Microsoft Corporation Zune HD AV Dock Setup Guide

station d’accueil HD et AV zune
estatión de acoplamiento HD y AV zune

Be sure to use the adapter plate designed for your Zune.
Assurez-vous d’utiliser la plaque d’adaptation conçue pour votre Zune.
Asegúrate que utilizas la placa de adaptador diseñada para tu Zune.

,$
%&$

(
,
%*

zune HD & AV dock

Touch-screen Zune players

An HDMI™ cable (included) and a high-denition
TV are required for high-denition viewing. Zune HD
and other touch-screen Zune players also work
with the composite A/V cable (included).

Want to charge while you sync? Connect the dock
to your computer and set Zune in the dock.

The dock’s optical digital audio output works only
with Zune HD (optical cable not included).

Zune 80, 120

To see video on your TV, go to your player’s
Settings, Display, TV Out, and select On.

Zune 4, Zune 8, and Zune 16 are audio-only
players:

See the Zune Product Guide that came with
your Zune media player for important safety
information and troubleshooting tips.

For more, see the Zune User’s Guide at
www.zune.net/support.
