VENICE 240 Page 1 / 22
Ersatzteilliste - Bill of Materials
173042
VENICE 240 120V
173044
VENICE 240 240V
173020
VENICE 240 230V
Pos. Nr.
Best. Nr.
Zubehör
Accessories & packaging material
Mechanische Teile
Cabinet material
Ref. No.
Part No. Bezeichnung Qty Description
359941 BEDIENUNGSANL. VENICE 1 owner's manual VENICE
346832 KABEL-NETZ UL/CSA 10A/125V 1 power cable US
354619 KABEL-NETZ SAA 10A/250V 1 power cable UK
300425 KABEL-NETZ 2.0 M 10A 1 power cable Europe
302587 SICHER T 3.150 A/250V 1 fuse 3.15A slow blow
302583 SICHER T 1.600 A/250V 1 fuse 1.6A slow blow / US only !!
328391 SICHER-HALTER-KAPPE FEK 1 fuse holder carrier
360003 SCHUTZBEZUG VENICE 240 1 dust cover VENICE 240
360005 KRT. VENICE 240 1 carton inner V240
360006 KRT. VENICE 240 AUSSEN 1 carton outer V240
359944 STYROPOR-EINL. LI. VENICE 1 foam left hand
359945 STYROPOR-EINL. RE. VENICE 1 foam right hand
338158 SCHUTZHÜLLE 800X1200X0,07 1 plastic bag
341592 STECKER-FL. XLR 6POL 1 connector XLR male 6-pin
359877 DK 11,4 GR/WS/DG B 6FL 49 knob rotary l.gr/wh/l.gr
359876 DK 11,4 DG/WS/GR B 6FL 23 knob rotary gr/wh/l.gr
359878 DK 11,4 DG/WS/BL B 6FL 40 knob rotary gr/wh/bl
359879 DK 11,4 GR/WS/BL B 6FL 32 knob rotary l.gr/wh/bl
359990 DK 11,4 DG/WS/DG B 6FL 20 knob rotary gr/wh/gr
359991 DK 11,4 GR/WS/GN B 6FL 42 knob rotary l.gr/wh/gn
358364 DK 11,4 GR/WS/RT B 6FL 46 knob rotary l.gr/wh/rd
359993 DK 11,4 DG/SW/GE B 6FL 44 knob rotary gr/blk/yl
359994 DK 11,4 GR/SW/GE B 6FL 1 knob rotary l.gr/blk/yl
359995 DK 11,4 DG/WS/RT B 6FL 2 knob rotary gr/wh/rd
359946 SK 24X11 GR/SW 4X1,2 20 knob slide l.gr/blk
359947 SK 24X11 BL/SW 4X1,2 4 knob slide bl/blk
359948 SK 24X11 RT/SW 4X1,2 3 knob slide rd/blk
359949 SK 24X11 GN/SW 4X1,2 2 knob slide gn/blk
359645 TK 9,8X9,8 RT 3,3 25 knob switch red square
360000 TK 7,5X6 RT 3,3 22 knob switch red small
359999 TK 9,8X6 RT 3,3 2 knob switch red mid
358363 TK 7,5X6 GR 3,3 95 knob switch l.gr small
358360 TK 9,8X6 GR 3,3 34 knob switch l.gr mid
359863 TK 2,8 SW 3,3 20 knob switch blk +48V
359648 EINLEGEBLENDE VENICE 240 1 logo VENICE 240
335589 FUSS-GUMMI SJ 5009 SW 5 rubber foot
358632 KABEL-KONFEKT-BUS 12POL 3X 1 ribbon cable 12-way 3conn
358633 KABEL-KONFEKT-BUS 12POL 3X 1 ribbon cable 12-way 3conn
358635 KABEL-KONFEKT-BUS 12POL 4X 1 ribbon cable 12-way 4conn
358686 KABEL-KONFEKT 8POL 0.930M 1 ribbon cable assy 8-way
358687 KABEL-KONFEKT 8POL 1.120M 2 ribbon cable assy 8-way
VENICE 240 Page 2 / 22
Pos. Nr.
Best. Nr.
Printplatten, bestückt
Printed circuit board assemblies
852778
PCBAR#VENICE 240/320
1
pcb assy 85277 power supply
Ref. No.
