Operating and Installation Instructions Ventilation Hood

To prevent accidents and damage to the appliance, you must these instructions before installing the appliance and using it for the first time.

en-US M.-Nr. 10 118 580

read

Contents

IMPORTANT SAFETY INSTRUCTIONS................................................................. 4

Caring for the environment.................................................................................

Description of functions......................................................................................

Con@ctivity 2.0 function ........................................................................................ 15

Guide to the appliance.........................................................................................

Operation (Automatic mode)...............................................................................

Cooking with Con@ctivity 2.0 (Automatic mode)................................................... 18

Temporarily exiting Automatic mode ..................................................................... 20

Resuming Automatic mode ................................................................................... 20

Operation (Manual mode)....................................................................................

Cooking without Con@ctivity 2.0 (Manual mode).................................................. 21

Turning on the fan .................................................................................................. 21

Selecting the power level....................................................................................... 21

Selecting the Delayed shut down time .................................................................. 21

Turning off the fan.................................................................................................. 21

Dimming and turning the overhead lighting on/off ................................................ 22

Power management............................................................................................... 22

Operation (Automatic and Manual modes)........................................................

Filter saturation indicator ....................................................................................... 23

Adjusting the filter saturation indicator for grease filters .................................. 23

Checking the filter saturation indicator............................................................. 24

Adjusting the height of the canopy........................................................................ 24

Cleaning and care................................................................................................

Stainless steel housing .......................................................................................... 25

Grease filters.......................................................................................................... 26

Installation ............................................................................................................

Before installation .................................................................................................. 29

Installation parts..................................................................................................... 29

Appliance dimensions............................................................................................ 30

Distance between cooktop and ventilation hood (S) ............................................. 31

Installation recommendations................................................................................ 32

Structural support.................................................................................................. 32

Removing the protective film ................................................................................. 32

Exhaust duct......................................................................................................... 42

Condensate trap .................................................................................................... 43

Contents

Electrical connection...........................................................................................

Grounding Instructions .......................................................................................... 44

Activating Con@ctivity 2.0...................................................................................

Installation of the Con@ctivity 2.0 stick ................................................................. 45

Activating the Con@ctivity 2.0 function ................................................................. 45

Activating the ventilation hood ......................................................................... 45

Activating the cooktop...................................................................................... 46

Activation failed ................................................................................................ 46

Deactivating Con@ctivity 2.0 ................................................................................. 46

Service and warranty...........................................................................................

Location of the data plate...................................................................................... 47

Technical data .....................................................................................................

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

This appliance complies with current safety requirements. Impr

oper use of the appliance can lead to personal injury and

material damage.

Read all instructions before installing or using the appliance for the first time. Only use the appliance for its intended purpose.

Keep these operating instructions in a safe place and pass them on to any future user.

Use

AUTION: For General Ventilating Use Only. Do Not Use To

 C

Exhaust Hazardous Or Explosive Materials And Vapors.

 This applianc

described in these operating instructions.

e is intended for residential use only. Use only as

 This ventilation hood is designed for domestic use and for use in

ar residential environments.

simil

 This venti  It

must only be used to extract and clean vapors produced during

cooking. Any other use occurs at the owner's own risk.

lation hood is not intended for outdoor use.

 This appliance is suitable for installation above gas or electric

king surfaces.

coo

 P

ersons who lack physical, sensory or mental abilities, or experience with the appliance should not use it without supervision or instruction by a responsible person.

Children

IMPORTANT SAFETY INSTRUCTIONS

 As w

by children.

 Please super

them play with it.

 Dange

etc. are disposed of safely and kept out of the reach of children.

ith any appliance, close supervision is necessary when used

vise children in the vicinity of the hood and do not let

r of suffocation! Ensure that any plastic wrappings, bags,

IMPORTANT SAFETY INSTRUCTIONS

Technical safety

 W

ARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,

OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

– Use this appliance only in the manner intended by the

man

ufacturer. If you have questions, contact Miele.

– Before servicing or cleaning the appliance, switch power off at

the ser prevent power from being switched on accidentally. If the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel.

vice panel and lock the service disconnecting means to

 Installatio

a Miele authorized service technician in accordance with national and local safety regulations and the provided installation instructions. Contact Miele’s Technical Service Department for examination, repair or adjustment. Repairs and other work by unauthorized persons could be dangerous and may void the warranty.

 A d

check for visible signs of damage. Never use a damaged ventilation hood.

amaged ventilation hood oven can be dangerous. Always

 Be cer

qualified technician. To guarantee the electrical safety of this appliance, continuity must exist between the appliance and an effective grounding system. It is imperative that this basic safety requirement be met. If there is any doubt, have the electrical system of the house checked by a qualified electrician.

