Midea MCCU-16CN1 User Manual

Midea R410A 50Hz

Compressor Condensing Unit

Technical Manual

DM15-01.01.17en

Applicable Model:

MCCU-03CN1 MCCU-05CN1 MCCU-07CN1 MCCU-10CN1 MCCU-12CN1 MCCU-16CN1 MCCU-22CN1 MCCU-28CN1 MCCU-35CN1 MCCU-45CN1 MCCU-53CN1 MCCU-61CN1 MCCU-70CN1 MCCU-105CN1

Midea reserves the right to discontinue, or change specification or designs at any time without notices and

without incurring obligations.

1

Midea R410A 50Hz T1 Compressor Condensing Unit

Content

Part. 1 Performance ............................. 3

Part. 2 Installation .............................. 38

Appendix: VRF Solution .................... 67

2

Midea R410A 50Hz T1 Compressor Condensing Unit

Part. 1 Performance

1. Product lineup ................................................................ 4

2. External Appearance ..................................................... 4

3. Nomenclature ................................................................. 6

4. Specifications ................................................................ 7

5. Dimensions (Unit: mm) ............................................... 18

6. Refrigerant circuits ...................................................... 24

7. Wiring Diagrams .......................................................... 28

8. Electrical datas ............................................................ 34

9. Sound Levels ............................................................... 34

10. Connection accessory list (Optional) ...................... 35

3

1. Product lineup

Outdoor unit

Cooling capacity

Model

Power supply

W

Btu/h

MCCU-03CN1

220-240V~, 1Ph, 50Hz

3,200

10,920

MCCU-05CN1

5,300

18,080

MCCU-07CN1

7,100

24,230

MCCU-10CN1

380-415V~, 3Ph, 50Hz

10,500

35,830

14,000

47,770

MCCU-16CN1

16,000

54,590

MCCU-22CN1

22,000

75,060

MCCU-28CN1

28,000

95,540

MCCU-35CN1

380-400V~,3Ph, 50Hz

35,000

119,420

MCCU-45CN1

380-415V~, 3Ph, 50Hz

45,000

153,540

MCCU-53CN1

380-400V~,3Ph, 50Hz

53,000

180,840

MCCU-61CN1

61,000

208,130

MCCU-70CN1

70,000

238,840

MCCU-105CN1

105,000

358,260

MCCU-03CN1

MCCU-05CN1

MCCU-07CN1

MCCU-10CN1

Model names of units with cooling only:

MCCU-12CN1

Midea R410A 50Hz T1 Compressor Condensing Unit

2. External Appearance

4

Midea R410A 50Hz T1 Compressor Condensing Unit

MCCU-22CN1 MCCU-28CN1

MCCU-35CN1

MCCU-45CN1

MCCU-53CN1, MCCU-61CN1

MCCU-70CN1, MCCU-105CN1

MCCU-12CN1 MCCU-16CN1

5

3. Nomenclature

M CCU – 53 C N1

Midea R410A 50Hz T1 Compressor Condensing Unit

Refrigerant type: R410A Function code

C: Cooling only H: Heat pump

Nominal cooling capacity (53×1,000W) Compressor Condensing Unit Midea

6

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-03CN1

MCCU-05CN1

Power supply

\

220-240V~, 1Ph, 50Hz

Ambient temperature range

°C

17~46

Cooling

Capacity

kW

3.2

5.3

Max. input

kW

1.60

2.85

Max. current A 7.5

15.0

Noise level

dB(A)

29.4

44.0

Compressor

Type / Quantity \ Rotary / 1

Rotary / 1

Model \ PA150X2C-4FT

PA225M2CS-4KU2

Brand

\

GMCC

Capacity W 3,660

5,500

Input

W

1,260

1,835

Capacitor \ 35µF/450V

50µF/450V

Rated current (RLA)

A

5.8

8.5

Oil charge \ 480 (Ester oil VG74)

750 (Ester oil VG74)

Refrigerant

Type / Charged

\

R410A / 800g

R410A / 860g

Fan

Type / Quantity

\

Axial fan / 1

Motor model \ YDK24-6F(B)

YDK48-6H(A)