CNACx 343516 FL.STECKER 4.8/0.5 1 connector 4.8mm faston
CNGND 343516 FL.STECKER 4.8/0.5 1 connector 4.8mm faston
CNPE2 330269 FL.STECKER 6.3/0.8 1 connector 6.3mm faston
CNPE3 330269 FL.STECKER 6.3/0.8 1 connector 6.3mm faston
CNT01 329022 FL.STECKER 6.3/0.8 1 connector 6.3mm faston
CNT02 329022 FL.STECKER 6.3/0.8 1 connector 6.3mm faston
CN00x 343516 FL.STECKER 4.8/0.5 1 connector 4.8mm faston
CN02A 344975 MESSERLST. 10POL 1 connector male 10-pin
CN021 344862 MESSERLST. 8POL 1 connector male 8-pin
CN022 345489 MESSERLST. 6POL 1 connector male 6-pin
C0001 341714 KO-SO 0.10MF 275V 20% K 1 safety cap 100nF/275V
C0002 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0003 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0004 335935 KO-EL 2200.000MF 35V 1 cap electrolytic 2200uF/35V
C0005 335935 KO-EL 2200.000MF 35V 1 cap electrolytic 2200uF/35V
C0008 335935 KO-EL 2200.000MF 35V 1 cap electrolytic 2200uF/35V
C0009 335935 KO-EL 2200.000MF 35V 1 cap electrolytic 2200uF/35V
C0010 335935 KO-EL 2200.000MF 35V 1 cap electrolytic 2200uF/35V
C0011 335935 KO-EL 2200.000MF 35V 1 cap electrolytic 2200uF/35V
C0012 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0013 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0014 327815 KO-EL 22.000MF 25V 1 cap electrolytic 22uF/25V
C0015 327815 KO-EL 22.000MF 25V 1 cap electrolytic 22uF/25V
C0016 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0017 341920 KO-EL 470.000MF 63V 1 cap electrolytic 470uF/63V
C0018 301478 KO-EL 22.000MF 63V 1 cap electrolytic 22uF/63V
C0019 301491 KO-EL 100.000MF 50V 1 cap electrolytic 100uF/50V
C0020 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0021 335935 KO-EL 2200.000MF 35V 1 cap electrolytic 2200uF/35V
C0022 342923 KO-FOL 0.220MF 63V 5% 1 cap mylar 220nF
C0023 307445 KO-EL 10.000MF 35V 1 cap electrolytic 10uF/35V
C0024 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0025 343530 KO-EL 47.000MF 50V 1 cap electrolytic 47uF/50V
C0026 343530 KO-EL 47.000MF 50V 1 cap electrolytic 47uF/50V
C0027 335935 KO-EL 2200.000MF 35V 1 cap electrolytic 2200uF/35V
C0028 327815 KO-EL 22.000MF 25V 1 cap electrolytic 22uF/25V
Part No. Bezeichnung Qty Description
358688 KABEL-KONFEKT 12POL 0.900M 1 ribbon cable assy 12-way
358689 KABEL-KONFEKT 12POL 0.800M 1 ribbon cable assy 12-way
358690 KABEL-KONFEKT 12POL 0.720M 1 ribbon cable assy 12-way
354302 KABEL-KONFEKT 6POL 0.600M 1 ribbon cable 6-way
348388 KABEL-KONFEKT 10POL 0.620M 2 ribbon cable assy 10-way
341984 KABEL-KONFEKT 4POL 0.150M 1 ribbon cable assy 4-way
353397 KABEL-KONFEKT 18POL 0.110M 10 ribbon cable assy 18-way
358390 SEITENTEIL LINKS VENICE 1 side wing left hand
358534 SEITENTEIL RECHTS VENICE 1 side wing rihgt hand
359769 FRONTLEISTE VENICE 240 1 armrest VENICE 240
359631 FRONTBL-BED VENICE 240 1 front panel VENICE 240
359632 RÜCKWAND-BED VENICE 240 1 rear panel VENICE 240
358691 RKT VENICE 100-240V 1 mains transformer VENICE
VENICE 240 Page 3 / 22
Pos. Nr.
Best. Nr.
Ref. No.
