Midea MSG-05CR, MSG-07CR, MSG-09CR, MSG-07HR, MSG-09HR Service Manual
...
MSG-07CRN2; MSG-07HRN2
MSG-09CRN2; MSG-09HRN2
MSG-12CRN2; MSG-12HRN2
MSG-16CRN2; MSG-16HRN2
MSG-18CRN2; MSG-18HRN2
MSG-21CRN2; MSG-21HRN2
Content
- 1 -
Content
1. Precaution....................................................................................................................1
1.1 Safety Precaution ...................................................................................................................... 1
1.2 Warning ..................................................................................................................................... 1
2. Function .......................................................................................................................3
3. Dimension .................................................................................................................... 5
3.1 Indoor unit.................................................................................................................................. 5
3.2 Outdoor unit ............................................................................................................................... 6
4. Specification ................................................................................................................7
5. Refrigerant cycle diagram......................................................................................... 11
6. Operation limits .........................................................................................................12
6.1 Cooling operation..................................................................................................................... 12
6.2 Heating operation .................................................................................................................... 12
7. Schematic diagram and Wiring diagram .................................................................13
7.1 Schematic diagram .................................................................................................................. 13
7.2 Wiring diagram......................................................................................................................... 14
8. Installation details......................................................................................................19
8.1 Wrench torque sheet for installation......................................................................................... 19
8.2 Connecting the cables ............................................................................................................. 19
8.3 Pipe length and the elevation...................................................................................................19
8.4 Air purging of the piping and indoor unit .................................................................................. 20
8.5 Pumping down (Re-installation) ............................................................................................... 21
8.6 Re-air purging (Re-installation) ................................................................................................22
8.7 Balance refrigerant of the 2-way, 3-way valves........................................................................ 23
8.8 Evacuation ............................................................................................................................... 24
8.9 Gas charging ........................................................................................................................... 25
9. Capacity table ............................................................................................................26
9.1 MSG-07CRN2.......................................................................................................................... 26
9.2 MSG-07HRN2.......................................................................................................................... 26
9.3 MSG-09CRN2.......................................................................................................................... 27
9.4 MSG-09HRN2.......................................................................................................................... 27
9.5 MSG-12CRN2.......................................................................................................................... 28
9.6 MSG-12HRN2.......................................................................................................................... 28
9.7 MSG-16CRN2.......................................................................................................................... 29
9.8 MSG-16HRN2.......................................................................................................................... 29
9.9 MSG-18CRN2.......................................................................................................................... 30
9.10 MSG-18HRN2.......................................................................................................................... 30
9.11 MSG-21CRN2.......................................................................................................................... 31
9.12 MSG-21HRN2.......................................................................................................................... 31
10. Electronic function....................................................................................................32
10.1 Electronic control working environment ................................................................................... 32
Content
- 2 -
10.2 Proper symbols and their meaning .......................................................................................... 32
10.3 Function ................................................................................................................................... 32
10.4 Protection................................................................................................................................. 33
10.5 Fan-only mode......................................................................................................................... 33
10.6 Cooling mode........................................................................................................................... 33
10.7 Dehumidifying mode ................................................................................................................ 34
10.8 Heating mode .......................................................................................................................... 35
10.9 Defrosting mode(available for heating mode) .......................................................................... 36
10.10 Auto mode ............................................................................................................................... 37
10.11 Force cooling function.............................................................................................................. 38
10.12 Sleep mode.............................................................................................................................. 38
10.13 Auto restart function................................................................................................................. 39
10.14 Anion (optional)........................................................................................................................ 39
11. Model and Parameters ..............................................................................................40
12. Troubleshooting.........................................................................................................41
12.1 Display board........................................................................................................................... 41
12.2 Troubleshooting ....................................................................................................................... 42
12.3 Diagnostic chart ....................................................................................................................... 43
12.4 Resetting phenomenon often occurs during operation............................................................. 44
12.5 Operation lamp flashes and Timer lamp off. ............................................................................ 44
12.6 Operation lamp flashes and Timer lamp on. ............................................................................ 44
12.7 Operation lamp off and Timer lamp flashes ............................................................................. 45
12.8 Operation lamp on and Timer lamp flashes ............................................................................. 45
12.9 Operation lamp flashes, Timer lamp flashes ........................................................................... 45
13. Characteristic of temperature sensor......................................................................46
Service manual
- 1 -
1. Precaution
1.1 Safety Precaution
To prevent injury to the user or other people and property damage, the following instructions must be followed.
Incorrect operation due to ignoring instruction will cause harm or damage.
