miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

User’s Manual

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 2

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

Table of Contents

1 GENERAL 3

2 TECHNICAL DATA 3

2.1 Profibus DP Interface 4

2.1.1 Characteristic Data 4

2.1.2 DP Configuration Data 5

2.1.3 DP Diagnosis Data 6

2.1.4 DP Parameter Data 6

2.1.5 DP Output Data 6

2.1.6 DP Input Data 6

2.2 Transmit Data Frame (DP Output -> Serial Interface) 7

2.3 Receive Data Frame (Serial Interface -> DP Input) 8

3 CONNECTOR PIN ASSIGNMENTS 9

3.1 LEDs 9

3.2 Connectors 10

3.3 Settings 11

4 APPENDIX 13

4.1 Warranty / Liability 13

4.2 Declaration of Conformity 14

4.3 Versions Overview 15

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 3

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

1 General

Using the universal interface, Profibus DP output data are transmitted via
the serial RS interface, and frames received by the serial RS interface are
copied to the Profibus DP input data.

The mechanical design is laid out for top-hat rail mounting.
Settings for bus termination, address and options can be made simply by
using DIP switches.

2 Technical Data

Specifications

Interface 1: Profibus DP
Baud rate: 9,6 kBaud…12 MBaud
Addresses: 0…126

Interface 2: RS232 / 485 / 422
Baud rate: 1200 to 115200 baud
Data formats: 7 / 8 Bit
Parity: 7 Bit: none (2 stop bits),
8 Bit: even, odd, none (1 stop bit)

Operating voltage: +12…+30 VDC
Power consumption: approx. 200 mA at 12 VDC
approx. 100 mA at 24 VDC

Housing: aluminium profile
Housing size: 26 x 105 x 70 mm (W x H x D)
Mounting: to 35 mm DIN top hat rail
Protection: Front panel: IP 00
Operating temperature: 0…+50 °C
Storage temperature: -25…+60 °C

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 4

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

2.1 Profibus DP Interface

2.1.1 Characteristic Data

ID Number: 05D0h
GSD File: MICR05D0.GSD
Cyclical User Data: max. 200 bytes output,

max 200 bytes input,
max. 300 bytes output + input

Standard Configuration: 2x 0x3F (32 input-/output bytes)
Parameter Data: Standard 7 Byte
User PRM: none
Diagnosis: Standard 6 Byte
External Diagnosis: none
Transmission Speed: 9.6 kBaud / 19.2 kBaud / 93.75 kBaud /

187.5 kBaud / 500 kBaud / 1.5 MBaud /
3 MBaud, 6 MBaud, 12 MBaud

Protocol: Profibus DP DIN19245, part 3

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 5

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

2.1.2 DP Configuration Data

The configuration of the Profibus interface normally happens using the
GSD file. It is initially imported into the "Device Catalog" of the
configuration software. Subsequently, the Profibus interface can be
“dragged” into the bus system and then be configured.

With the configuration, the user can individually adapt data width within
the data transfer. Data widths of 1 to 16 bytes maximum are possible.
By specifying these identifiers in any order, the desired total data width is set
for both the input and the output data.

Data Identifier Number of Bytes Function / Description

0x10 1 Input data
0x11 2 Input data

: : :

0x1F 16 Input data
0x20 1 Output data

0x21 2 Output data

: : :

0x2F 16 Output data
0x30 1/1 Input / output data (1 byte each)

0x31 2/2 Input / output data (2 bytes each)

: :

0x3F 16/16 Input / output data (16 bytes each)

The maximum number of input and output bytes is 200 bytes each.
However a total number of 300 bytes (input + output) may not be exceeded.

 Default configuration: 2x 0x3F = 32 input and 32 output bytes

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 6

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

2.1.3 DP Diagnosis Data

The interface does not support any extended diagnosis data. Default
diagnosis is utilised.

2.1.4 DP Parameter Data

The User_Prm_Data are not utilised by the interface. However, a test is run
to determine whether or not User_Prm_Data are transferred by the Profibus
master. If User_Prm_Data are transferred, Profibus initialisation is disabled
and the slave must be reconfigured and parameterised.

Note:
Standard parametrisation is required and is normally installed by the utilised
DP configurators.

2.1.5 DP Output Data

The interface supports output data which have been configured to the
length selected during configuration. The minimum number of output data
is 0 bytes, the maximum number is 200 bytes.

Send frames are entered to the output data.
 At least 3 output bytes are required if send frames are used.

2.1.6 DP Input Data

The interface supports input data which have been configured to the
length selected during configuration. The minimum number of input data
is 0 bytes, the maximum number is 200 bytes.

Receive frames are entered into the input data.
 At least 3 input bytes are required if receive frames are used.

