User’s Manual
UPRIGHT FREEZER
WHS-507FWEW1 / WHS-507FWESS1
WHS-625FWEW1 / WHS-625FWESS1
WHS-772FWEW1 / WHS-772FWESS1
Contents
Introductions
Important safety Instructions
Grounding requirement
Features
Package contents
Interior
Touch pad controls
Setting up your freezer
Before using your freezer
Finding a suitable location
Leveling your freezer
Providing a proper power supply
Installing the door handle
Using your freezer
Using the lock button
Switching between freezer and refrigerator modes
Quick freezing foods
Switching between fahrenheit and celsius
Maintaining your freezer
Storing your freezer
Moving your freezer
Tips on saving energy
Understanding alerts
High temp alert
Temp out of range alert
Door open alert
How do I reset my freezer to factory defaults
Troubleshootings
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
3
3
5
6
6
6
7
7
7
8
8
8
9
10
11
11
11
12
12
12
12
13
13
13
13
14
14
15
18
2
Introductions
Congratulations on your purchase of a high-quality MIDEA product. Your
represents the state of the art in upright freezer design and is designed
for reliable and trouble-free performance.
Important Safety Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within your freezer.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying your freezer.
WARNING:
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
DO NOT use this appliance near water.
6.
Clean only with a damp cloth.
7.
DO NOT block any ventilation openings.
8.
Install in accordance with the manufacturer’s instructions.
9.
DO NOT install near any heat sources, such as radiators, heat registers,
stoves or other apparatus that produces heat.
10.
DO NOT defeat the safety purpose of the polarized or grounding-type
plug. Apolarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong sre provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
11.
Protect the power cord from being walked on or pinched, particularly
at plugs, convenience receptacles, and rhe point where they exit from
the appliance.
3
12.
DO NOT attempt to modify or extend the power cord of this appliance.
13.
Unplug this appliance during lightning storms or when it will not be
used for long periods of time.
14.
Make sure that the available AC power matches the voltage
requirements of this appliance.
15.
DO NOT handle the plug with wet hands. This could result in an electric
shock.
16.
Unplug the power cord by holding the plug, never by pulling the cord.
17.
DO NOT turn the appliance on or off by plugging or unplugging the
power cord.
18.
Refer all servicing to qualified service personnel. Servicing is required
when the appliance has been damaged in any way, such as the
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the appliance, the appliance has been exposed
to rain or moisture, does not operate normally, or has been dropped.
19.
To reduce the risk of fire or electric shock, DO NOT expose this appliance
to rain, moisture, dripping, or splashing, and no objects filled with
liquids should be placed on top of it.
20.
DO NOT use extension cords or ungrounded (two-prong) adapters.
21.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
22.
Children should be supervised to ensure that they DO NOT play with
the appliance.
23.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarly qualified person, in order
to avoid a hazard.
24.
Take down the doors and leave the shelves in place so that children
may not easily climb inside.
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in electric shock, fire,
or death.
1.
WARNING - Keep ventilation openings, in both the freezer and the
built-in structure, clear of obstruction.
2.
WARNING - DO NOT touch the interior of the freezer with wet hands.
This could result in frost bites.
4
WARNING - DO NOT use mechanical devices or other means to
3.
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING - DO NOT damage the refrigerant circuit.
4.
WARNING - DO NOT damage the refrigerant tubing when handling,
5.
moving or using the freezer.
WARNING - DANGER - Never allow children to play with, operate,
6.
or crawl inside the freezer.
Risk of child entrapment. Before you throw away your old freezer:
1) Take down the doors.
2) Leave the shelves in place so that children may not easily climb
inside.
Unplug the freezer before carrying out user maintenance on it.
7.
This freezer can be used by children age eight years and older and
8.
persons with reduced physical or mental capabilities or lack of
experience and knowledge if they are given supervision or instruction
concerning the use of the freezer in a safe way and understand the
hazards involved. Children should not play with the freezer. Cleaning
and maintenance should not be performed by children without
supervision.
If component part is damaged, it must be replaced the manufacturer,
9.
its service agent or similar qualified persons in order to avoid a hazard.
Please dispose of the freezer according to local regulations as the
10.
freezer contains flammable gas and refrigerant.
Follow local regulations regarding disposal of the freezer due to
11.
flammable refrigerant and gas. All refrigeration products contain
refrigerants, which under the guidelines of federal law must be
removed before disposal. It is the consumer’s responsibility to
comply with federal and local regulations when disposing of this
product.
12.
This freezer is intended to be used in household and similar
environments.
DO NOT store or use gasoline or any flammable liquids inside or
13.
in the vicinity of this freezer.
DO NOT use extension cords or ungrounded (two-prong) adapters with
14.
this freezer. If the power cord is too short, have a qualified electrician
install an outlet near the freezer. Use of an extension cord can
negatively affect the freezer’s performance.
Grounding requirement
This freezer must be grounded. This freezer is equipped with a cord
having a grounding wire with a grounding plug. The plug must be
inserted into an outlet that is properly installed and grounded.
5
Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or service person if the grounding
instructions are not completely understood or if doubt exists as to
whether the freezer is properly grounded.
Features
Package contents
17 / 21 cubic foot upright freezer
•
Door handle, screws and hex wrench
•
Interi
Notes
The illustrations shown in this user guide are only for reference.
The actual product may differ slightly.
1
5
2
3
4
1
Air flow outlet
2
Wire shelf
3
Air flow inlet
4
Wire drawer
5
Door tray
6
Leveling feet (2 - bottom front)
Wheels (2 - Bottom back)
6
