Micro Star Co MS3870 Users Manual

CM11BGN-BT (MS-3870)

Wireless 11b/g/n + Bluetooth BT2.1 EDR

Combo Slim Module

User’s Guide

i

FCC Caution

1. The device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.

2. FCC RF Radiation Exposure Statement: The equipment complies with FCC
RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum
distance of 20 centimeters between the radiator and your body.

3. This Transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.

4. Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user authority to operate
the equipment.

FCC Statement

This device is intended only for OEM integrators under the following

1) The antenna must be installed such that 20 cm is maintained between antenna

and users, and

2) The transmitter module may not be co-located with any other transmitter or

antenna.

As long as 2 conditions above are met, further transmitter test will not required. However,
the OEM integrator is still responsible for testing end-product for any additional compli­ance requirements required with module installed (for example, digital device emissions,
PC peripheral requirements, etc.).

Important Note

In the event that these conditions can not be example certain laptop configurations or co­location with another transmitter), then the FCC authorization is no longer considered
valid the FCC ID can not be used on the final product. In these circumstances, OEM
integrator will be responsible for re-evaluating the end product (including the transmitter)
and obtaining a separate FCC authorization.

ii

End Product Labeling

This transmitter module is authorized only for use in device where antenna may be
installed such that 20 cm may be maintained between antenna and users (for example
access points, routers, wireless ADSL and similar equipment). The final end product
must be labeled in a area with the following: “ Contains TX FCC ID: I4L-MS3870”.

Manual Information for End Users

The end user must not have manual instructions to remove or install device. The user
manual for end users must include the following information in a prominent location:
“IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements,
the antenna used for this transmitter must be installed to provide a separation distance of
at least 20 cm from all persons and must not be co-located operating in conjunction with
any other antenna or transmitter.” as a result of e-mail transmission.”

Important Safety Precautions

Always read and follow these basic safety precautions carefully when handling any
piece of electronic component.

1. Keep this User’s Guide for future reference.

2. Keep this equipment away from humidity.

3. Lay this equipment on a reliable flat surface before setting it up.

4. The openings on the enclosure are for air convection hence protects the
equipment from overheating.

5. All cautions and warnings on the equipment should be noted.

6. Never pour any liquid into the opening that could damage or cause electrical
shock.

7. If any of the following situations arises, get the equipment checked by a
service personnel:

Liquid has penetrated into the equipment
The equipment has been exposed to moisture
The equipment has not work well or you can not get it work

according to User’s Manual

The equipment has dropped and damaged
If the equipment has obvious sign of breakage

8. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
UNCONDITIONED, STORAGE TEMPERATURE ABOVE 100O C OR
BELOW -20OC, IT MAY DAMAGE THE EQUIPMENT.

iii

Introduction

>>> 1.1 CM11BGN-BT (MS-3870) - Wireless 11b/g/n +

Bluetooth BT2.1 Combo Slim Module

MSI CM11BGN-BT (MS-3870), the Wireless 11b/g/n +
Bluetooth Combo Slim Module, which can be used to integrate
with such systems as notebook, mini-barebone, portable PC.
With MSI MS-3870 embedded inside, a system could provide
users with the ability and flexibility to connect up to Internet
wirelessly via 802.11b/g/n with speed up to 150Mbps, and to
link with peripherals wirelessly through BluetoothTM v2.1 and
advanced EDR (Enhanced Data Rate) technology. Bluetooth
v2.1 technology increases the data rate of BluetoothTM v1.1/1.2
from 1.0Mbps to 2.1Mbps.

MSI MS-3870 is taking advantage of leading technologies from
Ralink and CSR. It addresses the co-existence issues in PAN
(Personal Area Network) and WLAN (Wireless Local Area
Network) markets by providing true simultaneous connectivity
while deploying IEEE 802.11b/g/n and Bluetooth v2.1 Along
with this combo solution, a system installed with a single mod­ule is able to offer dual mode capability of WiFi and BluetoothTM.
It will benefit system vendors in miniaturization of system di­mension and BOM cost reduction, as well as also make users
happy with the all-in-one functionality.

