MicroWeb MNC-W200 User Manual

MPEG4/JPEG Dual Mode

Network IP Camera

PROFESSIONAL SERIES

User Manual

[Model MNC-L200/MNC-W200]

Revision 1.0.0

This manual is intended for administrators and users of the WebView MPEG4/JPEG

Dual Mode Network IP Camera[Model MNC-L200/MNC-W200], and is applicable for
software release 1.4.0 and later. It includes instructions for using and managing the WebView
MPEG4/JPEG Dual Mode Network IP Camera on your network. Previous experience of
networking will be of use when using this product. Some knowledge of UNIX or Linux-based
systems may also be beneficial, for developing shell scripts and applications. Later versions of
this document will be posted to www.micro-web.co.kr , as required.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures;

- Re-orient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment to an outlet on a different circuit to the receiver.

- Consult your dealer or an experienced radio/TV technician for help.

- Shielded (STP) network cables must be used with this unit to ensure compliance with EMC

standards.

This equipment has been tested and found to comply with the limits for Part 15 of FCC rules, which are
designed to provide reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference, in which
case the user at his/her own expense will be required to take whatever measures may be required to
correct the interference.

FCC Caution : Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

This device complies with Part 15 of FCC Rules. Operation of the device is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference that may cause undesired operation.

MPEG4 NETWORK IP CAMERA User’s Guide

Important Note:
FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator and
your body.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IEEE 802.11b or 802.11g operation of this product in U.S.A. is firmware-limited to channels 1through

11.

The availability of some specific channels and/or operational frequency bands are country dependent and
are firmware programmed at the factory to match the intended destination. The firmware setting is not
accessible by the end user.

This equipment generates and radiates radio frequency energy, and must be installed and operated while
maintaining a minimum body-to-camera distance of 3 feet (1 meter).

T rademark Acknowledgments

ActiveX, Apple, Boa, Ethernet, Internet Explorer, Linux, Microsoft, Mozilla, Netscape
Navigator, OS/2, Real, QuickTime, UNIX, Windows, WWW are registered trademarks of the
respective holders. Java and all Java-based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States and other countries.

Video Standard and Product Classification

As the video standard varies country to country, users are asked to check it first and choose right
model. The two most common video standards used are NTSC and PAL.
NTSC is the video system or standard used in North America and most of South America. In
NTSC, 30 frames are transmitted each second. Each frame is made up of 525 individual scan
lines.
PAL is the predominant video system or standard mostly used overseas. In PAL, 25 frames are
transmitted each second. Each frame is made up of 625 individual scan lines.

Up to video standard, the models of MPEG4/JPEG dual mode Network IP Camera are as
follows;

3

MPEG4 NETWORK IP CAMERA User’s Guide

MNC-L200N : Wired MPEG4/JPEG Dual Mode Network IP Camera for NTSC standard
MNC-L200P : Wired MPEG4/JPEG Dual Mode Network IP Camera for PA L standard
MNC-W200N : Wireless and wired MPEG4/JPEG Dual Mode Network IP Camera for NTSC
standard
MNC-W200P : Wireless and wired MPEG4/JPEG Dual Mode Network IP Camera for PAL
standard

To determine your video standard, refer to the chart below ;

PAL

Afghanistan, Algeria, Argentina (N),
Austria, Australia, Bangladesh, Belgium,
Brazil (M), China, Denmark, Finland,
Germany, Hong Kong, Iceland, India,
Indonesia, Iraq, Ireland, Israel, Italy,
Jordan, Kenya, Kuwait, Liberia,
Malaysia, Netherlands, Nigeria, Norway,
New Guinea, Pakistan, Singapore, South
Africa, South W. Africa, Sudan, Sweden,
Switzerland, Thailand, Turkey, Uganda,
United Kingdom, United Arab Emirates,
Yugoslavia, Zambia

MPEG4/JPEG Dual Mode Network IP Camera Family
[Model : MNC-L200/MNC-W200]
User Manual
Version 1.0.0

NTSC

Canada, Chile, Costa Rica, Cuba,
Dominican Republic, Ecuador, Japan,
Mexico, Nicaragua, Panama, Peru,
Philippines, Puerto Rico, South
Korea, Taiwan, U.S.A.

Oct. 2006

4

MPEG4 NETWORK IP CAMERA User’s Guide

Important Notice

1. Camera surveillance laws may differ for each country. Please contact the local authorities to

avoid any surveillance law violations.

2. Please note that the CCD lens that comes with the Mpeg4 Network IP Camera can be

damaged permanently if the camera lens is exposed to direct sunlight. If your application

demands prolonged exposure to sunlight, you should consider equipping it with a sun visor.

