Midea MDRF632FG User manual
REFRIGERATOR
Four Door
EN
USER MANUAL
Warning:
Before using this product, please
read this manual carefully and
keep it for future reference.
The design and specifications are
subject to change without prior
notice. Consult with your dealer
or manufacturer for details.
Version: 001-9-2021
MODEL: MDRF632FG
SERIES
www.midea.com
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Dear user
THANK YOU and CONGRATULATIONS on your purchase of this
high-quality Midea product. Your Midea refrigerator is designed for
reliable, trouble-free performance.
For future reference, please record your product model and serial
number on the back of the product or above the compressor
compartment on the right.
Model Number________________________________________
Serial Number_________________________________________
1. SAFETY INFORMATION .................................................................3
Shooting
Trouble
Appendix
2. PROPER USE OF REFRIGERATOR ..............................................11
2.1 PLACEMENT ....................................................................................... 11
2.2 ENERGY SAVING TIPS ................................................................. 12
2.3 CHANGING THE LIGHT ................................................................ 12
2.4 START TO USE ................................................................................ 13
2.5 COMPONENTS ................................................................................14
2.6 FUNCTIONS ..................................................................................... 15
2.7 OPERATING INSTRUCTIONS .....................................................16
2.8 LEVELING DOORS ........................................................................19
2.9 LEVELING FEET ............................................................................. 19
3. MAINTENANCE OF REFRIGERATOR ........................................ 20
3.1 OVERALL CLEANING ................................................................... 20
3.2 CLEANING DOOR TRAY ............................................................. 21
3.3 DEFROSTING ................................................................................... 21
3.4 OUT OF OPERATION ................................................................... 21
4. TROUBLE SHOOTING ..................................................................22
5. APPENDIX .....................................................................................23
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
1. SAFETY INFORMATION
YOUR SAFETY AND THE SAFETY OF OTHERS ARE VERY
IMPORTANT
To prevent injury to the user or other persons and property damage,
these instructions must be followed. Incorrect operation due to ignoring
instructions may cause harm or damage, including death.
The level of risk is shown by the following indications.
This is a prohibition symbol.
Any incompliance with instructions marked with this symbol may result in damage to the product or endanger
Prohibition
symbol
Warning
symbol
Cautioning
symbol
the personal safety of the user.
This is a warning symbol.
It is required to operate in strict observance of instructions marked with this symbol; otherwise damage to the
product or personal injury may be caused.
This is a cautioning symbol.
Instructions marked with this symbol require special caution. Insucient caution may result in slight or
moderate injury or damage to the product.
IMPORTANT SAFETY INSTRUCTIONS
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
Trouble
Appendix
Risk of fire / Flammable materials
WARNING
• This appliance is intended to be used in household and similar
applications such as sta kitchen areas in shops, oces and other
working environments; farm houses and by clients in hotels, motels
and other residential type environments; bed and breakfast type
environments; catering and similar non-retail applications.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
EN-3
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
Trouble
Appendix
• Children should be supervised to ensure that they do not play with
the appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• The appliance has to be unplugged after use and before carrying out
user maintenance.
• WARNING: Keep ventilation openings in the appliance
enclosure or in the built-in structure clear of obstructions.
• WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
• WARNING: Do not damage the refrigerant circuit.
• WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the type
recommended by the manufacturer.
• WARNING: Please dispose of the refrigerator according to local
regulations since it uses flammable blowing gas and refrigerant.
• WARNING: When positioning the appliance, ensure the supply
cord is not trapped or damaged.
• WARNING: Do not place multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
• WARNING: Do not use extension cords or ungrounded
(twoprong) adapters.
• WARNING: To avoid a hazard due to instability of the appliance,
it must be fixed in accordance with the instructions.
• To Prevent Children From Being Entrapped, The Keys Must Be Kept
Out Of Reach Of Children And Not In The Vicinity Of Chest Freezer
(Or Refrigerator) (suitable for products with locks).
EN-4
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
DANGER
• Risk of child entrapment. Before you dispose of your old refrigerator
or chest freezer:
-Take o the doors.
-Leave the shelves in place so that children may not easily climb inside.
• The refrigerator must be disconnected from mains power before
attempting the installation of accessories.
• Refrigerant and cyclopentane foaming material used for the appliance
are flammable. Therefore, when the appliance is scrapped, it shall
be kept away from any fire source and be recovered by a special
recovering company with corresponding qualification other than be
disposed by combustion, so as to prevent damage to the environment
or any other harm.
• For doors or lids fitted with locks, the keys must be kept out of reach
of children and not in the vicinity of the refrigerating appliance, in
order to prevent children from being locked inside.
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
Trouble
Appendix
EN-5
Information
Safety
For EU standard:
• This appliance can be used by children aged from 8 years and above
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
Trouble
Appendix
• To avoid contamination of food, please observe the following
• For a freestanding appliance: this refrigerating appliance is not
• Any replacement or maintenance of the LED lamps is intended to
• This product contains two light sources of energy eciency class (G).
WARNING
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning the use of the appliance in a safe way
and understand the hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance shall not be made by
children without supervision. Children aged from 3 to 8 years are
allowed to load and unload refrigerating appliances.
instructions:
– Opening the door for long periods of time can cause a significant
increase of the temperature in the compartments of the appliance.
– Clean regularly surfaces that can come in contact with food and
accessible drainage systems.
– Clean water tanks if they have not been used for 48h; flush the
water system connected to a water supply if water has not been
drawn for 5 days. (Note 1)
– Store raw meat and fish in suitable containers in the refrigerator, so
that it is not in contact with or drip onto other food.
