Microsoft RM-889 User Manual
Nokia Lumia 510 User Guide
Issue 1
2Contents
Contents
Safety 4
Get started 6
Keys and parts 6
Back, start, and search keys 7
Insert the SIM card 8
Charge your phone 10
Antenna locations 12
Switch the phone on or off 12
Create your Windows Live ID 13
Windows Live ID 14
Nokia account 14
Copy contacts from your old phone 15
Lock or unlock the keys and screen 16
Headset 16
Change the volume 17
Access codes 17
Set your phone to sync with your
computer 18
Basics 19
About the start screen and apps
menu 19
Touch screen actions 19
Use your phone when it's locked 23
Switch between open apps 24
Personalize your phone 24
Text input 26
Search your phone and the web 29
Control your phone with your voice 30
Icons on the status bar 30
Use your phone in flight mode 31
Increase battery life 31
Calls 32
Call a contact 32
Call the last dialed number 32
Call your voice mailbox 32
Divert calls to your voice mailbox or
another phone number 33
Make a conference call 33
Silence an incoming call 34
Use your voice to call a contact 34
Contacts & social networking
services 35
Contacts 35
Social networks 38
Internet 40
Internet connections 40
Internet 42
Messaging & mail 44
Messages 44
Mail 46
Camera 49
About the camera 49
Take a picture 49
Take a close-up picture 50
Take a picture in the dark 50
Take a picture of a moving object 51
Camera tips 51
Record a video 51
Save location information to your
pictures 51
Send a picture or video 52
Share your pictures and videos 53
Your pictures 53
About the Pictures hub 53
View pictures 53
Mark a picture as a favorite 55
Upload pictures and videos to the
web 55
Change the background in the
Pictures hub 55
Create an album 56
Copy your pictures between your
phone and PC 56
Entertainment 56
Music and videos 56
Marketplace 58
Games 61
Maps & navigation 62
Positioning and location services 62
Nokia Maps 63
Nokia Drive 67
Office 72
Clock 72
Calendar 73
Microsoft Office Mobile 75
Use the calculator 79
Connectivity & phone management 80
Bluetooth 80
Copy a picture or other content
between your phone and PC 81
Keep your phone software and
applications up to date 81
Back up, sync, and restore your
phone 82
Free up phone memory 83
Remove an application from your
phone 83
Security 83
Contents 3
Support 85
Product and safety information 85
Index 92
4Safety
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further info, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when cell phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for
use with this device. Third-party chargers that comply with the IEC/EN
62684 standard, and that can connect to your device micro USB connector,
may be compatible. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The device screen is made of glass. This glass can break if the device is
dropped on a hard surface or receives a substantial impact. If the glass
breaks, do not touch the glass parts of the device or attempt to remove
the broken glass from the device. Stop using the device until the glass is
replaced by qualified service personnel.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for
long periods. Exercise caution when holding your device near your ear while
the loudspeaker is in use.
Safety 5
6 Get started
Get started
Keys and parts
1 Connector for headphones and loudspeakers (3.5 mm)
2 Earpiece
3 Proximity sensor. Do not cover, for example, with protective film or tape.
4 Volume key
5 Power/Lock key
6 Camera key
7 Microphone
8 Back key
9 Start key
10 Search key
11 Micro-USB connector. Used also to charge the battery.
12 Camera lens
13 Loudspeaker
Back, start, and search keys
The back, start, and search keys help you to navigate your phone.
Back key
Return to the previous screen
. Your phone remembers all the apps and websites you have visited since the
Press
last time your screen was locked.
Switch between open apps
Press and hold
, swipe left or right, and select the desired app.
Get started 7
Start key
Go to the start screen
Press
.
Control your phone with your voice
Press and hold
, and say a voice command.
This feature may not be available in all languages.
8 Get started
Search key
Search the web
Press
.
Insert the SIM card
Important: This device is designed to be used with a mini-UICC SIM card, also
known as a micro-SIM card only. A micro-SIM card is smaller than the standard SIM
card. Use of incompatible SIM cards may damage the card or the device, and may
corrupt data stored on the card.
