RM-852
User Guide
58 pgs1.01 Mb0

Microsoft RM-852 User Guide

Download
5555555 Issue 1 EN
Cyan
Magenta
Yellow
Black
Cyan
Magenta
Yellow
Contents
Cyan
Magenta
Yellow
Black
Get started..........................................................................5
Your dual SIM phone...............................................................................................5
Keys and parts........................................................................................................6
Insert a SIM card and battery ................................................................................8
Insert a second SIM card........................................................................................9
Insert or remove a memory card.........................................................................10
Charge the battery...............................................................................................11
Switch on..............................................................................................................11
Copy content from your old phone.....................................................................13
Set which SIM card to use....................................................................................14
Lock the keys and screen ....................................................................................15
Change the volume..............................................................................................15
Phone basics.....................................................................16
Switch between home screens............................................................................16
Explore your phone..............................................................................................17
Add a shortcut to My screen................................................................................19
Change the wallpaper...........................................................................................20
Change your ringtone..........................................................................................21
About Nokia Store.............................................................22
Calls...................................................................................23
Make a call ...........................................................................................................23
Contacts............................................................................24
2
Cyan
Magenta
Yellow
Save a name and phone number.........................................................................24
Cyan
Magenta
Yellow
Black
Write text..........................................................................25
Use the on-screen keypad...................................................................................25
Use the on-screen keypad...................................................................................26
Use predictive text...............................................................................................27
Messaging..........................................................................28
Send a message...................................................................................................28
Write using the on-screen keyboard...................................................................29
Mail ...................................................................................30
Send a mail...........................................................................................................30
Photos and videos.............................................................31
Take a photo.........................................................................................................31
Record a video......................................................................................................32
Web....................................................................................33
Browse the web....................................................................................................33
Add a bookmark...................................................................................................35
Connectivity......................................................................36
Connect to a wireless headset............................................................................36
Maps..................................................................................37
Search for a place................................................................................................37
3
Cyan
Magenta
Yellow
Support and updates........................................................38
Cyan
Magenta
Yellow
Black
Troubleshooting...................................................................................................38
Back up content to a memory card.....................................................................40
About phone software updates ..........................................................................41
Update phone software using your PC................................................................42
Update phone software using your phone.........................................................43
Restore original settings......................................................................................44
Access codes........................................................................................................45
Product and safety information.......................................47
4
Cyan
Magenta
Yellow
Get started
Cyan
Magenta
Yellow
Black
Your dual SIM phone
You can have two SIM cards in your phone.
Some benefits of a dual SIM phone
• Have two phone numbers, but carry one phone – use a work and personal SIM at the same time.
• It doesn't matter which number people call – both SIMs are active.
• Save money – use the best network service provider for a situation.
• Stay in touch – avoid differences in network coverage between service providers.
Both SIM cards are available at the same time when the device is not being used, but while one SIM card is active, for example, making a call, the other is unavailable.
If you only have one SIM card, put the card into the SIM1 card holder. Some features and services may only be available when using the SIM card in the SIM1 card holder. If there is a SIM card only in the SIM2 card holder, you can only make emergency calls.
Availability of SIMs
• When you set one SIM to be used for outgoing calls, sending text or multimedia messages, or uploading and downloading data, the other SIM can still receive calls or text and multimedia messages.
• When one SIM is having a call, sending or receiving text or multimedia messages, or uploading or downloading data, the other is not available.
5
Cyan
Magenta
Yellow
Keys and parts
Cyan
Magenta
Yellow
Black
1 Charger connector 6 End/Power key 2 Micro-USB connector 7 Microphone 3 Headset connector (Nokia AV
connector 3.5 mm)
4 Volume keys 9 Screen 5 Lock key 10 Earpiece
8 Call key
6
Cyan
Magenta
Yellow
11 Camera lens. Before using the
Cyan
Magenta
Yellow
Black
camera, remove the protective tape from the lens.
12 SIM card slot (SIM 2) 14 Loudspeaker
13 Memory card slot
7
Cyan
Magenta
Yellow
Insert a SIM card and battery
Cyan
Magenta
Yellow
Black
1
Switch the phone off, and remove the back cover.
2
If the battery is in the phone, lift it out.
3
Slide the SIM under the holder with the contact area face down.
4
Line up the battery contacts, and push the battery in.
5
Replace the back cover.
6
To remove the SIM, press the tongue down, and slide the SIM out.
8
Cyan
Magenta
Yellow
Insert a second SIM card
Cyan
Magenta
Yellow
Black
1
Open the SIM cover.
2
Put the SIM in with the contact area face up.