Fan dimension

mm

Φ401

Φ424

Drive type \ Direct

Direct

Capacitor \ 2.5µF/450V

3µF/450V

Motor input W 63

111

Motor speed

rpm

800

890

Coil

Type \ Copper tube and aluminum fin

Copper tube and aluminum fin

Tube size

mm

Φ7.94

Φ7

No. of rows \ 1

2

Fin space

mm

1.6

1.4

Length × Height

mm

762×484

658×546

Number of circuits \ 2

8

Refrigerant pipe

Liquid side / Gas side

mm

Φ6.35/Φ12.7

Max. pipe length m 20

20

Max. difference in level

m

10

Connection wire

Power wire

\

2×2.5mm2+1×1.5mm2 (Ground)

2×4.0mm2+1×2.5mm2 (Ground)

Signal wire \ 1×1.0mm

2

1×1.0mm

2

Dimension (W×H×D)

mm

848×549×300

825×597×315

Packing (W×H×D)

mm

910×575×335

890×650×360

Net / Gross weight

kg

30.5/33

36.5/39.5

4. Specifications

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB/19°CWB; outdoor temperature: 35°CDB/24°C WB. Equivalent refrigerant pipe: 7.5m.

7

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-07CN1

MCCU-10CN1

Power supply

\

220-240V~, 1Ph, 50Hz

380-415V~, 3Ph, 50Hz

Ambient temperature range

°C

17~46

Cooling

Capacity

kW

7.1

10.5

Max. input

kW

3.50

5.30

Max. current A 18.0

10

Noise level

dB(A)

72.6

58

Compressor

Type / Quantity \ Rotary / 1

Scroll / 1

Model \ PA290G2CS-4MU1

C-SBN303H8D

Brand

\

GMCC

Sanyo

Capacity W 7,260

9,800

Input

W

2,430

3,650

Capacitor \ 50µF/450V

/

Rated current (RLA)

A

11.65

6.58

Oil charge \ 850 (Ester oil VG74)

1,700 (FV68S)

Refrigerant

Type / Charged

\

R410A / 1,350g

R410A / 2,500g

Fan

Type / Quantity

\

Axial fan / 1

Motor model \ YDK53-6C

YDK190-6D(B)

Fan dimension

mm

Φ460

Φ560

Drive type \ Direct

Direct

Capacitor \ 3µF/450V

10µF/450V

Motor input W 136

290

Motor speed

rpm

800

830

Coil

Type \ Copper tube and aluminum fin

Copper tube and aluminum fin

Tube size

mm

Φ7

No. of rows \ 2

1.6

Fin space

mm

1.5

Length × Height

mm

766×630

898×882

Number of circuits \ 4

7

Refrigerant pipe

Liquid side / Gas side

mm

Φ9.52/Φ12.7

Φ9.52/Φ19

Max. pipe length m 20

30

Max. difference in level

m

10

20

Connection wire

Power wire

\

2×6.0mm2+1×4.0mm2 (Ground)

4×4.0mm2+1×2.5mm2 (Ground)

Signal wire \ 1×1.0mm

2

1×1.0mm

2

Dimension (W×H×D)

mm

916×702×360

1,077×967×396

Packing (W×H×D)

mm

965×755×420

1,120×1,100×435

Net / Gross weight

kg

48.5/52

85.8/95.6

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

8

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-16CN1

Power supply

\

380-415V~, 3Ph, 50Hz

Ambient temperature range

°C

17~46

Cooling

Capacity

kW

14.0

16.0

Max. input

kW

6.10

8.50

Max. current A 12

13

Noise level

dB(A)

58

59

Compressor

Type / Quantity \ Scroll / 1

Scroll / 1

Model \ C-SBN373H8D

C-SBN453H8D

Brand

\

Sanyo

Capacity W 14,100

16,400

Input

W

4,750

5,750

Capacitor

\

/

Rated current (RLA)

A

8.22

9.77

Oil charge \ 1,700 (FV68S)

1,700 (FV68S)

Refrigerant

Type / Charged

\

R410A / 3,000g

R410A / 3,050g

Fan

Type / Quantity

\

Axial fan / 2

Motor model \ YDK65-6F(B)

YDK65-6F(B)

Fan dimension

mm

Φ455

Drive type \ Direct

Direct

Capacitor \ 4µF/450V

4µF/450V

Motor input W 174

174

Motor speed

rpm

825

Coil

Type \ Copper tube and aluminum fin

Copper tube and aluminum fin

Tube size

mm

Φ7

Φ7.94

No. of rows \ 2

2

Fin space

mm

1.5

1.6

Length × Height

mm

845×1,092

837×1,100

Number of circuits \ 8

8

Refrigerant pipe

Liquid side / Gas side

mm

Φ9.52/Φ19

Max. pipe length m 30

30

Max. difference in level

m

20

Connection wire

Power wire

\

4×4.0mm2+1×2.5mm2 (Ground)

