Digital Console for Live and Studio with 40 Input Channels, 32 MIDAS PRO
Microphone Preampli ers and 25 Mix Buses and Live Multitrack Recording
2M32 LIVEQuick Start Guide3
Important Safety
Instructions
LEGAL DISCLAIMER
Instrucciones de
seguridad
NEGACIÓN LEGAL
GARANTÍA LIMITADA
LIMITED WARRANTY
Terminals marked with this symbol carry
electrical current of su cient magnitude
to constitute risk of electric shock.
Use only high-quality professional speaker cables with
¼" TS or twist-locking plugs pre-installed. Allother
installation or modi cation should be performed only
by quali edpersonnel.
This symbol, wherever it appears,
alertsyou to the presence of uninsulated
dangerous voltage inside the
enclosure-voltage that may be su cient to constitute a
risk ofshock.
This symbol, wherever it appears,
alertsyou to important operating and
maintenance instructions in the
accompanying literature. Please read the manual.
Caution
To reduce the risk of electric shock, donot
remove the top cover (or the rear section).
No user serviceable parts inside. Refer servicing to
quali ed personnel.
Caution
To reduce the risk of re or electric shock,
do not expose this appliance to rain and
moisture. The apparatus shall not be exposed to dripping
or splashing liquids and no objects lled with liquids,
suchas vases, shall be placed on the apparatus.
Caution
These service instructions are for use
by quali ed ser vice personnel only.
Toreduce the risk of electric shock do not perform any
servicing other than that contained in the operation
instructions. Repairs have to be performed by quali ed
servicepersonnel.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampli ers) that produce heat.
9. Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. Ifthe
provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Use only attachments/accessories speci ed by
themanufacturer.
12. Use only with the
cart, stand, tripod, bracket,
or table speci ed by the
manufacturer, orsold with
the apparatus. When a cart
is used, use caution when
moving the cart/apparatus
combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to quali ed service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has
beendropped.
15. The apparatus shall be connected to a MAINS socket
outlet with a protective earthing connection.
16. Where the MAINS plug or an appliance coupler is
used as the disconnect device, the disconnect device shall
remain readily operable.
17. Correct disposal of this
product: This symbol indicates
that this product must not be
disposed of with household
waste, according to the WEEE
Directive (2012/19/EU) and
your national law. This product
should be taken to a collection center licensed for the
recycling of waste electrical and electronic equipment
(EEE). The mishandling of this type of waste could have
a possible negative impact on the environment and
human health due to potentially hazardous substances
that are generally associated with EEE. At the same time,
your cooperation in the correct disposal of this product
will contribute to the e cient use of natural resources.
For more information about where you can take your
waste equipment for recycling, please contact your local
city o ce, or your household waste collection service.
18. Do not install in a con ned space, such as a book
case or similar unit.
19. Do not place naked ame sources, such as lighted
candles, on the apparatus.
20. Please keep the environmental aspects of battery
disposal in mind. Batteries must be disposed-of at a
battery collection point.
21. Use this apparatus in tropical and/or
moderate climates.
For the applicable warranty terms and conditions
and additional information regarding MUSIC Tribe’s
Limited Warranty, please see complete details online at
music-group.com/warranty.
Important information
1. Register online. Please register your new
MUSIC Tribe equipment right after you purchase it by
visiting midasconsoles.com. Registering your purchase
using our simple online form helps us to process your
repair claims more quickly and e ciently. Also, read the
terms and conditions of our warranty, if applicable.
2. Malfunction. Should your MUSIC Tribe
Authorized Reseller not be located in your vicinity,
you may contact the MUSIC Tribe Authorized Ful ller for
your country listed under “Support” at midasconsoles.com.
Should your country not be listed, please check if your
problem can be dealt with by our “Online Support” which
may also be found under “Support” at midasconsoles.com.
Alternatively, please submit an online warranty claim at
midasconsoles.com BEFORE returning the product.
3. Power Connections. Before plugging the
unit into a power socket, please make sure you are using
the correct mains voltage for your particular model.
Faulty fuses must be replaced with fuses of the same type
and rating without exception.
Las terminales marcadas con este símbolo
transportan corriente eléctrica de
magnitud su ciente como para constituir
un riesgo de descarga eléctrica. Utilice solo cables de
altavoz profesionales y de alta calidad con conectores
TS de 6,3 mm o de bayoneta pre jados. Cualquier otra
instalación o modi cación debe ser realizada únicamente
por un técnico cuali cado.
Este símbolo, siempre que aparece,
leadvierte de la presencia de voltaje
peligroso sin aislar dentro de la caja;
estevoltaje puede ser su ciente para constituir un riesgo
dedescarga.
Este símbolo, siempre que aparece,
leadvierte sobre instrucciones operativas
y de mantenimiento que aparecen en la
documentación adjunta. Por favor, lea el manual.
Atención
Para reducir el riesgo de descarga
eléctrica, no quite la tapa (o la parte
posterior). No hay piezas en el interior del equipo que
puedan ser reparadas por el usuario. Si es necesario,
póngase en contacto con personal cuali cado.
Atención
Para reducir el riesgo de incendio o
descarga eléctrica, no exponga este
aparato a la lluvia, humedad o alguna otra fuente que
pueda salpicar o derramar algún líquido sobre el aparato.
Nocoloque ningún tipo de recipiente para líquidos sobre
el aparato.
Atención
Las instrucciones de servicio deben
llevarlas a cabo exclusivamente personal
cuali cado. Para evitar el riesgo de una descarga eléctrica,
no realice reparaciones que no se encuentren descritas
en el manual de operaciones. Lasreparaciones deben ser
realizadas exclusivamente por personalcuali cado.
1. Lea las instrucciones.
2. Conserve estas instrucciones.
3. Preste atención a todas las advertencias.
4. Siga todas las instrucciones.
5. No use este aparato cerca del agua.
6. Limpie este aparato con un paño seco.
7. No bloquee las aberturas de ventilación. Instale el
equipo de acuerdo con las instrucciones del fabricante.
8. No instale este equipo cerca de fuentes de calor
tales como radiadores, acumuladores de calor, estufas u
otros aparatos (incluyendo ampli cadores) que puedan
producir calor.
9. No elimine o deshabilite nunca la conexión a tierra
del aparato o del cable de alimentación de corriente.
Unenchufe polarizado tiene dos polos, uno de los cuales
tiene un contacto más ancho que el otro. Una clavija con
puesta a tierra dispone de tres contactos: dos polos y la
puesta a tierra. El contacto ancho y el tercer contacto,
respectivamente, son los que garantizan una mayor
seguridad. Si el enchufe suministrado con el equipo no
concuerda con la toma de corriente, consulte con un
electricista para cambiar la toma de corriente obsoleta.
10. Coloque el cable de suministro de energía de manera
que no pueda ser pisado y que esté protegido de objetos
a lados. Asegúrese de que el cable de suministro de
energía esté protegido, especialmente en la zona de la
clavija y en el punto donde sale del aparato.
11. Use únicamente los dispositivos o accesorios
especi cados por el fabricante.
12. Use únicamente la
carretilla, plataforma,
trípode, soporte o mesa
especi cados por el
fabricante o suministrados
junto con el equipo.
Altransportar el equipo,
tenga cuidado para evitar
daños y caídas al tropezar con algún obstáculo.
13. Desenchufe el equipo durante tormentas o si no va a
utilizarlo durante un periodo largo.
14. Confíe las reparaciones únicamente a servicios
técnicos cuali cados. La unidad requiere mantenimiento
siempre que haya sufrido algún daño, si el cable de
suministro de energía o el enchufe presentaran daños,
sehubiera derramado un líquido o hubieran caído objetos
dentro del equipo, si el aparato hubiera estado expuesto
a la humedad o la lluvia, si ha dejado de funcionar de
manera normal o si ha sufrido algún golpe o caída.
15. Al conectar la unidad a la toma de corriente eléctrica
asegúrese de que la conexión disponga de una unión
atierra.
16. Si el enchufe o conector de red sirve como único
medio de desconexión, éste debe ser accesiblefácilmente.
17. Cómo debe deshacerse de
este aparato: Este símbolo indica
que este aparato no debe ser
tratado como basura orgánica,
según lo indicado en la Directiva
WEEE (2012/19/EU) y a las
normativas aplicables en su país.
