Microsoft RM-803 User Manual
Nokia 710 User Guide
Issue FCC RM-803 30 Sept 2011
2Contents
Contents
Safety 4
Get started 6
Keys and parts 6
Insert the SIM card 7
Charge your phone 8
Antenna locations 10
Switch the phone on or off 11
Create your accounts 11
Windows Live ID 12
Copy contacts from your old phone 13
Lock or unlock the keys and screen 14
Headset 14
Change the volume 15
Access codes 15
Set your phone to sync with your
computer 16
Basics 17
About the start screen 17
Touch screen actions 18
Use your phone when it's locked 21
Switch between open apps 22
Personalise your phone 22
Write text 23
Search your phone and the web 25
Control your phone with your voice 26
Indicators on the status bar 26
Use your phone offline 27
Prolong battery life 27
Switch battery saver mode on
manually 28
Calls 28
Call a contact 28
Call the last dialled number 29
Call your voice mailbox 29
Divert calls to your voice mailbox or
another phone number 29
Make a conference call 30
Silence an incoming call 30
Use your voice to call a contact 30
Contacts & social networking
services 31
Contacts 31
Social networks 34
Internet 36
Internet connections 36
Internet 38
Messaging & mail 39
Messages 39
Mail 42
Camera 44
About the camera 44
Take a picture 44
Take a close-up picture 45
Take a picture in the dark 45
Take a picture of a moving object 45
Camera tips 45
Record a video 46
Save location information to your
pictures and videos 46
Send a picture 46
Share your pictures and videos 47
Your pictures 47
About the Pictures hub 47
View pictures 48
Mark a picture as a favourite 48
Upload pictures and videos to the
web 49
Change the background in the Pictures
hub 49
Create an album 49
Copy your pictures between your
phone and PC 50
© 2011 Nokia. All rights reserved.
Entertainment 50
Music and videos 50
Marketplace 52
Maps & navigation 55
Positioning and location services 55
Bing Maps 55
Drive 59
Office 61
Clock 61
Calendar 62
Microsoft Office Mobile 63
Use the calculator 67
Connectivity & phone
management 67
Bluetooth 67
USB data cable 68
Keep your phone software and
applications up to date 69
Back up, sync, and restore your phone 70
Free up phone memory 70
Remove an application from your
phone 71
Security 71
Support 72
Contents 3
Product and safety information 72
Index 78
© 2011 Nokia. All rights reserved.
4Safety
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further information, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for use
with this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The device screen is made of glass. This glass can break if the device is
dropped on a hard surface or receives a substantial impact. If the glass breaks,
do not touch the glass parts of the device or attempt to remove the broken
glass from the device. Stop using the device until the glass is replaced by
qualified service personnel.
© 2011 Nokia. All rights reserved.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near your
ear when the loudspeaker is in use.
Safety 5
© 2011 Nokia. All rights reserved.
6Get started
Get started
Keys and parts
1 Micro-USB connector. Also used to charge the battery.
2 Connector for headphones and loudspeakers (3.5 mm)
3 Power key/Key lock button
4 Volume/Zoom key
5 Camera key
6 Search key
7 Start key
8 Back key
© 2011 Nokia. All rights reserved.
Get started 7
9 Microphone
10 Camera flash
11 Camera lens
12 Loudspeaker
Insert the SIM card
Your phone uses a micro-SIM card, also known as a mini-UICC card.
Do not attach any stickers to your SIM card.
1 With the back of the phone facing you, place your fingernail in the gap on the right
edge of the phone, and carefully lift and remove the back cover.
2 If the battery is inserted, lift it out.
3 Make sure the contact area is facing down, and insert the SIM card.
© 2011 Nokia. All rights reserved.
8Get started
4 Line up the battery contacts, and insert the battery.
5 Replace the back cover.
Remove the SIM card
1 Remove the back cover and battery.
2 Use the opening above the SIM card holder to push the card out of the holder.
Charge your phone
About the battery
Use only Nokia approved chargers designated for this phone. You can also use a
compatible USB data cable to charge your phone.
You can set your phone to automatically switch power save mode on when the battery
charge level is low. Select
> and battery saver > Always turn on Battery Saver
when battery is low.
When power save mode is switched on, you may not be able to change the settings of
all apps.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge it
before you can switch on your phone for the first time.