C0029 301491 KO-EL 100.000MF 50V 1 cap electrolytic 100uF/50V
C0030 341920 KO-EL 470.000MF 63V 1 cap electrolytic 470uF/63V
C0031 341920 KO-EL 470.000MF 63V 1 cap electrolytic 470uF/63V
C0032 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0033 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
D0005 301254 DIODE 1N 4148 AXIAL 1 diode 1N 4148
D0006 301254 DIODE 1N 4148 AXIAL 1 diode 1N 4148
D0007 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0008 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0009 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D001A 304364 DIODZ ZPY 30V 1.30W 1 diode zener 30V
D0010 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0011 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0012 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0013 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0014 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0015 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0016 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0017 358946 DIODE 1N 5401 BEARB.AUS 1 diode 1N 5401
D0018 358946 DIODE 1N 5401 BEARB.AUS 1 diode 1N 5401
D0019 358946 DIODE 1N 5401 BEARB.AUS 1 diode 1N 5401
D0020 358946 DIODE 1N 5401 BEARB.AUS 1 diode 1N 5401
D0021 301254 DIODE 1N 4148 AXIAL 1 diode 1N 4148
D0022 301254 DIODE 1N 4148 AXIAL 1 diode 1N 4148
D0023 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0025 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
D0026 304360 DIODE 1N 4007 GEGURTET 1 diode 1N 4002
E0001 356656 RELAIS 845-N-2C-S-24VDC 1 relay 24V
E0002 356656 RELAIS 845-N-2C-S-24VDC 1 relay 24V
E0003 356745 RELAIS M4-24H 1 relay 24V
F0002 302587 SICHER T 3.150 A/250V 1 fuse 3.15A slow blow
F0003 302587 SICHER T 3.150 A/250V 1 fuse 3.15A slow blow
F0004 302582 SICHER T 1.000 A/250V 1 fuse 1A slow blow
F0005 305205 SICHER T 2.500 A/250V 1 fuse 2.5A slow blow
G0001 357140 GLRI GBU 8K 1 rectifier
I0001 354199 IC SPNG.REGL. LM 317 T 1 IC LM 317 voltage regulator
I0002 354929 IC SPNG.REGL. LM 337 T 1 IC LM 337 voltage regulator
I0003 354199 IC SPNG.REGL. LM 317 T 1 IC LM 317 voltage regulator
I0004 354199 IC SPNG.REGL. LM 317 T 1 IC LM 317 voltage regulator
JS001 338835 STECKER-KALTGERÄTE 1 connector male mains
00010 301233 TRANS BD 246 B 0 transistor BD 246 B
00010 301234 TRANS BD 245 B 0 transistor BD 245 B
Q0003 348423 TRANS MPSA 92 1 transistor MPSA 92
Q0004 306928 TRANS BC 560 C 1 transistor BC 560 C
Q0005 306928 TRANS BC 560 C 1 transistor BC 560 C
Q0006 306928 TRANS BC 560 C 1 transistor BC 560 C
Q0007 306928 TRANS BC 560 C 1 transistor BC 560 C
Q0008 348591 TRANS BC 618 DARL. TO 92 1 transistor BC 618
Q0009 307150 TRANS BC 337-25 TO 92 1 transistor BC 337-25
S0001 354927 SCHALTER-NETZ 1 switch mains
00005 303576 SICHER-HALTE-FEDER 8 fuse clip
00010 328390 SICHER-HALTER FAU 1 fuse holder
Part No. Bezeichnung Qty Description
VENICE 240 Page 4 / 22
Pos. Nr.
Best. Nr.
813468
PCBAR#VENICE 160/240/320
2
pcb assy 81346 input mono
Ref. No.