En lugar de ello deberá llevarlo al punto limpio más
cercano para el reciclaje de sus elementos eléctricos/
electrónicos (EEE). Al hacer esto estará ayudando a
prevenir las posibles consecuencias negativas para el
medio ambiente y la salud que podrían ser provocadas
por una gestión inadecuada de este tipo de aparatos.
Además, el reciclaje de materiales ayudará a conservar
los recursos naturales. Para más información acerca del
reciclaje de este aparato, póngase en contacto con el
Ayuntamiento de su ciudad o con el punto limpio local.
18. No instale esta unidad en un espacio muy reducido,
tal como encastrada en una librería o similar.
19. No coloque objetos con llama, como una vela
encendida, sobre este aparato.
20. Tenga presentes todas las advertencias relativas
al reciclaje y correcta eliminación de las pilas. Las pilas
deben ser siempre eliminadas en un punto limpio y nunca
con el resto de la basura orgánica.
21. Use este aparato en rangos de temperatura
moderados y/o tropicales.
Si quiere conocer los detalles y condiciones aplicables
de la garantía así como información adicional sobre la
Garantía limitada de MUSIC Tribe, consulte online toda la
información en la web music-group.com/warranty.
Aspectos importantes
1. Registro online. Le recomendamos que
registre su nuevo aparato MUSIC Tribe justo después de su
compra accediendo a la página web midasconsoles.com.
El registro de su compra a través de nuestro sencillo
sistema online nos ayudará a resolver cualquier
incidencia que se presente a la mayor brevedad posible.
Además, aproveche para leer los términos y condiciones de
nuestra garantía, si es aplicable en su caso.
2. Averías. En el caso de que no exista un distribuidor
MUSIC Tribe en las inmediaciones, puede ponerse en
contacto con el distribuidor MUSIC Tribe de su país,
que encontrará dentro del apartado “Support” de nuestra
página web midasconsoles.com. En caso de que su país no
aparezca en ese listado, acceda a la sección “Online Support”
(que también encontrará dentro del apartado “Support”
de nuestra página web) y compruebe si su problema aparece
descrito y solucionado allí. De forma alternativa, envíenos a
través de la página web una solicitud online de soporte en
periodo de garantía ANTES de devolvernos el aparato.
3. Conexiones de corriente. Antes de enchufar
este aparato a una salida de corriente, asegúrese de que dicha
salida sea del voltaje adecuado para su modelo concreto.
En caso de que deba sustituir un fusible quemado, deberá
hacerlo por otro de idénticas especi caciones, sin excepción.
4M32 LIVEQuick Start Guide5
Consignes de sécurité
DÉNI LÉGAL
GARANTIE LIMITÉE
Wichtige
Sicherheitshinweise
HAFTUNGSAUSSCHLUSS
BESCHRÄNKTE GARANTIE
Les points repérés par ce symbole portent
une tension électrique su sante pour
constituer un risque d’électrocution.
Utilisez uniquement des câbles d’enceintes professionnels
de haute qualité avec ches Jack mono 6,35 mm ou ches
à verrouillages déjà installées. Touteautre installation ou
modi cation doit être e ectuée uniquement par un
personnel quali é.
Ce symbole avertit de la présence d’une
tension dangereuse et non isolée à
l’intérieur de l’appareil - elle peut
provoquer des chocs électriques.
Attention
Ce symbol signale les consignes
d’utilisation et d’entre ! Tien importantes
dans la documentation fournie. Lisez les consignes de
sécurité du manuel d’utilisation de l’appareil.
Attention
Pour éviter tout risque de choc électrique,
ne pas ouvrir le capot de l’appareil ni
démonter le panneau arrière. L’intérieur de l’appareil
ne possède aucun élément réparable par l’utilisateur.
Laissertoute réparation à un professionnel quali é.
Attention
Pour réduire les risques de feu et de choc
électrique, n’exposez pas cet appareil à la
pluie, à la moisissure, aux gouttes ou aux éclaboussures.
Ne posez pas de récipient contenant un liquide sur
l’appareil (un vase par exemple).
Attention
Ces consignes de sécurité et d’entretien
sont destinées à un personnel quali é.
Pouréviter tout risque de choc électrique, n’e ectuez
aucune réparation sur l’appareil qui ne soit décrite par le
manuel d’utilisation. Les éventuelles réparations doivent
être e ectuées uniquement par un technicien spécialisé.
1. Lisez ces consignes.
2. Conservez ces consignes.
3. Respectez tous les avertissements.
4. Respectez toutes les consignes d’utilisation.
5. N’utilisez jamais l’appareil à proximité d’un liquide.
6. Nettoyez l’appareil avec un chi on sec.
7. Veillez à ne pas empêcher la bonne ventilation
de l’appareil via ses ouïes de ventilation. Respectezles
consignes du fabricant concernant l’installation
del’appareil.
8. Ne placez pas l’appareil à proximité d’une source
de chaleur telle qu’un chau age, une cuisinière ou tout
appareil dégageant de la chaleur (y compris un ampli
depuissance).
9. Ne supprimez jamais la sécurité des prises bipolaires
ou des prises terre. Les prises bipolaires possèdent deux
contacts de largeur di érente. Leplus large est le contact
de sécurité. Les prises terre possèdent deux contacts plus
une mise à la terre servant de sécurité. Si la prise du bloc
d’alimentation ou du cordon d’ali-mentation fourni ne
correspond pas à celles de votre installation électrique,
faites appel à un électricien pour e ectuer le changement
de prise.
10. Installez le cordon d’alimentation de telle façon
que personne ne puisse marcher dessus et qu’il soit
protégé d’arêtes coupantes. Assurez-vous que le cordon
d’alimentation est sufsamment protégé, notamment au
niveau de sa prise électrique et de l’endroit où il est relié à
l’appareil; cela est également valable pour une éventuelle
rallonge électrique.
11. Utilisez exclusivement des accessoires et des
appareils supplémentaires recommandés par lefabricant.
12. Utilisez
exclusivement des
chariots, des diables,
desprésentoirs, despieds
et des surfaces de
travail recommandés
par le fabricant ou
livrés avec le produit.
Déplacezprécautionneusement tout chariot ou diable
chargé pour éviter d’éventuelles blessures en cas dechute.
13. Débranchez l’appareil de la tension secteur en cas
d’orage ou si l’appareil reste inutilisé pendant une longue
période de temps.
14. Les travaux d’entretien de l’appareil doivent
être e ectués uniquement par du personnel qualié.
Aucunentretien n’est nécessaire sauf si l’appareil est
endommagé de quelque façon que ce soit (dommagessur
le cordon d’alimentation ou la prise par exemple), siun
liquide ou un objet a pénétré à l’intérieur du châssis, si
l’appareil a été exposé à la pluie ou à l’humidité, s’il ne
fonctionne pas correctement ou à la suite d’une chute.
15. L’appareil doit être connecté à une prise secteur
dotée d’une protection par mise à la terre.
16. La prise électrique ou la prise IEC de tout appareil
dénué de bouton marche/arrêt doit rester accessible
enpermanence.
17. Mise au rebut appropriée de
ce produit: Ce symbole indique
qu’en accord avec la directive DEEE
(2012/19/EU) et les lois en vigueur
dans votre pays, ce produit ne
doit pas être jeté avec les déchets
ménagers. Ce produit doit être
déposé dans un point de collecte agréé pour le recyclage
des déchets d’équipements électriques et électroniques
(EEE). Une mauvaise manipulation de ce type de déchets
pourrait avoir un impact négatif sur l’environnement
et la santé à cause des substances potentiellement
dangereuses généralement associées à ces équipements.
En même temps, votre coopération dans la mise au
rebut de ce produit contribuera à l’utilisation e cace
des ressources naturelles. Pour plus d’informations
sur l’endroit où vous pouvez déposer vos déchets
d’équipements pour le recyclage, veuillez contacter votre
mairie ou votre centre local de collecte des déchets.
18. N’installez pas l’appareil dans un espace con né tel
qu’une bibliothèque ou meuble similaire.
19. Ne placez jamais d’objets en ammés, tels que des
bougies allumées, sur l’appareil.
20. Gardez à l’esprit l’impact environnemental lorsque
vous mettez des piles au rebus. Les piles usées doivent
être déposées dans un point de collecte adapté.
