safety requirements.

Read all instructions before installing or using for the first time.

Keep these operating instructions in a safe place and pass them on to any future user.

Read all operating and installation instructions for any other appliance installed in combination with the plate warmer.

READ ALL INSTRUCTIONS!

Before installation make sure that

the voltage and frequency listed on the data plate correspond with the household electrical supply. This data must correspond in order to prevent injury and machine damage. If in doubt, consult a qualified technician.

The electrical safety of this

appliance can only be guaranteed when continuity exists between the appliance and an effective grounding system. The grounding system must comply with local and national safety regulations. It is imperative that this basic safety requirement be met. If there is any doubt, have the electrical system of the house checked by a qualified electrician. The manufacturer cannot be held responsible for the damages caused by an inadequate grounding system (e.g. electric shock).

Do not connect the appliance to

the electrical supply with an extension cord. Extension cords do not guarantee the required safety of the appliance.

This appliance must only be used

once it has been properly installed into cabinetry to ensure that all electrical components are protected.

Never open the outer casing of the

appliance. Tampering with electrical connections or components and mechanical parts is dangerous and may cause machine damage.

IMPORTANT SAFETY INSTRUCTIONS

Installation, repair and

maintenance work should be performed by a Miele authorized service technician. Work by unqualified persons could be dangerous and may void the warranty.

Hardwiring the appliance should

be performed by a certified electrician in compliance with all local and national codes and requirements. The manufacturer cannot be held responsible for the damages caused by an inadequate electrical connection.

Before installation or service,

disconnect the power supply to the work area by removing the fuse, "tripping" the circuit breaker or unplugging the unit. Pull the plug not the cord.

Use

The plate warmer interior gets very

hot when in use and remains hot for some time once turned off.

Use heat-resistant pot holders

when removing dishes. Be sure that they are not damp or wet. Danger of steam burns!

Pull the drawer out all the way

when removing dishes to avoid touching hot drawer parts.

To prevent burns do not touch hot

surfaces, use handles or knobs.

Do not let children access the

appliance or its controls. Supervise its use by the elderly or infirm.

Do not use the plate warmer to

reheat, cook or keep food and drinks warm. The condensation from food or drinks could lead to moisture damage in the appliance.

Do not lean or sit on the warming

drawer. This will damage the drawer. The drawer can hold a maximum of 55 lbs (25 kg).

Do not store anything in the

warming drawer. Forgotten items could melt or catch fire when the appliance is turned on. Flammable liquids and materials should never be stored in, above or under the plate warmer.

Do not use the plate warmer to

heat the room. Due to the high temperatures radiated, objects left near the appliance could be damaged.

Do not use a steam cleaner to

clean this appliance. Steam could penetrate electrical components and cause a short circuit. Pressurized steam may cause permanent damage to the surface and to components of the appliance, for which the manufacturer cannot accept responsibility.

To prevent injuries, do not use

accessories not recommended by Miele.

Do not install

outdoors.

Guide to the machine

a On/Off button b Temperature selector c Warming drawer d Non-slip mat e Indicator

Before using the plate warmer

Clean the plate warmer with a damp

cloth and wipe dry. Heat the empty plate warmer for a

minimum of 2 hours. Turn the temperature selector to "Maximum" (see "Selecting a temperature").

Vent the room when heating the

drawer for the first time.

Metal components have a protective coating which may give off a slight odor the first time your new appliance is heated. The smell will dissipate after a short time and does not indicate a faulty connection.

Use

The plate warmer is only intended for warming dishes.

Do not use the plate warmer to reheat, cook or keep food and drinks warm. Condensation from food and drinks may cause moisture damage to the appliance.

Use pot holders when removing dishes.

The drawer can hold a maximum of 55 lbs (25 kg).

Controls

The appliance works with a convection system. A fan distributes the heat evenly throughout the drawer. The air circulation heats the dishes fast and evenly.

A protective grill prevents contact with the heating element and fan.

The floor of the warming drawer has a non-slip mat to prevent plates and dishes from sliding when the drawer is opened and closed.

The controls consist of the temperature selector and the On/Off button. They are only visible when the drawer is open. The indicator on the front of the drawer show if the plate warmer is turned on or off.
