Midas F16, F32, F16R, F24 User Manual

F16, F16R, F24 and F32

Professional Audio Mixing

Consoles

Operator Manual

MUSIC Group Research UK Limited,

Klark Industrial Park,

Walter Nash Road,

Kidderminster.

Worcestershire.

DY11 7HJ.

England.

Tel: [phone]

Fax: [phone]

Email: [e-mail]
Website: www.midasconsoles.com

DOC02-VENICEXXXX

In line with the company’s policy of continual improvement, specifications and function may be

subject to change without notice. This document was correct at the time of writing. E&OE.

VeniceF — Operat

Issue E — November 2013

© MUSIC Group IP Ltd.

or Manual

Important safety instructions

CAUTION

ATTENTION

RISK OF ELECTRIC SHOCK!

DO NOT OPEN!

RISQUE DE CHOC ELECTRIQUE!

NE PAS OUVRIR!

Operator Manual iii

Terminals marked with this
symbol carry electrical current of
sufficient magnitude to constitute

risk of electric shock. Use only
high-quality commercially-available speaker
cables with ¼" TS plugs pre-installed. All other
installation or modification should be performed
only by qualified personnel.

This symbol, wherever it appears,

alerts you to the presence of

uninsulated dangerous voltage

inside the enclosure - voltage that
may be sufficient to constitute a risk of shock.

This symbol, wherever it appears,

alerts you to important operating

and maintenance instructions in

the accompanying literature.
Please read the manual.

Caution

To reduce the risk of electric

shock, do not remove the top

cover (or the rear section). No
user serviceable parts inside. Refer servicing to
qualified personnel.

Caution

To reduce the risk of fire or

electric shock, do not expose this

appliance to rain and moisture.
The apparatus shall not be exposed to dripping or
splashing liquids and no objects filled with liquids,
such as vases, shall be placed on the apparatus.

Caution

These service instructions are for

use by qualified service personnel

only. To reduce the risk of electric
shock do not perform any servicing other than that
contained in the operation instructions. Repairs
have to be performed by qualified service
personnel.

1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings.

Install in accordance with the manufacturer's
instructions.

8 Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.

9 Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A
grounding-type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

10 Protect the power cord from being
walked on or pinched particularly at plugs,
convenience receptacles, and the point where
they exit from the apparatus.

11 Use only attachments/accessories
specified by the manufacturer.

12 Use only with
the cart, stand, tripod,
bracket, or table
specified by the
manufacturer, or sold
with the apparatus.
When a cart is used,

use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.

13 Unplug this apparatus during lightning
storms or when unused for long periods of time.

14 Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such as
power supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.

15 The apparatus shall be connected to a
MAINS socket outlet with a protective earthing
connection.

16 Where the MAINS plug or an appliance
coupler is used as the disconnect device, the
disconnect device shall remain readily operable.

Legal disclaimer

Technical specifications and appearance are
subject to change without notice. The information
contained herein is correct at the time of printing.
All trademarks are the property of their respective
owners. MUSIC Group accepts no liability for any
loss which may be suffered by any person who
relies either wholly or in part upon any description,
photograph or statement contained herein. Colors
and specifications may vary slightly from product.
Midas products are sold th rough authorized
dealers only. Distributors and dealers are not

agents of MUSIC Group and have absolutely no
authority to bind MUSIC Group by any express or
implied undertaking or representation. This
manual is copyrighted. No part of this manual may
be reproduced or transmitted in any form or by
any means, electronic or mechanical, including
photocopying and recording of any kind, for any
purpose, without the express written permission
of MUSIC Group IP Ltd.

ALL RIGHTS RESERVED.
© 2013 MUSIC Group IP Ltd.
Tride

nt Chambers, Wickhams Cay, P.O. Box 146,

Road Town, Tortola, British Virgin Islands