TM

1

>>> 1.2 How MS-3870 Works

In WLAN Environment1.2.1
Ad-hoc Mode : An Ad-hoc network is a local area network or

other small network, especially one with wireless or temporary
plug-in connections, in which some of the network devices are
part of the network only for the duration of a communications
session. Users in the network can share files, print to a shared
printer, and access the Internet with a shared modem. In this
kind of network, new devices can be quickly added; however,
users can only communicate with other wireless LAN comput­ers that are in this wireless LAN workgroup, and are within
range.

MS-3870

WLAN+Bluetooth Combo Slim Module

MS-3870

WLAN+Bluetooth Combo Slim Module

2

Infrastructure Mode : The difference between Infrastructure
network and Ad-hoc network is that the former one includes an
Access Point. In an Infrastructure network, the Access Point can
manage the bandwidth to maximize bandwidth utilization. Addi­tionally, the Access Point enables users on a wireless LAN to
access an existing wired network, allowing wireless users to take
advantage of the wired networks resources, such as Internet,
email, file transfer, and printer sharing. The scale and range of the
Infrastructure networking are larger and wider than that of the
Ad-hoc networking.

MS-3870

WLAN+Bluetooth Combo Slim Module

MS-3870

WLAN+Bluetooth Combo Slim Module

3

In Bluetooth Connection

1.2.2

The term “Bluetooth” refers to a worldwide standard for the
wireless exchange of data between two devices. In order to ex­change data, two Bluetooth devices must establish a connection.
Before a connection is established, one device must request a
connection with another. The second device accepts (or rejects)
the connection. The originator of the request is known as the
client. The device that accepts (or rejects) the request is known
as the server. Many Bluetooth devices can act as both client and
server. Every Bluetooth device that provides a service must be
prepared to respond to a connection request. Bluetooth soft­ware is always running in the background on the server, ready to
respond to connection requests.

MS-3870

WLAN+Bluetooth Combo Slim Module

Bluetooth-enabled Devices

4

>>> 1.3 Specifications

Operation voltage 3.3V+/-10%

Operating System Microsoft® Windows® XP 32/ 64-bit,

Hardware
Specification

Environmental - Operating Temperature:

Dimensions (WxDxH) 80 x 10 x 3 mm

Weight 3.5g

Vista 32/64-bit, Win7 32/64-bit

0 ~ 65OC

- Operating Humidity:
10 ~ 90%, non-condensing

5

WLAN

Specification

Network Standard IEEE 802.11b/g/n

Frequency Band 2.400-2.4835 GHz

Data Rate IEEE 802.11b (auto-fallback):

- CCK: 11, 5.5 Mbps

- DQPSK: 2 Mbps

- DBPSK: 1 Mbps

IEEE 802.11g (auto-fallback):

- OFDM: 54, 48, 36, 24, 18, 12, 9 and
6 Mbps

IEEE 802.11n (auto-fallback):

-OFDM: 6.5 to 150 Mbps
(Follow MCS 0~7 standard)

Media Access ControlCSMA/CA with ACK

Transmission IEEE 802.11b (DSSS),

IEEE 802.11g/n (OFDM)

Network Architecture Ad-hoc Mode (Peer-to-Peer);

Infrastructure Mode

Antenna Type PCB printed antenna

Power Consumption 802.11b (11 Mbps):

328mA@3.3V in continuous Tx
231mA@3.3V in Rx

802.11g (54Mbps):
313mA@3.3V in continuous Tx
233mA@3.3V in Rx

802.11n draft 6.0:
HT20MHz: 308mA@3.3V in continuous
Tx / 232mA@3.3V in Rx (MCS7)
HT40MHz: 325mA@3.3V in continuous
Tx/ 283mA@3.3V in Rx (MSC7)

233mA@3.3V in standby mode

6

Channel IEEE 802.11g/n:

Ch. 1-11 – N. America
Ch. 1-13 – Japan
Ch. 1-13– Europe ETSI
Ch. 10-11 – Spain
Ch. 10-13 – France

IEEE 802.11b:
Ch. 1-11 – N. America
Ch. 1-14 – Japan
Ch. 1-13– Europe ETSI
Ch. 10-11 – Spain
Ch. 10-13 – France

Output Power 802.11b (11Mbps): 17.0 +/-1 dBm

802.11g (54Mbps): 14.0 +/-1 dBm

802.11n draft 6.0: 12.0 +/-1 dBm

Receiver Sensitivity 802.11b (11Mbps): CCK@8% PER = -76dBm
(Typical Value) 802.11g (54Mbps): OFDM@10% PER = -65dBm

