Midea MY-D6004B User Manual

Electric Pressure Cooker

USER MANUAL

MY-D6004B

IMPORTANT NOTE: Please read the manual carefully before operating your
product. Retain it for future reference.
(Picture are for reference only, atual product may differ from picture shown)

单色 双面印刷

20201009

钉

16161000010658

MIDEA-MY-CS6004WP­B(MY-D6004B)-0501

双胶纸 70g

Electric Pressure Cooker

USER MANUAL

MY-D6004B

IMPORTANT NOTE: Please read the manual carefully before operating your
product. Retain it for future reference.
(Picture are for reference only, atual product may differ from picture shown)

IMPORTANT PRECAUTIONS

Caution

1. Read all the instructions

2. This appliance is for household use only. Do not use out­doors.

3. This appliance is not intended for use by persons with
reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance
by a person responsible for their safety.

4. This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children;

5. Children should be supervised to ensure that they do not
play with the appliance;

6. This appliance is intended to be used in household and
similar applications such as:

-Staff kitchen areas in shops, office and other working envi­ronments;

-farm houses;

-by clients in hotels, motels and other residential type envi­ronments;

-bed and breakfast type environments;

7. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agentor similarly qualified per­sons in order to avoid a hazard.

8. Please turn off and unplug the appliance before cleaning,
maintenance or relocation and whenever it is not in use;

9. Do not immerse any part of the appliance in water or other
liquid.

10.The pressure regulator allowing the escape of steam
should be checked regularly to ensure that they are not
blocked.

11.The container must not be opened until the pressure has

decreased sufficiently.

1

IMPORTANT PRECAUTIONS

Caution

12.The heating element surface is subject to residual heat
after use, do not touch.

13.Warning: Avoid spillage on the connector.

14.Warning: Misuse may cause potential injury;

15.The appliance is not intended to be operated by means of
an external timer or a separate remote-control system.

16.Do not put the pressure cooker into a heated oven.

17.Move the pressure cooker under pressure with the greatest
care. Do not touch hot surfaces. Use the handles and
knobs. If necessary, use protection.

18.Do not let children near the pressure cooker when in use.

19.Do not use the pressure cooker for a purpose other than
the one for which it is intended.

20.This appliance cooks under pressure. Scalds may result
from inappropriate use of the pressure cooker. Make sure
that the cooker is property closed before applying heat, see
“instructions for use”.

21.Never force open the pressure cooker. Do not open before
making sure that its internal pressure has completely
dropped. See the “instructions for use”.

22.Never use your pressure cooker without adding water or
food, this would seriously damage it.

23.Do not fill the cooker beyond 2/3 of its capacity. When
cooking foodstuffs which expand during cooking, such as
rice or dehydrate vegetables, do not fill the cooker to more
than half of its capacity.

24.Use the appropriate heat source(s) according to the
instructions for use.

25.After cooking meat with a skin (e.g. ox tongue) which may
swell under the effect of pressure, do not prick the meat
which the skin is swollen; you might be scalded.

26.When cooking doughy food, gently shake the cooker
before opening the lid to avoid food ejection.

2

IMPORTANT PRECAUTIONS

Caution

27.Before each use, check that the valves are not obstructed.
See the instructions for use.

28.Never use the pressure cooker in its pressurized mode for
deep or shallow frying of food.

29.Do not tamper with any of the safety systems beyond the
maintenance instructions specified in the instructions for
use.

30.Only use manufacturer's spare parts in accordance with
the relevant model. In particular, use a body and a lid from
the same manufacturer indicated as being compatible.

31.KEEP THESE INSTRUCTIONS.

The appliance must not be disposed of with regular

household waste. At the end of its service life, the
appliance must be properly delivered to a collection
point for the recycling of electrical and electronic
equipment. By Collection and recycling of old appli­ances, you are making an important contribution to
the conservation of our natural resources and
provide for environmentally sound and healthy
disposal.

Licence holder:

Guangdong Midea Consumer Electric Manufacturing Co., Ltd.
19 Sanle Road, Beijiao, Shunde, 528311 Foshan, Guangdong,
People’s Republic Of China

Importer:

Customer service address:

3

Product Structure

Tips:

1. Please move the product with the handle of the cooker body;

2. Please remove the water from the housing cover with cloth.

Note:

① Exhaust valve: Pull out the exhaust valve from the lid. Clean the internal side

of the exhaust valve and the exhaust valve and float valve of the lid with
brush and cloth at least once a month.