 Reliable

it has been connected to the electrical supply.

o avoid damaging the ventilation hood, make sure that the

 T

connection data (voltage and frequency) on the data plate correspond to the building's power supply before connecting the appliance. When in doubt, consult a qualified electrician.

n, repair and maintenance work should be performed by

tain your appliance is properly installed and grounded by a

and safe operation of this hood can only be guaranteed if

IMPORTANT SAFETY INSTRUCTIONS

 Do not use a power bar or e

ventilation hood to electricity. These are a fire hazard and do not guarantee the required level of appliance safety.

o ensure safe operation, only use the ventilation hood after it has

 T

been properly installed.

 This venti

(e.g. on a ship).

 Adeq

simultaneously with devices that burn gas or other fuels.

lation hood may not be used in non-stationary locations

uate ventilation must be provided when the hood is operated

xtension cord to connect the

 Only open the housing as described in the enclosed "Installation

diagr

am" and in the "Cleaning and care" section of this manual. Under no circumstances should any other parts of the housing be opened. Tampering with electrical connections or components and mechanical parts is highly dangerous to the user and can cause operation faults.

 Defective components should be replaced by Miele original parts

only. Only with these parts can the manufacturer guarantee the safety of the appliance.

 During installation, maintenance, and repair work, the ventilation

hood must be disconnected from the electrical supply. It is only completely isolated from the electricity supply if one of the following applies:

– The circuit breakers on the electrical service panel are tripped. – The screw-type fuses on the electrical service panel have been

emoved.

– The power cable (if present) has been unplugged from the socket

(pull the plug no

t the cord).

IMPORTANT SAFETY INSTRUCTIONS

Proper use

 W

ARNING: TO REDUCE THE RISK OF A COOKTOP GREASE

FIRE:

– a) Never leave surface units unattended at high settings.

Boi

lovers cause smoking and greasy spillovers may ignite. Heat

oils slowly on low or medium settings. – b) Always turn the hood on when cooking at a high heat. – c) Clean the ventilation hood frequently. Grease should not be

all

owed to accumulate on the fan or filter.

– d) Use the proper pan size. Always use cookware appropriate for

the siz

 Never use an open flame beneath the ventilation hood.

o avoid the risk of fire, do not flambé or grill over an open flame. When turned on, the ventilation hood will draw any flames into the filter. Fat deposits may ignite.

 W

THE EVENT OF A COOKTOP GREASE FIRE, OBSERVE THE FOLLOWING*:

e of the cooking area.

ARNING: TO REDUCE THE RISK OF INJURY TO PERSONS IN

– a) SMOTHER FLAMES with a close fitting lid, cookie sheet, or

metal tray then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out immediately, EVACUATE AND

CALL THE FIRE DEPARTMENT. – b) NEVER PICK UP A FLAMING PAN - You may be burned. – c) DO NOT USE WATER, including wet dishcloths or towels - a

lent steam explosion will result.

vio – d) Use a fire extinguisher ONLY if:

– 1) You have a class ABC extinguisher, and you know how to operate it. – 2) The fire is small and contained in the area where it started. – 3) The fire department is being called. – 4) You can fight the fire with your back to an exit.

*Based on "Kitchen Firesafety Tips" published by NFPA.

IMPORTANT SAFETY INSTRUCTIONS

 The venti

excessive heat from a gas cooktop.

– When using the ventilation hood over a gas cooktop, ensure that

any burne

off when removing the cookware, even if doing so for just a short

time. – Select cookware that is suitable for the size of the burner. – Adjust the flame so that it never extends up the sides of the

okware.

co – Avoid overheating the cookware (e.g., when cooking with a wok).

 Always turn the ventila

prevent damage from condensation.

 Overheat

on fire. When cooking with oils or fats, do not leave pots, pans or fryers unattended. Never leave an electric grill unattended when grilling.

at and debris deposits impair the proper functioning of the

 F

ventilation hood. To ensure that cooking vapors are properly cleaned, never use the ventilation hood without the grease filters in place.

lation hood may become damaged if exposed to

rs in use are always covered by cookware. Turn burners

tion hood on whenever a burner is in use to

ed oils and fats can ignite and set the ventilation hood

 Ther

instructions in this manual.

 Please no

can cause the ventilation hood to become very hot. Do not touch the housing or the grease filters until the ventilation hood has cooled down.

e is a risk of fire if cleaning is not completed according to the

te that the heat rising from the stovetop during cooking

IMPORTANT SAFETY INSTRUCTIONS

Proper installation

 W

ARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,

OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

– a) Installation work and electrical wiring must be done by

quali

fied person(s) in accordance with all applicable codes and

standards, including fire-rated construction. – b) Sufficient air is needed for combustion and exhausting of

ses through the flue (chimney of fuel burning equipment to

prevent back drafting. Follow the heating equipment

manufacturer’s guideline and safety standards such as those

published by the National Fire Protection Association (NFPA) and

the American Society for Heating, Refrigeration and Air

Conditioning Engineers (ASHRAE), and the local code authorities. – c) When cutting or drilling into the wall or ceiling, do not damage

electrical wiring and other hidden utilities. – d) Ducted hoods must always be vented to the outdoors. – e) Do not use this hood with any solid-state speed control device.

o determine whether a ventilation hood may be operated above

 T

your cooking appliance, please refer to the information provided by the appliance's manufacturer.