Before service unit, be sure to read this service manual at first.
1.2 Warning
¾ Installation
Do not use a defective or underrated circuit breaker.
Use this appliance on a dedicated circuit.
There is risk of fire or electric shock.
For electrical work, contact the dealer, seller, a
qualified electrician, or an Authorized service center.
Do not disassemble or repair the product, there is risk of
fire or electric shock.
Always ground the product.
There is risk of fire or electric shock.
Install the panel and the cover of control box
securely.
There is risk of fire of electric shock.
Always install a dedicated circuit and breaker.
Improper wiring or installation may cause fore or electric
shock.
Use the correctly rated breaker of fuse.
There is risk of fire or electric shock.
Do not modify or extend the power cable.
There is risk of fire or electric shock.
Do not install, remove, or reinstall the unit by
yourself (customer).
There is risk of fire, electric shock, explosion, or injury.
Be caution when unpacking and installing the
product.
Sharp edges could cause injury, be especially careful of
the case edges and the fins on the condenser and
evaporator.
For installation, always contact the dealer or an
Authorized service center.
There is risk of fire, electric shock, explosion, or injury.
Do not install the product on a defective installation
stand.
It may cause injury, accident, or damage to the product.
Be sure the installation area does not deteriorate
with age.
If the base collapses, the air conditioner could fall with it,
causing property damage, product failure, and personal
injury.
Do not let the air conditioner run for a long time
when the humidity is very high and a door or a
windows is left open.
Moisture may condense and wet or damage furniture.
Take care to ensure that power cable could not be
pulled out or damaged during operation.
There is risk of fire or electric shock.
Do not place anything on the power cable.
There is risk of fire or electric shock.
Do not plug or unplug the power supply plug during
operation.
There is risk of fire or electric shock.
Do not touch (operation) the product with wet hands.
There is risk of fire or electric shock.
Do not place a heater or other appliance near the
power cable.
There is risk of fire and electric shock.
Do not allow water to run into electric parts.
It may cause fire, failure of the product, or electric shock.
Do not store or use flammable gas or combustible
near the product.
There is risk of fire or failure of product.
Do not use the product in a tightly closed space for a
long time.
Oxygen deficiency could occur.
When flammable gas leaks, turn off the gas and
open a window for ventilation before turn the
product on.
Do not use the telephone or turn switches on or off.
There is risk of explosion or fire.
If strange sounds, or small or smoke comes from
product. Turn the breaker off or disconnect the
power supply cable.
There is risk of electric shock or fire.
Stop operation and close the window in storm or
hurricane. If possible, remove the product from the
window before the hurricane arrives.
There is risk of property damage, failure of product, or
electric shock.
Do not open the inlet grill of the product during
operation. (Do not touch the electrostatic filter, if the
Service manual
- 2 -
unit is so equipped.)
There is risk of physical injury, electric shock, or product
failure.
When the product is soaked (flooded or submerged),
contact an Authorized service center.
There is risk of fire or electric shock.
Be caution that water could not enter the product.
There is risk of fire, electric shock, or product damage.
Ventilate the product from time to time when
operating it together with a stove, etc.
There is risk of fire or electric shock.
Turn the main power off when cleaning or
maintaining the product.
There is risk of electric shock.
When the product is not be used for a long time,
disconnect the power supply plug or turn off the
breaker.
There is risk of product damage or failure, or unintended
operation.
Take care to ensure that nobody could st ep on or fall
onto the outdoor unit.
This could result in personal injury and product damage.
¾ CAUTION
Always check for gas (refrigerant) leakage after
installation or repair of product.
Low refrigerant levels may cause failure of product.
Install the drain hose to ensure that water is drained
away properly.
A bad connection may cause water leakage.
Keep level even when installing the product.
To avoid vibration of water leakage.
Do not install the product where the noise or hot air
from the outdoor unit could damage the
neighborhoods.
It may cause a problem for your neighbors.
Use two or more people to lift and transport the
product.
Avoid personal injury.
Do not install the product where it will be exposed to
sea wind (salt spray) directly.
It may cause corrosion on the product. Corrosion,
particularly on the condenser and evaporator fins, could
cause product malfunction or inefficient operation.
¾ Operational
Do not expose the skin directly to cool air for long
periods of time. (Do not sit in the draft).
This could harm to your health.
Do not use the product for special purposes, such
as preserving foods, works of art, etc. It is a
consumer air conditioner, not a precision refrigerant
system.
There is risk of damage or loss of property.
Do not block the inlet or outlet of air flow.
It may cause product failure.