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 7

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

2.2 Transmit Data Frame (DP Output -> Serial Interface)

DP Output

Byte 1 Byte 2 Byte 3 Byte 4 ... Byte n + 2

Toggle byte Length

byte = n

Frame byte 1 Frame byte 2 ... Frame byte n

In order to transmit a frame via the serial interface, the individual frame bytes
must be entered at the Profibus side as output bytes 3 through (n + 2). After the
length byte (= frame length n) has been entered, the toggle byte must be
changed in order to start transmission.

The toggle byte is not checked again until after the current frame has been
transmitted. Transmission duration can be estimated based upon frame length
and baud rate.

*Transmission duration (max.) = Frame length x (11 / baud rate) x 1.2
In addition, the delay through the processing on the master side, the Profibus

transmission and the processing on slave side (< 5 ms) must be considered.

In many cases it is also possible to simply wait for the (mostly existing)
response frame which is visible through the toggle byte change at DP
input side.

If too few DP output bytes have been configured, the frame is shortened
accordingly!

Example:

Transmission of two frames (‘ABC’ and ‘DE’) one after the other in rapid
succession to the RS interface

Sequence DP Output

▼

Byte 1 Byte 2 Byte 3 Byte 4 Byte 5

1. Start of Profibus DP
communication

00

H

00H 00H 00H 00H

2. Enter frame data

00H 03H 41H („A“) 42H („B“) 43H („C“)

3. Transmit frame and
wait for transmission*

01H 03H 41H 42H 43H

4. Enter data for next frame 01H 02H 44H („D“) 45H („E“) XXH

5. Transmit next frame and
wait for transmission*

02

H

02H 44H 45H XXH

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 8

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

2.3 Receive Data Frame (Serial Interface -> DP Input)

DP Input

Byte 1 Byte 2 Byte 3 Byte 4 ... Byte n + 2

Toggle byte Length

byte = n

Frame byte 1 Frame byte 2 ... Frame byte n

Each time a frame has been received via the serial interface (frame end
recognised by means of timeout), it is entered as input bytes 3 through (n + 2),
and the frame length (n) is entered as byte 2 (= length byte). The toggle byte is
also increased by 1.

Thus only the toggle byte needs to be monitored at the Profibus side. As soon as
it’s value has changed, data can be read out from the received frame.

If too few DP input bytes are configured, the frame is shortened correspondingly!
The toggle byte is always set to 0 after Profibus communication is initialised.

Example:

Two frames (“Hello” and “World”) are received via the RS interface.

Sequence DP Input

▼

Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7

1. Start of
Profibus­ communication

00H

00H

00H

00H

00H

00H

00H

2. Frame “Hello“
was received

01

H

05

H

48H (“H“) 65H (“e“) 6CH (“l“) 6CH (“l“) 41H (“o“)

3. Frame “World“
was received

02

H

05

H

57H (“W“) 41H (“o“) 72H (“r“) 6CH (“l“) 64H (“d“)

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 9

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

3 Connector Pin Assignments

Front Side Bottom Side

3.1 LEDs

LED Status Meaning

red (FAULT)

ON no Profibus DP connection

or RAM error (if green LED OFF)

OFF Profibus DP connection established

green (RUN)

OFF Controller is not running (hardware error)
ON Controller is running
temporary OFF
(blinking)

UART communication
(frame has been sent or received)

Power Supply

Profibus DP

RS232/485/422

S3

S1

LED green

LED red

S2

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 10

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

3.2 Connectors

Power Supply

Pin Assignment

1 +12…+30 VDC
2 GND
3 PE

RS

Pin RS232 RS485 RS422

1 RxD
2 TxD
3 GND GND GND
4 Rx/Tx + Rx +
5 Rx/Tx - Rx ­6 Tx +
7 Tx ­8 PE PE PE

See chapter „Settings“ for interface selection.

Profibus DP

Pin Assignment

1
2
3 Rx+ / Tx+
4 RTS
5 GND, electrically isolated
6 +5V, electrically isolated
7
8 Rx- / Tx­9

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 11

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

3.3 Settings

Notes:

• See the marking on the DIP switches to determine ON/OFF positions

• The DIP switches may generally only be changed while power is OFF!

• Delivery settings: Following grey-coloured table entries

Switch S1 / S3-DIP7: Interface Selection

Switch S1 Switch S3
Interface DIP1 DIP2 DIP3 DIP4 DIP5 DIP6 DIP7

RS232 ON OFF OFF OFF OFF OFF OFF
RS422
without bus termination

OFF ON OFF OFF OFF OFF ON

RS422
with bus termination

OFF ON OFF OFF ON ON ON

RS485
without bus termination

OFF ON ON ON OFF OFF OFF

RS485
with bus termination

OFF ON ON ON ON ON OFF

Switch S2: Profibus Address, Bus Termination

DIP Switch Function

DIP 1 DP address Bit 20 (ON = 1)
DIP 2 DP address Bit 21 (ON = 2)
DIP 3 DP address Bit 22 (ON = 4)
DIP 4 DP address Bit 23 (ON = 8)
DIP 5 DP address Bit 24 (ON = 16)
DIP 6 DP address Bit 25 (ON = 32)
DIP 7 DP address Bit 26 (ON = 64)
DIP 8 reserved (= OFF)
DIP 9 both ON: Profibus bus termination activated

both OFF: no Profibus bus termination

DIP 10

Note: Only DP addresses 0 through 126 are allowed!
Delivery setting: DP address = 3