Do not use SIM cards that have been modified to fit the micro-SIM slot. To replace a
standard SIM card with a micro-SIM card, contact your service provider.
Do not attach any stickers to the card.
1 Place your fingernail in the gap on the lower right edge of the phone, and carefully
lift and remove the back cover.
2 If the battery is inserted, lift it out.
3 Make sure the contact area is facing down, and insert the card.
4 Line up the battery contacts, and insert the battery.
5 Replace the back cover.
Remove the SIM card
1 Remove the back cover and battery.
2 Pull the card out.
Get started 9
10 Get started
Charge your phone
About the battery
Use only Nokia approved chargers designated for this phone. You can also use a
compatible USB cable to charge your phone (included).
You can set your phone to automatically save power when the battery charge level is
low. Select
battery is low.
When your phone goes into battery saver mode, you may not be able to change the
settings of all apps.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your phone for the first time.
You do not need to charge the battery for a specific length of time, and you can use
the phone while it is charging.
If your phone is off when you start to charge the phone, it automatically switches on.
Make sure you use a compatible USB charger to charge your phone.
If the phone indicates a low charge, do the following:
Charge from a wall outlet
1 First connect the USB cable to the charger, plug the charger into a wall outlet,
then connect the micro-USB end of the USB cable to your phone.
> Settings and battery saver > Always turn on Battery Saver when
2 When the battery is full, unplug the charger from the phone, then from the wall
outlet.
Get started 11
To avoid breaking the USB cable connector, be careful when connecting or
disconnecting the charger cable.
Charge from a computer
You can use USB charging when a wall outlet is not available. Data can be transferred
while charging the device. The efficiency of USB charging power varies significantly,
and it may take a long time for charging to start and the device to start functioning.
1 First connect the USB cable to the computer, then to your phone.
12 Get started
2 When the battery is full, first unplug the USB cable from your phone, then from
the computer.
If the battery is completely discharged, it may take several minutes before the
charging indicator is displayed or before any calls can be made.
Antenna locations
Avoid touching the antenna area while the antenna is in use. Contact with antennas
affects the communication quality and may reduce battery life due to higher power
level during operation.
The antenna area is highlighted.
Switch the phone on or off
Switch the phone on
Press and hold the power key, until the phone vibrates.
Get started 13
Switch the phone off
Press and hold the power key, and drag the lock screen down.
Create your Windows Live ID
Your phone guides you through the initial setup when you put your SIM card in your
phone and switch your phone on for the first time. To access all Windows Live services,
create your Windows Live ID.
14 Get started
To create a Windows Live ID, you need an internet connection. For info about possible
data costs, contact your network service provider. If you can't connect to the internet,
you can create the account later.
If you already have a Windows Live ID, sign in with your existing username and
password.
Tip: Forgotten your password? You can request it to be sent to you in a mail or text
message.
To create your Windows Live ID later, go to www.live.com.
To make an emergency call during the initial setup, select emergency call.
Windows Live ID
With a Windows Live ID, you can access Windows Live and Zune services with a single
username and password on your computer or phone. You can also use the same
username and password to access Xbox Live services on your Xbox.
With your Windows Live ID, you can, for example:
• Download content from Marketplace
• Back up your contacts in Windows Live
• Upload, store, and share pictures and documents on SkyDrive
• Keep track of and lock your lost phone with Find My Phone
• Get your gaming achievements on your phone, and add to them when you play
games on your phone
The available services may vary.
To learn more about Windows Live ID and Windows Live services, go to
www.live.com.
Nokia account
With your Nokia account, you can access Nokia services with a single username and
password, both on your phone and compatible computer. The available services may
vary.
You can:
• Download content from Nokia services
• Save details about your phone model and contact information. You can also add
your payment card details.
Get started 15
To learn more about the Nokia account and Nokia services, go to www.nokia.com/
support.
To create a Nokia account later, go to account.nokia.com.