3
Push the card in until it locks into place. Close the cover.
4
To remove the SIM, push the SIM in until it's free.
5
Pull the SIM out.
9
Cyan
Magenta
Yellow
Insert or remove a memory card
Cyan
Magenta
Yellow
Black
1
Open the memory card slot cover.
2
Put the memory card in with the contact area face up.
3
Push the card in until it locks into place. Close the cover.
4
To remove the memory card, push the card in until it's free.
5
Pull the memory card out.
10
Cyan
Magenta
Yellow
Charge the battery
Cyan
Magenta
Yellow
Black
Switch on
1
Plug the charger into a wall outlet.
2
Connect the charger to the phone.
1, 2 in "Feature specific
See instructions".
3
Battery full? Unplug from the phone, then from the wall outlet.
1
Press and hold the power key.
2
Select the date field, and set the date.
3
Select the time field, and set the time.
date & time
date
31-10-2011
time:
10:03
time zone:
GMT London
daylight saving:
+0 hours
date & time
date
31-10-2011
time:
10:03
time zone:
GMT London
daylight saving:
+0 hours
11
Cyan
Magenta
Yellow
4
Cyan
Magenta
Yellow
Black
Select the time zone, and select if daylight saving time is used.
date & time
date
31-10-2011
time:
10:03
time zone:
GMT London
daylight saving:
+0 hours
5
Select .
Tip: To switch the phone off, press and hold the power key.
date & time
date
31-10-2011
time:
10:03
time zone:
GMT London
daylight saving:
+0 hours
12
Cyan
Magenta
Yellow
Copy content from your old phone
Cyan
Magenta
Yellow
Black
Easily get your contacts, calendar, and other stuff to your new phone.
1. Switch Bluetooth on in both phones.
2. On your new phone, select settings and sync & backup > phone switch.
3. Select copy to this and what you want to copy, then select
4. Select your old phone from the list of found devices.
5. Follow the instructions shown on both phones.
13
.
Cyan
Magenta
Yellow
Set which SIM card to use
Cyan
Magenta
Yellow
Black
You can set the default SIM card to use to make a call, send a message, or connect to the internet. If you name your SIMs, you can see at a glance which is, for example, for work and which is for personal use.
Select SIM manager.
Select from the following:
or — Use the SIM in either the internal SIM holder or the
external SIM slot as the default SIM.
— When a SIM is needed, you are asked which SIM to use.
— Set which SIM to use in different cases. For example, you can use one SIM to make calls, but another to connect to the internet. To change the settings, select personalise.
Rename a SIM card
Select the SIM you want to rename, then write the new name.
Tip: To quickly change between SIMs and modes, swipe down from the top of the screen, then tap the SIM area.
14
Cyan
Magenta
Yellow
Lock the keys and screen
Cyan
Magenta
Yellow
Black
Change the volume
Lock the keys and screen when not using your phone.
1
To lock, press the key lock button.
2
To unlock, press the key lock button, then swipe left or right.
Is the volume too loud during a call or when listening to the radio?
1
Use the volume keys.
2
Better.
15
Cyan
Magenta
Yellow
Phone basics
Cyan
Magenta
Yellow
Black
tuesday
10:03
Switch between home screens
Your phone has three home screens, one for apps, one for your favourite shortcuts, and one for your most used app, such as the dialler.
Swipe left or right.
• My screen is the place where you can add your favourite contacts and shortcuts.
• On the apps screen, you can open apps, and organise them to your liking.
• On the dialler screen, you can make calls. In place of the dialler, you can also have the music player or radio.
Tip: To personalise the dialler screen, tap and hold My screen, swipe to the dialler screen, and select the app you want.
123
456
789
16
Cyan
Magenta
Yellow
Explore your phone
Cyan
Magenta
Yellow
Black
1
Tap an app or other item to open it.
2
Tap and hold an item to see more options.
3
To swipe, steadily slide your finger to the desired direction.
10:03
tuesday
4
To scroll, slide your finger quickly up or down, then lift your finger.
5
To zoom, slide two fingers apart or together on the screen.
6
To go back to the previous view,
.
select
17
Cyan
Magenta
Yellow
7
Cyan
Magenta
Yellow
Black
To go back to the home screen, select
.
8
To view notifications, swipe down from the top of the screen. Se e
3.
18
Cyan
Magenta
Yellow
tuesday
Cyan
Magenta
Yellow
Black
10:03
Add a shortcut to My screen
Want to open your favourite apps straight from My screen? Add shortcuts to your most used features.
1. Tap and hold My screen, and select
2. Select an item, such as a widget or action, and select
Remove a shortcut
Tap and hold My screen, and select remove.