© 2011 Nokia. All rights reserved.
Get started 9
You do not need to charge the battery for a specific length of time, and you can use the
phone while it is charging.
If the phone indicates a low charge, do the following:
Charge from a wall outlet
1 First connect the USB cable to the charger, and the charger to the wall outlet, then
connect the USB cable to your phone.
2 When the battery is full, disconnect the charger from the phone, and then from the
wall outlet.
To avoid breaking the charger connector, be careful when connecting or disconnecting
the charger cable.
© 2011 Nokia. All rights reserved.
10 Get started
Charge from a computer
You can use USB charging when a wall outlet is not available. Data can be transferred
while charging the device. The efficiency of USB charging power varies significantly, and
it may take a long time for charging to start and the device to start functioning.
1 First connect the USB cable to the computer, then to your phone.
2 When the battery is full, first disconnect the USB cable from your phone, then from
the computer.
If the battery is completely discharged, it may take several minutes before the charging
indicator is displayed or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Antenna locations
Avoid touching the antenna area while the antenna is in use. Contact with antennas
affects the communication quality and may reduce battery life due to higher power level
during operation.
© 2011 Nokia. All rights reserved.
The antenna area is highlighted.
Switch the phone on or off
Switch the phone on
Press and hold the power key, until the phone vibrates.
Switch the phone off
Press and hold the power key, and drag the lock screen down.
Get started 11
Create your accounts
Your phone guides you through the initial setup when you insert your SIM card and
switch your phone on for the first time. To access all Windows Live and Nokia services,
create your Windows Live ID and Nokia account.
© 2011 Nokia. All rights reserved.
12 Get started
To create a Windows Live ID and Nokia account, you need an internet connection. For
information about possible data costs, contact your network service provider. If you
can't connect to the internet, you can create the accounts later.
If you already have a Windows Live ID or Nokia account, sign in with your existing
username and password.
Tip: Forgotten your password? You can request it to be sent to you in a mail or text
message.
To create a Windows Live ID later, connect your phone to your PC, and open the Zune
PC app, and you are prompted to create an account.
To create a Nokia account later, use your phone to access a Nokia service, and you are
prompted to create an account.
To make an emergency call during the initial setup, select emergency call.
Windows Live ID
With a Windows Live ID, you can access all Windows Live and Zune services with a single
username and password on your computer or phone.
© 2011 Nokia. All rights reserved.
Get started 13
With your Windows Live ID, you can, for example:
• Download content from Marketplace
• Back up your contacts in Windows Live
• Keep track of and lock your lost phone with Find My Phone
To learn more about Windows Live ID and Windows Live services, go to
www.live.com.
Copy contacts from your old phone
Have your nearest and dearest instantly at your fingertips. Use the Contacts Transfer
app to easily copy your contacts from your old phone.
Your old phone needs to support Bluetooth.
1 Select > Contacts Transfer.
2 Make sure Bluetooth is activated on both phones, and that they are set to be visible
to other devices.
3 On your new phone, select your old phone from the list of found devices.
4 Follow the instructions displayed on both phones.
© 2011 Nokia. All rights reserved.
14 Get started
If your contacts are written in a language that is not supported by your new phone, the
contact information may not be displayed correctly.
If you have previously backed up your contacts in Windows Live, you can also import
them to your phone straight from the service.
Lock or unlock the keys and screen
To avoid accidentally making a call when your phone is in your pocket or bag, lock the
keys and screen of your phone.
Lock the keys and screen
Press the power key.
Unlock the keys and screen
Press the power key, and drag the lock screen up.
Set the keys and screen to lock automatically
Select
> and lock+wallpaper > Screen times out after, and select the length
of time after which the keys and screen are locked automatically.
Headset
You can connect a compatible headset or compatible headphones to your phone.
© 2011 Nokia. All rights reserved.
Get started 15
Do not connect products that create an output signal, as this may damage the device.
Do not connect any voltage source to the audio connector. If you connect an external
device or headset, other than those approved by Nokia for use with this device, to the
audio connector, pay special attention to volume levels.
Change the volume
Use the volume keys. They control all sounds, including the volume of alarms and
reminders.
The built-in loudspeaker allows you to speak and listen from a short distance without
having to hold the phone to your ear.
Switch the loudspeaker on or off during a call
Select
or .