21. Utilisez l’appareil dans un climat tropical
et/ou modéré.
Pour connaître les termes et conditions de garantie
applicables, ainsi que les informations supplémentaires
et détaillées sur la Garantie Limitée de MUSIC Tribe,
consultez le site Internet music-group.com/warranty.
Informations importantes
1. Enregistrez-vous en ligne. Prenez le
temps d’enregistrer votre produit MUSIC Tribe aussi vite
que possible sur le site Internet midasconsoles.com. Le fait
d’enregistrer le produit en ligne nous permet de gérer
les réparations plus rapidement et plus e cacement.
Prenez également le temps de lire les termes et conditions
de notre garantie.
2. Dysfonctionnement. Si vous n’avez pas de
revendeur MUSIC Tribe près de chez vous, contactez le
distributeur MUSIC Tribe de votre pays : consultez la liste
des distributeurs de votre pays dans la page “Support” de
notre site Internet midasconsoles.com. Si votre pays n’est
pas dans la liste, essayez de résoudre votre problème avec
notre “aide en ligne” que vous trouverez également dans
la section “Support” du site midasconsoles.com. Vous
pouvez également nous faire parvenir directement votre
demande de réparation sous garantie par Internet sur le
site midasconsoles.com AVANT de nous renvoyer le produit.
3. Raccordement au secteur. Avant de relier
cet équipement au secteur, assurez-vous que la tension
secteur de votre région soit compatible avec l’appareil.
Veillez à remplacer les fusibles uniquement par des
modèles exactement de même taille et de même valeur
électrique — sans aucune exception.
Vorsicht
Die mit dem Symbol markierten
Anschlüsse führen so viel Spannung,
dassdie Gefahr eines Stromschlags besteht.
Verwenden Sie nur hochwertige, professionelle
Lautsprecherkabel mit vorinstallierten 6,35 mm
MONO-Klinkensteckern oder Lautsprecherstecker
mit Drehverriegelung. Alle anderen Installationen
oder Modi kationen sollten nur von quali ziertem
Fachpersonal ausgeführt werden.
Achtung
Um eine Gefährdung durch Stromschlag
auszuschließen, darf die Geräteabdeckung
bzw. Geräterückwand nicht abgenommen werden.
ImInnern des Geräts be nden sich keine vom Benutzer
reparierbaren Teile. Reparaturarbeiten dürfen nur von
quali zier tem Personal ausgeführt werden.
Achtung
Um eine Gefährdung durch Feuer bzw.
Stromschlag auszuschließen, darf dieses
Gerät weder Regen oder Feuchtigkeit ausgesetzt werden
noch sollten Spritzwasser oder tropfende Flüssigkeiten
in das Gerät gelangen können. Stellen Sie keine mit
Flüssigkeit gefüllten Gegenstände, wie z. B. Vasen,
aufdasGerät.
Achtung
Die Service-Hinweise sind nur durch
quali zier tes Personal zu befolgen.
Umeine Gefährdung durch Stromschlag zu vermeiden,
führen Sie bitte keinerlei Reparaturen an dem Gerät
durch, die nicht in der Bedienungsanleitung beschrieben
sind. Reparaturen sind nur von quali ziertem
Fachpersonaldurchzuführen.
1. Lesen Sie diese Hinweise.
2. Bewahren Sie diese Hinweise auf.
3. Beachten Sie alle Warnhinweise.
4. Befolgen Sie alle Bedienungshinweise.
5. Betreiben Sie das Gerät nicht in der Nähe vonWasser.
6. Reinigen Sie das Gerät mit einem trockenen Tuch.
7. Blockieren Sie nicht die Belüftungsschlitze. Beachten
Sie beim Einbau des Gerätes die Herstellerhinweise.
8. Stellen Sie das Gerät nicht in der Nähe von
Wärmequellen auf. Solche Wärmequellen sind z. B.
Heizkörper, Herde oder andere Wärme erzeugende Geräte
(auch Verstärker).
9. Entfernen Sie in keinem Fall die
Sicherheitsvorrichtung von Zweipol- oder geerdeten
Steckern. Ein Zweipolstecker hat zwei unterschiedlich
breite Steckkontakte. Ein geerdeter Stecker hat zwei
Steckkontakte und einen dritten Erdungskontakt.
Derbreitere Steckkontakt oder der zusätzliche
Erdungskontakt dient Ihrer Sicherheit. Falls das
mitgelieferte Steckerformat nicht zu Ihrer Steckdose
passt, wenden Sie sich bitte an einen Elektriker, damit die
Steckdose entsprechend ausgetauscht wird.
10. Verlegen Sie das Netzkabel so, dass es vor
Tritten und scharfen Kanten geschützt ist und nicht
beschädigt werden kann. Achten Sie bitte insbesondere
im Bereich der Stecker, Verlängerungskabel und an
der Stelle, an der das Netzkabel das Gerät verlässt,
aufausreichendenSchutz.
11. Das Gerät muss jederzeit mit intaktem Schutzleiter
an das Stromnetz angeschlossen sein.
12. Sollte der Hauptnetzstecker oder eine
Gerätesteckdose die Funktionseinheit zum Abschalten
sein, muss diese immer zugänglich sein.
13. Verwenden Sie nur Zusatzgeräte/Zubehörteile,
dielaut Hersteller geeignet sind.
14. Verwenden
Sie nur Wagen,
Standvorrichtungen,
Stative, Halter oder Tische,
die vom Hersteller benannt
oder im Lieferumfang
des Geräts enthalten
sind. Falls Sie einen
Wagen benutzen, seien Sie vorsichtig beim Bewegen
der Wagen- Gerätkombination, umVerletzungen durch
Stolpern zuvermeiden.
15. Ziehen Sie den Netzstecker bei Gewitter oder wenn
Sie das Gerät längere Zeit nicht benutzen.
16. Lassen Sie alle Wartungsarbeiten nur von
quali zier tem Service-Personal ausführen. EineWartung
ist notwendig, wenn das Gerät in irgendeiner Weise
beschädigt wurde (z. B. Beschädigung des Netzkabels oder
Steckers), Gegenstände oder Flüssigkeit in das Geräteinnere
gelangt sind, das Gerät Regen oder Feuchtigkeit ausgesetzt
wurde, das Gerät nicht ordnungsgemäß funktioniert oder
auf den Boden gefallen ist.
17. Korrekte Entsorgung
dieses Produkts: Dieses
Symbol weist darauf hin, das
Produkt entsprechend der
WEEE Direktive (2012/19/EU)
und der jeweiligen nationalen
Gesetze nicht zusammen mit
Ihren Haushaltsabfällen zu entsorgen. DiesesProdukt
sollte bei einer autorisierten Sammelstelle für
Recycling elektrischer und elektronischer Geräte (EEE)
abgegeben werden. Wegen bedenklicher Substanzen,
diegenerell mit elektrischen und elektronischen Geräten
in Verbindung stehen, könnte eine unsachgemäße
Behandlung dieser Abfallart eine negative Auswirkung
auf Umwelt und Gesundheit haben. Gleichzeitig
gewährleistet Ihr Beitrag zur richtigen Entsorgung dieses
Produkts die e ektive Nutzung natürlicher Ressourcen.
Fürweitere Informationen zur Entsorgung Ihrer Geräte
bei einer Recycling-Stelle nehmen Sie bitte Kontakt zum
zuständigen städtischen Büro, Entsorgungsamt oder zu
Ihrem Haushaltsabfallentsorgerauf.
18. Installieren Sie das Gerät nicht in einer beengten
Umgebung, zum Beispiel Bücherregal oder ähnliches.
19. Stellen Sie keine Gegenstände mit o enen
Flammen, etwa brennende Kerzen, auf das Gerät.
20. Beachten Sie bei der Entsorgung von Batterien
den Umweltschutz-Aspekt. Batterien müssen bei einer
Batterie-Sammelstelle entsorgt werden.
21. Verwenden Sie das Gerät in tropischen und/oder
gemäßigten Klimazonen.
Die geltenden Garantiebedingungen und zusätzliche
Informationen bezüglich der von MUSIC Tribe gewährten
beschränkten Garantie nden Sie online unter
music-group.com/warranty.
