UB11B, MS-6823
Wireless 11b USB Adapter
User’ s Guide
FEDERAL COMMUNICATIONS COMMISSION
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:(1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection. This equipment generates, uses and can radiated radio
frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
FCC Radio Frequency Interference Statement
This equipment complies with the FCC RF radiation exposure limits set forth for
Uncontrolled environment. This device and its antenna must not be collocated or
Operating in conjunction with any other antenna or transmitter.
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR INTERNATIONAL. We take every care in the preparation of this document, but no
guarantee is given as to the correctness of its contents. Our products are under
continual improvement and we reserve the right to make changes without notice.
Trademarks
All trademarks used in this manual are the sole property of their respective owners.
Windows is a registered trademark of Microsoft Corporation.
Revision History
Revision History Date
V 1.0 First Release June 2003
Important Safety Precautions
Always read and follow these basic safety precautions carefully when handling any
piece of electronic component.
1. Keep this User’ s Manual for future reference.
2. Keep this equipment away from humidity.
3. Lay this equipment on a reliable flat surface before setting it up.
4. The openings on the enclosure are for air convection hence protects the
equipment from overheating.
5. All cautions and warnings on the equipment should be noted.
6. Never pour any liquid into the opening that could damage or cause
electrical shock.
7. If any of the following situations arises, get the equipment checked by a
service personnel:
Liquid has penetrated into the equipment
The equipment has been exposed to moisture
The equipment has not work well or you can not get it work
according to User’ s Manual
The equipment has dropped and damaged
If the equipment has obvious sign of breakage
8. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT UNCONDITIONED, STORAGE TEMPERATURE ABOVE 60O C OR BELOW -20OC, IT
MAY DAMAGE THE EQUIPMENT.
Introduction
>>> 1.1
UB11B (MS-6823) - Wireless 11b
USB Adapter
UB11B (MS-6823), compliant with IEEE802.11b, is a
high-efficiency wireless adapter for wireless networking
at home, in office or in public places. This hot-plug,
USB-interface adapter connects directly to any USBready desktop/notebook computers, so that you can
share files, printers, and high-speed access the Internet
over your existing wireless network easily, without
disassembling your computer.
The UB11B (MS-6823) has a data rate up to 11Mbps,
and can auto-negotiate to 5.5, 2, 1Mbps to be compatible with any IEEE 802.11b device.
The UB11B (MS-6823) is available to Microsoft Windows
operating systems (Windows® XP/2000/ME/98SE) and
can be integrated into networking with either Ad-hoc
mode (computer-to-computer, without an Access Point)
or Infrastructure mode (computer-to-access point, an
Access Point is required).
1
>>> 1.2
How UB11B (MS-6823) Works
Ad-hoc Mode : An Ad-hoc network is a local area network
or other small network, especially one with wireless or
temporary plug-in connections, in which some of the
network devices are part of the network only for the
duration of a communications session. Users in the
network can share files, print to a shared printer, and
access the Internet with a shared modem. In this kind of
network, new devices can be quickly added; however,
users can only communicate with other wireless LAN
computers that are in this wireless LAN workgroup, and
are within range.
(MS-6823)
(MS-6823)
2
Infrastructure Mode : The difference between Infrastructure network and Ad-hoc network is that the former one
includes an Access Point. In an Infrastructure network,
the Access Point can manage the bandwidth to maximize
bandwidth utilization. Additionally, the Access Point
enables users on a wireless LAN to access an existing
wired network, allowing wireless users to take advantage
of the wired networks resources, such as Internet, email,
file transfer, and printer sharing. The scale and range of
the Infrastructure network are larger and wider than that
of the Ad-hoc networking.
(MS-6823)
(MS-6823)
3
>>> 1.3
Specifications
Form Factor USB 1.1
Standard IEEE 802.11b
Frequency Range 2.4GHz to 2.497GHz
Data Rate 1, 2, 5.5 and 11 Mbps
Network Protocols TCP/IP, NetBEUI, IPX/SPX
Support
Operating Channels USA/Canada: 11 channels;
European: 13 channels;
Japan: 14 channels
Modulation Technology Direct Sequence Spread
Spectrum (DSSS), DBSK,
DQPSK, CCK
Media Access Protocol CSMA/CA with ACK
Security / Encryption 64-/128-bit WEP
Range Outdoor: 50m ~ 300m
Indoor: 10m ~ 100m
LED One Power/Link LED
Operating system Microsoft® Windows® 98SE/
ME/2000/XP
4
Environmental Operating Temperature:
0 ~ 45OC
Operating Humidity:
10 ~ 90%, non-condensing
Operation Voltage 5.0 VDC(+/- 0.5V)
Dimensions (WxDxH) 75 X 22 X 13mm
Weight 18g
5
>>> 1.4
System Requirements
Before installing the UB11B (MS-6823), your PC should
meet the following:
Desktop/notebook PC with an available USB port.
Windows® 98SE/ME/2000/XP operating system.
Minimum 5M bytes free disk space for installing the driver
and utilities.
CD-ROM drive, double speed or higher.
>>> 1.5
Package Contents
Unpack the package and check all the items carefully. If
any item contained is damaged or missing, please
contact your local dealer as soon as possible. Also, keep
the box and packing materials in case you need to ship
the unit in the future. The package should contain the
following items:
One Wireless 11b USB Adapter.
One strap.
One Quick Installation Guide.
One CD title including drivers, utilities, user’s manual
and quick guide.
6