② Sealing ring: Please remove oil and dirt from the sealing ring with detergent

and brush.

③ Water box: After cooking, the steam may stay in the water box of the external

pot as water. Water in the box should be removed for avoiding bad odor,
please clean it with clean cloth.

Disassemble and install the block proof cover and seal ring

Disassemble and install the block proof cover

Block
proof
cover

Disassemble and install the seal ring

Seal ring

Disassemble Install
Pull it out upwards Press it down to install

Disassemble
Pull it out upwards Press it down to install

Install

1. Check if the seal ring
and block proof cover
are correctly installed in
the upper cover before
use each time.

2. After use, please clean
the seal ring and around
of block proof cover for
avoiding jamming the
cover, keep it clean to
avoid bad odor.

1. Please do not pull the
seal ring, otherwise, the
distorted seal ring may
influence the seal and
pressure effect.

2. Do not use the dam
aged seal ring, please
replace it at the autho
rized repair office.

Use and maintain the inner pot

1. Do not empty

It may cause yellowish and spotted inner pot or distorted bottom if it is empty for
a long time.

2. Do not use it to store the acid, alkali and preserved foods for a long
period

Although the inner pot has excellent anti-corrosion performance, it may cause
corrosion of certain degree, the suggested time of keep warm shall not exceed
2h.

4

Use and maintain the inner pot

3. Keep it clean to prolong the service life
Do not immerse it in water for a long period.

Clean the inner pot with soap, mild detergent or warm water to remove dust,
oil and dirt.

4.

Do not use a metal shovel or other hard tool, otherwise it will damage the

inner surface of pot.

Prepare For Cooking

1 Opening the lid correctly

• Hold the handle of upper cover, turn it
anticlockwise for about 30°till the lid at unlock
state, and then lift the upper cover.

2 Check if the parts and accessories of lid
are well installed

• Check if the floater valve and exhaust valve
are jammed, confirm if the sealing ring and
block proof cover are well installed.

3. Take out the inner pot, put the foods and
water into the inner pot

• The total amount of foods and water shall not
exceed the Max marked on the inner pot.

4 Put the inner pot into the cooker

• Wipe to clean the external surface of inner
pot, foreign object and water are not allowed
on the inner surface of electric pressure
cooker;

• Turn the inner pot to left and right to ensure
good contact with the heating plate.

5 Safely close the lid

• Before closing the lid, check if the sealing ring
is well installed.

• Hold the handle of upper cover, aim the lid as
“unlock state”, put the top cover horizontally
on the cooker body, turn the upper cover
clockwise for about 30°to the lock place as
“Lock State”.

6 Put the exhaust valve well

• When working, please turn the exhaust valve
to the sealing place, which means the electric
pressure cooker keeps at sealing state;

• For manual exhaust, please turn the exhaust
valve handle to the exhaust place, the electric
pressure cooker keeps at the exhaust state;

5

(Picture are for reference only, atual
product may differ from picture shown)

Unlock State

Usable Capacity

Lock State

Prepare For Cooking

when exhausting, do not keep the hands or
face above the exhaust opening;

• Check if the floater valve drops down before
working (before heating, the floater valve is
down).

Sealing schematic
diagram

Exhaust schematic
diagram

General Function

1. Switch on If the buttons are inactive when use, please confirm if the lid is closed
at the right place, the buttons are inactive if the lid is not closed correctly for
product of this series.

2. After cooking, the cooker may automatically enter into the keep warm state.
After cooking, the cooker may automatically enter into the keep warm
state(Some funtion). and the indicator display "0H(0 hour), 1H(1 hour), 2H(2

hour)... "or " L0:00(0 min), L0:01(1 min)...."

Tips:

When the cooker is working, it is normal that it makes "cluck" sound, please set

your heart at relax when use.

To cook a small amount of foods, the inner pot may possibly be lifted when opening

the lid, please shake the lid to drop the inner pot in the cooker body and then
remove the lid.

Safely open the lid

1. Cut off power supply or remove the power plug

2. Exhaust method
A. Quickly open the lid (For non-fluid foods)
Turn the exhaust valve to the exhaust place for exhausting, Some unit by
pressing steam release button “ ” till the float valve drops down.
B. Generally open the lid
Keep the electric pressure cooker cool naturally till the float valve drops down.