Access codes
PIN or PIN2 code
(4-8 digits)
These protect your SIM card against unauthorised use or are
required to access some features.
You can set your phone to ask for the PIN code when you switch
it on.
If not supplied with your SIM card or you forget the codes,
contact your service provider.
If you enter the code incorrectly three times in a row, you need
to unblock the code with the PUK or PUK2 code.
PUK or PUK2 code
(8 digits)
© 2011 Nokia. All rights reserved.
These are required to unblock a PIN or PIN2 code.
If not supplied with your SIM card, contact your service provider.
16 Get started
IMEI number
(15 digits)
This is used to identify valid phones in the network. The number
can also be used to block, for example, stolen phones.You may
also need to give the number to Nokia Care services.
To view your IMEI number, dial *#06#.
Lock code (security
code)
(min. 4 digits)
This helps you protect your phone against unauthorised use.
You can set your phone to ask for the lock code that you define.
Keep the code secret and in a safe place, separate from your
phone.
If you forget the code and your phone is locked, your phone will
require service. Additional charges may apply, and all the
personal data in your phone may be deleted.
For more information, contact a Nokia Care point or your phone
dealer.
Set your phone to sync with your computer
With the Zune PC app, you can sync music, videos, and pictures between your phone
and your compatible computer. You can also back up and update your phone with the
latest software, to improve performance and get new features.
© 2011 Nokia. All rights reserved.
Basics 17
To download and install the latest version on your PC, or to learn more about Zune, go
to www.zune.net.
Tip: If you're using an Apple Mac, download Windows Phone 7 Connector for Mac from
www.windowsphone.com.
If you have previously used another app, such as Nokia Ovi Suite, to sync your files
between your phone and computer, you can set Zune to sync files to the same folders
you have used earlier, and have your music and other content easily synced to your new
phone.
Basics
About the start screen
Your start screen contains tiles that you can select to open apps or call contacts. Live
tiles show you what's going on and what you've missed.
The animated live tiles show notifications of missed calls and received messages, the
latest news and weather forecasts, feeds from web TV channels, your friends' online
statuses, and more.
© 2011 Nokia. All rights reserved.
18 Basics
The start screen is yours to personalise. Pin contacts, apps, music, pictures, feeds,
mailboxes, and other favourites, so they're always with you. When you pin contacts,
their updates are displayed on the tile, and you can call them directly from the start
screen.
Tip: To quickly open the apps menu, swipe left on the start screen.
Touch screen actions
To use your phone, tap or tap and hold the touch screen.
Important: Avoid scratching the touch screen. Never use an actual pen, pencil, or
other sharp object on the touch screen.
Open an app or other screen element
Tap the app or element.
Tap and hold to open a menu with further options
Place your finger on an item, until the menu opens.
© 2011 Nokia. All rights reserved.
Basics 19
Example: To edit or delete a calendar appointment, tap and hold the appointment, and
select the appropriate option.
Tap and hold to drag an item
Place your finger on the item for a second or two, and slide your finger acro ss the screen.
Swipe
Place a finger on the screen, and steadily slide your finger in the desired direction.
© 2011 Nokia. All rights reserved.
20 Basics
Example: Swipe left or right between the start screen and the apps menu, or between
different views in the hubs. To quickly scroll through a long list or menu, slide your
finger quickly in a flicking motion up or down the screen, then lift your finger. To stop
the scrolling, tap the screen.
© 2011 Nokia. All rights reserved.
Basics 21
Zoom in or out
Place two fingers on an item, such as a map, picture, or web page, and slide your fingers
apart or together.
Use your phone when it's locked
You can use certain features of your phone when it is locked, without having to enter
the security code.
You can, for example:
• Make an emergency call
• Change how your phone notifies you about incoming calls
• Answer or reject an incoming call
• Pause or resume playing music, or skip to another song
To wake up your phone, press the power key.
Make an emergency call
Swipe up on the lock screen, and select emergency call.
Change how incoming calls are notified
Press a volume key, and select
or .
Pause or resume music, or skip to another song
Use the music player controls displayed at the top of the screen.
You can also see:
• The date and time
• Your next calendar event
• Missed calls or messages
© 2011 Nokia. All rights reserved.
22 Basics
Switch between open apps
You can see which apps and tasks are open in the background, and switch between
them.
Press and hold
, swipe left or right, and select the desired app.