Tip: Try tapping different areas on My screen. You can, for example, change the date and time, set alarms, or add to your calendar also from My screen.
10:03
tuesday
shortcut.
.
on the shortcut you want to
19
Cyan
Magenta
Yellow
tuesday
Cyan
Magenta
Yellow
Black
10:03
Change the wallpaper
Want to see a favourite landscape or your family photos in the background of the lock screen? You can change the wallpaper to personalise the lock screen to your liking.
1. Select settings and wallpaper.
2. Select a folder and a photo.
Tip: You can also take a photo on your phone, and use that.
10:03
tuesday
20
Cyan
Magenta
Yellow
Change your ringtone
Cyan
Magenta
Yellow
Black
You can set a different ringtone for each profile.
1. Select settings > tone profiles and a profile.
2. Select ringtone.
3. Select a ringtone from open files or your downloaded tones. The
ringtone plays so you can see if you like it.
4. When you've found a ringtone you like, select YES.
Tip: Download more ringtones from Nokia Store. To learn more about Nokia Store, go to www.nokia.com/support.
Tip: You can also change the message alert tone. Select msg. alert tone and a tone.
21
Cyan
Magenta
Yellow
About Nokia Store
Cyan
Magenta
Yellow
Black
Download mobile games, apps, videos, themes, wallpapers, and ringtones to your phone from Nokia Store.
Select store.
Many items are free of charge; some you need to pay for with your credit card or on your phone bill. The availability of payment methods depends on your country of residence and your network service provider. To learn more about Nokia Store, go to www.nokia.com/
support.
22
Cyan
Magenta
Yellow
Calls
Cyan
Magenta
Yellow
Black
Make a call
1. Select phone, or swipe left to open the dialler.
2. Type in the phone number.
The + character may not work in all regions. In this case, type in the international access code directly.
3. Press
4. If asked, select the SIM to use.
5. To end the call, press
Answer a call
Press
When you receive a call, your phone shows you which SIM is used.
Decline a call
Press
.
.
.
.
23
Cyan
Magenta
Yellow
Contacts
Cyan
Magenta
Yellow
Black
Save a name and phone number
Add new contacts to your phone.
Select contacts.
Select
, then write the name, number, and other details.
If asked, select where to save the contact.
Edit the details of a contact
Select a contact and
Add more details
> add detail and a detail.
Select
, then edit the details.
24
Cyan
Magenta
Yellow
Write text
Cyan
Magenta
Yellow
Black
Use the on-screen keypad
To open the traditional alphanumeric keypad, turn the phone to portrait mode.
1 Close key 6 Input options key - Switch
2 Character keys 7 Symbol key - Type in a special
predictive text input on or off, change the writing language, or switch to the on-screen keyboard.
character.
25
Cyan
Magenta
Yellow
3 Smiley key - This may not be
Cyan
Magenta
Yellow
Black
available in all languages.
4 Space key 9 Backspace key - Delete a
5 Shift key - Change the
character case. This may not be available in all languages.
Close the keypad
Swipe down on the keypad. You can also select and hold the close key.
Switch back to using the keyboard
Turn the phone to landscape mode.
Use the on-screen keypad
To open the on-screen keypad when writing text, turn the phone to portrait mode.
Type in a character
1. Select a character key repeatedly until the character is shown.
There are more characters available than are shown on the key.
2. If the next lett er is on th e same key, wait unti l the curs or is shown , then select the key again.
Type in a space
Select
Move the cursor to the next line
Select
.
three times.
8 Character/number mode key
- Switch between characters and numbers.
character.
26
Cyan
Magenta
Yellow
Type in a number
Cyan
Magenta
Yellow
Black
Select
Type in a special character
Select the sym key, then select the special character.
Use predictive text
Predictive text is not available in all languages.
1. Select
2. Start writing a word. Your phone suggests possible words as you
write. When the correct word is shown, select the word.
3. If the word is not in the dictionary, select the pop-up and add the new word to the dictionary.
When using predictive text, you can set your phone to complete and type in words for you automatically.
Use word completion
Select
, then select the number.
> prediction > .
, and
> word completion > .
27
Cyan
Magenta
Yellow
Messaging
Cyan
Magenta
Yellow
Black
Send a message
Keep in touch with your family and friends through messages.
1. Select messaging and
2. To add a contact as a recipient, select
phone number.
3. Write your message in the text box.
Tip: To include an attachment, such as a photo or video, select insert content.
4. Select
If asked, select which SIM to use.