Weitere wichtige
Informationen
1. Online registrieren. Bitte registrieren Sie
Ihr neues MUSIC Tribe-Gerät direkt nach dem Kauf auf
der Website midasconsoles.com. Wenn Sie Ihren Kauf
mit unserem einfachen online Formular registrieren,
können wir Ihre Reparaturansprüche schneller und
e zienter bearbeiten. Lesen Sie bitte auch unsere
Garantiebedingungen, falls zutre end.
2. Funktionsfehler. Sollte sich kein MUSIC Tribe
Händler in Ihrer Nähe be nden, können Sie den
MUSIC Tribe Vertrieb Ihres Landes kontaktieren,
der auf midasconsoles.com unter „Support“ aufgeführt
ist. Sollte Ihr Land nicht aufgelistet sein, prüfen Sie
bitte, ob Ihr Problem von unserem „Online Support“
gelöst werden kann, den Sie ebenfalls auf behringer.com
unter „Support“ nden. Alternativ reichen Sie bitte Ihren
Garantieanspruch online auf midasconsoles.com ein,
BEVOR Sie das Produkt zurücksenden.
3. Stromanschluss. Bevor Sie das Gerät an
eine Netzsteckdose anschließen, prüfen Sie bitte, ob Sie
die korrekte Netzspannung für Ihr spezielles Modell
verwenden. Fehlerhafte Sicherungen müssen ausnahmslos
durch Sicherungen des gleichen Typs und Nennwerts
ersetzt werden.
6M32 LIVEQuick Start Guide7
Instruções de Segurança
Importantes
LEGAL RENUNCIANTE
GARANTIA LIMITADA
安全にお使いいただくために
限定保証
法的放棄
Aviso!
Terminais marcados com o símbolo
carregam corrente elétrica de magnitude
su ciente para constituir um risco de choque elétrico.
Use apenas cabos de alto-falantes de alta qualidade
com plugues TS de ¼" ou plugues com trava de torção
pré-instalados. Todas as outras instalações e modi cações
devem ser efetuadas por pessoasquali cadas.
Este símbolo, onde quer que o encontre,
alerta-o para a leitura das instruções de
manuseamento que acompanham o
equipamento. Por favor leia o manual de instruções.
Atenção
De forma a diminuir o risco de choque
eléctrico, não remover a cobertura
(ouasecção de trás). Não existem peças substituíveis por
parte do utilizador no seu interior. Para esse efeito recorrer
a um técnico quali cado.
Atenção
Para reduzir o risco de incêndios ou
choques eléctricos o aparelho não deve ser
exposto à chuva nem à humidade. Além disso, não deve
ser sujeito a salpicos, nem devem ser colocados em cima
do aparelho objectos contendo líquidos, tais como jarras.
Atenção
Estas instruções de operação devem ser
utilizadas, em exclusivo, por técnicos de
assistência quali cados. Para evitar choques eléctricos
não proceda a reparações ou intervenções, que não as
indicadas nas instruções de operação, salvo se possuir as
quali - cações necessárias. Para evitar choques eléctricos
não proceda a reparações ou intervenções, que não as
indicadas nas instruções de operação. Só o deverá fazer se
possuir as quali cações necessárias.
1. Leia estas instruções.
2. Guarde estas instruções.
3. Preste atenção a todos os avisos.
4. Siga todas as instruções.
5. Não utilize este dispositivo perto de água.
6. Limpe apenas com um pano seco.
7. Não obstrua as entradas de ventilação. Instale de
acordo com as instruções do fabricante.
8. Não instale perto de quaisquer fontes de calor tais
como radiadores, bocas de ar quente, fogões de sala
ou outros aparelhos (incluindo ampli cadores) que
produzam calor.
9. Não anule o objectivo de segurança das chas
polarizadas ou do tipo de ligação à terra. Uma cha
polarizada dispõe de duas palhetas sendo uma mais larga
do que a outra. Uma cha do tipo ligação à terra dispõe
de duas palhetas e um terceiro dente de ligação à terra.
A palheta larga ou o terceiro dente são fornecidos para
sua segurança. Se a cha fornecida não encaixar na sua
tomada, consulte um electricista para a substituição da
tomada obsoleta.
10. Proteja o cabo de alimentação de pisadelas ou
apertos, especialmente nas chas, extensões, e no local
de saída da unidade. Certi que -se de que o cabo eléctrico
está protegido. Veri que particularmente nas chas, nos
receptáculos e no ponto em que o cabo sai doaparelho.
11. O aparelho tem de estar sempre conectado à rede
eléctrica com o condutor de protecção intacto.
12. Se utilizar uma cha de rede principal ou uma
tomada de aparelhos para desligar a unidade de
funcionamento, esta deve estar sempre acessível.
13. Utilize apenas ligações/acessórios especi cados
pelofabricante.
14. Utilize apenas com
o carrinho, estrutura,
tripé, suporte, ou mesa
especi cados pelo
fabricante ou vendidos
com o dispositivo.
Quandoutilizar um
carrinho, tenha cuidado ao
mover o conjunto carrinho/dispositivo para evitar danos
provocados pela terpidação.
15. Desligue este dispositivo durante as trovoadas
ou quando não for utilizado durante longos períodos
detempo.
16. Qualquer tipo de reparação deve ser sempre
efectuado por pessoal quali cado. É necessária uma
reparação sempre que a unidade tiver sido de alguma
forma dani cada, como por exemplo: no caso do cabo
de alimentação ou cha se encontrarem dani cados;
naeventualidade de líquido ter sido derramado ou
objectos terem caído para dentro do dispositivo; no caso
da unidade ter estado exposta à chuva ou à humidade;
seesta não funcionar normalmente, ou se tiver caído.
17. Correcta eliminação deste
produto: este símbolo indica que
o produto não deve ser eliminado
juntamente com os resíduos
domésticos, segundo a Directiva
REEE (2012/19/EU) e a legislação
nacional. Este produto deverá
ser levado para um centro de recolha licenciado para a
reciclagem de resíduos de equipamentos eléctricos e
electrónicos (EEE). O tratamento incorrecto deste tipo
de resíduos pode ter um eventual impacto negativo
no ambiente e na saúde humana devido a substâncias
potencialmente perigosas que estão geralmente
associadas aos EEE. Ao mesmo tempo, a sua colaboração
para a eliminação correcta deste produto irá contribuir
para a utilização e ciente dos recursos naturais. Paramais
informação acerca dos locais onde poderá deixar o seu
equipamento usado para reciclagem, é favor contactar
os serviços municipais locais, a entidade de gestão de
resíduos ou os serviços de recolha de resíduosdomésticos.
18. Não instale em lugares con nados, tais como
estantes ou unidades similares.
19. Não coloque fontes de chama, tais como velas
acesas, sobre o aparelho.
20. Favor, obedecer os aspectos ambientais de descarte
de bateria. Baterias devem ser descartadas em um ponto
de coletas de baterias.
21. Use este aparelho em climas tropicais e/
ou moderados.
O MUSIC Tribe não se responsabiliza por perda alguma
que possa ser sofrida por qualquer pessoa que dependa,
seja de maneira completa ou parcial, de qualquer
descrição, fotogra a, ou declaração aqui contidas.
Dados técnicos, aparências e outras informações
estão sujeitas a modi cações sem aviso prévio.
Todas as marcas são propriedade de seus respectivos
donos. MIDAS, KLARK TEKNIK, LAB GRUPPEN,
Para obter os termos de garantia aplicáveis e condições e
informações adicionais a respeito da garantia limitada do
MUSIC Tribe, favor veri car detalhes na íntegra através do
website music-group.com/warranty.
Outras Informações
Importantes
1. Registre-se online. Por favor, registre seu
novo equipamento MUSIC Tribe logo após a compra
visitando o site midasconsoles.com Registrar sua compra
usando nosso simples formulário online nos ajuda a
processar seus pedidos de reparos com maior rapidez e
e ciência. Além disso, leia nossos termos e condições de
garantia, caso seja necessário.
2. Funcionamento Defeituoso.
Caso seu fornecedor MUSIC Tribe não esteja localizado
nas proximidades, você pode contatar um distribuidor
MUSIC Tribe para o seu país listado abaixo de “Suporte”
em midasconsoles.com. Se seu país não estiver na
lista, favor checar se seu problema pode ser resolvido
com o nosso “Suporte Online” que também pode ser
achado abaixo de “Suporte”em midasconsoles.com.