– Two-star
pre-frozen food, storing or making ice-cream and making ice cubes.
(Note 2)
– One-star
not suitable for freezing fresh food. (Note 3)
– For appliances without a 4-star
refrigerating appliance is not suitable for freezing foodstus. (Note 4)
– If the refrigerating appliance is left empty for long periods of time,
switch o, defrost, clean, dry, and leave the door open to prevent
mould developing within the appliance.
Notes 1, 2, 3, 4: Please confirm whether it is applicable according to
your product.
intended to be used as a built-in appliance.
be made by the manufacturer, its service agent or similar qualified
persons.
frozen-food compartments are suitable for storing
, two-star and three-star compartments are
compartment: this
EN-6
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
State of California Proposition 65 Warnings:
WARNING: Cancer and Reproductive Harm
-www.P65Warnings.ca.gov.
PROPER DISPOSAL
Information
Safety
Proper Use of
Refrigerator
WARNING
Suocation Hazard
Before you dispose of your old chest freezer or refrigerator:
• Remove the door or lid so that children cannot hide or get trapped
inside your old appliance.
• Leave any shelves in place so that children may not easily climb inside.
• Failure to follow these instructions can result in death or brain damage.
IMPORTANT:
Flammable gas and refrigerant used. It is the consumer’s responsibility to comply
with Federal and Local regulations when disposing of this product. Refrigerants must
be evacuated by a licensed, EPA-certified refrigerant technician in accordance with
established procedures.
Maintenance of
Refrigerator
Shooting
Trouble
Appendix
EN-7
ELECTRICITY-RELATED
WARNINGS
Information
Refrigerator
Refrigerator
Shooting
• Do not pull the power cord
Safety
• To ensure safe use, do not
Proper Use of
• Please use a dedicated power
Maintenance of
Trouble
when pulling the power plug of
the refrigerator. Please firmly
grasp the plug and pull out from
the socket.
damage the power cord or
use the power cord when it is
damaged or worn.
socket; the power socket
shall not be shared with other
electrical appliances.
• Do not use electrical
appliances on top of the
appliance, unless they are of
the type recommended by the
manufacturer.
WARNINGS RELATED
TO PLACING ITEMS
• Do not place flammable,
explosive, volatile and
highly corrosive items in the
refrigerator to prevent damages
to the product or fire accidents.
• Do not place flammable items
near the refrigerator to avoid
fire.
Appendix
• The power cord should be firmly
contacted with the socket,
otherwise fire may be caused.
• Please ensure that the
grounding electrode of the
power socket is equipped with a
reliable grounding line.
• Please turn o the valve of
leaking gas and open the doors
and windows in case of leakage
of gas and other flammable
substances. Do not unplug the
refrigerator and other electrical
appliances considering that
spark may cause a fire.
• This product is a household
refrigerator and is only suitable
for the storage of food.
According to national standards,
a household refrigerator shall
not be used for other purposes,
such as storage of blood, drugs
or biological products.
• Do not store beer, beverages
or other fluids contained in
bottles or enclosed containers
in the freezing chamber of
the refrigerator, otherwise the
bottles or enclosed containers
may crack due to freezing and
cause damages.
Freezing chamber
EN-8
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
WARNINGS FOR USE
• Do not arbitrarily disassemble
or reconstruct the refrigerator,
nor damage the refrigerant
circuit; maintenance of the
appliance must be conducted by
a specialist.
• A damaged power cord must be
replaced by the manufacturer,
its maintenance department or
related professionals in order to
avoid danger.
• The gaps between refrigerator
door and body are small. Do
not place your hands in these
areas to prevent squeezing your
fingers. Please be gentle when
opening the refrigerator door to
avoid articles falling out.
• Do not pick up food or
containers with wet hands in
the freezing chamber when the
refrigerator is running, especially
metal containers in order to
avoid frostbite.
• Do not allow children to enter or
climb inside the refrigerator to
prevent that children are sealed
in the refrigerator or injured by
the falling refrigerator.
• Do not spray or wash the
refrigerator; do not place the
refrigerator in moist places easy
to be splashed with water so
as not to aect the electrical
insulation properties of the
refrigerator.
• Do not place heavy objects
on top of the refrigerator
considering that objects may
fall when opening the door, and
accidental injuries might be
caused.
• Please pull out the plug in case
of power failure or cleaning. Do
not connect the refrigerator
to power supply within five
minutes to prevent damages
to the compressor due to
successive starts.
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
Trouble
Appendix
EN-9
ENERGY WARNINGS
1. Refrigerating appliances
Information
Information
Safety
Safety
Proper Use of
Proper Use of
Refrigerator
Refrigerator
2. Sparkling beverages shall not
Maintenance of
Maintenance of
Refrigerator
Refrigerator
Shooting
Shooting
Trouble
Trouble
DISPOSAL
Appendix
Appendix
might not operate consistently
(possibility of defrosting
of contents or temperature
becoming too warm in the
frozen food compartment)
when set for an extended
period of time below the cold
end of the temperature range
for which the refrigerating
appliance is designed.
be stored in a freezing chamber
or a lower temperature
compartment. Certain drinks
(such as ice water) shall not be
too cold for drinking.
Refrigerant and cyclopentane foaming material used for the
refrigerator are flammable. Therefore, when the refrigerator
is scrapped, it shall be kept away from any fire source and be
recovered by a special recovering company with corresponding
qualification other than be disposed by combustion, so as to
prevent damage to the environment or any other harm.
time(s) recommended by the
food manufacturers for any
kind of food and particularly for
commercially quick-frozen food
in food-freezer and frozenfood storage compartments or
cabinets.