Use a soft cloth to clean. Do not use harsh
detergents, solvents, etc.
There is risk of fire, electric shock, or damage to the
plastic parts of the product.
Do not touch the metal parts of the product when
removing the air filter. They are very sharp.
There is risk of personal injury.
Do not step on pr put anything on the product.
(outdoor units)
There is risk of personal injury and failure of product.
Always insert the filter securely. Clean the filter
every two weeks or more often if necessary.
A dirty filter reduces the efficiency of the air conditioner
and could cause product malfunction or damage.
Do not insert hands or other object through air inlet
or outlet while the product is operated.
There are sharp and moving parts that could cause
personal injury.
Do not drink the water drained from the product.
It is not sanitary could cause serious health issues.
Use a firm stool or ladder when cleaning or
maintaining the product.
Be careful and avoid personal injury.
Replace the all batteries in the remote control with
new ones of the same type. Do not mix old and mew
batteries or different types of batteries.
There is risk of fire or explosion.
Do not recharge or disassemble the batteries. Do not
dispose of batteries in a fire.
They may burn of explode.
If the liquid from the batteries gets onto your skin or
clothes, wash it well with clean water. Do not use the
remote of the batteries have leaked.
The chemical in batteries could cause burns or other
health hazards.
Service manual
- 3 -
2. Function
The function will be
operate in any operation
Indoor unit
Operation ON/OFF by remote controller
Room temperature sensor.
Pipe temperature sensor.
Sensing by room temperature
Maintain the room temperature in accordance with the setting temperature.
Room temperature control
Indoor fan is delayed for 5 sec at the starting.
Starting temperature control
Restarting is for approx. 3 minutes..
Time Delay Safety control
High, med, low, breeze.
Indoor fan speed control
Light up in the LED (LCD) for each operation mode.
The unit will decide the louver direction according to operation mode.
Two-direction air vane
The fan is turn to low speed (cooling/heating).
The unit will be turn off after seven hours.
Sleep mode auto control
The function is usually used in rainy days in
springtime or damp areas.
Independent dehumidification
Operation indication Lamps (LED)
The louver can be set at the desired position or swing up and
down automatically
Air flow Direction control
The unit can be change by the room temperature.
Auto mode
Easy clean panel
Flexible wiring connection
Defrost mode
Temp. Compensation
Prevent the cold wind at
the beginning of unit start.
Anti-cold function
Auto-restart function
Self-diag. function
Service manual
- 4 -
The unit can operate in cooling mode at low ambient temperature conditions.
The unit has 3 mins delay between continuously ON/OFF operations.
Outdoor unit
Power relay control
Low ambient kit
Bird tail propeller fan makes the outdoor unit run more quietly.
Low noise air flow system
The hydrophilic fin can improve the heating efficiency at operation mode.
Hydrophilic aluminum fin
It is only operated in the heating operation mode except defrosting operation.
Discharge pipe temperature protect
Anti-rust cabinet
4 way valve control
Made from electrolytic zinc steel sheet and anti-rust coated components.
It protects the valves and prevents water from dripping.
Valve protection
Service manual
- 5 -
3. Dimension
3.1 Indoor unit
