Before using your air conditioner, please read
-
-
-
-
-
-
-
-
this manual carefully and keep it for future reference.
WINDOW/WALL TYPE
-
ROOM AIR CONDITIONER
Prior to installation this air-conditioning unit
must be submitted for approval by the utility
service which provides electricity.
SOCIABLE REMARK
When using this air conditioner in the European countries, the following information must be followed:
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
It is prohibited to dispose of this appliance in domestic household waste.
For disposal, there are several possibilities:
A) The municipality has established collection systems, where electronic waste can be
disposed of at least free of charge to the user.
B) When buying a new product, the retailer will take back the old product at least free
of charge.
C) The manufacture will take back the old appliance for disposal at least free of charge
to the user.
D) As old products contain valuable resources, they can be sold to scrap metal dealers.
Wild disposal of waste in forests and landscapes endangers your health when
hazardous substances leak into the ground-water and find their way into the food chain.
CONTENTS
1.SAFETYINSTRUCTIONS.................................................2
2. UNIT PARTS IDENTIFICATION ................. .............................................5
3. AIR CONDITIONER FEATURES.............................................................6
4. CARE AND CLEANING ..........................................................................8
5. INSTALLATION.........................................................................................9
6. TROUBLESHOOTING TIPS.................................................................12
7. SPECIFICATIONS ................................................................................13
Read This Manual
Inside you will find many helpful hints on how to use and maintain your air conditioner
properly. Just a little preventive care on your part can save you a great deal of time
and money over the life of your air conditioner. You'll find many answers to common
problems in the chart of troubleshooting tips. If you review our chart of Troubleshooting
Tips first, you may not need to call for service at all.
!
CAUTION
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
the appliance. Cleaning and user maintenance shall not be made by children without
supervision. ( be applicable for the European Countries )
This appliance is not intended for use by persons (including children) with reduced
physical ,sensory or mental capabilities or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. (be applicable for other countries except the
European Countries )
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
The appliance shall be installed in accordance with national wiring regulations.
Do not operate your air conditioner in a wet room such as a bathroom or laundry room.
The appliance with electric heater shall have at l east 1 m eter s pace t o t he c ombustible
materials.
Contact the authorised service technician for repair or maintenance of this unit.
Contact the authorised installer for installation of this unit.
11
SAFETY PRECAUTIONS
To prevent injury to the user or other people and property damage, the following instructions
must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage.
The seriousness is classified by the following indications.
WARNING
!
CAUTION
!
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage to property.
Meanings of symbols used in this manual are as shown below.
Never do this.
!
!!
Plug in power plug
properly.
Otherwise, it may cause electric
shock or fire due to excess heat
generation.
!!
Do not modify power cord
length or share the outlet
with other appliances.
It may cause electric shock or
fire due to heat generation.
!!
Always ensure effective
earthing.
Incorrect earthing may cause
electric shock.
!!
Unplug the unit if strange
sounds, smell, or smoke
comes from it.
It may cause fire and electric
shock.
!!
Leave the door closed
while the air conditioner
is running.
It is not designed to cool the
entire house.
!!
Ventilate room before operating air
conditioner if there is a gas leakage from
another appliance.
It may cause explosion, fire and, burns.
Always do this.
WARNING
!
Do not operate or stop the
unit by inserting or pulling
out the power plug.
It may cause electric shock or fire
due to heat generation.
Do not operate with wet
hands or in damp
environment.
It may cause electric shock.
Do not allow water to run
into electric parts.
It may cause failure of machine
or electric shock.
Do not use the socket if it is
loose or damaged.
It may cause fire and electric
shock.
Do not use the power cord
close to heating appliances.
It may cause fire and electric
shock.
Do not disassemble or modify unit.
It may cause failure and electric shock.
Do not damage or use an
unspecified power cord.
It may cause electric shock or fire.
If the power cord is damaged, it
must be replaced by the manufac turer or an authorised service
centre or a similarly qualified per son in order to avoid a hazard.
Do not direct airflow at
room occupants only.
This could damage your health.
!!
Always install circuit
breaker and a dedicated
power circuit.
Incorrect installation may cause
fire and electric shock.
Do not open the unit
during operation.
It may cause electric shock.
Do not use the power cord near
flammable gas or combustibles, such
as gasoline, benzene, thinner, etc.
It may cause an explosion or fire.
22
When the air filter is to be
removed, do not touch the
metal parts of the unit.
It may cause an injury.
!!
When the unit is to be
cleaned, switch off, and turn
off the circuit breaker.
Do not clean unit when
power is on as it may cause
fire and electric shock, it may
cause an injury.
!!
Stop operation and close
the window in storm or
hurricane.
Operation with windows
opened may cause wetting
of indoor and soaking of
household furniture.
Do not place obstacles
around air-inlets or inside
of air-outlet.
It may cause failure of
appliance or accident.
CAUTION
!
Do not clean the air
conditioner with water.
Water may enter the unit and
degrade the insulation. It may
cause an electric shock.
Do not put a pet or house
plant where it will be
exposed to direct air flow.
This could injure the pet or
plant.
!!
Hold the plug by the head
of the power plug when
taking it out.
It may cause electric shock
and damage.
!!
Ensure that the installation bracket of
the outdoor appliance is not damaged
due to prolonged exposure.
If bracket is damaged, there
is concern of damage due to
falling of unit.
!!
Ventilate the room well when
used together with a stove,
etc.
An oxygen shortage may occur.
Do not use for special
purposes.
Do not use this air conditioner to
preserve precision devices, food,
pets, plants, and art objects.
It may cause deterioration of
quality, etc.
!!
Turn off the main power
switch when not using the
unit for a long time.
It may cause failure of product
or fire.
!!
Always insert the filters
securely. Clean filter once
every two weeks.
Operation without filters may
cause failure.
Do not use strong detergent such as wax or
thinner but use a soft cloth.
Appearance may be
deteriorated due to change
Do not place heavy object on the
power cord and ensure that the cord
is not compressed.
There is danger of fire or
electric shock.
of product color or
scratching of its surface.
!!
Use caution when unpacking and
installing. Sharp edges could cause injury.
!!
Do not drink water drained
from air conditioner.
It contains contaminants and
could make you sick.
!!
If water enters the unit, turn the unit off at the power
outlet and switch off the circuit breaker. Isolate
supply by taking the power-plug out and contact a
qualified service technician.