Personalise your phone
Personalise the start screen
Would you like to have only the content you need on the start screen? Move or remove
tiles, and pin contacts, apps, and websites to the start screen.
You can also pin music and pictures, your latest mail, favourite contacts, and more. When
you pin a contact, their feed updates are displayed on the tile, and you can call them
directly from the start screen.
Pin a contact
In the People hub, select and hold the contact, and select pin to Start.
Pin an app
In the apps menu, select and hold the app, and select pin to Start.
Pin a website
At the website, select
> pin to start.
Move a tile
Select and hold the tile, drag it to the new location, and press
.
Remove a tile from the start screen
Select and hold the tile, and select
.
Change your theme
You can change the colours, to match your taste and mood.
© 2011 Nokia. All rights reserved.
Basics 23
Select > and theme > Background or Accent colour.
Tip: You can save battery power if you use a darker background.
Change the background pictures
Want to view your favourite landscape or pictures of your family more often? You can
change the background picture of the lock screen and the Pictures hub and live tile.
Change the lock screen wallpaper
1 Select
2 Select a picture, adjust it to get the best possible fit, and select
> and lock+wallpaper > change wallpaper.
.
Change the background of the Pictures hub and live tile
1 In the Pictures hub, select
2 Select a picture, adjust it to get the best possible fit, and select
> choose background.
.
Tip: If you like variety, select shuffle background, and the phone will shuffle through
your pictures.
Personalise your ringtone and other tones
You can personalise your phone tones.
Select
> and ringtones+sounds.
Select the type of ringtone or alert you want to change, and select the sound.
Tip: You can use the Zune PC app to create ringtones from your favourite songs.
Silence your phone
When you switch silent mode on, all ringtones and alert tones are muted. Use this when
you are, for example, at the cinema or in a meeting.
Press a volume key, and select ring
your phone to vibrate, vibrate mode
. Silent mode is switched on. If you have set
is switched on.
Set your phone to vibrate
Select
> and ringtones+sounds, and switch Vibrate to On .
Write text
Use the virtual keyboard
To open the virtual keyboard, select a text input field. You can use the virtual keyboard
when holding your phone upright or on its side.
© 2011 Nokia. All rights reserved.
24 Basics
1 Character keys
2 Shift key
3 Numbers and symbols key
4 Smiley key
5 Space key
6 Language key. Only available when more than one writing language has been
selected.
7 Enter key
8 Backspace key
The keyboard layout can vary in different apps.
Switch between upper and lower case characters
Select the shift key before inserting the character. To switch caps lock mode on, select
the key twice. To return to normal mode, select the shift key again.
Insert a number or a special character
Select the numbers and symbols key. Some of the special character keys can bring up
more symbols. To see more related symbols, select and hold a special character.
Tip: To quickly insert a number or a commonly used special character, select the
numbers and symbols key, and slide your finger to the character without lifting.
Add an accent to a character
Select and hold the character, and select the accented character.
Delete a character
Select the backspace key.
Switch between the writing languages
Select the language key.
© 2011 Nokia. All rights reserved.
Basics 25
Move the cursor
Tap and hold the screen near the text, until a cursor is displayed. Without lifting your
finger, drag the cursor to the desired location.
To move the cursor to the next row or text input field, select the enter key. The function
of the enter key can change in different apps. For example, in the web address field of
the web browser, it acts as the Go icon.
Add more writing languages
You can add several writing languages for your keyboard and switch between the
languages when writing.
Select
> and keyboard, and select the languages you want to write in.
Switch between the languages when writing
Select the language key.
Search your phone and the web
Explore your phone, the web, and the outside world. With Bing search, you can use the
virtual keyboard or your voice to enter your search words. You can also use your phone
camera to scan things, such as barcodes and book and DVD covers, and get further
information on what your phone recognises.
Search the web
1 Press
.
2 Enter your search word in the search field, and select from the proposed matches.
3 Select
.
4 To specify your search results, select local or images.
Use voice search
1 Press
2 Select
.
in the search field.
3Say Find or Search for and your search word.
Search inside an app
1 In an app, such as Messaging or Marketplace, select
.
2 Enter your search word in the search field, and select from the proposed matches.
3 Select
.
Use vision search
1 Press
© 2011 Nokia. All rights reserved.
.
Loading...