Copy contacts from your old phone
Have your nearest and dearest instantly at your fingertips. Use the Contacts Transfer
app to easily copy your contacts from your old phone.
Your old phone needs to have Bluetooth, and the contacts need to be stored in the
phone memory, not on the SIM. The app does not work with all phone models.
1 On your old phone, switch Bluetooth on.
2 On the start screen of your new phone, swipe left to the apps menu, then select
Contacts Transfer.
3 Select Continue, then switch Bluetooth on.
4 Select your old phone from the list of found devices, then follow the instructions
shown on both phones.
If your contacts are written in a language that is not supported by your new phone,
the contact info may not be shown correctly.
16 Get started
If you have previously backed up your contacts in Windows Live, you can also import
them to your phone straight from the service.
Lock or unlock the keys and screen
To avoid accidentally making a call when your phone is in your pocket or bag, lock the
keys and screen of your phone.
Lock the keys and screen
Press the power key.
Unlock the keys and screen
Press the power key, and drag the lock screen up.
Set the keys and screen to lock automatically
Select
> Settings and lock+wallpaper > Screen times out after, and select the
length of time after which the keys and screen are locked automatically.
Headset
You can connect a compatible headset or compatible headphones to your phone.
Get started 17
Do not connect products that create an output signal, as this may damage the device.
Do not connect any voltage source to the audio connector. If you connect an external
device or headset, other than those approved by Nokia for use with this device, to
the audio connector, pay special attention to volume levels.
Change the volume
Press the volume keys up or down.
The volume keys control all sounds, including the volume of alarms and reminders.
Tip: When you change the volume, you can also switch your phone to silent or normal
mode. Select
The built-in loudspeaker allows you to speak and listen from a short distance without
having to hold the phone to your ear.
Switch the loudspeaker on or off during a call
Select
, , or .
.
Access codes
PIN code
(4-8 digits)
This protects your SIM against unauthorized use or is required
to access some features.
You can set your phone to ask for the PIN code when you switch
it on.
If not supplied with your card or you forget the code, contact
your service provider.
If you type in the code incorrectly three times in a row, you
need to unblock the code with the PUK code.
18 Get started
PUK code
(8 digits)
IMEI number
(15 digits)
Lock code (security
code)
(min. 4 digits)
The personal unblocking key (PUK) code and the universal personal unblocking key
(UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code,
respectively. These codes are not supplied with the SIM card. Contact your local
service provider for the codes.
Set your phone to sync with your computer
With the Zune PC app, you can sync music, videos, and pictures between your phone
and your compatible computer. You can also back up and update your phone with the
latest software, to improve performance and get new features.
This is required to unblock a PIN code.
If not supplied with your SIM, contact your service provider.
This is used to identify valid phones in the network. The
number can also be used to block, for example, stolen phones.
You may also need to give the number to Nokia Care services.
To view your IMEI number, dial *#06#.
This helps you protect your phone against unauthorized use.
You can set your phone to ask for the lock code that you
define.
Keep the code secret and in a safe place, separate from your
phone.
If you forget the code and your phone is locked, your phone
will require service. Additional charges may apply, and all the
personal data in your phone may be deleted.
For more information, contact Nokia Care or your phone
dealer.
Basics 19
1 Download and install the latest version of Zune on your PC from www.zune.net.
Tip: If you're using an Apple Mac, download Windows Phone 7 Connector for Mac
from the Mac App Store.
2 Make sure your phone is not locked with a security code.
3 Connect your phone to your computer with a compatible USB cable, then follow
the instructions shown on your computer.
4 To change Zune sync settings, on your computer, select SETTINGS.
If you have previously used another app, such as Nokia Suite or Nokia Ovi Suite, to
sync your files between your phone and computer, you can set Zune to sync files to
the same folders you have used earlier, and have your music and other content easily
synced to your new phone.
Basics
About the start screen and apps menu
The two main views in your phone are:
• Start screen
Tap the tiles to open your favorite apps. Animated tiles show missed calls and
received messages, the latest news and weather forecasts, your friends' online
statuses, and more.