Alternativamente, favor enviar uma solicitação de garantia
online em midasconsoles.com ANTES da devolução
do produto.
3. Ligações. Antes de ligar a unidade à tomada,
assegure-se de que está a utilizar a voltagem correcta para
o modelo em questão. Os fusíveis com defeito terão de
ser substituídos, sem qualquer excepção, por fusíveis do
mesmo tipo e corrente nominal.
注意
感電の.恐れがありますので、カ
バーや その他の部品を取り外
したり、開けたりしないでください。高品
質なプロ用スピーカーケーブル(¼" T S標準
ケーブルおよびツイストロッキングプラ
グケーブル)を使用してください。
for the selected channel with the GAIN
rotary control. Press the 48 V button to apply
phantom power for use with condenser
microphones and press the Ø button to
reverse the channel’s phase. The LED meter
displays the selected channel’s level. Press the
LOW CUT button and select the desired
high-pass frequency to remove unwanted
lows. Press the VIEW button to access more
detailed parameters on the Main Display.
(2) GATE/DYNAMICS - Press the GATE button
to engage the noise gate and adjust the
threshold accordingly. Press the COMP button
to engage the compressor and adjust the
threshold accordingly. When the signal level
in the LCD meter drops below the selected
gate threshold , the noise gate will silence
the channel. When the signal level reaches
the selected dynamics threshold, the peaks
will be compressed. Press the VIEW button
to access more detailed parameters on the
MainDisplay.
(3) EQUALISER - Press the EQ button to
engage this section. Select one of the four
frequency bands with the LOW, LO MID, HI MID and HIGH buttons. Press the MODE
button to cycle through the types of EQ
available. Boost or cut the selec ted frequency
with the GAIN rotary control. Select the
speci c frequency to be adjusted with the
FREQUENCY rotary control and adjust the
bandwidth of the selected frequency with the
WIDTH rotary control. Press the VIEW button
to access more detailed parameters on the
Main Display.
(4) BUS SENDS - Quickly adjust the bus sends by
selecting one of the four banks, followed by
one of the four rotary controls. Press the VIEW
button to access more detailed parameters on
the Main Display.
(5) RECORDER - Connect an external memory
stick to install rmware updates, load and
save show data, and to record performances.
Press the VIEW button to access more detailed
Recorder parameters on the Main Display.
(6) MAIN BUS - Press the MONO CENTRE or
MAIN STEREO buttons to assign the channel to the main mono or stereo bus. When MAIN
STEREO (stereo bus) is selected, the PAN /
BAL adjusts to the left-to-right positioning.
Adjust the overall send level to the mono
bus with the M/C LEVEL rotary control.
Press the VIEW button to access more detailed
parameters on the Main Display.
(7) MAIN DISPLAY - The majority of the M32’s
controls can be edited and monitored via
the Main Display. When the VIEW button is
pressed on any of the control panel functions,
it is here that they can be viewed. The main
display is also used for accessing the 60+
virtual e ects. See section 3. Main Display.
(8) MONITOR - Adjust the level of the monitor
outputs with the MONITOR LEVEL rotar y
control. Adjust the level of the headphones
output with the PHONES LEVEL rotary control.
Press the MONO button to monitor the audio
in mono. Press the DIM button to reduce the
monitor volume. Press the VIEW button to
adjust the amount of attenuation along with all
other monitor-related functions.
(9) TA LKB ACK - Connec t a talkback microphone
via a standard XLR cable via the EXT MIC
socket. Adjust the level of the talk back mic
with the TALK LEVEL rotary control. Select the
destination of the talkback signal with the TAL K A/TALK B buttons. Press the VIEW button to
edit the talkback routing for A and B.
(10) SCENES - This section is used to save and
recall automation scenes in the console,
allowing di erent con gurations to be
recalled at a later time. Please refer to the User
Manual for more details on this topic.
(11) ASSIGN - Assign the four rotary controls
to various parameters for instant access to
commonly-used functions. The LCD displays
provide quick reference to the assignments of
the active layer of custom controls. Assign each
of the eight custom ASSIGN buttons (numbered
5-12) to various parameters for instant access
to commonly-used functions. Press one of the
SET buttons to activate one of the three layers of
custom-assignable controls. Please refer to the
User Manual for more details on this topic.
(12) MUTE GROUPS - Press one of the buttons in
the MUTE GROUPS section to activate one of
the mute groups. For more details, see MUTE GRP in section 3. Main Display.
(13) INPUT CHANNELS - The Input Channels
section of the console o ers 16 separate
input channel strips. The strips represent four
separate layers of input for the console, which
can each be accessed by pressing one of the
following buttons:
• • INPUTS 1-16 - the rst and second blocks
eight channels assigned on the ROUTING/
HOME page
• • INPUTS 17-32 - the third and fourth
blocks of eight channels assigned on the
ROUTING / HOME page
• • AUX IN / USB - the fth block of six
channels & USB Recorder, and eight
channel FX returns (1L ...4R)
• • BUS MAST - this allows you to adjust the
levels of the 16 Mix Bus Masters, which is
useful when including Bus Masters into
DCA Group assignments, or when mixing
buses to matrices 1-6.
Press any of the above buttons (located to the
left of the Channel Strip) to switch the input
channel bank to any of the four layers listed
above. The button will illuminate to show
which layer is active.
You will nd a SEL (select) button on top
of every channel which is used to direc t the
control focus of the user’s interface, including
all channel-related parameters to that channel.
There is always exactly one channel selected.
The LED display shows the current audio signal
level through that channel.
The SOLO button isolates the audio signal for
monitoring that channel.
The LCD Scribble Strip (which can be edited
via the Main Display) shows the current
channel assignment.
The MUTE button mutes the audio for that
channel.
(14) GROUP/BUS CHANNELS - This section o ers
eight channel strips, assigned to one of the
following layers:
• • GROUP DCA 1-8 - Eight DCA (Digitally
Controlled Ampli er) groups
• • BUS 1-8 - Mix Bus masters 1-8
• • BUS 9-16 - Mix Bus Masters 9-16
• • MTX 1-6 / MAIN C - Matrix Outputs 1-6
and the Main Centre (Mono) bus.
The SEL, SOLO & MUTE buttons, the LED
display, and the LCD scribble strip all behave in
the same way as for the INPUT CHANNELS.
(15) MAIN CHANNEL - This controls the Master
Output stereo mix bus.
The SEL, SOLO & MUTE buttons, and the LCD
scribble strip all behave in the same way as for
the INPUT CHANNELS.
The CLR SOLO button removes any solo
functions from any of the other channels.
Please refer to the User Manual for more information
on each of these topics.
(1)
(4)(6) (7)(8) (9)(10)(11)(5)
(2)(3)
2. Rear Panel
(1) MONITOR/CONTROL ROOM OUTPUTS-
connect a pair of studio monitors using
XLR or ¼" cables. Also includes a 12 V / 5 W
lamp connection.
(2) OUTPUTS 1 - 16 - Send analogue audio
to external equipment using XLR cables.
Outputs15 and 16 by default carry the main
stereo bus signals.
(3) INPUTS 1 - 32 - Connect audio sources
(suchas microphones or line level sources)
viaXLR cables.
(4) POWER - The IEC mains socket and
ON/OFF switch.
(5) DN32-LIVE INTERFACE CARD - Transmit up to
32channels of audio to and from a computer
via USB 2.0, as well as record up to 32 channels
to SD/SDHC cards.
(6) REMOTE CONTROL INPUTS - Connect to a PC
for remote control via Ethernet cable.
(7) MIDI IN/OUT - Send and receive MIDI
commands via 5-pin DIN cables.
(8) AES/EBU OUT - Send digital audio via 3-pin
AES/EBU XLR cable.
(9) ULTRANET - Connect to a personal
monitoring system, such as the BEHRINGER
P16, via Ethernet cable.
(10) AES50 A/B - Transmit up to 96 channels in
and out via Ethernet cables.
(11) AUX IN/OUT - Connect to and from external
equipment via ¼" or RCA cables.
Please refer to the User Manual for more information
on each of these topics.