4. Prevent an undue rise in
temperature of frozen
food while defrosting the
refrigerating appliance, such
as wrapping the frozen food in
several layers of newspaper.
5. A rise in temperature of frozen
food during manual defrosting,
maintenance or cleaning can
shorten the storage life.
3. Do not exceed the storage
When the refrigerator is scrapped, disassemble the doors, and
remove gaskets of door and shelves; place the doors and shelves
in a proper place, so as to prevent trapping children.
Correct Disposal of this product:
This marking indicates that this product should not be
disposed with other household waste. To prevent possible
harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact
the retailer where the product was purchased. They take this
product in for environmental safe recycling.
EN-10
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
2. PROPER USE OF REFRIGERATOR
2.1 PLACEMENT
• Before use, remove all packing
materials, including bottom
pads, foam pads and tapes
inside of the refrigerator; tear
o the protective film on the
doors and the refrigerator body.
• Keep away from heat and
avoid direct sunlight. Do not
place the refrigerator in moist
or wet places to prevent rust
or reduction of the insulating
eect.
• Do not spray or wash the
refrigerator; do not place the
refrigerator in moist places easy
to be splashed with water so
as not to aect the electrical
insulation properties of the
refrigerator.
• Spare enough space for
convenient opening of doors
and drawers according to the
statement of the distributor.
10cm
W
W
135°
A
10cm
10cm
B
10cm
Front View
Top View
Width “W”
Depth “D”
(without handle)
Height “H”
A
B
The measurements in the above table
may dier, depending on the measuring
method.
10cm
H
D
Side View
833
653
1775
1400
1000
(unit: mm)
10cm
Information
Information
Safety
Safety
Proper Use of
Proper Use of
Refrigerator
Refrigerator
Maintenance of
Maintenance of
Refrigerator
Refrigerator
Shooting
Shooting
shooting
Trouble
Trouble
Trouble
Appendix
Appendix
The space on top of the
•
refrigerator shall be greater
than 10cm, and the refrigerator
should be placed against a
wall with a distance of more
than 10cm to facilitate heat
dissipation.
NOTE
This refrigerator needs to be installed
independently and cannot be built-in.
Otherwise, it will cause problems such
as failure to install, performance and life
of the product are reduced. Also, the
manufacturer does not provide basic
product warranty.
EN-11
2.2 ENERGY SAVING
TIPS
2.3 CHANGING THE
LIGHT
Information
Safety
• Let hot foods cool down to
Proper Use of
Refrigerator
Maintenance of
Refrigerator
• Be sure to wrap food properly,
• The appliance should be located
Shooting
shooting
Appendix
• Appliance storage bins should
Trouble
Trouble
• Organize and label food to
in the coolest area of the room,
away from heat producing
appliances or heating ducts, and
out of direct sunlight.
room temperature before
placing it in the appliance.
Overloading the appliance
forces the compressor to run
longer. Food that freezes too
slowly may lose quality, or spoil.
and wipe containers dry before
placing them in the appliance.
This cuts down on frost build-up
inside the appliance.
not be lined with tin foil, wax
paper, or paper toweling.
Liners interfere with cold
air circulation, making the
appliance less ecient.
reduce door openings and
extended searches. Remove as
many items as needed at one
time, and close the door as soon
as possible.
• Any replacement or
maintenance of the LED lamps
is intended to be made by the
manufacturer, its service agent
or similar qualified persons.
The light source in this product is
only to be replaced by qualified
engineers.
1. First remove the plug.
2. Remove the light cover with a
screwdriver.
3. Take down the lamp panel.
4. Remove the connection terminal.
EN-12
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
2.4 START TO USE
• Before initial start, keep the
refrigerator still for two hours
before connecting it to power
supply.
• Before placing any fresh or
frozen foods, the refrigerator
should have run for 2 - 3 hours,
or for above 4 hours in summer
when the ambient temperature
is high.
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
NOTE
This product is not recommended for use
with sockets or main switch with A/GFCI
function, otherwise it may cause tripping.
1. It does not pose a safety risk when
tripped.
2. If tripping persists, it is recommended
to replace the socket or main switch
without A/GFCI function.
Shooting
shooting
Trouble
Trouble
Appendix
EN-13
Information
Safety
2.5 COMPONENTS
(Refrigerating chamber)
Door tray
LED lighting
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
shooting
Trouble
Trouble
Appendix
Refrigerating chamber
• The Refrigerating Chamber is
• Cooked food should not be
• Food is recommended to be
• The glass shelves can be
Shelf
Big drawer
Upper drawer
Middle drawer
Bottom drawer
The picture above is only for reference. The actual configuration will depend on the
physical product or statement by the distributor
Freezing chamber
• The low temperature freezing
suitable to store of a variety of
fruits, vegetables, beverages and
other food consumed in the short
term; suggested storage time 3
to 5 days.
placed in the refrigerating
chamber until cooled down to
room temperature.
sealed up before placing it into
the refrigerator.
adjusted up or down for proper
storage space and easy use.
chamber may keep food fresh for
a long time and it is mainly used
to store frozen food and making
ice.
• The freezing chamber is suitable
to store meat, fish, rice balls and
other food not to be consumed
short-term.
• Chunks of meat are preferably to
be divided into small pieces for
quick freezing and easy access.
Please note that food should be
consumed within the shelf life.
• Freezing capacity value is
marked on the rating label.