You can rearrange the tiles, and pin contacts, apps, feeds, mailboxes, and other
favorites. Pinned contacts' updates are shown on the tile, and you can call them
directly from the start screen.
• Apps menu
All your apps are listed here, in alphabetical order. Have a lot of apps? To search
for an app, select
Tip: To switch between the start screen and apps menu, select
swipe left or right.
.
or , or simply
Touch screen actions
To use your phone, tap or tap and hold the touch screen.
Important: Avoid scratching the touch screen. Never use an actual pen, pencil, or
other sharp object on the touch screen.
Open an app or other screen element
Tap the app or element.
20 Basics
Tap and hold to open a menu with further options
Place your finger on an item, until the menu opens.
Example: To edit or delete a calendar appointment, tap and hold the appointment,
and select the appropriate option.
Tap and hold to drag an item
Place your finger on the item for a second or two, and slide your finger across the
screen.
Basics 21
Swipe
Place a finger on the screen, and steadily slide your finger in the desired direction.
22 Basics
Example: Swipe left or right between the start screen and the apps menu, or between
different views in the hubs. To quickly scroll through a long list or menu, slide your
finger quickly in a flicking motion up or down the screen, then lift your finger. To stop
the scrolling, tap the screen.
Zoom in or out
Place two fingers on an item, such as a map, picture, or web page, and slide your
fingers apart or together.
Basics 23
Use your phone when it's locked
You can use certain features of your phone when it is locked, without having to enter
the security code.
You can, for example:
• Change how your phone notifies you about incoming calls
• Answer or reject an incoming call
• Pause or resume playing music, or skip to another song
To wake up your phone, press the power key.
Change how incoming calls are notified
Press a volume key, and select
, , or .
Pause or resume music, or skip to another song
Use the music player controls displayed at the top of the screen.
You can also see:
24 Basics
• The date and time
• Your next calendar event
• Missed calls or messages
Switch between open apps
You can see which apps and tasks are open in the background, and switch between
them.
Press and hold
, swipe left or right, and select the desired app.
Personalize your phone
Personalize the start screen
Would you like to have only the content you need on the start screen? Move or remove
tiles, and pin contacts, apps, and websites to the start screen.
You can also pin music and pictures, your latest mail, favorite contacts, and more.
When you pin a contact, their feed updates are shown on the tile, and you can call
them directly from the start screen.
Pin a contact
1Select
> People.
2 Select and hold the contact, then select pin to Start.
Basics 25
Pin an app
1 Select
2 Select and hold the app, then select pin to Start.
Pin a website
Go to a website, then select
Move a tile
Select and hold the tile, drag and drop it to the new location, then tap the screen.
Remove a tile from the start screen
Select and hold the tile, then select
Change your theme
You can change the colors, to match your taste and mood.
Select
Tip: You can save battery power if you use a darker background.
Change the background pictures
Want to view your favorite pictures more often? You can change the background
picture of the lock screen, or the Pictures hub or live tile.
Change the lock screen wallpaper
1 Select
2 Select a picture, adjust it to get the best possible fit, and select
Change the background of the Pictures hub and live tile
1 In the Pictures hub, select
2 Select a picture, adjust it to get the best possible fit, and select
Tip: If you like variety, select shuffle background, and the phone will shuffle through
your pictures.
to go to the apps menu.
> pin to start.
.
> Settings and theme > Background or Accent color.
> Settings and lock+wallpaper > change wallpaper.
.
> choose background.
.
Personalize your ringtone and other tones
You can personalize your phone tones.
Select
Select the type of ringtone or alert you want to change, and select the sound.
> Settings and ringtones+sounds.
26 Basics
Tip: You can use the Zune PC app to create ringtones from your favorite songs.
Make your own ringtone
You can use your own sound files as ringtones.