Sending a message with an attachment, such as a photo or video, may be more expensive than sending a normal text message. For more info, contact your network service provider.
See
.
4, 5, 6.
.
. You can also type in a
28
>
Cyan
Magenta
Yellow
Write using the on-screen keyboard
Cyan
Magenta
Yellow
Black
When writing text, select > input type, then select the language and full keyboard.
Add an accent to a character
Select and hold the character. This may not be available in all languages.
Switch between character cases
.
Select
Type in a space
Select
Move the cursor to the next line
Select
Delete a character
Select
.
.
.
29
Cyan
Magenta
Yellow
Mail
Cyan
Magenta
Yellow
Black
Mike
Hello Anna! Anna
Hi Mike!
Send a mail
Would you like to send a mail while on the go? With your phone, you can read and send mail, even when not sitting at your desk.
1. Select mail and a mail account.
2. Select
3. To add a recipient, select
To: field.
4. Write the subject and your message.
Tip: To include an attachment, such as a photo, select
5. Select
.
, or manually write the address in the
.
.
30
Cyan
Magenta
Yellow
Photos and videos
Cyan
Magenta
Yellow
Black
Take a photo
1. To open the camera, select camera.
2. To zoom in or out, use the volume keys.
3. Select
Photos are saved in gallery.
Close the camera
Select
.
.
31
Cyan
Magenta
Yellow
Record a video
Cyan
Magenta
Yellow
Black
Besides taking photos with your phone, you can also capture your special moments as videos.
To open the video camera, select video.
1. To start recording, select
2. To zoom in or out, use the volume keys.
3. To stop recording, select
Videos are saved in gallery.
Close the camera
Select
.
.
.
32
Cyan
Magenta
Yellow
Web
Cyan
Magenta
Yellow
Black
Paris
Browse the web
Catch up on the news, and visit your favourite websites on the go.
Select internet.
Go to a website
Write the web address in the address bar.
Move on the web page
Drag the page with your finger.
Zoom in
Tap the section of the web page you want to see better.
Zoom out
Double-tap the screen.
Tip: To zoom in or out, you can also place two fingers on the screen, and slide your fingers apart or together.
Search the internet
Write a search word in the address bar. If asked, select your default search engine.
Go back to a previously visited web page
> history and the web page.
Select
33
Cyan
Magenta
Yellow
Tip: To show the address bar and toolbar when browsing, select .
Cyan
Magenta
Yellow
Black
Tip: You can download web apps from Nokia Store. When you first open a web app, it is added as a bookmark. For more info, go to
www.nokia.com/support.
34
Cyan
Magenta
Yellow
travel
Cyan
Magenta
Yellow
Black
Paris
www.nokia.com
Add a bookmark
If you visit the same websites all the time, add them as bookmarks, so you can easily access them.
Select internet.
While browsing, select
Go to a bookmarked website
and a bookmark.
Select
> add to favourites.
35
Cyan
Magenta
Yellow
Connectivity
Cyan
Magenta
Yellow
Black
Connect to a wireless headset
Want to keep working at your computer during a call? Use a wireless headset. You can also answer a call, even if your phone's not directly at hand.
Select settings > connectivity > Bluetooth.
1. Make sure Bluetooth is on.
2. Switch the headset on.
3. To search for your headset, select
4. Select the headset.
5. You may need to type in a passcode (such as 1234).
.
36
Cyan
Magenta
Yellow
Maps
N
Cyan
Magenta
Yellow
Black
Search for a place
You can search for locations, such as street addresses, and places, such as restaurants.
1. Select maps.
2. Select
3. Write the name of the place or the address.
to see the toolbar, then select .
37
Cyan
Magenta
Yellow
Support and updates
Cyan
Magenta
Yellow
Black
Troubleshooting
If you have an issue, do the following:
• Switch the phone off, and remove the battery. After about a minute, put the battery back in, and switch the phone on again.
• Update your phone software: Select settings and phone > device updates.
• Restore the original factory settings: End all calls and connections, and select settings and restore factory sett. > settings only.
If your issue remains unsolved, contact Nokia for repair options at www.nokia.com/support. Before sending your phone for repair, back up your data, as all personal data in your phone may be deleted.
You can also go to www.nokia.com/support where you can find:
• Troubleshooting info
• News on apps and downloads
• Longer version of this user guide
• Software update info
• Details about features and technologies, and the compatibility of devices and accessories
38
Cyan
Magenta
Yellow
For additional product support info, see the warranty and reference
Cyan
Magenta
Yellow
Black
leaflet included with your Nokia device.