(1)
(2)
(6)
(3)(4)(5)
(7)
(6)(8)(9)(3)(4)(5)
(7)
(8)(9)
(10)
(11)
(12)
(13)(14)(15)
12M32 LIVEQuick Start Guide13
3. Main Display
(3)
(4)(5)
(1)(2)
(1) DISPLAY SCREEN - The controls in this section
are used in conjunction with the colour screen
in order to navigate and control the graphical
elements it contains.
By including dedicated rotary controls that
correspond to the adjacent controls on the
screen, as well as including cursor buttons,
theuser can quickly navigate and control all of
the colour screen’s elements.
The colour screen contains various displays
that give visual feedback for the operation of
the console, and also allow the user to make
various adjustments not provided for by the
dedicated hardware controls.
(2) MAIN/SOLO METERS - This triple 24-segment
meter displays the audio signal level output
from the main bus, as well as the main centre
or solo bus of the console.
(3) SCREEN SELECTION BUTTONS - These
eight illuminated buttons allow the user to
immediately navigate to any of the eight
master screens that address di erent sections
of the console. The sections that can be
navigated are:
• • HOME - The HOME screen contains an
overview of the selected input or output
channel, and o ers various adjustments
not available through the dedicated toppanel controls.
The HOME screen contains the following
separate tabs:
home: General signal path for the
selected input or output channel.
con g: Allows selection of the signal
source/destination for the channel,
con guration of insert point, and
other settings.
gate: Controls and displays the channel
gate e ect beyond those o ered by the
dedicated top-panel controls.
dyn: Dynamics - controls and displays the
channel dynamics e ect (compressor)
beyond those o ered by the dedicated
top-panel controls.
eq: Controls and displays the channel
EQ e ect beyond those o ered by the
dedicated top-panel controls.
sends: Controls and displays for channel
sends, such as sends metering and
send muting.
main: Controls and displays for the
selected channel’s output.
• • METERS - The meters screen displays
di erent groups of level meters for
various signal paths, and is useful for
quickly ascertaining if any channels need
level adjustment. Since there are no
parameters to adjust for the metering
displays, none of the metering screens
contain any ‘bottom of the screen’
controls that would normally be adjusted
by the six rotary controls.
The METER screen contains the following
separate screen tabs, each containing
level meters for the relevant signal paths:
channel, mix bus, aux/fx, in/out and rta.
• • ROUTING - The ROUTING screen is where
all signal patching is done, allowing
the user to route internal signal paths
to and from the physical input/output
connectors located on the console’s
rear panel.
The ROUTING screen contains the
following separate tabs:
home: Allows patching of physical inputs
to the 32 input channels and aux inputs of
the console.
out 1-16: Allows patching of internal
signal paths to the console’s 16 rear panel
XLR outputs.
aux out: Allows patching of internal
signal paths to the console’s six rear panel
¼" / RCA auxiliary outputs.
p16 out: Allows patching of internal signal
paths to the 16 outputs of the console’s
16-channel P16 Ultranet output.
card out: Allows patching of internal
signal paths to the 32 outputs of the
expansion card.
aes50-a: Allows patching of internal
signal paths to the 48 outputs of the rear
panel AES50-A output.
aes50-b: Allows patching of internal
signal paths to the 48 outputs of the rear
panel AES50-B output.
xlr out: Allows the user to con gure the
XLR outs on the rear of the console in
blocks of four, from either local inputs,
the AES streams, or expansion card.
• • SETUP - The SETUP screen o ers controls
for global, high-level functions of the
console, such as display adjustments,
sample rates & synchronisation, user
settings, and network con guration.
The SETUP screen contains the following
separate tabs:
global: This screen o ers adjustments
for various global preferences of how the
console operates.
con g: This screen o ers adjustments for
sample rates and synchronisation, aswell
as con guring high-level settings for
signal path buses.
remote: This screen o ers di erent
controls for setting up the console as a
control surface for various DAW recording
software on a connected computer. It also
con gures the MIDI Rx/Tx preferences.
network: This screen o ers di erent
controls for attaching the console to a
standard Ethernet network. (IP address,
Subnet Mask, Gateway.)
scribble strip: This screen o ers controls
for various customisation of the console’s
LCD scribble strips.
preamps: Shows the analogue gain for
local mic inputs (XLR at the rear) and
phantom power, including setup from
remote stage boxes (e.g. DL16) connected
via AES50.
card: This screen selects the input/
output con guration of the installed
interface card.
• • LIBRARY - The LIBRARY screen allows
loading and saving of commonly-used
setups for the channel inputs, e ects
processors, and routing scenarios.
The LIBRARY screen contains the
following tabs:
channel: This tab allows the user to load
and save commonly used combinations
of the channel processing, including
dynamics andequalisation.
e ects: This tab allows the user to
load and save commonly used e ects
processor presets.
routing: This tab allows the user to load
and save commonly used signal routings.
• • EFFECT S - The EFFECTS screen controls
various aspects of the eight e ects
processors. On this screen the user
can select speci c types of e ects for
the eight internal e ects processors,
con gure their input and output paths,
monitor their levels, and adjust the
various e ects parameters.
The EFFECTS screen contains the
following separate tabs:
home: The home screen provides a
general overview of the virtual e ects
rack, displaying what e ect has been
inserted in each of the eight slots, as well
as displaying input/output paths for each
slot and the I/O signal levels.
fx1-8: These eight duplicate screens
display all of the relevant data for
the eight separate e ects processors,
allowing the user to adjust all parameters
for the selected e ect.
• • MUTE GRP - The MUTE GRP screen allows
for quick assignment and control of the
console’s six mute groups, and o ers two
separate functions:
1. Mutes the active screen during the
process of assigning channels to
mute groups. This ensures that no
channels are accidentally muted
during the assignment process
during a live performance.
2. It o ers an additional interface
for muting/unmuting the groups
in addition to the dedicated mute
group buttons at the bottom of
the console.
• • UTILITY - The UTILITY screen is a
supplemental screen designed to work in
conjunction with the other screens that
may be in view at any particular moment.
The UTILITY screen is never seen by itself,
it always exists in the context of another
screen, and typically brings up copy, paste
and library or customisation functions.
(4) ROTARY CONTROLS - These six rotary controls
are used to adjust the various elements
located directly above them. Each of the six
controls can be pushed inward to activate a
button-press function. This function is useful
when controlling elements that have a dual
on/o status that is best controlled by a
button, as opposed to a variable state that is
best adjusted by a rotary control.
(5) UP/DOWN/LEFT/RIGHT NAVIGATION
CONTROLS - The LEFT and RIGHT controls
allow for left-right navigation among the
di erent pages contained within a screen
set. A graphical tab display shows which
page you are currently on. On some screens
there are more parameters present than
can be adjusted by the six rotary controls
underneath. In these cases, use the UP
and DOWN buttons to navigate through
any additional layers contained on the
screen page. The LEFT and RIGHT buttons
are sometimes used to con rm or cancel
con rmation pop-ups.
Please refer to the User Manual for more information
on each of these topics.
14M32 LIVEQuick Start Guide15
4. Quick Reference Section
Editing Channel Strip LCDs
1. Hold down the select button for the channel you
wish to change and press UTILITY.
2. Use the rotary controls below the screen to
adjust parameters.
3. There is also a dedicated Scribble Strip tab on
the SETUP menu.
4. Select the channel while viewing this screen
to edit.
Using Buses
Bus Setup:
The M32 o ers ultra exible busing as each channel’s
bus sends can be independently Pre- or Post-Fader,
(selectable in pairs of buses). Select a channel
and press VIEW in the BUS SENDS section on the
channel strip.
Reveal options for Pre/Post/Subgroup by pressing
the Down Navigation button by the screen.
To con gure a bus globally, press its SEL button and
then press VIEW on the CONFIG/PREAMP section
on the channel strip. Use the third rotary control to
change con gurations. This will a ect all channel
sends to this bus.
Note: Mix buses can be linked in odd-even adjacent
pairs to form stereo mix buses. To link buses
together, select one and press the VIEW button near
the CONFIG/PRE AMP section of the channel strip.
Press the rst rotary control to link. When sending
to these buses, the odd BUS SEND rotary control will
adjust send level and even BUS SEND rotary control
will adjust pan/balance.
Matrix Mixes
Matrix mixes can be fed from any mix bus as well as
the MAIN LR and Centre/Mono bus.