4×10.0mm2+1×6.0mm2 (Ground)

Signal wire \ 1×1.0mm

2

1×1.0mm

2

Dimension (W×H×D)

mm

987×1,167×400

Packing (W×H×D)

mm

1,032×1,307×443

Net / Gross weight

kg

91.6/102

96.6/107

MCCU-12CN1

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

9

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-22CN1

Power supply

\

380-415V~, 3Ph, 50Hz

Ambient temperature range

°C

17~52

Cooling

Capacity

kW

22.0

Max. input

kW

11.70

Max. current

A

19.3

Noise level

dB(A)

65

Compressor

Type / Quantity

\

Scroll / 1

Model

\

ZP90KCE-TFD-522

Brand

\

Copeland

Capacity

W

21,900

Input

W

6,950

Capacitor

\ / Rated current (RLA)

A

16.5

Oil charge

\

2,513 (POE)

Refrigerant

Type / Charged

\

R410A / 5,400g

Fan

Type / Quantity

\

Axial fan / 2

Motor model

\

YDK210-6A

Fan dimension

mm

Φ530

Drive type

\

Direct

Capacitor

\

10μF/450V

Motor input

W

Hi: 284; Lo: 202

Motor speed

rpm

Hi: 920/930; Lo: 650/710 (4 blades/3 blades)

Coil

Type

\

Copper tube and aluminum fin

Tube size

mm

Ф7.94

No. of rows

\ 2 Fin space

mm

1.4

Length × Height

mm

2,177×880

Number of circuits

\

9

Refrigerant pipe

Liquid side / Gas side

mm

Ф9.52/Ф22

Max. pipe length

m

50

Max. difference in level

m

30

Connection wire

Power wire

\

5×6.0mm

2

Signal wire

\

2×1.0mm

2

Dimension (W×H×D)

mm

1,260×908×700

Packing (W×H×D)

mm

1,320×1,060×730

Net / Gross weight

kg

171/190

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

10

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-28CN1

Power supply

\

380-415V~, 3Ph, 50Hz

Ambient temperature range

°C

17~52

Cooling

Capacity

kW

28.0

Max. input

kW

14.40

Max. current

A

23.7

Noise level

dB(A)

67

Compressor

Type / Quantity

\

Scroll / 1

Model

\

ZP120KCE-TFD-522

Brand

\

Copeland

Capacity

W

29,200

Input

W

9,200

Capacitor

\ / Rated current (RLA)

A

20

Oil charge

\

3,253 (POE)

Refrigerant

Type / Charged

\

R410A / 6,000g

Fan

Type / Quantity

\

Axial fan / 2

Motor model

\

YDK400-4C

Fan dimension

mm

Φ530

Drive type

\

Direct

Capacitor

\

25μF/450V

Motor input W Hi: 621/587; Lo: 388/388 (4 blades/3 blades)

Motor speed

rpm

Hi: 1,180/1,230; Lo: 790/870 (4 blades/3 blades)

Coil

Type

\

Copper tube and aluminum fin

Tube size

mm

Ф7

No. of rows

\ 3 Fin space

mm

1.3

Length × Height

mm

2,179×882

Number of circuits

\

20

Refrigerant pipe

Liquid side / Gas side

mm

Ф9.52/Ф25

Max. pipe length

m

50

Max. difference in level

m

30

Connection wire

Power wire

\

5×6.0mm

2

Signal wire

\

2×1.0mm

2

Dimension (W×H×D)

mm

1,260×908×700

Packing (W×H×D)

mm

1,320×1,060×730

Net / Gross weight

kg

185/202

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

11

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-35CN1

Power supply

\

380-400V~, 3Ph, 50Hz

Ambient temperature range

°C

17～52

Cooling

Capacity

kW

35.0

Max. input

kW

17.30

Max. current

A

28.5

Noise level

dB(A)

69

Compressor

Type / Quantity

\

Scroll / 1

Model

\

SH140A4ALC

Brand

\

Danfoss

Capacity

W

34,700

Input

W

10,862

Capacitor

\ / Rated current (RLA)

A

21.4

Oil charge

\

3,300 (POE-160SZ)

Refrigerant

Type / Charged

\

R410A / 7,200g

Fan

Type / Quantity

\

Axial fan / 2

Motor model

\

YDK400-4C

Fan dimension

mm

Φ530

Drive type

\

Direct

Capacitor

\

25μF/450V

Motor input W Hi: 621/587; Lo: 388/388 (4 blades/3 blades)