EN-14
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
IMPORTANT:
Drawers, food boxes, shelves, etc. placed according to the position in the picture above
are the most energy ecient.
When the product is tested according to IEC 62552:2007, the test conditions are as
follows: Remove the middle drawer of the freezing compartment and move the upper
drawer to the middle drawer position.
NOTE
Storage of too much food during operation after the initial connection to power may
adversely aect the freezing eect of the refrigerator. Food stored should not block the
air outlet; or otherwise the freezing eect will also be adversely aected
2.6 FUNCTIONS
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
shooting
Trouble
Trouble
Appendix
The picture above is only for reference. The actual configuration will depend on the
physical product or statement by the distributor
1. Screen
①Refrigerator icon
②Freezer icon
③Super cool/freezing icon
④Temperature display icon
⑤Fruit/vegetable icon
⑥Meat icon
2. Control buttons
A. Temperature up button
B. Temperature zone selection button
C. Temperature down button
D. Super cool/freezing button
E. Variable temperature button
F. Lock/unlock button
⑦Drink icon
EN-15
2.7 OPERATING INSTRUCTIONS
Information
Safety
• The first time the power is turned on, the complete display will light
Proper Use of
Refrigerator
• In case of error, the display shows the error code in the refrigerating
Display
• Under normal circumstances, if there is no any manual operation of the
Maintenance of
Refrigerator
Lock /unlock
Shooting
shooting
• In unlocked state, press and hold the lock button for 3 seconds to
Trouble
Trouble
• The logo goes out and the buzzer sounds to confirm that the display
• In locked state, press and hold the lock button for 3 seconds to
Appendix
• The logo lights up and the buzzer sounds to confirm that the display
up for 3 seconds. The starting beep sounds and the screen enters
normal operation. First time using the refrigerator, temperatures of the
refrigerating and freezing chambers should be set to 5°C and -18°C
respectively.
temperature display area (see next page); during normal operation, the
display shows the set temperature of the cooling compartment.
refrigerator for 30 seconds, the control panel will lock automatically,
and in locked state, the display light will go out after 30 seconds.
enter the lock state.
panel is locked, all buttons are locked.
enter the unlocked state.
panel is unlocked, all buttons are working again.
Temperature setting of refrigerating chamber
• Press the temperature zone selection button to choose the
setting temperature zone of the refrigerating chamber, then press
button
or to adjust the setting temperature of the refrigerating
chamber. The temperature setting range for the refrigerating chamber
is 2°C to 8°C.
Temperature setting of freezing chamber
• Press the temperature zone selection button to choose the
setting temperature zone of the freezing chamber, then press button
or to adjust the setting temperature of the freezing chamber. The
temperature setting range for the freezing chamber is -24°C to -16°C.
EN-16
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
Temperature setting of variable temperature chamber
• Press the vario temperature button to adjust the setting
temperature of the vario chamber, the adjusting range is
fruit/vegetables, drinks and meat.
Mode setting
Information
Safety
• When super cool mode is set, the temperature of the refrigerating
chamber is automatically set to 2°C; super cool mode is exited after
6hours.
• Exit super cool mode mode, and the temperature of the
refrigerating chamber will automatically return to the previously set
temperature.
• When super freezing mode is set, the temperature of the freezing
chamber is automatically set to -24°C; defrosting starts after 18 hours
and the mode is exited after 24 hours.
• Exit super freezing mode , and the temperature of the freezing
chamber will automatically return to the previously set temperature.
• According to IEC62552:2007, the testing condition is as follows: start
the super freezer mode in advance, and wait until the fridge enters
automatic defrosting, then apply the freezer load.
• The maximum defrosting time is 72 hours and the minimum is 12 hours
at 32°C.
• Recommended setting: refrigerating chamber 4°C, freezing chamber
-18°C.
Sabbath mode
• Unlock the fridge, then simultaneously press and hold the and lock
buttons for 4 seconds to access Sabbath mode. Press any key to exit. In
this mode the fridge status is as follows:
a. Display control board and lights remain o, no alarm.
b. The refrigerator cools normally.
c. Within five minutes of opening the door, compressor and fan motor
status do not change.
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
shooting
Trouble
Trouble
Appendix
Storage upon power failure
• In case of power failure, the working mode will be locked and
maintained until the power is back.
EN-17
Fault indication
• The following warnings appearing on the display indicate
Information
Safety
Error code Error description
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
shooting
Trouble
Trouble
Appendix
corresponding faults of the refrigerator. Though the refrigerator
may still have cold storage function with the following faults, please
contact a maintenance specialist to ensure optimized operation of the
appliance.
E1 Temperature sensor failure of refrigerating chamber
E2 Temperature sensor failure of freezing chamber
E3 Temperature sensor failure of vario chamber
E4 Failure defrosting sensor in the refrigerating chamber
E5 Freezing defrost sensor detection circuit error
E6 Communication error
E7 Circulation of temperature detection circuit error
EH Moisture sensor error
NOTE
When the set temperature of the freezer changes, if set relevant function mode (e.g.
quick-cold mode, quick-freezer mode, quick-cold and freezer mode, vocation mode), the
relevant function mode should be quit or canceled at once.
NOTE
The quick freezing function is designed to maintain the nutritional value of the food in the
freezer. It can freeze the food in the shortest possible time. If a large amount of food is
frozen at one time, we recommend turning on the quick-freezing function. At this time, the
freezing speed of the freezer compartment is increased, which can quickly freeze the food,
eectively lock the nutrition of the food, and facilitate storage. In case of power failure,
the working mode is locked and maintained.
