Microsoft RM-813 User Manual

Nokia 302 User Guide

Cyan

Magenta

Yellow

Black

5555555

Issue 1

Cyan

Magenta

Yellow

Black

2 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Contents

Safety 5

Get started 7

Keys and parts 7
Write with the
keyboard 9
Messaging key 11
Insert a SIM card and
battery 11
Insert a memory card 13
Charge the battery 14
Switch the phone on or
off 16
Antenna locations 17
Attach a strap 17

Basic use 18

Access codes 18
Lock the keys 20
Indicators 21
Copy content from your
old phone 22

Change the volume of a
call, song, or video 23
Use your phone without
a SIM card 23

Calls 24

Make a call 24
Call the last dialled
number 24
View your missed calls 24

Contacts 25

Save a name and phone
number 25
Use speed dial 26

Write text 27

Write using the
keyboard 27
Predictive text input 28

Messaging 29

Send a message 29
Listen to voice
messages 31

Cyan

Magenta

Yellow

Black

www.nokia.com/support 3

Cyan

Magenta

Yellow

Black

Personalise your
phone 31

About the home screen 31
Personalise the home
screen 32
Personalise your phone
tones 33

Time management 34

Change the time and
date 34
Alarm clock 34
Add an appointment 35

Connectivity 36

Bluetooth 36
USB data cable 38
Connect to a WLAN 39

Music and audio 42

FM radio 42
Media player 44

Camera 46

Take a picture 46
Record a video 47

Send a picture or video 47

Web 48

About the web browser 48
Browse the web 49
Clear your browsing
history 50

Keep in touch with
your online friends 51

About Communities 51

Mail and chat 52

About Mail 52
Send a mail 52
Read and reply to mail 53
About Chat 53
Chat with your friends 53

Nokia Services 54

Availability and costs of
Nokia Services 54
Access Nokia Services 55

Phone management 55

Cyan

Magenta

Yellow

Black

4 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Update phone software
using your phone 55
Update phone software
using your PC 57
Restore original
settings 57
Back up your pictures
and other content to a
memory card 58

Protect the
environment 58

Save energy 58
Recycle 59

Product and safety
information 59

Index 71

Cyan

Magenta

Yellow

Black

Safety 5

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not following them may be
dangerous or illegal. For further information, read the
complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is
not allowed or when it may cause interference
or danger, for example, in aircraft, in hospitals
or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted
areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.

INTERFERENCE

All wireless devices may be susceptible to
interference, which could affect performance.

Cyan

Magenta

Yellow

Black

6Safety

Cyan

Magenta

Yellow

Black

QUALIFIED SERVICE

Only qualified personnel may install or repair
this product.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do
not hold the device near your ear when the
loudspeaker is in use.

Cyan

Magenta

Yellow

Black

Get started 7

Cyan

Magenta

Yellow

Black

Get started

Keys and parts

1 Charger connector
2 Headset connector/Nokia AV connector (3.5 mm)
3 Micro-USB connector

Cyan

Magenta

Yellow

Black

8Get started

Cyan

Magenta

Yellow

Black

4 Earpiece
5 Screen
6 Selection key
7 Social key
8 Call key
9 Bluetooth key. Press and hold to access the Bluetooth

settings.

10 WLAN key. Press and hold to access the WLAN settings.
11 Navi™ key (scroll key)
12 Selection key
13 Messaging key
14 End/Power key
15 Keyboard

1

2

3

4

5

Cyan

Magenta

Yellow

Black

Get started 9

Cyan

Magenta

Yellow

Black

1 Camera lens. Before using the camera, remove the

protective tape from the lens.

2 Wrist strap hole
3 Loudspeaker
4 Memory card slot
5 Back cover release latch

Write with the keyboard

Your phone has a full keyboard.

1 Function key. To insert special characters printed at

the top of keys, press the function key, and then press
the corresponding key. To enter several special

Cyan

Magenta

Yellow

Black

10 Get started

Cyan

Magenta

Yellow

Black

characters in a row, press the function key twice. To
return to normal mode, press the function key.

Shift key. To switch between the upper and lower

2

case modes, press the shift key twice. To enter a single
upper case letter in lower case mode, or a single lower
case letter in upper case mode, press the shift key, and
then press the desired alphabet key.

