Microtek ArtixScan DI 3130c Start Guide

Start Here

Installing your Microtek ArtixScan DI 3130c

Unpack Contents

Unpack your scanner package and check for major components.

1. ArtixScan DI 3130c scanner

2. Document feed tray

3. Hi-Speed USB cable

4. Software CDs/DVDs

5. Card Holder

6. Power adapter

7. Power cord

Install Software

Important: You must install software before

connecting your scanner.

Always close any open programs and turn off Anti-virus utilities before installing software.

A. Turn on your computer.

B. Place the Microtek Software CD/DVD into a drive, and follow the on-screen instructions to

install the scanner driver and software.

C. Restart your computer at the end of all software installation.

NOTE: If the Microtek Software Installer screen does not come up automatically, double-click the following in succession: “My Computer”; the CD/DVD-ROM icon; then cdsetup.exe to start the installer program.

Install the Document Feed Tray

Before using the Document Feed Tray with your scanner, you need to install it on the scanner. Follow the instructions and graphs below to correctly install the Document Feed Tray.

A. Lift up the Release button in the direction

of the arrow shown to open the scanner cover.

B. Install the Document Feed Tray on the

scanner;

a). insert the four flanges (tabs) of the

feed tray into the holes on the scanner, indicated in the graphic by blue circles.

b). push down the two flanges (tabs)

located at the rear of feed tray into another two holes, indicated in the graphic by red circles.

Make sure the Document Feed Tray snaps into place and sits tightly on the scanner.

C. Close the scanner cover. You would hear

a click sound when the scanner cover returns to its original position.

Connect Scanner

To the power adapter

A. Connect the power adapter to the back of the scanner.

B. Plug one end of the power cord into

the power adapter, and plug the other end of the power cord into a wall outlet or other power source.

To the Hi-Speed USB cable

C. Connect one end of the cable to your computer.

D. Connect the other end of the cable to the scanner’s USB port.

E. Turn the power switch at the back panel of your scanner to “On”; once the scanner is

detected by your system, the LED (green) will brighten, and the scanner is ready to scan.

Customize the Function Button

The ArtixScan DI 3130c is equipped with one Select and one Enter buttons, used to automate a number of customized and predefined operations, such as scanning to a file, sending an image to your printer, scanning for OCR, etc. Customizing is done through the Save Settings to Function Button command in the ScanWizard DI, refer to the ArtixScan DI 3130c User’s Manual for more details.

LED Display: Show the selected function number.

Select button

Enter button

• Select: Toggle through the number lists of your preferred functions.

• Enter: Start scan and carry out the result of the selected function number.
