Micro Star Co BT560 User Manual

Qcom

MD560(B)

User’s Manual

FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

--Consult the dealer or an experienced radio/TV technician for help.

CAUTION:

Any changes or modifications not expressly approved by the grantee of this device could void the

user's authority to operate the equipment.

FCC RF Radiation Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled

environment.

Contents

Qcom

1. Contents

2. Introduction

3. Bluetooth Basics

4. Installation Overview

4.1 Installation Procedures of Bluetooth Utility

4.2 Installation Procedures of Modem Driver

5. Troubleshooting

2

2. Introduction

Qcom

Thank you for purchasing QCOM Bluetooth and Modem Daughter Card. This manual

will assist you with the installation procedure.

The package you have received should contain the following items:

• Bluetooth and Modem Daughter Card

• User manual

• CD containing Agere Systems AC’97 Modem driver, Wireless LAN

Management utility and driver software.

Note: if anything is missing, please contact your vendor

The CD contains drivers and utility software; this is used for managing the Bluetooth

and Modem Daughter Card and needed component is included for Agere Systems

AC’97 Modem.

The MD560 (B) is designed to provide modem and Bluetooth function on a MDC

form factor. The Bluetooth function is based on CSR BlueCore3-ROM Single Chip

Bluetooth System, which implements the full speed class 2 Bluetooth operation with

full 7 slave piconet support. The interface of MD560 (B) Bluetooth function to

host system is USB and full compliant with USB V2.0.

The modem function is based on any AC97/Azalia modem chipset, it provides a

digital, programmable line interface to meet global telephone line requirements.

3

3. Wireless Bluetooth Basics

Qcom

Wireless Bluetooth systems offer a great number of advantages over a traditional,

wired system. Wireless Bluetooth are more flexible, easier to setup and manage and

often more cost effective than their wired equivalence.

Using radio frequency (RF) technology. Bluetooth transmits and receives data over

the air, minimizing the need for wired connections. Thus, Bluetooth combines data

connectivity with user mobility, and, through simplified configuration, enable

movable LANs.

With wireless Bluetooth, users can access shared information without looking for a

place to plug in and network managers can set up or augment networks without

installing or moving wires. Wireless Bluetooth offers the following productivity,

convenience and cost advantages over traditional wired networks.

• Mobility – Wireless Bluetooth systems can provide LAN users with access to

real-time information anywhere in their organization. This mobility

supports productivity and service opportunities not possible with wired

networks.

• Installation Speed and Simplicity – Installing a wireless Bluetooth system can be

fast and easy and can eliminate the need to pull cable through walls

and ceilings.

• Installation Flexibility – wireless technology allows the network to go where wires

cannot go.

• Reduced Cost-of-Ownership – While the initial investment required for wireless

Bluetooth hardware might be higher than the cost of wired LAN

hardware, overall installation expenses and life-cycle costs will be

significantly lower. Long- term cost benefits are greatest in dynamic

environments requiring frequent moves, adds, and changes.

• Scalability – Wireless Bluetooth systems can be configured in a variety of

topologies to meet the needs of specific applications and installations.

Configurations are easily changed and range from peer-to-peer

networks suitable for a small number of users to full infrastructure

networks of thousands of users that allows roaming over a broad area.

4
