Read these simple guidelines. Not following them may be dangerous or illegal.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference
or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for use with th is device.
Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to
your device micro USB connector, may be compatible. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The device screen is made of glass. This glass can break if the device is dropped on a hard
surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of
the device or attempt to remove the broken glass from the device. Stop using the device until the
glass is replaced by qualified service personnel.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Exercise caution when holding your device near your ear while the loudspeaker is in use.
Learn where the antennas are located on your phone to get the best possible performance.
Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the
communication quality and may reduce battery life due to higher power level during operation.
The antenna areas are highlighted.
Insert a SIM card
Learn how to put a SIM card in your phone.
Important: This devi ce is desig ned t o be u sed wi th a mini-UICC SIM card, also known as a microSIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM
cards may damage the card or the device, and may corrupt data stored on the card.
Make sure your phone is switched off before inserting the SIM card.
1. Push gently on the camera flash, and pull the edge of the back cover until it comes off.
Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while
charging the device. The efficiency of USB charging power varies significantly, and it may take
a long time for charging to start and the device to start functioning.
First connect the USB cable to the computer, then to your phone. When the battery is full, first
disconnect the USB cable from your phone, then from the computer.
Battery
Take good care of your battery, it's the life force of your phone.
Use only Nokia approved chargers designated for this phone. You can also use a compatible USB
cable to charge your phone (included).
First start-up
Learn how to get your new phone up and running.
Your new phone comes with great features that will be installed when you start your phone for the
first time. Allow some minutes for your phone to be ready.
Switch the phone on
Are you ready? Switch your phone on, and start exploring it.
Press and hold the power key until the phone vibrates.
Switch the phone off
Press and hold the power key, and drag the lock screen down.
With a Microsoft account, you can access all Microsoft services with a single username and password
on your computer or phone. You can also use the same username and password on your Xbox.
With your Microsoft account, you can, for example:
• Download content from Store
• Back up your contacts
• Upload, store, and share pictures and documents.
• Back up your phone on SkyDrive.
• Play Xbox games
• Get your avatar and gaming achievements on your phone, and add to them when you play games
on your phone
• Keep track of and lock your lost phone with Find My Phone
• Get feeds from social networking services to your People hub
To learn more about Microsoft account and what can you do with it, go to
www.windowsphone.com.
Create your Microsoft account
Spice up your life and get more from your phone – create a Microsoft account.
To create a Microsoft account, you need an internet connection. If you don't have a data plan, the
data transmission costs may pile up quickly. For info about possible data costs, contact your network
service provider. If you can't connect to the internet, you can create the account later.
1. Switch on your phone with the SIM card in the phone.
2. To set up your phone, follow the instructions shown on the screen.
3. Create your Microsoft account, or sign in with your existing username and password.
Tip: Forgot your password? You can request it to be sent to you in a mail or text message.
Tip: To create a Microsoft account later, open a Microsoft app or service on your phone. Or on
the start screen, swipe left, and tap
your account on the internet, go to www.live.com.
To make an emergency call during the initial set-up, tap emergency call.
Copy contacts
Have your nearest and dearest instantly at your fingertips. Use the Transfer my Data app to easily
copy your contacts from your old phone.
Settings > email+accounts > add an account. To create
Tip: If you have an older Windows Phone device, or have previously backed up your contacts in
Windows Live, add your account to your phone, and import them to your phone straight from
the service.
Your old phone needs to support Bluetooth. The contacts on your old phone need to be stored in the
phone memory, not on the SIM. The app does not work with all phone models.
1. On your old phone, switch Bluetooth on.
2. On the start screen of your new phone, swipe left, and tap Transfer my Data.
3. Tap continue, and switch Bluetooth on.
4. Select your old phone from the list of found devices, and follow the instructions shown on both
phones.
If your contacts are written in a language that is not supported by your new phone, the contact
information may not be shown correctly.
Lock the keys and screen
Want to avoid accidentally making a call when your phone is in your pocket or bag?
Do not connect products that create an output signal, as this may damage the device. Do not connect
any voltage source to the audio connector. If you connect an external device or headset, other than
those approved for use with this device, to the audio connector, pay special attention to volume
levels.
Change the volume
Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change the
volume to your liking.
Use the volume keys.
The volume keys control all sounds, including the volume of alarms and reminders.
Tip: When you change the volume, you can also switch your phone to silent or normal mode. On
the volume control bar at the top of the screen, tap
, , or .