EN-18
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
2.8 LEVELING DOORS
Precautions before operation:
• Before making changes
the refrigerator must be
disconnected from power.
Before adjusting the door,
precautions should be taken to
prevent any personal injury.
• Schematic diagram of leveling
the door body
List of tools to be provided to the user
pliers
Hinge
Pliers
grommet
Not level
The picture above is only for reference.
The actual configuration will depend on
the physical product or statement by the
distributor
1) Raise the lower door up to the
level of the higher door.
2) Insert the supplied washers
in the gap between the hinge
grommet and the lower hinge by
using pliers. The number of washers
you will need to insert depends on
the gap.
When the fridge door is low:
Open the door; use a wrench to
loosen the locking nut and to turn
the adjusting nut counter-clockwise
to raise the door. Once the doors
are aligned, tighten the locking nut
by turning it anti-clockwise.
Washer
Lower hinge
When the fridge door is high:
Open the door; use a wrench to
turn the adjusting nut clockwise to
lower the door. Once the doors are
aligned, tighten the locking nut by
turning it anti-clockwise.
2.9 LEVELING FEET
1) Precautions before operation:
Before making changes the
refrigerator must be disconnected
from power.
Before adjusting the leveling feet,
precautions should be taken to
prevent any personal injury.
2) Schematic diagram of leveling
feet
3) Adjusting procedures:
a. Turn the feet clockwise to raise
the refrigerator.
b. Turn the feet counter-clockwise
to lower the refrigerator.
c. Adjust the right and left feet
based on the procedures above to
a horizontal level.
IMPORTANT:
The picture above is only for reference.
The actual configuration will depend on
the physical product or statement by the
distributor
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
shooting
Trouble
Trouble
Appendix
EN-19
3. MAINTENANCE OF REFRIGERATOR
Information
Refrigerator
Refrigerator
3.1 OVERALL CLEANING
Safety
• Dust behind the refrigerator and
Proper Use of
• Check the door gasket regularly
Maintenance of
• The interior of the refrigerator
• Please turn o the power before
Shooting
Trouble
• Use a soft cloth or sponge
Appendix
• For areas that are dicult to
• Do not use soap, detergent,
on the floor must be cleaned to
improve the cooling eect and
energy saving.
to make sure there is no debris.
Clean the door gasket with a
soft cloth dampened with soapy
water or diluted detergent.
should be cleaned regularly to
avoid odors.
cleaning the interior, remove all
food, drink, shelves, drawers,
etc.
to clean the inside of
the refrigerator with two
tablespoons of baking soda and
a quart of warm water. Then
rinse with water and wipe clean.
After cleaning, open the door
and let it dry naturally before
turning on the power.
clean inside the refrigerator
(such as narrow places, gaps
or corners), we recommend to
wipe them regularly with a soft
rag, soft brush, etc. and when
necessary, with some tools
(such as thin sticks) to ensure
no contaminants or bacterial
accumulation in these areas.
scrub powder, spray cleaner,
etc., as these may cause odors
inside the refrigerator or
contaminate food.
• Clean the door tray, shelves
and drawers with a soft cloth
dampened with soapy water or
diluted detergent. Dry with a
soft cloth or dry naturally.
• Wipe the outer surface of the
refrigerator with a soft cloth
dampened with soapy water,
detergent, etc., and then wipe
dry.
• Do not use hard brushes,
scouring pads, wire brushes,
abrasives (such as toothpaste),
organic solvents (such as
alcohol, acetone, banana oil,
etc.), boiling water, acid or
alkaline items, which may
damage the fridge surface
and interior. Boiling water
and organic solvents such as
benzene may deform or damage
plastic parts.
• Do not rinse directly with
water or other liquids during
cleaning to avoid short circuit or
aect electrical insulation after
immersion.
Unplug the refrigerator for defrosting and
cleaning.
EN-20
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
3.2 CLEANING DOOR
TRAY
The picture above is only for reference.
The actual configuration will depend on
the physical product or statement by the
distributor
• Use both hands to squeeze
the tray and push it upward to
remove it (see arrows in the
Figure below).
• You can adjust the installation
height according to your
requirement.
3.3 DEFROSTING
• The refrigerator is made based
on the air-cooling principle
and thus has automatic
defrosting function. Frost
formed due to change of
season or temperature may
also be manually removed by
disconnection of the appliance
from power supply or by wiping
with a dry towel.
3.4 OUT OF OPERATION
• Power failure: In case of power
failure, even if it is in summer,
food inside the appliance can
be kept for several hours; during
the power failure, the times
of opening the doors must be
reduced, and no more fresh
food should be placed into the
appliance.
• Long-term non-use: Unplug
and clean the appliance and
leave the doors open to prevent
odors.
• Moving: Before the refrigerator
is moved, take all objects
out, fix the glass partitions,
vegetable holder, freezing
chamber drawers etc. with tape,
and tighten the leveling feet;
close the doors and fix them
with tape. During the move,
the appliance must not be laid
upside down or horizontally, or
be exposed to strong vibration;
the inclination during the move
should be no more than 45°.
Information
Safety
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
Trouble
Appendix
IMPORTANT:
The appliance shall run continuously once
it is started. Generally, the operation of
the appliance shall not be interrupted;
otherwise the service life may be
impaired
EN-21
4. TROUBLE SHOOTING
The following simple issues can be handled by the user. Please call the
Information
Information
Refrigerator
Refrigerator
Refrigerator
Refrigerator
Shooting
Shooting
Appendix
Appendix
after-sale service department if the issues are not solved.