3. The Mpeg4 Network IP Camera is not weatherproof. Please be aware of environmental

specifications included in the manual. For outdoor use, please use a weatherproof case to

protect the Mpeg4 Network IP Camera from water, moisture, or temperature (higher or lower

than specification). For Mpeg4 Network IP Camera cleaning, gently wipe with clean dry

cloth.

4. Be sure to use only the DC adapter that is provided with your camera. Connecting the Mpeg4

Network IP Camera directly to AC current may cause electric damages to the Camera.

5. Be cautious when handling Network IP Camera. Physical shocks may cause serious damage.

6. Be sure to mount the Mpeg4 Network IP Camera securely to avoid any human injures. Please

keep the Mpeg4 Network IP Camera out of reach of children.

7. If Mpeg4 Network IP Camera does not operate properly, please contact the closest local

Mpeg4 Network IP Camera distributor for after sales service. In all cases, you are prohibited

to disassemble the product. If so, warranty is invalid.

5

MPEG4 NETWORK IP CAMERA User’s Guide

TABLE OF CONTENTS

1

PRODUCT OVERVIEW 8

1.1 ABOUT MPEG4 NETWORK IP CAMERA 8

1.2 MAIN FEATURES AND BENEFITS 9

2 PHYSICAL DESCRIPTION 10

2.1 CONTENTS 10

2.2 FRONT SIDE VIEW AND LED DESCRIPTION 11

2.3 REAR VIEW AND DESCRIPTION 12

3 INSTALLATION SUMMARY 13

4 ASSIGNING IP ADDRESS & ACCESSING MPEG4 NETWORK IP
CAMERA’S HOMEPAGE 14

4.1 ASSIGNING IP ADDRESS 14

4.2 ASSIGNING IP ADDRESS BY USING IP INSTALLER 15

4.2.1 CONNECTING NETWORK IP CAMERA TO PC 15

4.2.2 USING IP INSTALLER 16

4.3 ASSIGNING IP ADDRESS BY USING HYPER TERMINAL 18

4.3.1 CONFIGURING HYPER TERMINAL 18

4.3.2 ASSIGNING IP ADDRESS 20

4.4 ACCESSING MPEG4 NETWORK IP CAMERA HOMEPAGE 23

4.4.1 STARTING WEB BROWSER 23

4.4.2 LOGIN PAGE 24

4.4.3 MPEG4 NETWORK IP CAMERA’S HOMEPAGE 28

5 ADJUSTING THE CAMERA LENS 30

5.1 ADJUSTING THE FOCUS 30

5.2 REPLACING THE LENS 30

6

MPEG4 NETWORK IP CAMERA User’s Guide

6 CONFIGURING ADMINISTRA TION TOOLS 32

6.1 OVERVIEW OF ADMINISTRATION MENU 33

6.2 IMAGE CONFIGURATION 34

6.3 NETWORK CONFIGURATION 38

6.4 ADMIN, USER CONFIGURATION 42

6.5 EVENT TRIGGER CONFIGURATION 43

6.6 SYSTEM & TIME CONFIGURATION 48

7 POE (POWER OVER ETHERNET) SUPPORT 55

APPENDIX 56

A. TECHNICAL SPECIFICATIONS 56
B. FAQ 58
C. TROUBLE SHOOTING 61
D. UTILIZING IP ADDRESSES ON LOCAL NETWORK 65

INTRODUCTION 65
IP CONSTRUCTION AND NETWORK CLASS 65
C CLASS NETWORK 66

E. UPDATING FIRMWARE 69

IDENTIFY THE VERSION OF FIRMWARE 69
DOWNLOAD NEW FIRMWARE 69
INSTALL NEW FIRMWARE 69

F. THE I/O CONNECTOR 71
G. RS 232 CABLE 72
H. DYNAMIC DOMAIN NAME SERVER (DDNS) 74
HOW TO USE DYNDNS DDNS SERVER 77
I. HIGH SPEED SOLUTIONS 81
J. REINSTATING THE FACTORY DEFAULT SETTINGS 83
K. GLOSSARY OF TERMS 85

K. Glossary of Terms 81

7

MPEG4 NETWORK IP CAMERA User’s Guide

1 Product Overview

1.1 About Mpeg4 Network IP Camera

[Model : MNC-L200] [Model : MNC-W200]

The Mpeg4 Network IP Camera is an all-in-one networking device, which contains a digital color camera,

powerful web server, optimized embedded operating system, hardware for image compression, and a

physical Ethernet connection. The camera does not need any additional software or hardware. Simply

provide power and connect an Ethernet Cable and view from any computer on the Network.

The Mpeg4 IP Camera is ideal for surveillance applications that require high quality, full motion video

and audio, as well as comparatively low bandwidth demands on the network. Mpeg4 Network IP Camera

provides an easy user interface for remote access to receive the optimal synchronized video and audio

from anywhere anytime over the Internet with the popular Internet Explorer Web Browser, as easy as

surfing any regular Web sites. More than just a high-performance Network Camera, the Mpeg4 Network

IP Camera also possesses many advanced features to provide the adequate personal or SI solutions, such

as, Remote Surveillance, Home/Business Security, Audio/Video Conference, motion detection etc....