802.11n draft 6.0:
HT20 @ 10% PER = -64 dBm
HT40 @ 10% PER = -61dBm

7

Bluetooth

Specification

Network Standard Bluetooth v2.1 Class II +EDR

Frequency Band 2.400 - 2.4835 GHz

Data Rate Up to 3Mbps

Channel 79 sub-channels

Transmission FHSS (Frequency Hopping Spread

Spectrum)

Modulation n/4 DQPSK@2Mbps, 8DQPSK@3Mbps

Antenna Type PCB printed antenna

Power Consumption 66mA in continuous Tx

8.6mA in standby mode

Max. Output Power 0~4 dBm

Max. Input Level -20 dBm@BER<0.1%

Receiver Sensitivity -82dBm @ BER<0.1%

Range Up to 10 m operating range

(outdoor operating range)

Physical Links Support ACL and SCO link

Network Capabilities Support piconet point-to-point and

point-to multipoint connections

Link Manager 3-slot Packets: Yes

5-slot Packets: Yes
Slot Offset: Yes
Timing Accuracy: Yes
Switch: Yes
Hold Mode: Yes
Sniff Mode: Yes
Test Mode: Yes
Park Mode: Yes
RSSI: Yes
Power Control: Yes
Authentication: Yes
Encryption: Yes

8

>>> 1.4 System Requirements

Before installing MS-3870, your PC should meet the following
items:

- Windows® XP 32/ 64-bit, Vista 32/64-bit, Win7 32/64-bit
operating system.

- Minimum 5MB free disk space for installing the driver and
utilities.

- One CD-ROM drive, double speed or higher.

>>> 1.5 Package Contents

Unpack the package and check all the items carefully. If any item
contained is damaged or missing, please contact your local dealer
as soon as possible. Also, keep the box and packing materials in
case you need to ship the unit in the future. The package should
contain the following items:

- One Wireless 11b/g/n + Bluetooth Combo Slim Module.

- One Installation CD-ROM including drivers, utilities, and the
manual files.

9

>>> 1.6 Product View

10

Software Installation

This chapter describes the procedures of installing the driver
and utility. Follow the instruction step by step to finish the
installation. If you use Windows® 98SE/ME, please prepare
the Windows® Setup CD at hand before installing the driver;
because the system will ask you to insert the Setup CD to copy
files during the installation.

Please NOTE that the MS-3870 should be installed into your
computer before installing the driver and utility. Then, the
operating system will detect a new device and start to configure
the new device. Click Cancel here to start installation from the
InstallShield Wizard.

The adapter model you installed

Click

Tip: The MS-3870 adapter

should be installed into your PC
before installing the driver and
utility.

11

STEP

1

Insert the software CD into your CD-ROM drive, and the Setup
program should launch automatically.

If the Autorun program doesn’t launch automatically, click Start

at the taskbar and select Run.... Type E:\setup.exe (where E is

your CD-drive) in the Open box and click OK to launch the

Setup program manually.

The main screen of Setup program will appear as below.

STEP

2

1. Click the Install WLAN Driver button.

2. The welcome screen of InstallShield Wizard appears.

Click Next.

3. Read and accept the License Agreement; then, click Next.

4. Click Install and the program will copy the necessary

files to the system. The progress indicator shows the
installing status.

5. Click Finish when the WLAN driver installation is

completed.

12

STEP

3

1. Click the Install Bluetooth Driver button.

2. The welcome screen of InstallShield Wizard appears.

Click Next.

3. Read and accept the License Agreement; then, click Next.

4. Click Next to install the driver in the default destination

folder.

5. Click Install and the program will copy the necessary

files to the system. The progress indicator shows the
installing status.

6. Click Finish when the bluetooth driver installation is

completed.

STEP

4

Click the Exit button.

The Wireless LAN icon and Bluetooth icon will appear in the
status bar.

Bluetooth icon

Wireless LAN icon

13

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and receiver.

● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV technician for help.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the device.

IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your
body.

OEM integrator is still responsible for testing their end product for any additional compliance requirements
required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the IC authorization is no longer considered valid
and the IC No. can not be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate IC
authorization.

End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20
cm may be maintained between the antenna and users. The final end product must be labeled in a visible
area with the following: “Contains TX IC: 3715A-MS3870”

This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