Motor speed

rpm

Hi: 1,180/1,230; Lo: 790/870 (4 blades/3 blades)

Coil

Type

\

Copper tube and aluminum fin

Tube size

mm

Ф7

No. of rows

\ 3 Fin space

mm

1.3

Length × Height

mm

(1,380×882)+(1,380×882)

Number of circuits

\

20+20

Refrigerant pipe

Liquid side / Gas side

mm

Ф12.7/Ф28.6

Max. pipe length

m

50

Max. difference in level

m

30

Connection wire

Power wire

\

5×6.0mm

2

Signal wire

\

2×1.0mm

2

Dimension (W×H×D)

mm

1,260×908×700

Packing (W×H×D)

mm

1,320×1,060×730

Net / Gross weight

kg

199/215

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

12

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-45CN1

Power supply

\

380-415V~, 3Ph, 50Hz

Ambient temperature range

°C

17～46

Cooling

Capacity

kW

45.0

Max. input

kW

26.90

Max. current

A

47.9

Noise level

dB(A)

70

Compressor

Type / Quantity

\

Scroll / 3

Model

\

E605DH-59D2YG

Brand

\

Hitachi

Capacity

W

15,390

Input

W

5,130

Capacitor

\ / Rated current (RLA)

A

8.8

Oil charge

\

500 (FVC68D)

Refrigerant

Type / Charged

\

R410A / 10,000g

Fan

Type / Quantity

\

Axial fan / 2

Motor model

\

YDK380-4D

Fan dimension

mm

Φ560/Φ562

Drive type

\

Direct

Capacitor

\

20μF/450V

Motor input W Hi: 615/580; Lo: 425/420 (4 blades/3 blades)

Motor speed

rpm

Hi: 1,000/1,090; Lo: 780/870 (4 blades/3 blades)

Coil

Type

\

Copper tube and aluminum fin

Tube size

mm

Ф7.94

No. of rows

\ 2 Fin space

mm

1.6

Length × Height

mm

2,286×1,232

Number of circuits

\

28

Refrigerant pipe

Liquid side / Gas side

mm

Ф16/Ф32

Max. pipe length

m

50

Max. difference in level

m

30

Connection wire

Power wire

\

5×15.0mm

2

Signal wire

\

2×1.0mm

2

Dimension (W×H×D)

mm

1,250×1,615×765

Packing (W×H×D)

mm

1,305×1,790×820

Net / Gross weight

kg

288/308

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

13

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-53CN1

Power supply

\

380-400V~, 3Ph, 50Hz

Ambient temperature range

°C

18~46

Cooling

Capacity

kW

53.0

Max. input

kW

23.70

Max. current

A

45.2

Noise level

dB(A)

73

Compressor

Type / Quantity

\

Scroll / 2

Model

\

SH105A4ALC

Brand

\

Danfoss

Capacity

W

26,816

Input

W

8,472

Capacitor

\ / Rated current (RLA)

A

16.4

Oil charge

\

3,300ml (POE-160SZ)

Refrigerant

Type / Charged

\

R410A / 11,000g

Fan

Type / Quantity

\

Axial fan / 2

Motor model

\

YS600-6P

Fan dimension

mm

Φ650

Drive type

\

Direct

Capacitor

\ \ Motor input

W

750

Motor speed

rpm

930

Coil

Type

\

Copper tube and aluminum fin

Tube size

mm

Φ7.94

No. of rows

\ 3 Fin space

mm

1.6

Length × Height

mm

2,209×1,100

Number of circuits

\

12+12

Refrigerant pipe

Liquid side / Gas side

mm

（Ф12.7/Ф25）×2

Max. pipe length

m

50

Max. difference in level

m

30

Connection wire

Power wire \ 4×16.0mm2+1×10.0mm2 (Ground)

Signal wire

\

2×1.0mm

2

Dimension (W×H×D)

mm

1,825×1,245×899

Packing (W×H×D)

mm

1,844×1,272×924

Net / Gross weight

kg

395/405

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

14

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-61CN1

Power supply

\

380-400V~, 3Ph, 50Hz

Ambient temp range

°C

17~46

Cooling

Capacity

kW

61.0

Max. input

kW

28.20

Max. current

A

51.0

Noise level

dB(A)

76

Compressor

Type / Quantity

\

Scroll / 2

Model

\

SH120A4ALC

Brand

\

Danfoss

Capacity

W

29,950

Input

W

9,462

Capacitor

\ / Rated current (RLA)

