Midland Rupture Disc Device Maintance Manual

Rupture Disc Devices

Operation
Inspection
and
Maintenance

Doc. No. A-424/A-460 Rev. 1.3 6/18

Supersedes: Rev. 1.2 9/11

ITEM No. PART NAME

1 Top

2 Base

3 Disc

4 Retainer

5 Swing Pin

6 Nut

7 Stud

8 Hinge Pin

9 Eye Bolt Pin

10 Chain

11 Cotter Pin

12 Eye Bolt

13 Wire Seal

Rupture Disc

Devices

CAUTION: IMPORTANT SAFEGUARDS

Midland rupture disc devices are used in connection with a variety of products, many of which
are hazardous materials and could cause serious injury or damage.

Always use extreme caution and proper equipment when involved with hazardous materials.

This device should only be handled by qualified personnel.

Read all of these Instructions carefully before proceeding.

SAVE THESE INSTRUCTIONS!