Safety
Safety
Proper Use of
Proper Use of
Maintenance of
Maintenance of
Trouble
Trouble
Malfunction Check whether the appliance is connected to power or whether the plug
Odor Odorous food should be tightly wrapped.
Long operation of
the compressor
Light fails to turn onCheck whether the refrigerator is connected to power supply and
Door cannot be
properly closed
Loud noises Check whether the floor is level and whether the refrigerator is placed in
Door seal fails to
be tight
Water pan
overflows
Hot housing Heat dissipation of the built-in condenser via the housing, which
Surface
condensation
Abnormal noise Buzz: The compressor may produce buzzes during operation, and the
is inserted properly.
Check whether the voltage is too low.
Check whether there is a power failure or circuits have tripped.
Check whether there is any rotten food.
Clean the inside of the refrigerator.
Long operation of the refrigerator is normal in summer when the
ambient temperature is high.
We do not suggest placing too much food in the appliance at the same
time.
Food must cool down before being placed in the appliance.
The doors are opened too frequently.
whether the illuminating light is damaged.
Have the light replaced by a specialist.
The door is stuck by food packages.
Too much food inside.
The refrigerator is tilted.
a stable position.
Check whether accessories are placed at proper locations.
Remove foreign matters on the door seal.
Heat the door seal and then cool it for restoration
(or blow it with an electrical drier or use a hot towel for heating).
There is too much food in the chamber or food stored contains too
much water, resulting in heavy defrosting.
The doors are not closed properly, resulting in frosting due to entry of
air and increased water due to defrosting.
is normal. When the housing becomes hot due to high ambient
temperature, storage of too much food or shutdown of the compressor,
provide good ventilation to facilitate heat dissipation.
Condensation on the exterior surface and door seals of the refrigerator is
normal when the ambient humidity is too high. Just wipe the condensate
with a clean towel.
buzzes are loud particularly upon start or stop. This is normal.
Creak: Refrigerant flowing inside the appliance may produce creak,
which is normal.
EN-22
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
5. APPENDIX
Installation Instructions
For refrigerating appliances with climate class
Depending on the climate class, this refrigerating appliance is intended to
be used at ambient temperature ranges as specified following table.
The climate class can be found on the rating plate. The product may not
operate properly at temperatures outside of the specified range.
You can find the climate class on the label inside your refrigerator
Eective temperature range
The refrigerator is designed to operate normally in the temperature range
specified by its class rating.
Ambient temperature range °C
Class Symbol
IEC 62552
(ISO 15502)
ISO 8561
Information
Information
Safety
Safety
Proper Use of
Proper Use of
Refrigerator
Refrigerator
Maintenance of
Maintenance of
Refrigerator
Refrigerator
Extended
temperate
SN +10 to +32 +10 to +32
Temperate N +16 to +32 +16 to +32
Subtropical ST +16 to +38 +18 to +38
Tropical T +16 to +43 +18 to +43
NOTE
The cooling performance and power consumption of the refrigerator may be aected by
the ambient temperature, the door-opening frequency, and the location of the refrigerator.
We recommend adjusting the temperature settings as appropriate.
Shooting
Shooting
shooting
Trouble
Trouble
Trouble
Appendix
Appendix
EN-23
How to store for best preservation (applicable models only)
Cover food to retain moisture and prevent them from picking up odors
from other food. A large pot of food like soup or stew should be divided
into small portions and put in shallow containers before being refrigerated.
Information
A large cut of meat or whole poultry should be divided into smaller pieces
Safety
or placed in shallow containers before being refrigerated.
Placement of foods
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
shooting
Trouble
Trouble
Appendix
Shelves Shelves are adjustable to accommodate a variety of
packages.
Specialized
compartment
(applicable
models only)
Sealed crisper drawers provide an optimal storage
environment for fruit and vegetables. Vegetables require
higher humidity while fruit requires lower humidity.
Crispers are equipped with control devices to control
the humidity level (*depending on model and options).
An adjustable temperature meat drawer maximizes the
storage time of meat and cheese.
Storage in the
door
Do not store perishable food in the door. Eggs should
be stored in the carton on a shelf. The temperature of
the storage bins in the door fluctuates more than the
temperature inside the cabinet. Keep the door closed as
much as possible.
Freezer
compartment
You can store frozen food, make ice cubes and freeze fresh
food in the freezer compartment.
NOTE
Freeze fresh, undamaged food only. Keep food which is to be frozen away from food which
is already frozen. To prevent food from losing its flavor or drying out, place in airtight
containers.
EN-24
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
Refrigerator & Freezer Storage Chart
The shelf life depends on temperature and exposure to moisture. Since product
dates are not a guide for the safe use of a product, consult this chart and follow
these tips.