CN006 348802 MESSERLST. 12POL 1 connector male 12-pin
CN007 348802 MESSERLST. 12POL 1 connector male 12-pin
CN008 348802 MESSERLST. 12POL 1 connector male 12-pin
CN01y 346759 MESSERLST. 18POL 1 connector male 18-pin
C001A 357452 KO-KER 330.0PF 100V 10% 1 cap ceramic 330pF
C0017 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C002A 357452 KO-KER 330.0PF 100V 10% 1 cap ceramic 330pF
C003A 357453 KO-EL 1000.000MF 6.3V 1 cap elctrolytic 1000uF/6.3V
C004A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C006A 342936 KO-FOL 0.150MF 63V 5% 1 cap mylar 150nF
C007A 342936 KO-FOL 0.150MF 63V 5% 1 cap mylar 150nF
C008A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C009A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C010A 336094 KO-FOL 6800.000PF 100V 5% 1 cap mylar 6800pF
C011A 301524 KO-KER 47.0PF 500V 10% 1 cap ceramic 47pF
C012A 300302 KO-FOL 1200.000PF 100V 5% 1 cap mylar 1200pF
C013A 326923 KO-FOL 3300.000PF 63V 5% 1 cap mylar 3300pF
C014A 341276 KO-FOL 0.012MF 100V 5% 1 cap mylar 12nF
C015A 327393 KO-FOL 4700.000PF 63V 5% 1 cap mylar 4700pF
C016A 336095 KO-FOL 0.100MF 63V 5% 1 cap mylar 100nF
C017A 336094 KO-FOL 6800.000PF 100V 5% 1 cap mylar 6800pF
C018A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C019A 342934 KO-FOL 0.033MF 100V 5% 1 cap mylar 33nF
C020A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C021A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C022A 301543 KO-KER 330.0PF 500V 10% 1 cap ceramic 330pF
C023A 358639 KO-EL 220.000MF 16V 1 cap electrolytic 220uF/16V
C024A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C025A 336094 KO-FOL 6800.000PF 100V 5% 1 cap mylar 6800pF
C028A 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C029A 357451 KO-KER 68.0PF 100V 2% 1 cap ceramic 68pF
C030A 357451 KO-KER 68.0PF 100V 2% 1 cap ceramic 68pF
C031A 335787 KO-KER 15.0PF 100V 2% 1 cap ceramic 15pF
C032A 335787 KO-KER 15.0PF 100V 2% 1 cap ceramic 15pF
C080A 343532 KO-EL 100.000MF 25V 1 cap electrolytic 100uF/25V
C081A 343532 KO-EL 100.000MF 25V 1 cap electrolytic 100uF/25V
C090A 340523 KO-EL 22.000MF 16V 1 cap electrolytic 22uF/16V
C091A 340523 KO-EL 22.000MF 16V 1 cap electrolytic 22uF/16V
C82AB 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C83AB 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C84AB 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C85AB 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C86AB 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C87AB 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C88AB 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C89AB 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
D001A 301254 DIODE 1N 4148 AXIAL 1 diode 1N 4148
D005A 301254 DIODE 1N 4148 AXIAL 1 diode 1N 4148
D006A 354005 LED GE 3MM LOW CURRENT 1 led yellow
D007A 354003 LED RT 3MM LOW CURRENT 1 led red
D008A 354004 LED GN 3MM LOW CURRENT 1 led green
Part No. Bezeichnung Qty Description
VENICE 240 Page 5 / 22
Pos. Nr.
Best. Nr.
822308
PCBAR#VENICE 160/240/320
1
pcb assy 82230 input stereo
Ref. No.
D009A 354003 LED RT 3MM LOW CURRENT 1 led red
D010A 301297 DIODE BAT 85 SCHOTTKY 1 diode BAT 85
D011A 301297 DIODE BAT 85 SCHOTTKY 1 diode BAT 85
D012A 354005 LED GE 3MM LOW CURRENT 1 led yellow
I001A 354933 IC NJM 2068 D DUAL IN 1 IC NJM 2068
I02AB 327197 IC NE 5532 P 2FACH OP 1 IC NE 5532 N
I03AB 358898 IC MC 33178 2FACH OP 1 IC MC 33178
I04AB 358661 IC NJM 2060 D 1 IC NJM 2060
I05AB 358661 IC NJM 2060 D 1 IC NJM 2060
I06AB 327197 IC NE 5532 P 2FACH OP 1 IC NE 5532 N
I07AB 343502 IC LM 2901 N 1 IC LM 2901
Q001A 343536 TRANS 2SA 1084 E TO 92 1 transistor 2SA 1084 E
Q002A 343536 TRANS 2SA 1084 E TO 92 1 transistor 2SA 1084 E
Q003A 348421 TRANS 2N 3906 1 transistor 2N 3906
Q004A 348421 TRANS 2N 3906 1 transistor 2N 3906
Q005A 348421 TRANS 2N 3906 1 transistor 2N 3906
R086A 340299 WI-SI 2.20 OHM 0.30W 5% 1 safety resistor 2.20 Ohm
R087A 340299 WI-SI 2.20 OHM 0.30W 5% 1 safety resistor 2.20 Ohm