8

MPEG4 NETWORK IP CAMERA User’s Guide

1.2 Main Features and Benefits

Convenient Operation

The Mpeg4 Network IP Camera does NOT need any additional software or interaction with any other
server. The only software needed is a common web browser, such as Microsoft Internet Explorer 4.x or
above.

Open Standards

The Mpeg4 Network IP Camera supports TCP/IP networking, SMTP e-mail, FTP, HTTP and other
Internet-related protocols; the Network IP Camera can be used in a mixed operating system environment
with Windows, Unix, Mac and OS/2. It integrates easily into other www/Intranet applications and CGI
scripts.

Simple Administration

Using a standard web browser, you can configure and manage the Mpeg4 Network IP Camera directly
from its own embedded web pages. The embedded operating system is upgradeable through the network;
please check with your local WEBVIEW dealer or visit www.micro-web.co.kr

External Devices

The auxiliary Input/Output Connector on the camera allows you to connect your Network IP Camera to a
variety of external devices; such as IR-sensors, switches, and alarm relays.

Security

Your MPEG4 Network IP Camera includes a self-contained web server, which means that digital images
can be secured like any other Internet host. Your Network Administrator, using the unit’s security settings
in combination with an organization’s Internet firewall, normally implements data protection. The
Administrator can decide whether individuals, groups, or the whole world may access the camera. The
Mpeg4 Network IP Camera supports multi-user password protection
Compression and Performance
With a variable frame rate dependent on the image quality & bit rate, the Network IP Camera delivers
Mpeg4 video at up to 30 images per second.
Dual Mode Compression
For application providers, system integrators and other AP’s, this camera also supports JPEG
compression as well as MPEG4 video.
Full Duplex Two Way Audio supported.

for firmware upgrades.

Full duplex two way audio is available by connecting external microphone and speaker to MPEG4
Network IP Camera.

IEEE 802.3af Standard PoE(Power over Ethernet) supported.
Software

IP installer – for quick installation
Multi-Viewer for viewing 4 cameras

9

MPEG4 NETWORK IP CAMERA User’s Guide

2 Physical Description

2.1 Contents

Check all items packed inside the box as below.

ITEM DESCRIPTION REMARKS

Network IP

Camera

Installation CD

Power Supply

Stand

Connection Cable

Installation

Foldout

Mpeg4 Network Camera

IP installer, Upgrade

program, Manual, Multi-Viewer etc.

AC Power adapter and power cord

Wall & Table attached stand Iron Material

RS232 Cable Black Cable

Quick Installation Guide Printed Paper

AC adapter (AC110V-240V) and

Program CD

Power Black Cable

z You can use a general camera stand or tripod for MPEG4 Network IP Camera.

10

MPEG4 NETWORK IP CAMERA User’s Guide

2.2 Front Side View and LED Description

Power LED (Red): Once power is supplied to the Network IP Camera, the Red LED will be on.

Operating Status LED (Green): This LED indicates the Network IP Camera’s operating status. Once

power is supplied, it is on and then it blinks once every second as long as the video is transmitted on the

network during its normal operation. When there is no video transmission the led stop blinking. Under

event trigger situation, the green LED become red & blinks rapidly. During simultaneous operation of

event trigger capture & video monitoring it blink rapidly & alternately red & green.

Network Activity LED (Orange): This LED indicates network activity. If orange LED is on, that means

Network LED

Status LED

Power LED

network is up and running & if it is off, that means network is down and not working.

.

11

MPEG4 NETWORK IP CAMERA User’s Guide

2.3 Rear View and Description

Power Connector

Wireless Antenna
[for MNC-W200N, MNC-W200P]

Mini DIN for

Zoom/Focus Control/
RS232 Communication

Network Connector

External
Speaker

External
Microphone

GPIO Connector

Power Connector: Only use the supplied AC Adapter to avoid any possible damage from electric shock.

Network Connector: Connect 10 baseT Ethernet or 100 base TX Fast Ethernet cable.

GPIO Connector

(please refer to Appendix F – I/O Connectors).

: To connect external devices such as infrared Sensors, alarms, or motion detectors

Mini DIN Connector: To connect external devices such as external Zoom/Focus Lens mechanism, or

directly to a serial port for camera configuration via HyperTerminal (please refer to Appendix G - RS

232 Cable).
SPK: Use to connect to external speaker for Audio communication. The Audio sent over N/w from

Connected Camera client can be delivered through this externally connected speaker.
MIC: The external MIC for Audio Input. The live Audio can be captured & transmitted to the connected
camera client via the use of this MIC.
RESET : Return your camera to factory default settings

12