Milk products
Product Refrigerator Freezer
Milk 1 week 1 month
Butter 2 weeks 12 months
Ice cream - 2 - 3 weeks
Natural cheese 1 month 4 - 6 months
Cream cheese 2 weeks Not recommended
Yogurt 1 month -
Information
Safety
Proper Use of
Refrigerator
Meat
Product Refrigerator Freezer
Fresh roasts, steaks, chops 3 - 4 days 2 - 3 months
Fresh ground meat, stew meat 1 - 2 days 3 - 4 months
Bacon 7 days 1 month
Sausage, raw from pork, beef,
turkey
1 - 2 days 1 - 2 months
Poultry / Eggs
Product Refrigerator Freezer
Fresh poultry 2 days 6 - 8 months
Poultry salad 1 day Eggs, Fresh in shell 2 - 4 weeks Not recommended
Fish / Seafood
Product Refrigerator Freezer
Fresh fish 1 - 2 days 3 - 6 months
Cooked fish 3 - 4 days 1 month
Fish salad 1 day Not recommended
Dried or pickled fish 3 - 4 weeks -
Fruit
Product Refrigerator Freezer
Apples 1 month Peaches 2 - 3 weeks Pineapple 1 week Other fresh fruit 3 - 5 days 9 - 12 months
Vegetables
Product Refrigerator Freezer
Asparagus 2 - 3 days Broccoli, Brussels sprouts, green
peas, mushrooms
Cabbage, cauliflower, celery,
cucumbers, lettuce
Carrots, beets, radishes 2 weeks -
3 - 5 days -
1 week -
Maintenance of
Refrigerator
Shooting
shooting
Trouble
Trouble
Appendix
EN-25
Information
Safety
SPECIAL FOR NEW EUROPEAN STANDARD
The ordered parts in the following table can be acquired through service
provider
Ordered part Provided by Minimum time required for
provision
Thermostat Professional maintenance
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Shooting
shooting
Trouble
Trouble
Appendix
Temperature
sensor
Printed circuit
board
Light source Professional maintenance
Door handle Professional repairers and
Door hinges Professional repairers and
Trays Professional repairers and
Baskets Professional repairers and
Door gaskets Professional repairers and
Dear customer
1. If you want to return or replace the product, please contact the store
where you bought it.
Remember to bring proof of purchase.
2. If your product breaks down and needs to be repaired, please contact
the after-sales service provider.
The shortest period for providing after-sales spare parts is 15 working
days.
personnel
Professional maintenance
personnel
Professional maintenance
personnel
personnel
final users
final users
final users
final users
final users
At least 7 years after the model
was launched
At least 7 years after the model
was launched
At least 7 years after the model
was launched
At least 7 years after the model
was launched
At least 7 years after the model
was launched
At least 7 years after the model
was launched
At least 7 years after the model
was launched
At least 7 years after the model
was launched
At least 10 years after the model
was launched
NOTE
The model information in the product database, as well as the model identifier, can be
the product.
Importer / Address: MIDEA HOME APPLIANCES UK LTD 5 New Street
Square, London, United Kingdom, EC4A 3TW
EN-26
Safety
Information
Proper Use of
Refrigerator
Maintenance of
Refrigerator
Trouble
Shooting
Appendix
DE
INHALT
1 Sicherheitshinweise
1.1 Warnung ....................................................................................................................................................1-2
1.2 Bedeutungen der Sicherheitswarnsymbole .................................................................................................. 3
1.3 Elektrizitätsbezogene Warnungen ................................................................................................................3
1.4 Warnhinweise zur Verwendung .......................................................................................................................4
1.5 Warnhinweise zur Platzierung von Gegenständen..........................................................................................4-5
1.6 Warnungen für Energie ................................................................................................................................5
1.7 Warnhinweise zur Entsorgung ......................................................................................................................5
2 Richtige Verwendung des Kühlschranks
2.1 Platzierung....................................................................................................................................................6
2.2 Nivellierfüße..................................................................................................................................................7
2.3 Nivellierungstür .............................................................................................................................................8
2.4 Ändern der Beleuchtung ...............................................................................................................................9
2.5 Inbetriebnahme.............................................................................................................................................9
2.6 Energiespartipps...........................................................................................................................................9
3 Aufbau und Funktionen
3.1 Hauptkomponenten ..................................................................................................................................... 10
3.2 Funktionen .................................................................
4 Wartung und Pflege des Kühlschranks
4.1 Allgemeine Reinigung ................................................................................................................................. 13
4.2 Reinigung der Türwanne ............................................................................................................................ 14
4.3 Abtauen ...................................................................................................................................................... 14
4.4 Außer Betrieb.............................................................................................................................................. 14
5 Fehlersuche
5.1 Fehlersuche ................................................................................................................................................ 15
............................................................................ 11-12
Liebe Anwender, vielen Dank, dass Sie sich für einen Midea-
Kühlschrank entschieden haben!
1 Sicherheitshinweise
1.1 Warnung
Warnung:
Dieses
vorgesehen
Bereiche
Hotels, Motels und anderen wohnungsähnlichen Umgebungen; Umgebungen des Typs „Bed and Breakfast“;
Catering und ähnliche Nicht-Einzelhandelsanwendungen.
Dieses
körperlicher Leistungsfähigkeit bestimmt,
sensorische
werden durch eine für ihre Sicherheit zuständige Person beaufsichtigt oder erhielten von ihr Anweisungen,
wie das Gerät zu benutzen ist).
Kinder
Wenn
qualifizierte Personen ersetzt werden, um eine Gefährdung zu vermeiden.
Bewahren
Das
Benutzer vom Netz getrennt werden.
Warnung:
Hindernissen.
Warnung:
des Abtauvorgangs, die nicht vom Hersteller empfohlen werden.
Warnung:
Warnung:
denn, es handelt sich um den vom Hersteller empfohlenen Typ.
Warnung:
Blähgas und Kältemittel verwendet.
Warnung:
oder beschädigt wird.
Warnung:
an.
Verwenden
Gefahr:
wegwerfen:
- Nehmen Sie die Türen ab.
- Lassen Sie die Einlegeböden an ihrem Platz, damit Kinder nicht so leicht hineinklettern können.
Der
installieren.