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 12

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

Switch S3: RS Interface Parameters

Baud Rate DIP 1 DIP 2 DIP 3

1200 OFF OFF OFF
2400 ON OFF OFF
4800 OFF ON OFF

9600 ON ON OFF
19200 OFF OFF ON
38400 ON OFF ON
57600 OFF ON ON

115200 ON ON ON

Data Format DIP 4 DIP 5

8 / N / 1 OFF OFF
8 / E / 1 ON OFF
8 / O / 1 OFF ON
7 / N / 2 ON ON

Receive Timeout* DIP 6 Baud Rate / Receive Timeout

short OFF 1200 Baud / 29 ms

2400 Baud / 16 ms

4800 Baud / 9 ms

9600 Baud / 6 ms
19200 Baud / 4 ms
38400 Baud / 3 ms
57600 Baud / 3 ms

115200 Baud / 3 ms

long ON 1200 Baud / 200 ms

2400 Baud / 100 ms

4800 Baud / 50 ms
9600 Baud / 25 ms

19200 Baud / 13 ms
38400 Baud / 10 ms
57600 Baud / 10 ms

115200 Baud / 10 ms

* Determines, after which duration a receive frame is considered to be finished

and should be announced to the Profibus DP (duration after the last received
byte). The interval between the individual frame bytes may not exceed this
duration (otherwise this would be interpreted as the end of the frame).

Mode DIP 8

Standard OFF

migan

(not relevant)

ON

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 13

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

4 Appendix

4.1 Warranty / Liability

For the product, liability is assumed for defects, which existed at the
delivery date according to our General Terms and Conditions.

Technically changes as well as errors are excepted. A claim for delivery of a new
product does not exist. The buyer has to check the received product immediately
and indicate evident defects at the latest 24 hours after detection. Non­observance of notification requirements is equated with acceptance of the defect.
Not immediately visible defects have to be indicated immediately after their
perception too.

Generally, defects and their symptoms must be described as accurately
as possible in order to allow for reproducibility and elimination. The buyer
must provide for access to the relevant device and all required and/or
useful information at no charge and must make all of the required data
and machine time available free of charge.

The guarantee does not cover defects, which result from non-observance
of the prescribed conditions of use, or from improper handling.

If the device has been placed at the disposal of the buyer for test
purposes and has been purchased subsequent to such testing, both
parties agree that the product is to be considered “used” and that it has
been purchased “as is”. No guarantee claims may be made in such
cases.

The General Terms and Conditions of microSYST Systemelectronic
GmbH in current version apply as well.

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 14

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

4.2 Declaration of Conformity

EG-Konformitätserklärung

Declaration of EC-Conformity

Produktbezeichnung:

miface PB

Product name:

Produktbeschreibung: Universa-Interface Profibus-DP / Serielle Schnittstelle /
Product description: Universal Interface Profibus DP / Serial Interface

Hersteller:

microSYST Systemelectronic GmbH

Manufacturer:

Albert-Einstein-Straße 7
92637 Weiden

Das bezeichnete Produkt stimmt mit
der folgenden Europäischen Richtlinie
überein:

We herewith confirm that the above
mentioned product meets the
requirements of the following standard:

Die Übereinstimmung des bezeichneten
Produktes mit den Vorschriften der
Richtlinie wird nachgewiesen durch die
vollständige Einhaltung folgender Normen:

The correspondence of the above mentioned
product with these requirements is proved by
the fact that these products meet with the
following single standards:

Nummer Bezeichnung Europäische Norm

2004/108/EG

Elektromagnetische
Verträglichkeit (EMV)

EN61000-6-2:2006
EN61000-6-3:2007

Weiden, den 23.05.2012

Harald Kilian

Leiter operatives Geschäft / COO
Prokurist / Authorized Signatory

miface PB

Universal Interface Profibus DP / Serial Interface RS232/485/422

Page 15

microSYST Systemelectronic GmbH, Albert-Einstein-Straße 7, 92637 Weiden
Tel. [phone], Fax [phone], www.microsyst.de, [e-mail]

4.3 Versions Overview

Version Date Comments

1.00

1.10

1.20

1.30

2012-09-17
2013-03-26
2013-10-17
2014-07-22

Kreuzer, Nickl: Document created
Company address, warranty
Logo
Operating voltage

Certified per DIN ISO 9001.
