Microsoft RM 958 Users Manual

User Guide
Nokia Asha 503 Dual SIM RM-958
Issue 1 EN
User Guide
Nokia Asha 503 Dual SIM

Contents

Safety 4
Get started 5
Keys and parts 5 Insert a SIM card, battery, and memory
card 5 Charge the battery 7 Set which SIM card to use 7 Copy contacts from your old phone 7
Basics 9
Display indicators 9 Touch screen actions 9 Switch between views 11 Check your activity 11 Change settings quickly 12 Prolong battery life 12 Reorganise the apps menu 13 Personalise the lock screen 13 Change your ringtone 13 Add a full keyboard or phone keypad 14 Add a writing language 14 Keys on the keyboard 14 Write using the keyboard 14 Keys on the keypad 15 Write using the keypad 15 Use predictive text 16 Nokia Store 16
People & messaging 17
Make a call 17 Save a name and phone number 17 Add social info to contacts 18
Update your status 18 Send a message 18 Mail for Exchange 19 Set up your mail account 19 Send a mail 20 Chat with your friends 20 Check your voice mail 21
Camera 22
Take a photo 22 Record a video 22 Share your photo or video 22
Maps & navigation 24
Find nearby places 24
Internet 25
Browse the web 25 Add a website to your favourites 25
Entertainment 26
Play a song 26 Listen to the radio 26
Office 27
Change the time and date 27 Set an alarm 27 Add a calendar entry 27
Phone management & connectivity 28
Share your content using Slam 28 Connect to a Wi-Fi network 28 Copy content between your phone and
computer 28 Update your phone software 29 Use your phone in flight mode 29
© 2013 Nokia. All rights reserved.
2
Access codes 29
Product and safety information 31
© 2013 Nokia. All rights reserved.
3

Safety

We invite you to read the instructions on this guide before using the device.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The device screen is made of glass. This glass can break if the device is dropped on a hard
surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Exercise caution when holding your device near your ear while the loudspeaker is in use.
SAR
This device meets RF exposure guidelines when used either in the normal use position against
the ear or when positioned at least 1.5 centimetres (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section of this user guide. For more info, go to www.sar-tick.com.
When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call.
© 2013 Nokia. All rights reserved.
4

Get started

Get to grips with the basics, and have your phone up and running in no time.

Keys and parts

Explore the keys and parts of your new phone. 1 Audio connector (3.5 mm AHJ)
2Earpiece 3Micro-USB connector 4 Volume/Zoom keys 5 Lock/Power key 6Microphone 7 Back key 8 Touch screen 9 Camera flash 10 Camera lens. Before using the camera,
remove the protective tape from the lens. 11 Back cover release button 12 Antenna area
You can set your phone to ask for the lock code that you define.
The antenna area is highlighted. Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the
communication quality and may reduce battery life due to higher power level during operation. Do not connect products that create an output signal, as this may damage the device. Do not connect
any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels.
Some of the accessories mentioned in this user guide may be sold separately.

Insert a SIM card, battery, and memory card

Learn how to insert a battery and SIM and memory cards.
Important: Your device uses a mini-UICC SIM card, also known as a micro-SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card.
Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.
© 2013 Nokia. All rights reserved.
5
1. Press the release button at the back of the phone, and carefully lift and remove the back cover.
2. If the battery is in the phone, lift it out.
3. Open the SIM holder, and slide the SIM into the holder, contact area face down. Close the holder,
and lock it into place.
4. Line up the battery contacts, and put the battery in.
5. Insert the second SIM into the SIM2 slot with the contact area face down. Push the SIM in until it
locks into place.
Tip: To remove the SIM, push the card in until it's released, then pull it out.
Tip: You can use 2G or 3G SIMs in both SIM1 and SIM2 slots. While 3G network is active on one
SIM, the other supports only 2G network.
Both SIM cards are available at the same time when the device is not being used, but while one SIM card is active, for example, making a call, the other is unavailable.
6. Push the memory card into the memory card slot until it locks into place.
Tip: To remove the memory card, push it in until it's released, then pull it out.
Important: Do not remove the memory card when an app is using it. Doing so may damage the
memory card and the device and corrupt data stored on the card.
7. Replace the back cover.
8. To switch on, press and hold the power key.
Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.
© 2013 Nokia. All rights reserved.
6

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can use your phone.
1. Plug the charger into a wall outlet.
2. Connect the charger to the phone. When done, unplug the charger from the phone, then from the
wall outlet.
If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.
Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.