 Safety r

above solid fuel stoves.

egulations prohibit the installation of a ventilation hood

 Insufficient distance between the cooking appliance and the

ventil

ation hood can result in damage to the hood. The minimum safety distances between the appliance and the bottom of the ventilation hood specified in the "Installation" section must be maintained, unless the appliance's manufacturer has indicated that a greater distance is required. If more than one cooking appliance is used beneath the ventilation hood, and if different minimum safety distances apply for these appliances, you should use the greater distance.

IMPORTANT SAFETY INSTRUCTIONS

 Be sur

section when mounting the ventilation hood.

 Metal par

Wear gloves to protect your hands from being cut.

e to observe the information contained in the "Installation"

ts can have sharp edges which may cause injury.

 When installing the exhaust duct, only use pipes or tubes made of

non-flammable material. These can be obtained from your Miele dealer or from Miele Technical Service.

 Exhaust air shou

which is otherwise in use and should not be channeled into ducting which ventilates rooms with fuel-burning installations.

exhaust air is to be extracted into a chimney or vent flue no

 If

longer used for other purposes, be sure to comply with all applicable regulations.

ARNING: TO REDUCE THE RISK OF FIRE USE ONLY METAL

 W

DUCTWORK.

ld not be vented into a chimney or vent flue

Cleaning and care

 Never use a st

The steam can reach the electrical components and cause a short circuit.

eam cleaner to clean the ventilation hood.

Accessories

 Use only genuine original Miele parts. If parts or accessories from

other manufacturers are used, the warranty will become void.

IMPORTANT SAFETY INSTRUCTIONS

FCC Declaration of Conformity

 These device

has been tested and found to be in compliance with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules of Operation and is subject to the following conditions: These devices may not cause harmful interference. These devices must accept any interference received, including interference that may cause undesired operation.

s comply with FCC Rules Part 15. This equipment

FCC Radiation Exposure Statement

 This equipment co

forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 8" (20 cm) between the radiator and your body.

mplies with FCC radiation exposure limits set

Industry Canada Statement

 This digi

Radio Noise Emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Complies with Canadian ICES-003 Class B specifications.

tal apparatus does not exceed the Class B limits for

Caring for the environment

Disposal of the packing mat

erial

The cardboard box and packing

erials protect the appliance during

mat shipping. They have been designed to be biodegradable and recyclable.

Ensure that any plastic wrappings, bag

s, etc. are disposed of safely and kept out of the reach of children. Danger of suffocation!

Disposal of your old appliance

Do not dispose of this appliance with your ho

Old appliances may contain materials that can be r your local recycling authority about the possibility of recycling these materials.

Before discarding an old appliance ensur children while being stored for disposal. Unplug it from the outlet, cut off its power cord and remove any doors to prevent hazards.

usehold waste.

ecycled. Please contact

e that it presents no danger to

Description of functions

The following functions are available on your ventilation hood, depending on the model:

Vented mode

The air is drawn in and cleaned by the

ease filters and directed outside.

Non-return flap

A non-return flap in the ducting

events the exchange of inside and

pr outside air from occurring when the ventilation hood is not in use. The flap is closed when the ventilation hood is turned off. When the ventilation hood is turned on, the non-return flap opens so that the exhaust air can be transported outside without any obstruction.

A non-return flap has been provided with the hood in case your ducting does not have o the outlet duct collar of the fan.

ne. It is inserted into

Description of functions

Con@ctivity 2.0 function

Automatic control This hood features a communication

fun

ction which enables the automatic control of the hood based on the operational status of a Miele induction cooktop.

To enable the communication function, the cooktop must be equipped with the corresponding Con@ctivity 2.0 stick .

Please refer to the installation instructions for the Con@ctivity 2.0 stick t

o determine whether connection

to your cooktop is possible.

The cooktop transmits information about its oper using a radio signal.

– When a burner is turned on, the

coo

ktop lighting on the hood turns on automatically. After a brief delay, the ventilation hood fan also comes on.

– During cooking, the hood

automatically selects the fan level based on the number of burners in operation and their power levels.

– Once you have turned off the

coo

ktop, the fan and the lighting will turn off automatically after a predetermined delay.

Detailed information about this function can be found under "Operation."

ational status to the hood

There must be radio contact between the coo able to use the Con@ctivity 2.0 function (see "Activating Con@ctivity 2.0").

ktop and the hood for you to be

Guide to the appliance

515

1 2 3 IS

+ 36 hidden pages