A

20.7

Oil charge

\

3,300ml (POE-160SZ)

Refrigerant

Type / Charged

\

R410A / 12,400g

Fan

Type / Quantity

\

Axial fan / 2

Motor model

\

YS1100-6

Fan dimension

mm

Φ700

Drive type

\

Direct

Capacitor

\ \ Motor input

W

1,300

Motor speed

rpm

940

Coil

Type

\

Copper tube and aluminum fin

Tube size

mm

Φ7.94

No. of rows

\ 3 Fin space

mm

1.6

Length × Height

mm

2,209×1,100

Number of circuits

\

12+12

Refrigerant pipe

Liquid side / Gas side

mm

（Ф12.7/Ф25）×2

Max. pipe length

m

50

Max. difference in level

m

30

Connection wire

Power wire

\

4×25.0mm2+1×16.0mm2 (Ground)

Signal wire

\

2×1.0mm

2

Dimension (W×H×D)

mm

1,825×1,245×899

Packing (W×H×D)

mm

1,844×1,272×924

Net / Gross weight

kg

395/405

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

15

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-70CN1

Power supply

\

380-400V~, 3Ph, 50Hz

Ambient temperature range

°C

17~46

Cooling

Capacity

kW

70.0

Max. input

kW

31.80

Max. current

A

56.5

Noise level

dB(A)

76

Compressor

Type / Quantity

\

Scroll / 2

Model

\

SH140A4ALC

Brand

\

Danfoss

Capacity

W

34,700

Input

W

10,862

Capacitor

\ / Rated current (RLA)

A

21.4

Oil charge

\

3,300ml (POE-160SZ)

Refrigerant

Type / Charged

\

R410A / 17,000

Fan

Type / Quantity

\

Axial fan / 2

Motor model

\

YS1100-6

Fan dimension

mm

Φ750

Drive type

\

Direct

Capacitor

\ \ Motor input

W

1,300

Motor speed

rpm

940

Coil

Type

\

Copper tube and aluminum fin

Tube size

mm

Φ7.94

No. of rows

\

3.6

Fin space

mm

1.6

Length × Height

mm

(1,355×1,100)+(1,325×1,100)

Number of circuits

\

25+25

Refrigerant pipe

Liquid side / Gas side

mm

（Ф12.7/Ф25）×2

Max. pipe length

m

50

Max. difference in level

m

30

Connection wire

Power wire

\

4×25.0mm2+1×16.0mm2 (Ground)

Signal wire

\

2×1.0mm

2

Dimension (W×H×D)

mm

2,158×1,258×1,082

Packing (W×H×D)

mm

2,168×1,275×1,105

Net / Gross weight

kg

508/523

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

16

Midea R410A 50Hz T1 Compressor Condensing Unit

Model

MCCU-105CN1

Power supply

\

380-400V~, 3Ph, 50Hz

Ambient temp range

°C

17~46

Cooling

Capacity

kW

105.0

Max. input

kW

40.70

Max. current

A

71.8

Noise level

dB(A)

78

Compressor

Type / Quantity

\

Scroll / 2

Model

\

SH184A4ALC

Brand

\

Danfoss

Capacity

W

44,661

Input

W

13,732

Capacitor

\ / Rated current (RLA)

A

27.6

Oil charge

\

3,600ml (POE-160SZ)

Refrigerant

Type / Charged

\

R410A / 18,000g

Fan

Type / Quantity

\

Axial fan / 2

Motor model

\

YS1500-6

Fan dimension

mm

Φ802

Drive type

\

Direct

Capacitor

\ \ Motor input

W

1,690

Motor speed

rpm

910

Coil

Type

\

Copper tube and aluminum fin

Tube size

mm

Φ7

No. of rows

\

3.6

Fin space

mm

1.5

Length × Height

mm

(1,325×756)×2+(1367×756)×2

Number of circuits

\

24+24

Refrigerant pipe

Liquid side / Gas side

mm

（Ф12.7/Ф25）×2

Max. pipe length

m

50

Max. difference in level

m

30

Connection wire

Power wire

\

4×35.0mm2+1×16.0mm2 (Ground)

Signal wire

\

2×1.0mm

2

Dimension (W×H×D)

mm

2,158×1,669×1,082

Packing (W×H×D)

mm

2,168×1,686×1,105

Net/ Gross weight

kg

570/582

Notes: Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.

17