To send to a Matrix, rst press the SEL button
above the bus you want to send. Use the four rotary
controls in the BUS SENDS section of the channel
strip. Rotary controls 1-4 will send to Matrix 1-4.
Press the 5-8 button to use the rst two rotary
controls to send to Matrix 5-6. If you press the VIEW
button, you will get a detailed view of the six Matrix
sends for the selected bus.
Access the Matrix mixes using layer four on the
output faders. Select a Matrix mix in order to access
its channel strip, including dynamics with 6-band
parametric EQ and crossover.
For a stereo Matrix, selec t a Matrix and press the
VIEW button on the CONFIG/PREAMP section of
the channel strip. Press the rst rotary control near
the screen to link, forming a stereo pair.
Note, stereo panning is handled by even BUS SEND
rotary controls as described in Using Buses above.
Using DCA Groups
Use DCA Groups to control the volume of multiple
channels with a single fader.
1. To assign a channel to a DCA, rst be sure you
have the GROUP DCA 1-8 layer selected.
2. Press and hold the select button of the DCA
group you wish to edit.
3. Simultaneously press the select buttons of a
channel you wish to add or remove.
4. When a channel is assigned, its select button
will light up when you press the SEL button of
its DCA.
Sends on Fader
To use Sends on Faders, press the Sends on Faders
button located near the middle of the console.
You can now use Sends On Faders in one of two
di erent ways.
1. Using 16 input faders: Select a bus on the
output fader section on right and the input
faders on the left will re ect the mix being sent
to the selected bus.
2. Using eight bus faders: Press the select button
of an input channel on the input section on the
left. Raise the bus fader on the right side of the
console to send the channel to that bus.
Mute Groups
1. To assign/remove a channel from a Mute Group,
press the MUTE GRP screen selection button.
You will know you are in edit mode when the
MUTE GRP button lights and the six Mute
Groups appear on the six rotary controls.
2. Now press and hold one of the six Mute Group
buttons you wish to use and simultaneously
press the SEL button of the channel you wish to
add to or remove from that Mute Group.
3. When complete, press the MUTE GRP button
again to reactivate the dedicated Mute Group
buttons on the M32.
4. Your Mute Groups are ready to use.
Assignable Controls
1. The M32 features user-assignable rotary
controls and buttons in three layers. Toassign
them, press the VIEW button on the
ASSIGNsection.
2. Use the Lef t and Right Navigation button to
select a Set or layer of controls. These will
correspond to the SET A, B and C buttons on
the console.
3. Use the rotar y controls to select the control and
choose its function.
Note: The LCD Scribble Strips will change to indicate
the controls for which they are set.
E ects Rack
1. Press the EFFEC TS button near the screen to
see an overview of the eight stereo e ects
processors. Keep in mind that e ects slots 1-4
are for Send type e ects, and slots 5-8 are for
Insert type e ects.
2. To edit the e ect, use the sixth rotary control to
select an e ects slot.
3. While a e ects slot is selected, use the fth
rotary control to change which e ect is in
that slot, and con rm by pressing the control.
Press the sixth rotary control to edit the
parameters for that e ect.
4. Over 60 e ects include Reverbs, Delay, Chorus,
Flanger, Limiter, 31-Band GEQ, and more.
Please refer to the User Manual for a full list
and functionality.
5. Firmware Updates & USB Stick Recording
To Update Firmware:
Download the new console rmware from the
M32 product page onto the root level of a USB
memory stick.
Press and hold the RECORDER section’s VIEW
button while switching the console on to enter the
update mode.
Plug the USB memory stick into the top panel
USB connec tor.
The M32 will wait for the USB drive to become ready
and then run a fully-automated rmware update.
When a USB drive fails to get ready, updating will
not be possible and we recommend switching
the console o / on again for booting the
previous rmware.
The update process will take two to three minutes
longer than the regular boot sequence.
To Record to the USB Stick:
Insert the USB Stick into the port on the RECORDER
section and press the VIEW button.
Use the second page for con guring the recorder.
Press the fth rotary control under the screen to
begin recording.
Use the rst rotary control to stop. Wait for the
ACCESS light to turn o before removing the stick.
Notes: Stick must be formatted for FAT le system.
Maximum record time is approximately three hours
for each le, with a le size limit of 2 GB. Recording
is at 16-bit, 44.1 kHz or 48 kHz depending on console
sample rate.
16M32 LIVEQuick Start Guide17
6. Block Diagram
7. Technical Speci cations
Processing
Input Processing Channels32 Input Channels, 8 Aux Channels, 8 FX Return Channels
Output Processing Channels16
16 aux buses, 6 matrices, main LRC100
Internal E ects Engines (True Stereo / Mono)16
Internal Show Automation (structured Cues / Snippets)500 / 100
Internal Total Recall Scenes (incl. Preampli ers and Faders)100
Signal Processing40-Bit Floating Point
A/D Conversion (8-channel, 96 kHz ready)114 dB Dynamic Range (A-weighted*)
D/A Conversion (stereo, 96 kHz ready)120 dB Dynamic Range (A-weighted*)
I/O Latency (Console Input to Output)0.8 ms
Network L atency (Stage Box In > Console > Stage Box Out)1.1 ms
Connectors
MIDAS PRO Series Microphone Preampli er (XLR)32
Talkback Microphone Input (XLR)1
RCA Inputs / Outputs2
XLR Output s16
Monitoring Outputs (XLR / ¼" TRS Balanced)2
Aux Inputs/O utputs (¼" TRS Balanced)6
Phones Output (¼" TRS)2 (Stereo)
Digital AES/EBU Output (XLR)1
AES50 Ports (KLARK TEKNIK SuperMAC)2
Expansion Card Interf ace32 Channel Audio Input / Output
ULTRANET P-16 Connector (No Power Supplied)1
MIDI Inputs / Outputs1
USB Type A (Audio and Data Impor t / Export)1
USB Type B, rear panel, for remote control1
Ethernet, R J45, rear panel, for remote control1
Mic Input C haracteri stics
DesignMIDAS PRO Series
THD+N (0 dB gain, 0 dBu output)< 0.01% (unweighted)
THD+N (+40 dB gain, 0 dBu to +20 dBu output)< 0.03% (unweighted)
Input Impedance (Unbalanced / Balanced)10 kΩ / 10 kΩ
Non-Clip Maximum Input Level+23 dBu
Phantom Power (Switchable per Input)+48 V