Sym key. To insert special characters not shown on

3

the keyboard, press the sym key, and select the desired
character.

4

5

6

Insert a variation of a letter

You can insert, for example, letters with accents. To insert
á, press and hold the sym key, and then press A repeatedly,
until the desired letter is displayed. The order and
availability of letters depends on the selected writing
language.

Backspace key. To delete a character, press the
backspace key. To delete several characters, press and
hold the backspace key.

Enter key. To move the cursor to the next row or text
input field, press the enter key. Additional functions
are based on the current context.

Ctrl key. To copy, cut, or paste text, while pressing
and holding the ctrl key, press C, X, or V. To select all,
while pressing and holding the ctrl key, press A.

Cyan

Magenta

Yellow

Black

Get started 11

Cyan

Magenta

Yellow

Black

Messaging key

To quickly write a mail or message, view your inbox, or
start chatting, on the home screen, press the messaging

.

key

Set what happens when you press the key

Select Menu > Settings and My shortcuts > Messaging

key, and select an option.

Insert a SIM card and battery

Important: This device is designed to be used with a

standard SIM card (see figure) only. Use of incompatible SIM
cards may damage the card or the device, and may corrupt
data stored on the card. Please consult your mobile
operator for the use of a SIM card that has a mini-UICC
cutout.

This phone is intended for use with a BL-5J battery. Always
use original Nokia batteries.

1 Pull the back cover release latch toward the bottom of

the phone, and remove the cover.

Cyan

Magenta

Yellow

Black

12 Get started

Cyan

Magenta

Yellow

Black

2 If the battery is inserted, lift it out.
3 Slide the SIM card holder to unlock it (1), and use your

fingernail to lift it. Make sure the contact area would
face down when the SIM card holder is lowered (2),
insert the SIM card into the holder, and lower the
holder (3). Slide the card holder to lock it (4).

Cyan

Magenta

Yellow

Black

Get started 13

Cyan

Magenta

Yellow

Black

4 Line up the contacts of the battery and the battery

compartment, and insert the battery. To replace the
back cover, direct the top locking catches toward their
slots, and press down until the cover locks into place.

Insert a memory card

Use only compatible memory cards approved by Nokia for
use with this device. Incompatible cards may damage the
card and the device and corrupt data stored on the card.

Your phone supports memory cards with a capacity of up
to 32 GB.

Cyan

Magenta

Yellow

Black

14 Get started

Cyan

Magenta

Yellow

Black

1 Open the cover of the memory card slot (1).
2 Make sure the contact area of the memory card is

facing down, and insert the card (2). Push the card in,
until it locks into place.

3 Close the cover of the memory card slot (3).

Remove the memory card

Push the card in, until it is released, and pull the card out.

Charge the battery

Your battery has been partially charged at the factory, but
you may need to recharge it before you can switch on your

Cyan

Magenta

Yellow

Black

Get started 15

Cyan

Magenta

Yellow

Black

phone for the first time. If the phone indicates a low
charge, do the following:

1 Connect the charger to a wall outlet.
2 Connect the charger to the phone.
3 When the phone indicates a full charge, disconnect the

charger from the phone, then from the wall outlet.

You do not need to charge the battery for a specific length
of time, and you can use the phone while it is charging.

If the battery is completely discharged, it may take several
minutes before the charging indicator is displayed or
before any calls can be made.

If the battery has not been used for a long time, to begin
charging, you may need to connect the charger, then
disconnect and reconnect it.

Cyan

Magenta

Yellow

Black

16 Get started

Cyan

Magenta

Yellow

Black

Switch the phone on or off

Press and hold the power key

You may be prompted to get the configuration settings
from your network service provider. For more information
on this network service, contact your network service
provider.

until the phone vibrates.

Cyan

Magenta

Yellow

Black

Get started 17

Cyan

Magenta

Yellow

Black

Antenna locations

The antenna area is highlighted.

Avoid touching the antenna area while the antenna is in
use. Contact with antennas affects the communication
quality and may reduce battery life due to higher power
level during operation.

Attach a strap

Remove the back cover, thread the strap through the hole,
and loop the strap around the wrist strap peg.