Icons shown on your phone
The bar at the top of the screen tells you the current time, battery and signal strength, and much
more.
Your calls are forwarded to another number or your voice mailbox.
There is no SIM card in your phone.
Your SIM card is locked.
A Bluetooth device is connected to your phone.
A Wi-Fi connection is available.
A Wi-Fi connection is active.
An app or service is using your location info.
Your phone is roaming and not on your home mobile network.
Vibrate mode is switched on.
Flight mode is switched on.
Silent mode is switched on.
The type of mobile network you're currently connected to may be shown with a single letter, a
combination of letters, or a combination of letters and numbers. For example,
your network service provider.
The icons may vary depending on your region or network service provider.
Your phone has two main views, making it easy for you to keep up with what is going on and what's
where.
Start screen (1): Animated live tiles show missed calls and received messages, the latest news and
weather forecasts, and more.
You can rearrange and resize the tiles, and pin contacts, apps, feeds, mailboxes, websites, and other
favourites. Updates of your pinned contacts are shown on the tile, and you can view your contacts'
details directly from the start screen.
Apps menu (2): All your apps are listed here, all neatly ordered.
Got a lot of apps? To look up one, tap
in the list to help you search. Tap any letter in the list, and tap the first letter of the app you want.
Tip: You can also search inside an app, such as Store.
. If you've got loads of apps, letters of the alphabet show up
Switch between views
If you don't have all the apps you need on your start screen, you can find them from the apps menu.
Example: Swipe left or right between the start screen and the apps menu, or between different
views in the hubs. To quickly scroll through a long list or menu, slide your finger quickly in a
flicking motion up or down the screen, and lift your finger. To stop the scrolling, tap the screen.
Zoom in or out
Place two fingers on an item, such as a map, photo, or web page, and slide your fingers apart or
together.
The available TTY/TDD modes may vary depending on your network service provider.
Use your phone in flight mode
In places where you don't want to make or receive calls, you can still access your music, videos, and
offline games if you switch flight mode on.
Flight mode closes connections to the mobile network and switches your phone's wireless features
off. If supported by your device, the NFC payment and ticketing feature of the device may remain
active. Comply with the instructions and safety requirements given by, for example, an airline, and
any applicable laws and regulations. Where allowed, you can connect to a Wi-Fi network to, for
example, browse the internet or switch Bluetooth and NFC sharing on in flight mode.
1. On the start screen, swipe left, and tap
2. Switch Status to On
Control your phone with your voice
Got your hands full, but need to use your phone? You can use your voice to make a call, send a text
message, search the web, or open an app.
This feature is not available in all languages. For info on the supported languages, go to
support.microsoft.com.
1. Press and hold
2. Say a voice command into your phone.
Example: To check your schedule, say Open calendar.
Tip: For more examples of voice commands, say Help.
Learn how to personalise the start screen, and how to change ringtones.
Personalise the start screen
Would you like to have only your most-used apps on the start screen? You can pin your favourite
apps, websites, and much more to the start screen, and move or resize tiles as you like.
1. To pin an app, swipe left to go to the apps menu.
2. Tap and hold the app, and tap pin to Start.
Pin a contact
People, tap and hold the contact, and tap pin to start.
Tap
When you pin a contact, their feed updates are displayed on the tile, and you can call them directly
from the start screen.
Pin a website
Go to a website, and tap
Move a tile
Tap and hold the tile, drag and drop it to the new location, and tap the screen.
To resize, tap and hold the tile, and tap the arrow icon.
To unpin the tile, tap and hold the tile, and tap .
Create a safe, fun start screen for kids
You can let your kids use some apps on your phone without having to worry about them accidentally
deleting your work mail, making online purchases, or doing anything else they shouldn't. Put selected
apps, games, and other favourites for kids to enjoy in their own start screen.
1. On the start screen, swipe left, and tap Settings.
2. Tap children's corner.
3. Choose which content your kids can use. You can also set a password to keep your kids from
accessing your own start screen.
Tip: Show your kids how they can personalise their start screen. To change, for example, the
background picture, tap customise. On the start screen, you can resize or move tiles in the
normal way.
Tip: To let your kids make an in-app purchase, such as buy game points, define a Wallet PIN.
You must enter the Wallet PIN to make each purchase. To define a Wallet PIN, on the start screen,
swipe left, and tap
Go to your own start screen
Press the power key twice, and swipe up on your own lock screen. If you've set a password, type it in.
Go back to the kid's start screen
On your own lock screen, swipe left, and on the kid's lock screen, swipe up.