S001A 357446 SCHALTER-TAST 2XUM 1 switch dpdt
S002A 357446 SCHALTER-TAST 2XUM 1 switch dpdt
S003A 357447 SCHALTER-TAST 4XUM 1 switch 4pdt
S004A 357447 SCHALTER-TAST 4XUM 1 switch 4pdt
S005A 357446 SCHALTER-TAST 2XUM 1 switch dpdt
S006A 357446 SCHALTER-TAST 2XUM 1 switch dpdt
S007A 357446 SCHALTER-TAST 2XUM 1 switch dpdt
VR01A 357442 P-DREH 2X 5KOHM LIN/LOG- 1 pot 2x5k Ohm
VR02A 357441 P-DREH 20KOHM LIN 1 pot 20k Ohm
VR03A 357435 P-DREH 2X200KOHM LOG- 1 pot 2x200k Ohm
VR04A 357439 P-DREH 10KOHM LIN 1 pot 10k Ohm
VR05A 357435 P-DREH 2X200KOHM LOG- 1 pot 2x200k Ohm
VR06A 357439 P-DREH 10KOHM LIN 1 pot 10k Ohm
VR07A 357441 P-DREH 20KOHM LIN 1 pot 20k Ohm
VR08A 357443 P-SHIB 10KOHM LOG+ 1 fader 10k Ohm
VR09A 358685 P-DREH 2X 10KOHM LOG-/LOG+ 1 pot 2x10k Ohm
VR10A 357437 P-DREH 50KOHM LOG- 1 pot 50k Ohm
VR11A 357437 P-DREH 50KOHM LOG- 1 pot 50k Ohm
VR12A 357437 P-DREH 50KOHM LOG- 1 pot 50k Ohm
VR13A 357437 P-DREH 50KOHM LOG- 1 pot 50k Ohm
VR14A 357436 P-DREH 2X 50KOHM LOG- 1 pot 2x50k Ohm
VR15A 357436 P-DREH 2X 50KOHM LOG- 1 pot 2x50k Ohm
Part No. Bezeichnung Qty Description
A0003 356641 KABEL-KONFEKT 6POL 0.230M 1 ribbon cable assy 6-way
CN007 348802 MESSERLST. 12POL 1 connector male 12-pin
CN008 348802 MESSERLST. 12POL 1 connector male 12-pin
CN01E 346759 MESSERLST. 18POL 1 connector male 18-pin
CN01F 346759 MESSERLST. 18POL 1 connector male 18-pin
CN017 344862 MESSERLST. 8POL 1 connector male 8-pin
CN018 344862 MESSERLST. 8POL 1 connector male 8-pin
CN020 348802 MESSERLST. 12POL 1 connector male 12-pin
CN021 344862 MESSERLST. 8POL 1 connector male 8-pin
CN022 345489 MESSERLST. 6POL 1 connector male 6-pin
VENICE 240 Page 6 / 22
Pos. Nr.
Best. Nr.
Ref. No.
CN024 348802 MESSERLST. 12POL 1 connector male 12-pin
CN025 348802 MESSERLST. 12POL 1 connector male 12-pin
CN026 344975 MESSERLST. 10POL 1 connector male 10-pin
CN06A 348802 MESSERLST. 12POL 1 connector male 12-pin
CN06B 348802 MESSERLST. 12POL 1 connector male 12-pin
CN19A 345489 MESSERLST. 6POL 1 connector male 6-pin
CN19B 345489 MESSERLST. 6POL 1 connector male 6-pin
C0001 301530 KO-KER 100.0PF 500V 10% 1 cap ceramic 100pF
C0002 301530 KO-KER 100.0PF 500V 10% 1 cap ceramic 100pF
C0003 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0004 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0005 301524 KO-KER 47.0PF 500V 10% 1 cap ceramic 47pF
C0006 301524 KO-KER 47.0PF 500V 10% 1 cap ceramic 47pF
C0007 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0008 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0009 340523 KO-EL 22.000MF 16V 1 cap electrolytic 22uF/16V
C001A 357452 KO-KER 330.0PF 100V 10% 1 cap ceramic 330pF
C0010 340523 KO-EL 22.000MF 16V 1 cap electrolytic 22uF/16V
C0011 301530 KO-KER 100.0PF 500V 10% 1 cap ceramic 100pF
C0012 301530 KO-KER 100.0PF 500V 10% 1 cap ceramic 100pF
C0013 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0014 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0015 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0016 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0017 301558 KO-KER 33.0PF 100V 2% 1 cap ceramic 33pF
C0018 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0019 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C002A 357452 KO-KER 330.0PF 100V 10% 1 cap ceramic 330pF
C0020 301530 KO-KER 100.0PF 500V 10% 1 cap ceramic 100pF
C0021 301530 KO-KER 100.0PF 500V 10% 1 cap ceramic 100pF
C0022 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0023 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0024 301519 KO-KER 10.0PF 500V 10% 1 cap ceramic 10pF
C0025 301519 KO-KER 10.0PF 500V 10% 1 cap ceramic 10pF
C0026 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0027 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0028 301558 KO-KER 33.0PF 100V 2% 1 cap ceramic 33pF
C0029 301558 KO-KER 33.0PF 100V 2% 1 cap ceramic 33pF
C003A 357453 KO-EL 1000.000MF 6.3V 1 cap elctrolytic 1000uF/6.3V
C0030 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0033 343532 KO-EL 100.000MF 25V 1 cap electrolytic 100uF/25V