39
Cyan
Magenta
Yellow
settings
Cyan
Magenta
Yellow
Black
contacts
messages
bookmarks
calendar
files
apps and games
Back up content to a memory card
Want to make sure you won't lose any important files? You can back up your phone memory to a compatible memory card.
Select settings > sync & backup.
1. Select create backup.
2. Select what you want to back up, then select
Restore a backup
Select restore backup and what you want to restore, then select
.
40
.
Cyan
Magenta
Yellow
About phone software updates
Cyan
Magenta
Yellow
Black
Stay in step with the beat – update your phone software to get new and enhanced features for your phone. Updating the software may also improve your phone performance.
It is recommended that you back up your personal data before updating your phone software.
Warning:
If you install a software update, you cannot use the device, even to make emergency calls, until the installation is completed and the device is restarted.
Using services or downloading content may cause transfer of large amounts of data, which may result in data traffic costs.
Before starting the update, connect a charger or make sure the device battery has enough power.
After the update, the instructions in the user guide may no longer be up to date. You may find the updated user guide at www.nokia.com/
support.
41
Cyan
Magenta
Yellow
Update phone software using your PC
Cyan
Magenta
Yellow
Black
Update your phone software with the Nokia Suite PC app. You can also back up the photos and other stuff in your phone to your computer.
You need a compatible PC, a high-speed internet connection, and a compatible USB cable to connect your phone to the PC.
To get more info and to download the app, go to www.nokia.com/ support.
7.
See
42
Cyan
Magenta
Yellow
Update phone software using your phone
Cyan
Magenta
Yellow
Black
You can update your phone software wirelessly. You can also set your phone to automatically check for updates.
You can only update your software when using the SIM in the internal SIM holder.
Select settings and phone > device updates.
1. To check if there is an update, select current sw details.
2. To download and install an update, select downl. phone sw, then
follow the instructions shown on the phone.
The update may take several minutes. If you encounter problems, contact your network service provider.
Check for updates automatically
Select auto SW update, then set how often to check.
Your network service provider may send updates over the air directly to your phone. For more info on this network service, contact your network service provider.
43
Cyan
Magenta
Yellow
Restore original settings
Cyan
Magenta
Yellow
Black
If your phone is not working properly, you can reset some settings to their original values.
1. End all calls and connections.
2. Select settings and restore factory sett. > settings only.
3. Type in the security code.
This does not affect documents or files stored on your phone.
After restoring the original settings, your phone switches off and then on again. This may take longer than usual.
44
Cyan
Magenta
Yellow
Access codes
Cyan
Magenta
Yellow
Black
PIN or PIN2 code
(4-8 digits)
PUK or PUK2 code
(8 digits)
IMEI number
(15 digits)
Lock code (security code)
(min. 5 digits)
These protect your SIM against unauthorised use or are required to access some features.
You can set your phone to ask for the PIN code when you switch it on.
If not supplied with your card or you forget the codes, contact your service provider.
If you type in the code incorrectly three times in a row, you need to unblock the code with the PUK or PUK2 code.
These are required to unblock a PIN or PIN2 code.
If not supplied with your SIM, contact your service provider.
See
8.
This is used to identify valid phones in the network. The number can also be used to block, for example, stolen phones. You may also need to give the number to Nokia Care services.
To view your IMEI number, dial *#06#.
This helps you protect your phone against unauthorised use.
You can set your phone to ask for the lock code that you define. The default lock code is 12345.
45
Cyan
Magenta
Yellow
Keep the code secret and in a safe place, separate
Cyan
Magenta
Yellow
Black
from your phone.
If you forget the code and your phone is locked, your phone will require service. Additional charges may apply, and all the personal data in your phone may be deleted.
For more information, contact Nokia Care or your phone dealer.
The personal unblocking key (PUK) code and the universal personal unblocking key (UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code, respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code. These codes are not supplied with the SIM card. Contact your local service provider for the codes.
46
Cyan
Magenta
Yellow
Product and safety information
Cyan
Magenta
Yellow
Black
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For further info, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES
FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
KEEP YOUR DEVICE DRY
Your device is not water­resistant. Keep it dry.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.
Feature specific instructions
Remember to comply with any applicable safety requirements.
Use only compatible memory cards approved by Nokia for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.
Important: This device is designed to be used with a standard SIM card (see figure) only. Use of incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card. Please consult your mobile operator for the use of a SIM card that has a mini-UICC cutout.
47
Cyan
Magenta
Yellow
If you only have one SIM card, put the
Cyan
Magenta
Yellow
Black
card into the SIM1 card holder. Some features and services may only be available when using the SIM card in the SIM1 card holder. If there is a SIM card only in the SIM2 card holder, you can only make emergency calls.