Switch the kid's start screen off
On your start screen, swipe left, tap
Change your theme
You can change the display colours, to match your taste and mood.
1. On the start screen, swipe left, and tap
2. Tap Background or Accent colour.
Personalise the lock screen
Would you like to make your lock screen look more unique? You can, for example, have your own
favourite photo in the background.
Find the balance between getting the most out of your phone while getting the battery life you need.
There are steps you can take to save power on your phone.
• Always charge the battery fully.
• Mute unnecessary sounds, such as key press sounds.
• Use wired headphones, rather than the loudspeaker.
• Close all apps you are not using. To close most of the apps, press
• Some apps may run in the background unnecessarily. On the start screen, swipe left, tap
Settings, swipe to applications, and tap background tasks. Tap the app you want to block, and
tap block.
Tip: You can set your phone to automatically save power when the battery charge level is low.
To check the battery status, and switch battery saver mode on, on the start screen, swipe left,
and tap
When your phone goes into battery saver mode, you may not be able to change the settings of all
apps.
Tip: You can choose when you want battery saver mode to be activated. Tap advanced.
To save power, you can also do the following:
Set the phone screen to switch off after
a short time
Lower the screen brightnessOn the start screen, swipe left, and tap
Use network connections selectively: • Set your phone to check for new mail less frequently,
Settings > battery saver.
On the start screen, swipe left, and tap
screen > Screen times out after.
brightness. Switch Automatically adjust to Off
select the level you want.
or even by request only. In every mailbox you have, tap
> settings > sync settings, and change the
setting for Download new content.
• Switch Bluetooth on only when needed.
• Use NFC on only when needed. To switch the tap
+send feature off, on the start screen, swipe left, tap
Settings > tap+send, and switch NFC sharing to
Off.
• Use a Wi-Fi connection to connect to the internet,
rather than a mobile data connection.
• Stop your phone scanning for available wireless
networks. On the start screen, swipe left, tap
Settings > WiFi, and switch WiFi networking to Off
.
• Stop your phone connecting to games. On the start
screen, swipe left, tap
• If you're listening to music or otherwise using your
phone, but don't want to make or receive calls, switch
flight mode on.
Save on data roaming costs
Want to go easy on your phone bills? You can save on data roaming costs by changing mobile data
settings. Data roaming means using your phone to receive data over networks that your network
service provider doesn't own or operate. Connecting to the internet when roaming, especially when
abroad, can raise data costs substantially. Your network service provider can charge you a fixed fee
for data transfer or on a pay as you use basis. To use the optimal connection method, change the
Wi-Fi, mobile data, and mail download settings.
Using a Wi-Fi connection is generally faster and less expensive than using a mobile data connection.
If both Wi-Fi and mobile data connections are available, your phone uses the Wi-Fi connection.
On the start screen, swipe left, and tap
1. Tap WiFi.
2. Make sure WiFi networking is switched to On
3. Select the connection you want to use.
Close a mobile data connection
Tap mobile network, and switch Data connection to off.
Stop data roaming
Tap mobile network, and switch Data roaming options to don't roam.
Tip: To save on data costs when travelling, save new maps to your phone before your journey,
and browse the maps offline. If you’re running low on space, you can remove some maps from
your phone.
Set mail download to manual
Set your phone to check for new mail less frequently, or even by request only. In every mailbox you
have, tap
> settings > sync settings, and change the setting for Download new content.
Settings.
.
Write text
Learn how to write text quickly and efficiently with your phone’s keyboard.
Use the on-screen keyboard
Writing with the on-screen keyboard is easy and fun. You can use the keyboard when holding your
phone in portrait or landscape mode.
The keyboard layout can vary in different apps
and languages. The language key is only shown
when more than one language is selected. The
example shows the English keyboard.
Switch between upper and lower case characters
Tap the shift key. To switch caps lock mode on, double-tap the key. To return to normal mode, tap
the shift key again.
Type in a number or special character
Tap the numbers and symbols key. To see more spec ial character keys, tap the shift key. Some special
character keys bring up more symbols. To see more symbols, tap and hold a symbol or special
character.
Tip: To put a full stop at the end of a sentence, and to start a new sentence, tap the space key
twice.
Tip: To quickly type in a number or special character, while holding the numbers and symbol
key, slide your finger to the character, and lift your finger.
Copy or paste text
Tap a word, drag the circles before and after the word to highlight the section you want to copy, and
