User Guide

Nokia XXX Dual SIM

Issue 1 EN

User Guide

Nokia XXX Dual SIM

Contents

	Safety	3	Take a photo	20
	Get started	4	Take a self-portrait	20
	Keys and parts	4	Take a panorama photo	21
	Insert a SIM card and battery	4	Send a photo or video	21
	Insert a second SIM card	6	Maps & navigation	22
	Insert a memory card	6	Find nearby places	22
	Charge the battery	7	Internet	23
	Set which SIM card to use	8	Browse the web	23
	Copy content from your old phone	8	Add a website to your favourites	23
	Basics	10	Entertainment	24
	Explore your phone	10	Listen to the radio	24
	Display indicators	11	Play a song	24
	Prolong battery life	11	Office	26
	Personalise your home screen	12	Add a calendar entry	26
	Change your ringtone	12	Change the time and date	26
	Set a song as your ringtone	12	Set an alarm	26
	Nokia Store	13	Phone management & connectivity	27
	Write text	13	Share your content using Slam	27
	People & messaging	14	Copy content between your phone and a
	Make or answer a call	14	computer	27
			Back up content to a memory card	28
	Save a name and phone number	14
			Update your phone software	28
	Add social info to contacts	15
			Access codes	28
	Send a message	15
			Product and safety information	30
	Check your voice mail	15
	Mail for Exchange	16
	Set up your mail account	17
	Send a mail	17
	Get social	18
	Chat with your friends	18
	Camera	20

© 2013 Nokia. All rights reserved.	2

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For further info, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or

blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

GLASS PARTS

The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of

the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

SAR

This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 1.5 centimetres (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section of this user guide.

For more info, go to www.sar-tick.com.

When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call.

© 2013 Nokia. All rights reserved.	3

Get started

Get to grips with the basics, and have your phone up and running in no time.

Keys and parts

Explore the keys and parts of your new phone.

	1	Micro-USB connector
	2	Headset connector (3.5 mm AHJ)
	3	Volume keys	2
	4	Scroll key	2
	5	End/Power key
	6	Back cover release hole
	7	Microphone
	8	Call key
	9	Selection keys
	10	Earpiece
	11	Camera flash

12Camera lens. Before using the camera, remove the protective tape from the lens.

13Back cover opening tool. If you lose the tool, you can also use a paper clip.

14Antenna area

15Loudspeaker

Tip: Lock the keys when not using your phone. Select Menu, and press *. To unlock, select Unlock, and press *.

Your phone uses S40 software.

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.

Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels.

The images in this guide may differ from your device screen.

Some of the accessories mentioned in this user guide may be sold separately.

Insert a SIM card and battery

Learn how to insert a SIM card and the battery.

The SIM1 holder can be used for both 3G and 2G SIMs.The SIM2 slot can only be used for 2G SIMs. 1. Push the tool into the hole until the cover is released. Remove the back cover.

© 2013 Nokia. All rights reserved.	4

2.If the battery is in the phone, lift it out.

3.Push the SIM in with the contact area face down.

4.Line up the battery contacts, and put the battery in.

5.Press the back cover down until it locks into place. To switch the phone on, press and hold the power key until the phone vibrates.

Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.

Important: To prevent damage to the SIM card, always remove the battery before you insert or remove the card. Only applies to SIM1.

© 2013 Nokia. All rights reserved.	5

Important: This device is designed to be used with a mini-UICC SIM card, also known as a microSIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card.

Insert a second SIM card

You can easily add a second SIM card (SIM2) without removing the battery.

1.Push the tool into the hole until the cover is released. Remove the back cover.

2.Push the SIM in with the contact area face down until it locks into place. The SIM2 slot can only be used for 2G SIMs.

3.To remove the SIM, push the card in until it's released, then pull it out.

If you only have one SIM card, put the card into the SIM1 card holder. Some features and services may only be available when using the SIM card in the SIM1 card holder. If there is a SIM card only in the SIM2 card holder, you can only make emergency calls.

Both SIM cards are available at the same time when the device is not being used, but while one SIM card is active, for example, making a call, the other is unavailable.

Insert a memory card

Learn how to insert a memory card into your phone.

Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

© 2013 Nokia. All rights reserved.	6

1.Push the tool into the hole until the cover is released. Remove the back cover, and lift out the battery.

2.Slide the memory card into place with the contact area face down.

3.To remove the card, pull it out.

Important: Do not remove the memory card when an app is using it. Doing so may damage the memory card and the device and corrupt data stored on the card.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can use your phone.

1.Plug the charger into a wall outlet.

2.Connect the charger to the phone. When done, unplug the charger from the phone, then from the wall outlet.

© 2013 Nokia. All rights reserved.	7

If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.

Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.

Set which SIM card to use

You can set the default SIM card to use to make a call, send a message, or connect to the internet. If you name your SIMs, you can see at a glance which is, for example, for work and which is for personal use.

1.Select Menu > SIM mgr..

2.To decide every time which SIM to use, select Ask every time.

3.Select SIM1 or SIM2 to set which SIM to use for which connection.

Rename your SIM card

Select Options > Rename.

Copy content from your old phone

Easily get your contacts, calendar entries, and other stuff to your new phone.

1.Switch Bluetooth on in both phones. To switch Bluetooth on on your new phone, select Menu >

Settings > Connectivity > Bluetooth.

2.On your new phone, select Menu > Settings > Sync & backup > Copy from dev..

3.Select what you want to copy, then select Done.

4.Choose your old phone from the list of found devices.

© 2013 Nokia. All rights reserved.	8

5.If asked, create a one-time passcode (such as 123), and select OK.

6.Check that the codes match on both phones.

7.Follow the instructions shown on both phones.

Tip: To quickly copy contacts from a compatible phone, select Menu > Transfer.

© 2013 Nokia. All rights reserved.	9

Basics

Learn how to get the most out of your new phone.

Explore your phone

Explore your phone with a simple key press.

1. To see the apps and features of your phone, press Menu.

Menu

2.To go to an app or feature, press the scroll key up, down, left, or right.

3.To open the app or select the feature, press Select.

Select

4. To go back to the previous view, press Back.

Back

5. To go back to the home screen, press .

© 2013 Nokia. All rights reserved.	10

Display indicators

The display indicators on your phone tell you the current time, battery and signal strength, and much more.

You have unread messages sent to SIM1, SIM2, or both.

You have unsent or failed messages from SIM1, SIM2, or both.

The keys are locked.

An alarm is set.

Bluetooth is on.

The phone is connected to a GSM network.

All incoming calls to SIM1, SIM2, or both are forwarded to another number.

The phone is connected to a headset.

The phone is connected to a device, such as a PC, with a USB cable.

The type of mobile network you're currently connected to may be shown with a single letter, a combination of letters, or a combination of letters and numbers. For example, , depending on your network service provider.

The icons may vary depending on your region or network service provider.

Prolong battery life

Get the most out of your phone while getting the battery life you need. There are steps you can take to save power on your phone.

•Always charge the battery fully.

•Mute unnecessary sounds, such as key press sounds.

•Use wired headphones, rather than the loudspeaker.

To save power, you can:

Lower the backlight brightness	Select Menu > Settings > Display > Backlight, and change
	the setting for Backlight intensity.

Set the backlight to switch off after a Select Menu > Settings > Display > Backlight, and change short time the setting for Backlight time-out.

© 2013 Nokia. All rights reserved.	11