Both SIM cards are available at the same time when the device is not being used, but while one SIM card is active, for example, making a call, the other is unavailable.
1 If the battery has not been used for a long time, to begin charging, you may need to connect the charger, then unplug and reconnect it.
2 If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.
Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.
3 Important: Avoid scratching the touch screen. Never use an actual pen, pencil, or other sharp object on the touch screen.
To enter the + character, used for international calls, select * twice.
This may not be possible in all regions. In this case, enter the international access code directly.
The + character may not work in all regions. In this case, enter the international access code directly.
Warning: When the flight profile is activated, you cannot make or receive any calls, including emergency calls, or use other features that require network coverage. To make a call, activate another profile.
Missed and received calls are logged only if supported by the network, and the phone is switched on and within the network service area.
You can only use speed dials for the contacts stored on your phone or on the SIM card in the internal SIM1 card holder.
Using services or downloading content may cause transfer of large
48
Cyan
Magenta
Yellow
amounts of data, which may result in
Cyan
Magenta
Yellow
Black
data traffic costs.
4 You can send text messages that are longer than the character limit for a single message. Longer messages are sent as two or more messages. Your service provider may charge accordingly.
Characters with accents, other marks, or some language options, take more space, limiting the number of characters that can be sent in a single message.
5 If the item you insert in a multimedia message is too large for the network, the device may automatically reduce the size.
6 Only compatible devices can receive and show multimedia messages. Messages may look different in different devices.
Sending a message with an attachment may be more expensive than sending a normal text message. For more information, contact your service provider.
Operating the device in hidden mode is a safer way to avoid malicious software. Do not accept Bluetooth connection requests from sources
you do not trust. You can also switch the Bluetooth function off when you are not using it.
7 You can only use Nokia Suite with the SIM card in the internal SIM card holder.
8 The personal unblocking key (PUK) code and the universal personal unblocking key (UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code, respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code. These codes are not supplied with the SIM card. Contact your local service provider for the codes.
Network services and costs
Your device is approved for use on the EGSM 850 and 1900 MHz networks. To use the device, you need a subscription with a service provider.
Using network services and downloading content to your device requires a network connection and may result in data traffic costs. Some product features require support from the network, and you may need to subscribe to them.
Take care of your device
Handle your device, battery, charger and accessories with care. The
49
Cyan
Magenta
Yellow
following suggestions help you
Cyan
Magenta
Yellow
Black
protect your warranty coverage.
• Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode electronic circuits. If your device gets wet, remove the battery, and allow the device to dry.
• Do not use or store the device in dusty or dirty areas. Moving parts and electronic components can be damaged.
• Do not store the device in high temperatures. High temperatures can shorten the life of the device, damage the battery, and warp or melt plastics.
• Do not store the device in cold temperatures. When the device warms to its normal temperature, moisture can form inside the device and damage electronic circuits.
• Do not attempt to open the device other than as instructed in the user guide.
• Unauthorised modifications may damage the device and
violate regulations governing radio devices.
• Do not drop, knock, or shake the device. Rough handling can break internal circuit boards and mechanics.
• Only use a soft, clean, dry cloth to clean the surface of the device.
• Do not paint the device. Paint can clog moving parts and prevent proper operation.
• Switch off the device and remove the batt ery from time to time for optimum performance.
• Keep your device away from magnets or magnetic fields.
• To keep your important data safe, store it in at least two separate places, such as your device, memory card, or computer, or write down important information.
Recycle
Always return your used electronic products, batteries, and packaging materials to dedicated collection points. This way you help prevent uncontrolled waste disposal and promote the recycling of materials.
50
Cyan
Magenta
Yellow
Check how to recycle your Nokia
Cyan
Magenta
Yellow
Black
products at www.nokia.com/ recycling.
About Digital Rights Management
When using this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights. Copyright protection may prevent you from copying, modifying, or transferring pictures, music, and other content.
Content owners may use different types of digital rights management (DRM) technologies to protect their intellectual property, including copyrights. This device uses various types of DRM software to access DRM-protected content. With this device you can access content protected with OMA DRM 2.0. If certain DRM software fails to protect the content, content owners may ask that such DRM software's ability to access new DRM-protected content be revoked. Revocation may also prevent renewal of such DRM­protected content already in your device. Revocation of such DRM software does not affect the use of content protected with other types of
DRM or the use of non-DRM­protected content.
Digital rights management (DRM) protected content comes with an associated licence that defines your rights to use the content.
If your device has OMA DRM­protected content, to back up both the licences and the content, use the backup feature of Nokia Suite.