Gerät ist für den Einsatz in Haushalten und ähnlichen Anwendungen wie z. B. Personalküchen
in Geschäften, Büros und anderen Arbeitsumgebungen; Bauernhöfen und von Kunden in
Gerät ist nicht für den Gebrauch durch Personen (einschließlich Kinder) mit eingeschränkter
oder geistige Fähigkeiten oder mangelnde Erfahrung und Kenntnisse, es sei denn, sie
sollten beaufsichtigt werden, um sicherzustellen, dass sie nicht mit dem Gerät spielen.
das Netzkabel beschädigt ist, muss es durch den Hersteller, seinen Kundendienst oder ähnlich
Sie keine explosiven Stoffe wie Spraydosen mit brennbarem Treibmittel in diesem Gerät auf.
Gerät muss nach dem Gebrauch und vor der Durchführung von Wartungsarbeiten am Gerät durch den
Halten Sie die Lüftungsöffnungen im Gerätegehäuse oder in der Einbaukonstruktion frei von
Verwenden Sie keine mechanischen Vorrichtungen oder andere Mittel zur Beschleunigung
Beschädigen Sie nicht den Kältemittelkreislauf.
Verwenden Sie keine elektrischen Geräte in den Lebensmittellagerfächern des Geräts, es sei
Bitte geben Sie den Kühlschrank gemäß den örtlichen Vorschriften auf, da er brennbares
Achten Sie bei der Positionierung des Geräts darauf, dass das Netzkabel nicht eingeklemmt
Bringen Sie keine Mehrfachsteckdosen oder tragbare Netzteile an der Rückseite des Geräts
Sie keine Verlängerungskabel oder ungeerdete (zweipolige) Adapter.
Gefahr des Einklemmens von Kindern. Bevor Sie Ihren alten Kühlschrank oder Gefrierschrank
Kühlschrank muss von der Stromquelle getrennt werden, bevor Sie versuchen, das Zubehör zu
Brandgefahr / brennbare Materialien
DE-1
für das Gerät verwendete Kältemittel und Cyclopentan-Schaumstoff sind brennbar.
Das
Wenn
speziellen Verwertungsunternehmen mit entsprechender Qualifikation verwertet werden, damit es nicht durch
Verbrennung entsorgt wird, um Umweltschäden oder andere Schäden zu vermeiden.
Für
verringerten physischen, sensorischen oder mentalen Fähigkeiten oder Mangel an Erfahrung und Wissen
benutzt werden, wenn sie beaufsichtigt oder bezüglich des sicheren Gebrauchs des Geräts unterwiesen
wurden und die daraus resultierenden Gefahren verstehen. Kinder dürfen nicht mit dem Gerät spielen.
Reinigung und Benutzerwartung dürfen nicht von Kindern ohne Aufsicht durchgeführt werden. Kinder im Alter
von 3 bis 8 Jahren dürfen das Be- und Entladen von Kühlgeräten durchführen.
Die
Schlüssel außerhalb der Reichweite von Kindern und nicht in der Nähe des Kühlgeräts aufbewahrt werden,
um zu verhindern, dass Kinder darin eingeschlossen werden.
Um
- Ein längeres Öffnen der Tür kann zu einem erheblichen Anstieg der Temperatur in den Fächern des Gerätes
führen.
- Reinigen Sie regelmäßig Oberflächen, die mit Lebensmitteln in Kontakt kommen können, und zugängliche
Drainagesysteme.
- Reinigen Sie Wassertanks, wenn sie 48 h lang nicht benutzt wurden; spülen Sie das an eine
Wasserversorgung angeschlossene Wassersystem, wenn 5 Tage lang kein Wasser entnommen wurde.
(Hinweis 1)
- Lagern Sie rohes Fleisch und Fisch in geeigneten Behältern im Kühlschrank, so dass sie nicht mit anderen
Lebensmitteln in Kontakt kommen oder auf diese tropfen.
- Zwei-Sterne-Tiefkühlfächer eignen sich zur Lagerung von vorgefrorenen Lebensmitteln, zur Aufbewahrung
oder Herstellung von Speiseeis und zur Herstellung von Eiswürfeln. (Hinweis 2)
- Ein-, Zwei- und Drei-Sterne-Fächer sind nicht für das Einfrieren von frischen Lebensmitteln geeignet.
(Hinweis 3)
- Bei Geräten ohne 4-Sterne-Fach: Dieses Kühlgerät ist nicht zum Einfrieren von Lebensmitteln geeignet.
(Hinweis 4)
- Wenn das Kühlgerät längere Zeit leer steht, schalten Sie es aus, tauen Sie es ab, reinigen Sie es, trocknen
Sie es und lassen Sie die Tür offen, um Schimmelbildung im Gerät zu vermeiden.
Hinweis 1,2,3,4: Bitte bestätigen Sie, ob dies für Ihren Produktfachtyp zutrifft.
Für
Der
oder
Dieses Produkt enthält eine Lichtquelle der Energieeffizienzklasse (G).
das Gerät verschrottet wird, muss es daher von jeglicher Feuerquelle ferngehalten und von einem
EN-Norm: Dieses Gerät kann von Kindern ab 8 Jahren und darüber sowie von Personen mit
Notwendigkeit, dass bei Türen oder Deckeln, die mit Schlössern und Schlüsseln ausgestattet sind, die
eine Kontamination der Lebensmittel zu vermeiden, beachten Sie bitte die folgenden Hinweise:
ein freistehendes Gerät: Dieses Kühlgerät ist nicht als Einbaugerät vorgesehen.
Austausch oder die Wartung der LED-Lampen soll durch den Hersteller, seinen Servicepartner
eine ähnlich qualifizierte Person erfolgen.
DE-2
Loading...