Equivalent Input Noise @ +45 dB gain (150 Ω source)-125 dBu (22 Hz-22 kHz, unweighted)
CMRR @ Unity Gain (Typical)> 70 dB
CMRR @ 40 dB Gain ( Typical)> 90 dB
OUT
MIX 1-16
Post Fader
FADER
MUTE
INSERT
Pre Fader
EQ
KEY-IN
COMP/
EXPAN
EQ
6-BAND
COMP/
EXPAN
INSERT
MIX 1–16
SOLOMATRIX
1 2 5 6
L R C L R
MAIN
1 2 15 16
MIX BUS
GENERATE
GAIN
SINE WAVE
PINK NOISE
WHITE NOISE
OSCILLATOR
USB
PLAY
USB
MEMORY
RECORDER
USB MEMORY
REC
LEVEL
USB
USB RECORDER
REC
Pre EQPost EQ
GAIN
SOLO
Post Fader
MUTE
GAIN
Matrix 1,3,5
mute
stereo
LCR
PAN (LR)
FADER
MUTE
INSERT
INSERT
Post Fader
Post Fader
Matrix 2,4,6
mute
mono
COMP/
EXPAN
EQ
4-BAND
COMP/
EXPAN
DUCK
GATE/
CUT
LOW
DELAY
GAIN
Post Pan
Post Fader
Pre Fader
Pre EQPost EQ
OUT
MAIN LRC
FADER
MUTE
INSERT
COMP/
6BAND
COMP/
INSERT
MAIN LRC
LCR
GAIN
PAN (LR)
FADER
EXPAN
EQ
EXPAN
stereo
MUTE
4BAND
ATT
EQ
Post Fader
PAN (LR)
PAN (LCR)
LCR
mono
stereo
stereo
mute
mute
stereo
Mix 1,3...15
Mix 2,4...16
PAN (LCR)
GAIN
SOLO
MUTE
EQ
KEY-IN
EQ
KEY-IN
Pre HP/Pre Gate/Post Gate/Pre EQ/Post EQ/Pre Fader/Post Fader/Post Pan L
Pre HP/Pre Gate/Post Gate/Pre EQ/Post EQ/Pre Fader/Post Fader/Post Pan L
Pre HP/Pre Gate/Post Gate/Pre EQ/Post EQ/Pre Fader/Post Fader/Post Pan R
Pre HP/Pre Gate/Post Gate/Pre EQ/Post EQ/Pre Fader/Post Fader/Post Pan R
Post Fader
Pre Fader
EQ
Pre EQPost EQ
mono
Post Pan
Post Fader
Pre Fader
Pre EQ
KEY-IN
Post Fader
Post Fader
MUTE
SOLO
GAIN
Matrix 1,3,5
Matrix 2,4,6
mute
mute
mute
mute
stereo
Mix 1,3...15
Mix 2,4...16
PAN (LCR)
GAIN
MUTE
Pre EQ/Pre Fader/Post Fader/Post Pan L
Pre EQ/Pre Fader/Post Fader/Post Pan R
MATRIX 1-6
FADER
MUTE
INSERT
1-6
MATRIX
GAIN
COMP/
6BAND
COMP/
INSERT
LCR
PAN (LR)
FADER
MUTE
Post Fader
SOLO
Pre EQ/Pre Fader/Post Fader/Post Pan L
Pre EQ/Pre Fader/Post Fader/Post Pan R
OUT
EXPAN
EQ
EXPAN
stereo
Post Fader
Pre Fader
EQ
Pre EQPost EQ
mono
KEY-IN
SOLO
stereo
Post Pan
Post Fader
Pre Fader
PHONES
PHONES
OUT
GAIN
Post Fader
MONITOR
mute
mute
Mix 1,3...15
Mix 2,4...16
PAN (LCR)
GAIN
SOLO
MUTE
Pre Fader/Post Fader/Post Pan L
Pre Fader/Post Fader/Post Pan L
Pre Fader/Post Fader/Post Pan R
Pre Fader/Post Fader/Post Pan R
OUT
MONITOR SOURCE IN
2
MONITOR L
OUT
MONITOR R
GAIN
GAIN
D/A
DELAY
MONO
+
GAIN
MI
D
FX OUT L
EFFECT
31 BAND GEQ
FX IN L
EFFECTS 1-8
AUX OUT 1-6
OUT 1-16
D/A
D/A
OUT
D/A
DELAY
SOLO / SOURCE
FX OUT R
31 BAND GEQ
FX IN R
MONITOR LR OUT
L+C/R+C MIX
ON
GAIN
+48V
TALKBACK
P16 BUS
AES/EBU OUT
6
L+C OUT
R+C OUT
+
+
COMP
A/D
(16ch)
MONITOR LR OUT
2
ATT
INSERT RETURN
INSERT SEND
PRE LOW CUT OUT
POST FADER OUT
CH 1–32
32
32
323232
DSP
PATCH
6
6
3
16
8 x 2
8 x 2
USB
USB
REC
PLAY
FX 1-8 IN (L / R)
FX 1-8 OUT (L / R)
Revision 1, 2014-06-27, JD
MIDAS M32 LIVE Block Diagram
MIX 1-16 INSERT SEND
MIX 1-16 INSERT RETURN
3
16
MATRIX 1-6 INSERT SEND
MAIN LRC INSERT RETURN
MATRIX 1-6 INSERT RETURN
PATCH CUE
MAIN LRC INSERT SEND
AUX Returns 1–8
AUX Returns 7–8 by default on USB Play
8
6
3
16
MIX 1-16 OUT
MATRIX 1-6 OUT
3
MAIN LRC OUT
MAIN LRC PRE EQ OUT
2
2
MONITOR LR OUT
MONITOR SOURCE IN
MONITOR L+C/R+C OUT
2
GAIN
STEREO FX RETURNS 1 L/R – 8 L/R
8 x 2
40
I/O
PATCH
A/D
A/D
PHANTOM
+48V
(1-32)
INPUT
AUX
RETURN
(1-6)
(48ch IN)
AES-50 A
(48ch IN)
AES-50 B
DELAY
16
SLOT
GAIN
(32ch IN)
6
GAIN
AES-50 A
(48ch OUT)
AES-50 B
(48ch OUT)
GAIN
16
SLOT
(32ch OUT)
8
16
16
18M32 LIVEQuick Start Guide19
FEDERAL COMMUNICATIONS
COMMISSION COMPLIANCE
INFORMATION
Responsible Part y Name: MUSIC Tribe Brands UK Ltd.
Address: Klark Industrial Park,
Walter Nash Road,
Kidderminster, Worcestershire,
DY11 7HJ United Kingdom
Phone Number: +44 1562 732290
M32
complies with the FCC rules as mentioned in the following paragraph:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful inter ference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Warni ng:
Operation of this equipment in a residential environment could cause
radio interference.
M32
Input/Output Characteris tics
Frequency Response @ 48 kHz Sample Rate0 dB to -1 dB (20 Hz-20 kHz)
Dynamic Range, Analogue In to Analogue Out 106 dB (22 Hz-22 kHz, unweighted)
A/D Dynamic R ange, Preampli er and Converter (Typic al)109 dB (22 Hz-22 kHz, unweighted)
D/A Dynamic Range, Converter and Output (Typical)109 dB (22 Hz-22 kHz, unweighted)
Crosstalk Rejection @ 1 kHz, Adjacent Channels100 dB
Output level, XLR Connectors (Nominal / Ma ximum)+4 dBu / +21 dBu
Output Impedance, XLR Connectors (Unbalanced / Balanced)50 Ω / 50 Ω
Input impedance, TRS Connector s (Unbalanced / Balanced)20 kΩ / 4 0 kΩ
Non-Clip Maximum Input Level, TRS Connector s+21 dBu
Output Level, TR S (Nominal / Maximum)+4 dBu / +21 dBu
Output Impedance, TRS (Unbalanced / Balanced)50 Ω / 50 Ω
Phones Output Impedance / Maximum output Level4 0 Ω / +21 dBu (Stereo)
Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain-85 dBu 22 Hz-22 kHz unweighted
Residual Noise Level, Out 1-16 XLR Connec tors, Muted-88 dBu 22 Hz-22 kHz unweighted
Residual Noise Level, TRS and Monitor ou t XLR Connectors-83 dBu 22 Hz-22 kHz unweighted
DN32-LIVE USB Inter face
USB 2.0 high speed, type-B (audio/MIDI interface)1
USB input / output channels, duplex32, 16, 8, 2
Windows DAW applications (ASIO, WASAPI and WDM audio device inter face)Win 7 32/64-bit, Win10 32/64-bit
Mac OSX DAW applications (Intel CPU only, no PPC support, CoreAudio)Mac OSX 10.6.8**, 10.7.5, 10.8, 10.9, 10.10, 10.11, 10.12
DN32-LIVE SD Card I nterface
SD card slots, SD/SDHC2
SD/SDHC supported le systemFAT32
SD/SDHC card capacity, each slot1 to 32 GB
Batter y for power blackout protection (optional)CR123A Lithium cell
SD card input / ou tput channels32, 16, 8
Sample rates (console clock)44.1 kHz / 48 kHz
Sample word length32 bit PCM
File format (uncompressed mult i-channel)WAV 8, 16 or 32 channels
Maximum recording time (32 ch, 44.1 kHz, 32-bit on two 32 GB SDHC me dia)200 min
Typical perf ormance recording or playback32 channels on class 10 media, 8 or 16 channels on class 6 media
Display
Main Screen7" TFT LCD, 800 x 480 Resolution, 262k Colours
Channel LCD Screen128 x 64 LCD with RGB Colour Back light
Main Meter24 Segment (-57 dB to Clip)
Power
Switch-Mode Power SupplyAuto-Ranging 100-240 VAC (50/60 Hz) ± 10%
Power Consumption120 W
Physical
Standard Operating Temperature Range5°C – 40°C (41°F – 104°F)
Dimensions891 x 612 x 256 mm (35.1 x 24.1 x 10.1")
Weight25 kg (55 lbs)
* A-weighte d figures are t ypically ~3 dB bet ter
** OSX 10.6.8 Co re Audio suppor ts up to 16x16 channel aud io