Other transfer methods may not transfer the licences which need to be restored with the content for you to be able to continue the use of OMA DRM-protected content after the device memory is formatted. You may also need to restore the licences if the files on your device become corrupted.
Tips and Offers
To help you take maximum advantage of your phone and services, you receive free customised text messages from Nokia. The messages contain tips and tricks and support.
To stop receiving the messages, select settings > Nokia account > Tips and Offers.
To provide the service described above, your mobile phone number,
51
Cyan
Magenta
Yellow
the serial number of your phone, and
Cyan
Magenta
Yellow
Black
some identifiers of the mobile subscription are sent to Nokia when you use the phone for the first time. Some or all information may also be sent to Nokia when updating software. This information may be used as specified in the privacy policy, available at www.nokia.com.
Batteries and chargers Battery and charger information
Your device is intended for use with a BL-4U rechargeable battery. Nokia may make additional battery models available for this device. Always use original Nokia batteries.
This device is intended for use when supplied with power from the following chargers: AC-11. The exact Nokia charger model number may vary depending on the plug type, identified by E, X, AR, U, A, C, K, B, or N.
The battery can be charged and discharged hundreds of times, but it will eventually wear out. When the talk and standby times are noticeably shorter than normal, replace the battery.
Battery safety
Always switch the device off and disconnect the charger before removing the battery. When you unplug a charger or an accessory, hold and pull the plug, not the cord.
When your charger is not in use, unplug it from the electri cal plug and the device. Do not leave a fully charged battery connected to a charger, as overcharging may shorten the battery’s lifetime. If left unused, a fully charged battery will lose its charge over time.
Always keep the battery between 15°C and 25°C (59°F and 77°F). Extreme temperatures reduce the capacity and lifetime of the battery. A device with a hot or cold battery may not work temporarily.
Accidental short-circuiting can happen when a metallic object touches the metal strips on the battery, for example, if you carry a spare battery in your pocket. Short­circuiting may damage the battery or the connecting object.
Do not dispose of batteries in a fire as they may explode. Dispose of batteries according to local
52
Cyan
Magenta
Yellow
regulations. Recycle when possible.
Cyan
Magenta
Yellow
Black
Do not dispose as household waste.
Do not dismantle, cut, open, crush, bend, puncture, or shred cells or batteries. If a battery leaks, do not let battery liquid touch skin or eyes. If this happens, immediately flush the affected areas with water, or seek medical help.
Do not modify, remanufacture, attempt to insert foreign objects into the battery, or immerse or expose it to water or other liquids. Batteries may explode if damaged.
Use the battery and charger for their intended purposes only. Improper use, or use of unapproved batteries or incompatible chargers may present a risk of fire, explosion, or other hazard, and may invalidate any approval or warranty. If you believ e the battery or charger is damaged, take it to a service centre for inspection before continuing to use it. Never use a damaged battery or charger. Only use the charger indoors.
Additional safety information Make an emergency call
1 Make sure the device is switched
on.
2 Check for adequate signal
strength. You may also need to do the following:
•Insert a SIM card.
• Deactivate call restrictions
you have activated for your device, such as call barring, fixed dialling, or closed user group.
• Make sure the flight profile is
not activated.
• If the device screen and keys
are locked, unlock them.
3 Press the end key repeatedly,
until the home screen is displayed.
4 To open the dialler, select
5 Enter the official emergency
number for your present location. Emergency call numbers vary by location.
6 Press the call key.
7 Give the necessary information
as accurately as possible. Do not end the call until given permission to do so.
Important: Activate both cellular and internet calls, if your device supports internet calls. The device
53
.
Cyan
Magenta
Yellow
may attempt to make emergency calls
Cyan
Magenta
Yellow
Black
both through cellular networks and through your internet call service provider. Connections in all conditions cannot be guaranteed. Never rely solely on any wireless device for essential communications like medical emergencies.
Small children
Your device and its accessories are not toys. They may contain small parts. Keep them out of the reach of small children.
Medical devices
Operation of radio transmitting equipment, including wireless phones, may interfere with the function of inadequately protected medical devices. Consult a physician or the manufacturer of the medical device to determine whether they are adequately shielded from external radio frequency energy.
Implanted medical devices
Manufacturers of medical devices recommend a minimum separation of
15.3 centimetres (6 inches) between a wireless device and an implanted medical device, such as a pacemaker or implanted cardioverter defibrillator, to avoid potential interference with the medical device.
Persons who have such devices should:
• Always keep the wireless device
more than 15.3 centimetres (6 inches) from the medical device.