C0034 343532 KO-EL 100.000MF 25V 1 cap electrolytic 100uF/25V
C0035 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0036 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0037 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0038 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0039 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C004A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0040 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0041 340521 KO-EL 2.200MF 50V 1 cap electrolytic 2.2uF/50V
C0042 340521 KO-EL 2.200MF 50V 1 cap electrolytic 2.2uF/50V
C0043 340523 KO-EL 22.000MF 16V 1 cap electrolytic 22uF/16V
C0044 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
Part No. Bezeichnung Qty Description
VENICE 240 Page 7 / 22
Pos. Nr.
Best. Nr.
Ref. No.
C0045 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0046 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0047 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0048 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0049 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C005A 358769 KO-KER 15.0PF 100V 2% 1 cap ceramic 15pF
C0050 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0051 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0052 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0053 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0054 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0055 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0056 343532 KO-EL 100.000MF 25V 1 cap electrolytic 100uF/25V
C0057 343532 KO-EL 100.000MF 25V 1 cap electrolytic 100uF/25V
C0058 340523 KO-EL 22.000MF 16V 1 cap electrolytic 22uF/16V
C0059 340521 KO-EL 2.200MF 50V 1 cap electrolytic 2.2uF/50V
C006A 342936 KO-FOL 0.150MF 63V 5% 1 cap mylar 150nF
C0060 340521 KO-EL 2.200MF 50V 1 cap electrolytic 2.2uF/50V
C0061 301558 KO-KER 33.0PF 100V 2% 1 cap ceramic 33pF
C0062 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0063 335787 KO-KER 15.0PF 100V 2% 1 cap ceramic 15pF
C0064 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0065 335787 KO-KER 15.0PF 100V 2% 1 cap ceramic 15pF
C0066 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0067 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0068 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0069 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C007A 342936 KO-FOL 0.150MF 63V 5% 1 cap mylar 150nF
C0070 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0071 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0072 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0073 301524 KO-KER 47.0PF 500V 10% 1 cap ceramic 47pF
C0074 301524 KO-KER 47.0PF 500V 10% 1 cap ceramic 47pF
C0075 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0076 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0077 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0078 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0079 301558 KO-KER 33.0PF 100V 2% 1 cap ceramic 33pF
C008A 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0080 301558 KO-KER 33.0PF 100V 2% 1 cap ceramic 33pF
C0081 329021 KO-KER 0.10MF 100V 20% 1 cap ceramic 100nF
C0082 301524 KO-KER 47.0PF 500V 10% 1 cap ceramic 47pF
C0083 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0084 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0085 301530 KO-KER 100.0PF 500V 10% 1 cap ceramic 100pF
C0086 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0087 301524 KO-KER 47.0PF 500V 10% 1 cap ceramic 47pF
C0088 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0089 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C009A 340523 KO-EL 22.000MF 16V 1 cap electrolytic 22uF/16V
C0090 301530 KO-KER 100.0PF 500V 10% 1 cap ceramic 100pF
C0091 340524 KO-EL 100.000MF 16V 1 cap electrolytic 100uF/16V
C0092 301524 KO-KER 47.0PF 500V 10% 1 cap ceramic 47pF
Part No. Bezeichnung Qty Description
Loading...