3. Open the lid
Turn the upper cover anticlockwise with the left hand, turn it to the cover open
limit place, lift the upper cover with the right hand to open the lid.
Do not open the lid before the pressure in the pot has been completely
released, do not open the lid fiercely if it is difficult to open.
Do not pull out the exhaust valve when turning the exhaust valve.
After cooking fluid foods (porridge and soup), do not turn the exhaust valve or
press the steam release button please cut off power supply to make it cool
naturally till the float drops before opening the lid.

6

Technical Data Of The Product

Model Capacity

MY-D6004B

Accessories

Spoon

Soup Spoon

Product Structure

1

2

3

4

Power
Supply

220-240V~
50/60Hz

5

6

7

8

9

10

11

Rated
Power

1000W 8.66"5.7 L

User Manual

No.

1

2

3

4

5

6

7

8

9

10

11

Size of
Inner Pot

Measuring cup

Working
Pressure

80kPa

Description

Lid

Seal ring

Water box(note)

Control Box

Float valve

Exhaust valve(note)

Sealing ring

Block proof cover

Inner pot

Cooker body handle

Cooker body

Keep Warm
Temperature

140° F~176° F

Power Cord
Components

Operation Part

Delay Timer Button

Pressure Level Button

“-” Button

Manual Setting Button

Keep Warm Button

Cooking Timer Button

Display Screen

“+”Button

Menu Button

Menu Function Panel

7

Function Selection

Operation Guidelines

Function

Cancel

Keep warm

Meat
Poultry
Vegetable
Steam
White Rice
Brown Rice
Beans
Broth
Curry
Soup
Multigrain
Congee

Sauté

Operation Guidelines

Exit work state: Press the “Keep Warm/ ” button to exit the

current work state.

Keep warm: Under standby state, Press the “Keep Warm/ ”

button to enter to keep warm state. The indicator display “0H

(0 hour)/1H (1 hour)/2H (2 hours)... ”

1. Normal cooking: Under standby state, press the “Menu” button,
the digital screen flashes “P01”, then press “+” or “-” button,
Select the program number you need. 10s later if no button is
pressed, the product automatically starts cooking, and starts
countdown when pressure rises to working pressure. When
finish cooking, the product will enter to keep warm state.

2. Preset cooking: Before the product starts cooking, press the
“Delay Timer” button to set the preset time, then press the“+” or
“-” button to adjust the timer. 10s later if no button is pressed, the
product automatically starts preset cooking, and starts count­down, when the countdown finishes, the cooking finish.

1. Normal cooking: Under standby state, press the “Menu” button,
the digital screen flashes “P01”, then press “+” or “-” button to
select the program number “P05”. 10s later if no button is
pressed, the product automatically starts cooking, the digital
screen displays countdown “0:30”, when finish, the product will
come back to standby state.

2. Caution: This function shall be no lid when cooking.

Slow Cook

Yogurt

Normal cooking: Under standby state, press the “Menu” button,

the digital screen flashes “P01”, then press “+” or “-” button to
select the program number “P06”. 10s later if no button is
pressed, the product automatically starts cooking, the digital
screen displays countdown “8:00”, when finish, the product will
come back to standby state.

Normal cooking: Under standby state, press the “Menu” button,

the digital screen flashes “P01”, then press “+” or “-” button to
select the program number “P15”. 10s later if no button is
pressed, the product automatically starts cooking, the digital
screen displays countdown “6:00”, when finish, the product will
come back to standby state.

8

Function Selection

Function

Manual
Setting

Operation Guidelines

1. Normal cooking: Under standby state, press the “Manual Setting”
button, the digital screen displays “30”. 10s later if no button is
pressed, the product automatically starts cooking, and starts
countdown when pressure rises to working pressure.

2. Preset cooking: Before the product starts cooking, press the
“Delay Timer” button to set the preset time, then press the“+” or
“-” button to adjust the timer. 10s later if no button is pressed, the
product automatically starts preset cooking, and starts count­down, when the countdown finishes, the cooking finish.

3. Pressure selection: Before the product starts cooking, press the
“Pressure Level” button to set the pressure level at “Low”/
“Medium” / “High” as you need. 10s later if no button is pressed,
the product automatically starts cooking.

9