Dimension
Mode
WH L
7K 750 250 188
9K 750 250 188
12K 750 250 188
16K 906 286 235
18K 906 286 235
21K 906 286 235
Service manual
- 6 -
3.2 Outdoor unit
Dimension
Mode
W H D L1L2L3
7K 700 535 235 458 280 540
9K 700 535 235 458 280 540
12K 780 540 250 530 315 590
16K 760 590 285 540 335 615
18K 760 590 285 540 335 615
21K 845 695 335 560 360 735
Service manual
- 7 -
4. Specification
MSG-07CRN2 MSG-07HRN2 MSG-09CRN2
Ph-V-Hz
1, 220-240V~,50Hz 1, 220-240V~,50Hz 1, 220-240V~,50Hz
Capacity Btu/h
7000 7000
9000
Input W
780 780
1000
Rated current A
3.5 3.5
4.4
EER Btu/w.h
9.0,2.6 9.0,2.6 9.0,2.6
Capacity Btu/h
----- 8000 -----
Input W
----- 800 -----
Rated current A
----- 3.6 -----
COP W/W
-----
2.9
----A4.4 4.4 6
A
18 18 19.8
Model
PG135X1C-4DZ2 PG135X1C-4DZ2 PG180X1C-4DZ3
Type
Rotary Rotary Rotary
Brand
TOSHIBA TOSHIBA TOSHIBA
Capacity Btu/h 8086/8172 8086/8172 10800
Input W 765/785 765/785 1015
Rated current(RLA) A 3.52/3.34 3.52/3.34 4.5
Locked rotor Amp(LRA) A 21 21.0 19.8
Thermal protector UP3SE0591-T71 UP3SE0591-T71 UP3SE0591-T61
Capacitor uF
25 25 30
Refrigerant oil ml
400 400 400
Model
RPG13H RPG13H RPG13H
Brand Welling Welling Welling
Input W
37.5 36.5 39.5
Capacitor uF
1.2 1.2 1.2
Speed(hi/mi/lo) r/min 1020/960/900 1020/960/900 1100/1020/950
m3/h
430/400/370 430/400/370 470/440/410
dB(A)
35/32/30 35/32/30 36/32/30
Model
YDK24-6T YDK24-6T YDK24-6T
Brand Welling Welling WELLING
Input W
70 70 70
Capacitor uF
333
Speed r/min
850 850 850
m
3
/
h
1500 1500 1600
dB(A)494952
g
650 740 620
MPa
2.8 2.8 2.8
Liquid side/ Gas side mm Ф6.35/Ф9.53 Ф6.35/Ф9.53
Ф6.35/Ф9.53
Max. refrigerant pipe length m 10 10 10
Max. difference in level m 5 5 5
℃
17-30 17-30 17-30
℃
18-45 -7 - 45 18-45
m
2
10-14 10-14 10-14
Model
Power supply
Cooling
Heating
Max. current
Starting current
Compressor
Indoor
fan motor
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R407C
Design pressure
Refrigerant
piping
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
Service manual
- 8 -
MSG-09HRN2 MSG-12CRN2 MSG-12HRN2
Ph-V-Hz
1, 220-240V~,50Hz 1, 220-240V~,50Hz 1, 220-240V~,50Hz
Capacity Btu/h 9000
12000 12000
Input W 1000
1330 1330
Rated current A 4.4
66
EER Btu/w.h
9.0,2.6 9.0 ,2.6 9.0 ,2.6
Capacity Btu/h 11000 -----
14000
Input W 1100 -----
1400
Rated current A 4.9 -----
6.3
COP W/W 2.9 ----- 2.9
A6 7 8
A
19.8
33 33
Model
PG180X1C-4DZ3
PG225X2C-4FT PG225X2C-4FT
Type
Rotary
rotary rotary
Brand
TOSHIBA TOSHIBA TOSHIBA
Capacity Btu/h 10800 13550/13700 13550/13700
Input W 1015 1290/1335 1290/1335
Rated current(RLA) A 4.5 6.1 6.1
Locked rotor Amp(LRA) A 19.8 33 33
Thermal protector UP3SE0591-T61 UP3RE0591-T56 UP3RE0591-T56
Capacitor uF
30
35 35
Refrigerant oil ml
400
480 480
Model
RPG13H RPG18H RPG18H
Brand Welling WELLING WELLING
Input W
38.5 50 50
Capacitor uF
1.2 1.5 1.5
Speed(hi/mi/lo) r/min 1100/1020/950 1250/1150/1050 1250/1150/1050
m3/h
470/440/410
500/450/400 500/450/400
dB(A)
36/32/30 40/36/34 40/36/34
Model
YDK24-6T
YDK25-6C YDK25-6C
Brand Welling WELLING WELLING
Input W
70
68 68
Capacitor uF
3
2.5 2.5
Speed r/min
850
900 900
m
3
/
h
1600 1900 1900
dB(A)525555
g 800 780 1100
MPa
2.8 2.8
2.8
Liquid side/ Gas side mm
Ф6.35/Ф9.53 Ф6.35/Ф12.7 Ф6.35/Ф12.7
Max. refrigerant pipe length m 10 10 10
Max. difference in level m 5 5 5
℃
17-30
17-30 17-30
℃
-7 - 45 18-45 18-45
m
2
14-21 18-26 18-26
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R407C
Design pressure
Refrigerant
piping
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Max. current