Set which SIM card to use

By default, your phone asks you which SIM to use for the connection. You can also set the default SIM for calls or messaging. If you name your SIMs, you can see at a glance which is, for example, for work or personal use.
Settings > Dual SIM.
Tap
1. Switch Always ask to Off
2. Select which SIM to use for which connection.
Availability of SIMs
• If you only have one SIM, put it into the SIM1 holder. Some features may only be available with the
SIM in the SIM1 holder.
• When you set one SIM to be used for outgoing calls or messages, or for data connections, the
other SIM can still receive calls or messages.
• When one SIM is having an active connection, the other SIM is not available.
Rename SIM
Tap SIM settings, and type in the new name under the card you want to name.
.

Copy contacts from your old phone

Get all your contacts to your new phone in one go. Your old phone must have Bluetooth, and the contacts must be stored in the phone memory, not on
the SIM.
1. On both your new and old phone, switch Bluetooth on, and make sure both phones are visible to others.
© 2013 Nokia. All rights reserved.
7
2. On your new phone, tap Contacts > Import contacts > Another device.
Tip: If you already have contacts on your phone, swipe up from the bottom of the screen, and tap Import contacts > Another device.
3. Move the phones close to each other. When the phones are connected using Bluetooth, the
contacts transfer starts. If your contacts are written in a language that is not supported by your new phone, the contact info
may not show correctly.
© 2013 Nokia. All rights reserved.
8

Basics

Learn how to get the most out of your new phone.

Display indicators

The display indicators on your phone tell you the current time, battery and signal strength, and much more.
An alarm is set. The silent profile is on.
Battery power level
You have new notifications. Swipe down from the top of the screen to see the details. Wi-Fi is on.
Signal strength Flight mode is on.
Bluetooth is on.
The type of mobile network you're currently connected to may be shown with a single letter, a combination of letters, or a combination of letters and numbers. For example, your network service provider.
The icons may vary depending on your region or network service provider.

Touch screen actions

Explore your phone with a tap or swipe.
1. To open an app or other item, tap the app or item.
, depending on
Important: Avoid scratching the touch screen.
2. To switch a setting on or off, tap the switch.
© 2013 Nokia. All rights reserved.
9
3. To see more options, tap and hold an item.
4. To swipe, for example, to another home screen, steadily slide your finger left or right.
5. To see more options, swipe up from the bottom of the screen if you can see three lines there.
6. To close an app and go back to the home screen, swipe in from the left or right of the screen.
7. To see notifications and change settings, swipe down from the top of the screen. To close the
menu, swipe up, or tap an empty area outside the menu.
© 2013 Nokia. All rights reserved.
10
8. To scroll through a long list or menu, slide your finger quickly up or down, and lift your finger.
9. To zoom, slide two fingers apart or together on an item.
Tip: For more info on touch screen actions, tap Care > Nokia Care > Tutorial.

Switch between views

Your phone has 2 home screens: one for keeping up with your activities, and another one for apps. Swipe left or right to switch between home screens.
Choose your view according to your needs:
Easily see what you've been doing lately, and check what's happening next in your calendar.
In the apps menu you can open apps and shortcuts, and rearrange them as you like.

Check your activity

Your phone makes it easy for you to always keep up with what's happening. In the apps menu, swipe left or right to view your activities. Here, you can see the following:
© 2013 Nokia. All rights reserved.
11