Cyan

Magenta

Yellow

Black

18 Basic use

Cyan

Magenta

Yellow

Black

The strap may be available separately.

Basic use

Access codes

PIN or PIN2
code

(4-8 digits)

These protect your SIM card against
unauthorised use or are required to access
some features.

You can set your phone to ask for the PIN
code when you switch it on.

Cyan

Magenta

Yellow

Black

PUK or PUK2

Cyan

Magenta

Yellow

Black

code

(8 digits)

IMEI number

(15 digits)

Lock code
(security
code)

(min. 5
digits)

Basic use 19

If not supplied with your SIM card or you
forget the codes, contact your service
provider.

If you enter the code incorrectly three
times in a row, you need to unblock the
code with the PUK or PUK2 code.

These are required to unblock a PIN or
PIN2 code.

If not supplied with your SIM card, contact
your service provider.

This is used to identify valid phones in the
network. The number can also be used to
block, for example, stolen phones.

To view your IMEI number, dial *#06#.

This helps you protect your phone against
unauthorised use.

You can set your phone to ask for the lock
code that you define. The default lock code
is 12345.

Keep the code secret and in a safe place,
separate from your phone.

Cyan

Magenta

Yellow

Black

20 Basic use

Cyan

Magenta

Yellow

Black

If you forget the code and your phone is
locked, your phone will require service.
Additional charges may apply, and all the
personal data in your phone may be
deleted.

For more information, contact a Nokia
Care Point or your phone dealer.

The personal unblocking key (PUK) code and the universal
personal unblocking key (UPUK) code (8 digits) are required
to change a blocked PIN code and UPIN code, respectively.
The PUK2 code (8 digits) is required to change a blocked
PIN2 code. These codes are not supplied with the SIM card.
Contact your local service provider for the codes.

Lock the keys

To avoid accidentally making a call when your phone is in
your pocket or bag, lock the keys.

Select Menu, and press the function key.

Unlock the keys

Select Unlock, and press the function key.

Cyan

Magenta

Yellow

Black

Basic use 21

Cyan

Magenta

Yellow

Black

Set the keys to lock automatically

1 Select Menu > Settings and Device > Automatic

keyguard > On.

2 Define the length of time after which the keys are

locked automatically.

Indicators

You have unread messages.
You have unsent, cancelled, or failed

messages.
The keypad is locked.

The phone does not ring for incoming calls or
text messages.
An alarm is set.

or

or

or

or

The phone is registered to the GPRS or EGPRS
network.
A GPRS or EGPRS connection is open.

The GPRS or EGPRS connection is suspended
(on hold).
The phone is registered to a 3G (UMTS)
network.
The phone is registered to a 3.5G (HSDPA)
network.
Bluetooth is activated.

WLAN is activated.

Cyan

Magenta

Yellow

Black

22 Basic use

Cyan

Magenta

Yellow

Black

All incoming calls are diverted to another
number.
Calls are limited to a closed user group.

The currently active profile is timed.
A headset is connected to the phone.
The phone is connected to another device,

using a USB data cable.

Copy content from your old phone

Want to copy your contacts, photos, and calendar from
your old compatible Nokia phone, so you can start using
your new phone without missing a beat? You can do that,
free of charge.

1 Switch Bluetooth on in both phones.

Cyan

Magenta

Yellow

Black

Basic use 23

Cyan

Magenta

Yellow

Black

Select Menu > Settings > Connectivity >

Bluetooth > On.

2 Select Menu > Settings > Sync and backup.
3 Select Phone switch > Copy to this.
4 Select the content to copy, thenDone.
5 Select your old phone from the list.
6 If needed, make up a passcode for this connection, and

type it into both phones. In some phones, the code may
be fixed. For details, see the user guide of your old
phone.

7 If asked, allow connection and copying requests.

Change the volume of a call, song, or video

Scroll up or down.

The built-in loudspeaker allows you to speak and listen
from a short distance without having to hold the phone to
your ear.

Activate the loudspeaker during a call

Select Loudspeak..

Use your phone without a SIM card

Do your children want to play with your phone, but you
don't want them to accidentally make a call? Some features

Cyan

Magenta

Yellow

Black