Starting current
Compressor
Indoor
fan motor
Model
Power supply
Cooling
Heating
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
Service manual
- 9 -
MSG-16CRN2 MSG-16HRN2 MSG18CRN2
Ph-V-Hz
1, 220-240V~,50Hz 220-240V~,50Hz 220-240V~,50Hz
Capacity Btu/h 16000 16000 17000
Input W 1810 1820 1890
Rated current A 8.3 8.3 8.5
EER Btu/w.h 8.8, 2.6 8.8, 2.6 9.0, 2.63
Capacity Btu/h 18000
Input W 1660
Rated current A 7.6
COP W/W 3.2
A131313
A414141
Model PG295*2CS-4KU1 PG295*2CS-4KU1 PG295*2CS-4KU1
Type Rotary Rotary Rotary
Brand GD Toshiba GD Toshiba GD Toshiba
Capacity Btu/h 18083 18083 18083
Input W 1760 1760 1760
Rated current(RLA) A 8.5 8.5 8.5
Locked rotor Amp(LRA) A 40 40 40
Thermal protector Internal Internal Internal
Capacitor uF 35UF/370V 35UF/370V 35UF/370V
Refrigerant oil ml 750 750 750
Model
RPG25 RPG25 RPG25
Brand WELLING WELLING WELLING
Input W 53 53 53
Capacitor uF 1.5uF/450V 1.5uF/450V 1.5uF/450V
Speed(hi/mi/lo) r/min 1260/1100/1000 1260/1100/1000 1260/1100/1000
m3/h
800/770/740 800/770/740 800/770/740
dB(A) 42/40/38 42/40/38 42/40/38
Model
YDK36-6 YDK36-6 YDK36-6
Brand WELLING WELLING WELLING
Input W
96 96 96
Capacitor uF
2.5μF/450V 2.5μF/450V
2.5μF/450V
Speed r/min
900 900 900
m
3
/
h
1900 1900 1900
dB(A) 53
53 53
g 1380
1380 2200
MPa 2.8
2.8 2.8
Liquid side/ Gas side mm
Ф6.35/Ф12.7 Ф6.35/Ф12.7 Ф6.35/Ф12.7
Max. refrigerant pipe length m 10 10 10
Max. difference in level m 5 5 5
℃
17-30 17-30 17-30
℃
18-45 -7 - 45 18-45
m
2
25-35 25-35 30-40
Model
Power supply
Cooling
Heating
Max. current
Starting current
Compressor
Indoor
fan motor
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R407C
Design pressure
Refrigerant
piping
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
Service manual
- 10 -
MSG-18HRN2 MSG-21CRN2 MSG-21 HRN2
Ph-V-Hz
1, 220-240V~,50Hz 1, 220-240V~,50Hz 1, 220-240V~,50Hz
Capacity Btu/h 17000
18000 18000
Input W 1890
2080 2080
Rated current A 8.5
9.5 9.5
EER Btu/w.h 9.0, 2.63
8.7, 2.54 8.7, 2.54
Capacity Btu/h 19000
----- 22000
Input W 1900
-----
2450
Rated current A 8.6
-----
11.2
COP W/W 2.93
-----
2.63
A131313
A41
44 44
Model PG295*2CS-4KU1
PG340X3CS-4KU2 PG340X3CS-4KU2
Type Rotary
Rotary Rotary
Brand GD Toshiba
TOSHIBA TOSHIBA
Capacity Btu/h 18083 20800 20800
Input W 1760 1970 1970
Rated current(RLA) A 8.5 9.2 9.2
Locked rotor Amp(LRA) A 40
Thermal protector Internal UP3SE0391-T09 UP3SE0391-T09
Capacitor uF 35UF/370V
50 50
Refrigerant oil ml 750
850 850
Model
RPG25 RPG25 RPG25
Brand WELLING WELLING WELLING
Input W 53
53 53
Capacitor uF 1.5uF/450V
1.5 1.5
Speed(hi/mi/lo) r/min 1260/1100/1000 1260/1100/1000 1260/1100/1000
m3/h
800/770/740 800/770/740 800/770/740
dB(A) 42/40/38
41/37/35 41/37/35
Model
YDK36-6 YDK53-6KB YDK53-6KB
Brand WELLING WELLING WELLING
Input W
96 150 150
Capacitor uF
2.5μF/450V 3.0μF/450V 3.0μF/450V
Speed r/min
900 840 840
m
3
/
h
1900 2300 2300
dB(A)535353
g
2100 2200
2100
MPa
2.8 2.8
2.8
Liquid side/ Gas side mm
Ф6.35/Ф12.7 Ф6.35/Ф12.7 Ф6.35/Ф12.7
Max. refrigerant pipe length m 15 20 20
Max. difference in level m 8 10 10
℃
17-30 17-30 17-30
℃
-7 - 45 18-45 -7 - 45
m
2
30-40 34-49 34-49
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R407C
Design pressure
Refrigerant
piping
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Max. current
Starting current
Compressor
Indoor
fan motor
Model
Power supply
Cooling
Heating
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
Service manual
- 11 -
5. Refrigerant cycle diagram
¾ Cooling only
¾ Heat pump mode
Loading...