1 Connect your phone to your computer with a compatible USB cable.
2 On your computer, open Zune.
3 Select the sound file you want to use as a ringtone. The file must be in MP3 or
WMA format, and should be less than 40 seconds long and less than 1 MB in size.
4 Right-click the file, then select Edit.
5Write ringtone in the genre field, or select it from the list.
6 Drag and drop the new ringtone to your phone.
7 On your phone, select
ringtone.
Silence your phone
When you switch silent mode on, all ringtones and alert tones are muted. Use this
when you are, for example, at the cinema or in a meeting.
Press a volume key to see the volume status bar, then select ring
is switched on. If you have set your phone to vibrate, vibrate mode is switched on
instead of silent mode.
Set your phone to vibrate
Select
Text input
Use the on-screen keyboard
To open the on-screen keyboard, select a text box. You can use the on-screen
keyboard when holding your phone in portrait or landscape mode.
> Settings and ringtones+sounds, and switch Vibrate to On .
> Settings and ringtones+sounds, then select your
. Silent mode
Basics 27
1 Character keys
2 Shift key
3 Numbers and symbols key
4 Smiley key
5 Space key
6 Language key. Shown when more than one writing language is used.
7 Enter key
8 Backspace key
The keyboard layout can vary in different apps.
Switch between upper and lower case characters
Select the shift key. To switch caps lock mode on, select the key twice. To return to
normal mode, select the shift key again.
Type in a number or special character
Select the numbers and symbols key. Some of the special character keys can bring
up more symbols. To see more related symbols, select and hold a symbol or special
character.
Tip: To quickly type in a number or commonly used special character, put a finger on
the numbers and symbols key, slide your finger to the character, then lift your finger.
Tip: To quickly type in a period and a space when you get to the end of a sentence,
select the space key twice.
Add an accent to a character
Select and hold the character, then select the accented character.
Delete a character
Select the backspace key.
Switch between the writing languages
Select the language key.
Move the cursor
Tap and hold the screen near the text until a cursor is shown. Without lifting your
finger, drag the cursor to the place you want.
To move the cursor to the next row or text box, select the enter key. The function of
the enter key can change in different apps. For example, in the web address box of
the web browser, it acts as the Go icon.
28 Basics
Use keyboard word suggestions
Your phone suggests words as you write, to help you write quickly and more
accurately.
Word suggestions are not available in all languages.
Select
1 Select a keyboard and Suggest text and highlight misspelled words.
2 In a text input field, start writing a word. Your phone suggests possible words as
3 To add a new word to the dictionary, write the word, select it, and then select the
Switch word suggestions off
Select a keyboard, then clear the Suggest text and highlight misspelled words check
box.
Remove all words manually added to suggestion list
Select reset suggestions.
> Settings and keyboard > typing settings.
you write. When the correct word is displayed, select the word.
plus sign (+) next to the word in the suggestion bar.
Add more writing languages
You can add several writing languages for your keyboard and switch between the
languages when writing.
Select
The language key is shown on the keyboard.
Switch between the languages when writing
Select the language key. The keyboard layout and word suggestions change according
to the language selected.
> Settings and keyboard, then select the languages you want to write in.
Basics 29
Search your phone and the web
Explore your phone, the web, and the outside world. With Bing search, you can use
the on-screen keyboard or your voice to write your search words. You can also use
your phone camera to scan things, such as barcodes and book and DVD covers, and
get further info on what your phone recognizes.
Some services may not be available in all countries, and may be provided only in
selected languages.
Search the web
1Press
2 Write your search word in the search box, then select
the proposed matches.
Tip: To see related search results, swipe to local or images.
Use voice search
1Press
2 Select
3Say Find or Search for and your search word.
Voice search is currently available in the following countries: Canada, France,
Germany, Italy, Spain, the United Kingdom, and the United States.
Search inside an app
1 In an app, such as Marketplace, select
2 Write your search word in the search box, then select
the proposed matches.
Use vision search
1Press
2 Select
.
. You can also select from
.
in the search box.
.
. You can also select from
.
, then scan text, QR codes, or barcodes.
Loading...