• Not carry the wireless device in
a breast pocket.
• Hold the wireless device to the
ear opposite the medical device.
• Turn the wireless device off if
there is any reason to suspect that interference is taking place.
• Follow the manufacturer
directions for the implanted medical device.
If you have any questions about using your wireless device with an implanted medical device, consult your health care provider.
Accessibility solutions
Nokia is committed to making mobile phones easy to use for all individuals, including those with disabilities. For more information, visit the Nokia website at
www.nokiaaccessibility.com.
54
Cyan
Magenta
Yellow
Hearing
Cyan
Magenta
Yellow
Black
Warning: When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.
Some wireless devices may interfere with some hearing aids.
Operating environment
This device meets radio frequency exposure guidelines in the normal use position at the ear or at least 1.5 centimetres (5/8 inch) away from the body. Any carry case, belt clip, or holder for body-worn operation should not contain metal and should position the device the above-stated distance from your body.
To send data files or messages requires a quality connection to the network. Data files or messages may be delayed until such a connection is available. Follow the separation distance instructions until the transmission is completed.
Vehicles
Radio signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles such as electronic fuel injection, electronic antilock braking, electronic
speed control, and air bag systems. For more info, check with the manufacturer of your vehicle or its equipment.
Only qualified personnel should install the device in a vehicle. Faulty installation or service may be dangerous and may invalidate your warranty. Check regularly that all wireless device equipment in your vehicle is mounted and operating properly. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the device, its parts, or accessories. Remember that air bags inflate with great force. Do not place your device or accessories in the air bag deployment area.
Potentially explosive environments
Switch off your device in any area with a potentially explosive atmosphere, for example near gas pumps at se rvice stations. Sparks in such areas could cause an explosion or fire resulting in bodily injury or death. Observe restrictions in fuel service stations, storage, and distribution areas; chemical plants; or where blasting operations are in progress. Areas with a potentially explosive atmosphere
55
Cyan
Magenta
Yellow
are often, but not always, clearly
Cyan
Magenta
Yellow
Black
marked. They include areas whe re you would be advised to turn off your vehicle engine, below deck on boats, chemical transfer or storage facilities and where the air contains chemicals or particles such as grain, dust, or metal powders. You should check with the manufacturers of vehicles using liquefied petroleum gas (such as propane or butane) to determine if this device can be safely used in their vicinity.
Certification information (SAR)
This mobile device meets guidelines for exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organisation ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health.
The exposure guidelines for mobile devices employ a unit of measurement known as the Specific Absorption Rate or SAR. The SAR limit stated in the ICNIRP guidelines is 2.0
watts/kilogram (W/kg) averaged over 10 grams of tissue. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands. The actual SAR level of an operating device can be below the maximum value because the device is designed to use only the power required to reach the network. That amount changes depending on a number of factors such as how close you are to a network base station.
The highest SAR value under the ICNIRP guidelines for use of the device at the ear is 0.63 W/kg (RM-852).
Use of device accessories may result in different SAR values. SAR values may vary depending on national reporting and testing requirements and the network band. Additional SAR information may be provided under product information at www.nokia.com.
Your mobile device is also designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA) and Industry Canada. These requirements set a SAR limit of 1.6 W/ kg averaged over one gram of tissue. The highest SAR value reported un der
56
Cyan
Magenta
Yellow
this standard during product
Cyan
Magenta
Yellow
Black
certification for use at the ear is 0.89 W/kg (RM-852) and when properly worn on the body is 0.80 W/kg (RM-852).
Copyright and other notices
© 2012 Nokia. All rights reserved.
Nokia, and Nokia Connecting People are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Oracle and Java are registered trademarks of Oracle and/ or its affiliates.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Nokia is under license.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http:// www.mpegla.com.
57
Cyan
Magenta
Yellow
To the maximum extent permitted by
Cyan
Magenta
Yellow
Black
applicable law, under no circumstances shall Nokia or any of its licensors be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.
The availability of products, features, applications and services may vary by region. For more information, contact your Nokia dealer or your service provider. This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.
Nokia does not provide a warranty for or take any responsibility for the functionality, content, or end-user
support of third-party applications provided with your devic e. By using an application, you acknowledge that the application is provided as is. Nokia does not make any representations, provide a warranty, or take any responsibility for the functionality, content, or end-user support of third­party applications provided with your device.
FCC/INDUSTRY CANADA NOTICE
This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Your device may cause TV or radio interference (for example, when using a device in close proximity to receiving equipment). If you require assistance, contact your local service facility.Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
5555555 Issue 1 EN
58
Cyan
Magenta
Yellow
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
