Microsoft Corporation Zune Sync Dock Setup Guide

station d’accueil et de
synchronisation zune/
estación de sincronización
y acoplamiento zune

Be sure to use the adapter plate designed for your Zune.
Assurez-vous d’utiliser la plaque d’adaptation conçue pour votre Zune.
Asegúrate que utilizas la placa de adaptador diseñada para tu Zune.

,$
%&$

(
,
%*

zune sync dock

Touchscreen Zune players

An HDMI™ cable (included in the Zune HD,

AV & Power Pack) and a high-denition TV are
required for high-denition viewing. Zune HD

and other touchscreen Zune players also work
with the composite A/V cable (included in

the Zune HD, AV & Power Pack).

To use the HDMI output, the dock’s USB cable

must be connected to AC power using the
Zune AC Adapter (included in the Zune HD,

AV & Power Pack).

The dock’s optical digital audio output works

only with touchscreen Zune players (optical

cable not included).

Zune 80, 120

To see video on your TV, go to your player’s Set­tings, Display, TV Out, and select On.

Zune 4, Zune 8, and Zune 16 are audio-only players:

See the ZuneTM Product Guide that came with

your Zune media player for important safety

information and troubleshooting tips.

For more, see the Zune User’s Guide at
www.zune.net/support.
