MID MID-7326CM User Manual

USER'S MANUAL

MID-7326CM

MID7326CM ENGLISH MANUAL AMLOGIC AML8726MX方 案
标准 说明 书，70g书纸,135x102mm,钉 装

Table of Contents

Table of Contents.. .................... ......... .......P1

Features..... .................... .........................P2

Unit at a Glance .... .................... ...............P3

Gett ing Started .................... ................P4-P5

About Applicatio ns........................... ....P5-P6

Preinstalled App lications .................... .......P6

Connect to a Wi-Fi ne twork....................P7-P 8

Opti onal Connec tions........................ ........P9

Specification s............................ .............P10

1

Features

2

Browse the Web.
Visit your favorite websites

Check your e-mail
Keep in touch with fr iends and fam ily

Watch YouTube™ vid eos
Browse the world’s most popular vide o­sharing communi ty

Read your favorit e books
Download thousa nds of books wi th the
included E-book r eader *

Discover thousa nds of apps for An droid™
Game s, applicat ions, and mor e with
marketplace(n eed for custo mer installed)

Connect to the Inte rnet wirele ssly
High-speed Wi-F i 802.11 b/g/n netwo rking

Enjoy your media li brary anywh ere

Portable powerh ouse plays po pular music,
video,and photo f ormats
microSD memory ca rd reader
Incr ease your sto rage capaci ty (up to 32 GB
supported)

Built-in camera
Convenient fron t-facing ca mera

Auto matic orien tation dete ction
Read any way you want ; the display a djusts
automatically !

Reading books in th e ePub format r equires
the included E-bo ok reader app lication.

(0.3 MP),

rear 2MP

Unit at a Glance

3

4.USB

Connect to a USB device or a computer to transfer
data (e.g. music, videos,photos, files).

5. HDMI

Connect to a TV or other displays.

6.DC IN 5V

Change and power the tablet with the included
power adapter.

7.RESET
Press this button to reset the system when the
device is halted.

8. microSD

Load external microSD memory cards here.

1 2

3

4

5

6
7

8

1. VOL+/VOL-

Press VOL+ to increase the volume level.
Press VOL- to decrease the volume level.

2. POWER

Press to turn the unit on, or to turn the screen on
or off.
Press and hold to access the Power Off menu.

3. Headphone

Audio output connection for headphones.

Getting Started

Turning the Tablet on or off

2. Touch ok the screen to turn off the tablet.

Turning the Screen On or off
(Standby)

When the tablet is on , you can turn off the
scre en to conserv e battery pow er. Simply press
the Po wer key once to t urn the screen
off. Press the Power key again to turn the
scre en back on.

To turn th e tablet on:
Press and hold the Po wer key until the LCD
scre en turns on. Wait until the Home screen
appears; the tabl et is now ready f or use.

To turn th e tablet off:

1.Pr ess and hold th e Power key unt il the
Device Options me nu appears.

To conserve battery p ower, the scre en
can be set to turn off automatically whe n
the ta blet is not in us e (between
15 seconds and 30 min utes).
This Screen timeo ut option can b e found
in the Display menu .

4

Getting Started

5

Unlocking the Screen

About Applications

To open an applicatio n, touch the ap plication
icon on the home scre en or in the Laun cher
where you can tap the i con right up on t he
home screen to get in ..

Launcher screen :

The screen shown above is for illustrative
purposes only. Reserves the right to modify
and improve the final list of applications
available on the tablet.

When the screen tur ns off, you will have t o
unlock the screen
when you turn it back o n.
To unlock the screen, d rag the lock ic on across
the sc reen toward s the lock icon .

.

About Applications

6

Preinstalled Applications

Some applications have been installed on your
tablet for your convenience.
These applications include:

Browse the web.

Perform simple ma thematica l operations.

Take pictures or vide os with the
fron tfacing cam era.

Check your e-mail .

Play music.

Acce ss the Settin gs menu to adjust the
tablet’s options.

Preinstalled Applications

Installing Applications

You can also down load an install additional
applications fr om the device ’s app lications
marketplace, th e web browser, o r other
sources.

The ta blet must be se t to allow installation of
applications fr om non-Mark et sources. The
Unknown sources o ption can be se t in the
Application set tings menu.

Musi c

Sett ings

7

Connect to a Wi-Fi network

The Notificatio n bar display s icons that indicate
your tablet’s Wi-Fi status.

Notification th at an open Wi-Fi network is
in range.

Connected to a Wi-F i network (wa ves
indicate connec tion streng th).

When Wi-Fi is on, the t ablet will look for and
display a list of ava ilable Wi-F i networks.

[no icon] There are no Wi-Fi networks in
range, or the Wi-Fi r adio is off.

1. Turn on the Wi-Fi radio if it is no t already
on. To turn on Wi-Fi:

a.Go t o the Home scre en: Press the Home
key.
b.Op en the Settin gs menu: tap the icon right
up on the home screen t o get into the
launcher, then tou ch Settings i con.
c.Op en the Wirele ss & networks menu: Slide
the icon to ON status .

If a net work that you h ave connected to
previously is fou nd, the table t will
connect to it.If yo u don’t see your
network in the list , you can force the
tablet to re-scan . To scan for networks,
tap th e Menu key, and then touch Scan.

WIF I1

WIF I2

8

Connect to a Wi-Fi network

To learn about how to add a Wi-Fi network
when it is not in range or when the router
is set to obscure the network name (SSID);
or to configure advanced Wi-Fi options,
please refer to the manual.

When you have successfully connected to a
Wi-Fi network, the Notifications bar at the the low
of the screen will show a Wi-Fi signal indicator.

2. Select an available Wi-Fi network to connect
to:

In the same Wi-Fi settings menu above,touch a
network in the list.

If the network is open,the tablet will prompt you to
confirm connection to the network. Touch Connect
to confirm.

If the network is secured (as indicated by a Lock
icon),the tablet will prompt you to enter a
password or other credentials.Touch the Wireless
password box to show the on-screen keyboard
and then use it to enter the password. Touch
Connect to confirm.

WIF I1

9

Optional Connections

Connecting to a Computer

3.Mount the storage.

Touch button Turn on USB storage to mount the
tablet’s built-in storage. When it is mounted, you
can copy files to or from your tablet.

Connect the tablet to a computer to transfer files.

1.Connect your tablet to the computer.

With the included USB cable: Plug the small end
of the cable into the USB 2.0 high speed
connector of the tablet. Plug the large end of the
cable into an available USB 2.0 high speed port
on the computer.

2.When your tablet is connected,slide up the
USB icon right down on the screen and then
touch icon USB connected.

10

Specifications

Music was tested with a 128 kbps MP3 file; video
was tested with a 1920x1080 MPEG-4/AVC file;
browsing was tested with the screen brightness
set to default. Actual playback results may vary.

Processor

RAM

Storage

Display

Wi-Fi Networking

Audio Output

PC Interface

Additional Features

Operating System

Power

Playback Time
(hours)

Amlogic 8726-MX Dual core 1.5GHz(cortex A9)

4~16GB(option) flash built-in; micro
SD card slot (max.32GB supported)

7.0”TFT LCD(1024x600), Capcitive touchscreen

IEEE 802.11 b/g/n

3.5mm headphone

USB 2.0 high speed

Up to 9 hours music,
4 hours video,
4 hours web browsing

Built-in microphone
Front facing camera(0.3MP), rear 2MP
1X1W speaker

Andro id™ 4.0

Rechargeable Li-poly battery power
Adapter(DC 5V, 2A)

1GB DDR3

WARNING

Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this

equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.
&onsult the dealer or an experienced radio/TV technician for help.

11
